Owner’s Manual
TE-889SLF
ATT ENTION
Please read your
owne r’s manual before
driving your scooter.

2
CONTENTS
INTRODUCTION ..................................................................................................................3
FEATURE GUIDE ................................................................................................................3
SAFET Y ADVICE .................................................................................................................4
EMI Warning ........................................................................................................................6
ADJUSTMENT .....................................................................................................................8
SCOOTER TILLER CONTROLS ......................................................................................10
FREE WHEEL OPERATION .............................................................................................12
ST ART ING TO DRIVE YOUR SCOOTER.........................................................................13
EXTRA GUIDELINES IN THE CONT ROL OF YOUR SCOOTER ..............................14
BATTERIES AND BAT TERY CHARGER .......................................................................15
MAINTENANCE ...................................................................................................................16
TROUBLE SHOOTING GUIDE .........................................................................................17
TECHNICAL SPECIFICATIONS.........................................................................................18
NOTES.....................................................................................................................................19
DISCLAIMER ........................................................................................................................20

3
INTRODUCTION
Congratulations on your purchase of the Shoprider® scooter. This scooter incorporates the
latest innovative designs patented and only available on a Shoprider® scooter. This
scooter can be used in confined spaces both indoors and outdoors. Direct drive
transaxles and electromagnetic brakes give a s afe and efficient ride. This Shoprider®
scooter is designed for persons with limited mobility.
Please read this manual carefully and thoroughly before us ing your scooter and
make sure you understand all the instructions.
FEATURE GUIDE
1. Tiller Handle Bar
2. Black Vinyl Captain Seat
3. Armrests
4. Seat Reclining
5. Black Pneumatic Tire
6. Footrest Ma t
7. Headlight
8. Indicator Light
9. Hazard Light
10. Front Basket
10
5
6
3
2
8
4
7
8
9
1

4
SAFETY ADVICE
• Do not c arry passengers.
• This mobility Product is intended to assis t you. For your own safety, please read the
Owner’s Manual before using the Scooter. If in any doubt, contact your supplier directly for
advice.
• Do not e xceed inclines over 12 degrees (20% grade).
• Driver weight may exceed weight of the unit, speed must be reduced when turning.
• Do not get on or off the scooter unless the brake is on and the scooter is switched off.
• Do not s witch off the scooter while the scooter is moving.
• Do not drive the scooter where you can not safely or legally walk.
• Do not attempt to drive o ver curbs greater than 1.5 inches in height. Doing so c ould cause
your scooter to turn over, causing personal injury or damage to the scooter. For curbs
less than 1.5 inches, always approach them at an angle of 90 degrees and at a low
speed.
• Do not drin k or use a mobile phone when driving your scooter.
• Do not e xceed the suggested user weight limit to use the product. Doing so, could cause
personal injury and invalidate the warranty.
• Always keep your feet on the scooter when moving.
• Please make sure that you are physically fit to operate this unit. Consult your
dealer/doctor for advice.
• Always slow down and proceed carefully when tra ve ling over rough or uneven ground.
• For individuals with balance problems , practice getting on the scooter with the assistance
of a qualified healthcare professional.
• Do not operate the scooter without anti-tip wheels installed.
• Do not use an escalator to move a scooter between floors or serious injury could occur.
• Do not drive the scooter on an incline that has oil, water or ice film on it.
• Do not try to lift the scooter by its seat, tiller, rear chassis cover, or any removable parts.
Any of these could cause injury to the user or damage to the scooter.
• Do not use parts or accessories that are not authorized by the original manufacturer of the
scooter.
• Before sitting in or exiting the scooter, REMOVE the key from the ignition. This will insure
the POWER is off and the scooter can not move under its own power. As a general
precaution, always remove the key from the ignition while the scooter is not in use. This
will prevent the use by untrained and unauthorized persons.

