Shiratech CAM1 User manual

CAM1
Quick Start Guide

Page 1of 9
CAM1 /Quick Start Guide
/
www.shiratech-solutions.com
Rev 1.0
INDEX
Quick Start...................................................................................................................................... 2
Document Revision History............................................................................................................ 9

Page 2of 9
CAM1 /Quick Start Guide
/
www.shiratech-solutions.com
Rev 1.0
Quick Start
Please perform the following steps in order to activate the 96Boards CAMERA 1 Mezzanine:
Equipment required:
•96Boards Avenger96 from Arrow
•Display with HDMI cable
•Keyboard + Mouse
•P.S to Avenger96 EVB board
Test process:
1. Burn the SD card with the imag “av96_ap1302_noswap_200815.img”
Use “Win32DiskImager” SW tool
2. Configure the boot switch on Avenger96 board
By select the SD CARD option (1,0,1)

Page 3of 9
CAM1 /Quick Start Guide
/
www.shiratech-solutions.com
Rev 1.0

Page 4of 9
CAM1 /Quick Start Guide
/
www.shiratech-solutions.com
Rev 1.0
3. Connect the 96Boards CAMERA 1 Mezzanine
4. Connect the 12V power supply to Avenger96 board
5. Wait until you will see the main screen:

Page 5of 9
CAM1 /Quick Start Guide
/
www.shiratech-solutions.com
Rev 1.0
6. Double clock on Camera icon
7. Wait few seconds until you will get the camera view

Page 6of 9
CAM1 /Quick Start Guide
/
www.shiratech-solutions.com
Rev 1.0
8. Second option open camera is by sending the following commands via the Terminal
cd /home/root
./v4l2_start.sh

Page 7of 9
CAM1 /Quick Start Guide
/
www.shiratech-solutions.com
Rev 1.0
The following screen will apreas:

Page 8of 9
CAM1 /Quick Start Guide
/
www.shiratech-solutions.com
Rev 1.0
And after 10 seconds you will get the following screen:

Page 9of 9
CAM1 /Quick Start Guide
/
www.shiratech-solutions.com
Rev 1.0
Document Revision History
Revision
Date
Author
Status and Description
0.9
08/10/2020
Shmuel Asis
Initial version
1.0
08/10/2020
Ori Makover
Template formatting
