Shiro SB2122 User manual

•User Manual •
SB2122
Basic Phone

SB2122 User Guide
1
FEATURES：
• Pulse/Tone selectable
• Ringer Hi/Lo selectable
• Incoming calls LED indicator
• Pause, Flash, Mute and Redial function
TABLE OF CONTENT
PRODUCT OVERVIEW..................................................................................... 2
1. SWITCH OPERATION................................................................................... 3
RINGER switch .........................................................................................3
PULSE/TONE switch ................................................................................... 3
2. FUNCTION KEY OPERATION .......................................................................... 3
FLASH key (600ms) ................................................................................3
MUTE key ............................................................................................... 3
REDIAL key ............................................................................................. 3
PAUSE key .............................................................................................. 3
4. ADDITIONAL NOTES ................................................................................... 3
INCOMING CALL LED INDICATOR ..................................................................... 3
TROUBLESHOOTING GUIDE..............................................................................3
DECLARATION OF CONFORMITY ........................................................................ 4
! Please ensure the phone is placed in a dry and ventilated place without corrosive air.

SB2122 User Guide
2
PRODUCT OVERVIEW
Description:
1. Incoming Call LED indicator
2. 0-9/*/# key
3. REDIAL key
4.FLASHkey
5.PAUSEkey
6. MUTE key
7. Handset Cord jack
8. PULSE/TONE switch
9. RINGER HI/LO switch
10. TEL LINE jack
456
1
2
3
7
8
9 10

SB2122 User Guide
3
1. SWITCH OPERATION
RINGER switch
You can set the ringer HI/LO volume using the switch.
PULSE/TONE switch
You can set the PULSE/TONE dial mode using the switch.
2. FUNCTION KEY OPERATION
FLASH key (600ms)
In the on-hook mode, press this key to auto-hang up for 600ms, after that you can press
REDIAL key or dial out another number.
MUTE key
While you are on the line, if you do not want the remote party to hear you, just press and
hold the MUTE key.
REDIAL key
In the handset off-hook mode, press this key to redial the last dialed number.
PAUSE key
In the handset off-hook mode, press the PABX external line key, e.g. “9” follow by this key to
include a 3 seconds pause before dialing subsequent numbers.
4. ADDITIONAL NOTES
INCOMING CALL LED INDICATOR
When there is incoming call, the LED will blink.
TROUBLESHOOTING GUIDE
(Q) I do not hear any dial tone from the handset.
(A) Ensure the handset cord is connected correctly to the handset cord jack at the base.
Ensure you have plug in the telephone cable from the telephone to the wall socket correctly.
If the problem persists, please check with your local dealer.

SB2122 User Guide
4
DECLARATION OF CONFORMITY
The telephone complies with the essential protective requirements and objectives of:
• EC R& TTE Directive 1999/5/EC
• EC Low Voltage Directive 73/23/EEC
• EC EMC Directive 89/336/EEC
And conforms to the following relevant harmonized standards:
• EMC: EN55022, EN55024
• Safety: EN 60950
Created on 28th October 2005. SB2122 Basic Phone.
Please visit us at www.shirocorp.com.