5
• Do not c onnect any foreign device to the scooter battery or charging port. This could
cause failure of the device, the scooter and personal injury.
• Make sure the tiller is properly adjusted and locked to the user or damage and injury could
result.
• It is not allowed to have any person sitting in the scooter when transported by a vehicle,
otherwise any injury or damage that might result.
• Do not use the scooter in the rain, near a shower or in a damp bathroom. Direct exposure
to ra in or dampness c ould cause the scooter to electrically malfunction and prematurely
rust.
• Do not lean against or pu ll forward on the tiller while mounting or dismounting the scooter.
Otherwise, injury may oc cur.
• Do not operate the unit o r turn the key on while charging.
• Whenever a center bolt of the wheel assembly has been loos ened, please replace a
specified new bolt from authorized dealers and secure with a torque of 240 ± 5 kg-cm
together with Loctite 271 adhesive (or equivalent).
• Regularly check on your Battery Charge. Always Charge the unit daily after use.
• Charging p lug has to be removed from the scooter after charging.
• Battery c ables must be securely fastened onto battery terminals by the authorized dealers
before using the unit.
• Batteries m ust be tied down correctly and securely.
• Any loose cable can not be allowed when the unit is driving.
• Must check the battery c harge remained before operating the unit.
• Always charge the batteries of the unit in a well ventilated area.
• If the unit went over or sank into deep water, please switch off power of the unit and
consult with your authorized dealer for help right away.
• Switch off power of the unit while not in use or before charging, removing and installing
the batte ries. Otherwise, injury and/or damage to the unit or surrounding property may
occur.
• Do not operate the unit in the way of exceeding to the product’s specification listed in this
owner’s manual.
• Do not use the thumb/finger lever befo re the key switch is turned on, or the operation will
be prohibited until to turn key switch off and then on.
• Avoid driving close to shoulder of the road.
• Always use low speed on downhill.
• Do not c ross the railway cross.
• Be sure to be well trained with full practice before using the mobility products on road.

6
EMI Warning
Shoprider® scooters may be susceptible to electromagnetic interference (EMI), which is a
kind of interfering e lectromagnetic energy (E M) emitted from sources such as radio stations,
TV stations, amateur radio (HAM) transmitters, two-way radio, and cellular phones. The
interference (from radio wave sources) can cause the scooter to release its brakes, move
by itself, or move in unintended directions. It can also permanently damage the scooter’s
control system. The sources of radiated EMI can be broadly classified into three types:
1. Hand-held portable transceivers (transmitters-receivers) with the antenna mounted
directly on the transmitting unit. Examples include: citizens band (CB) radios, “walkie
talkie”, security, fire and police transceivers, cellular telephones, and other personal
communic ation devices.
NOTE! So me ce llular telephones and similar devices transmit signals while they are
ON, even when not be ing used.
2. Medium-range mobile transceivers, such as those us ed in police cars, fire trucks,
ambulanc es , and taxis. These usually have the antenna mounted on the outside of the
vehicle.
3. Long-range transmitters and transc eivers, such as commercial broadcast transmitters
(radio and TV broadcas t antenna towers) and amateur (HAM) radios.
NOTE! Othe r types of hand-held devices, such as cordless phones, laptop
computers, AM/FM radios, TV sets, CD players, and cassette players, and small
appliances, such as electric shave rs and hair dryers, so far as we know, are not
likely to cause problems to the scooter.
Scooter Electromagnetic Interfe rence (EMI)
Because EM energ y rapidly becomes m ore intense as one moves closer to the transmitting
antenna (source), the EM fields from hand-held radio sources (transceivers) are of special
concern. It is possible to unintentionally bring high levels of EM energ y very close to the
scooter’s control system while using these devices. This can affect scooter movement and
braking. There fore, the warn ings listed below are recommended to prevent possible
interference with the control system of the scooter.

7
WARNINGS
1. Do not operate hand-held transceivers (transmitters-receivers), such as citizens band
(CB) radios, or turn ON pers onal communication devices, such as cellular phones, while
the scooter is turned ON.
2. Be aware of nearby transmitters, such as radio or TV stations, and try to avoid coming
close to them.
3. If unintended movement or bra ke release occurs, turn the scooter OFF as s oon as it is
safe.
4. Be aware that adding accessories or components, or modifying the scooter may make it
more susceptible to E MI.
NOTE! There is no e asy way to evaluate the overall immunity of the scooter.
5. Report all incidents of unintended movement or braking to your Shoprider® dealer, and
note whether the re are sources of EMI nearby.
WARNING: The original manufacturer and the importer of the scooter is not
responsible for damage or injury incurred due to improper and unsafe use of our
scooter.

8
ADJUSTMENTS
T iller Angle Adjustment (Fig. 1)
The tiller can be adjusted to five different positions.
To decide whic h position best fits your needs,
carefully pull the large b lack ball that is located on
the left hand side, at the joint base of tiller, and
gently lower or raise the tiller to select require angle.
Once you are satisfied with the angle of the tiller,
simply release the black ball and to lock the tiller
angel for your safety.
Armrest Angle Ad justme nt (Fig. 2)
Flip up the armrests to allow access to the
adjustable bolt and lock nut, unscrew the
lock-nut and screw the bolt in or out to
increase or decrease the angle. Re-tigh ten
the lock-nut. Your scooter is dispatched from the
factory with the arm rests set parallel to the floor.
Armrest He ight Adjustment (Fig. 3)
The vertical square tube connected with
the armrest can be reset to the desired
position by re-tightening the hand knob
for armrest height adjustment.
Lock-Nut
Adjusta ble
Bolt
Fig. 2
Arm res t Adjustabl e
Hand Knob
Fig. 3
Fig. 1
Tiller Angl e
Adjustable Ball

9
Seat Slide & Swivel Adjustment (Fig. 4)
Pulling up on the seat slide lever allows the
seat position to be ad justed forward or
backward. Release the lever and the seat
will lock in that position. Under the right
side of the seat there is a spring loaded red
lever. Pulling up on the lever allows the seat
to swivel, when released the seat will lock
into one of 3 positions.
Seat Re moval (Fig. 5)
Fold down the back o f the seat. Pull up the
swivel seat adjustable lever (fig. 4) and lift
seat off.
Seat He ight Adjustment (F ig. 5)
Remove s eat as described above. Loosen
seat tightening bolt by hex key wrench.
Remove the locking pin that secures the seat
adaptor. Lift the seat adaptor out of the seat
post. The seat height can be adjusted to 3
different s ettings by inserting the steel locking
pin in the required hole. Retighten the bolt and
replace the seat.
Armrest Width Ad justme nt (Fig. 6)
On the unders ide of the seat there are two
hand knobs, one either side. Loosening the
hand knob allows the armrest to be adjusted
to the required width, or removed for
transportation.
Do not use the scooter without the arms
being fitted.
Swivel Seat
Adjustable Lever
Seat Slide
Lever
Fig. 4
Seat Tightening
Bolt
Seat Locki ng Pin
Seat Post
Fig. 5
Armres t Adjustable
Tighteni ng Knob
Fig. 6

10
SCOOTER TILLER CONTROLS (Fig. 7)
(1 & 2) Speed Controls
The s peed c ontrol allows you to set a speed between 1 (minimum) and 10 (maximum).
Turn the dial knob counter-clockwise to “minimum” to decrease s peed, and clockwise
towards “maximum” to increase your speed. The “High / Low” switch for extra speed.
Please use extra caution when using the scooter in “High” mode.
NOTE: When attempting to climb slopes, you will need to set the dial to “h igh” setting.
Remember the higher the number you set your speed dial to, the faster your scooter will
travel.
(3) Battery Level Indicator
The gauge is marked from “E” empty, to “F” full. For extra clarity there is a c olored
graduated scale ranging from RED, (E) through YELLOW to GREEN, (F).
GREEN indicates ready for use.
YELLOW indicates batteries to be charged as soon as possible.
RED indicates charge batteries immediately.
(4) Lights
A b lue colored button operates the headlights.
(5) Horn
A yellow button operates the horn.
Fig. 7
3
1
6
5
7
5
8
2
9
4

11
(6) Thumb/Finger Lever Controls
The left thumb/finger lever controls the reverse and the right thumb/finger lever c ontrols the
forward motion. The amount of p ressure applied to each lever will determine the speed the
scooter travels at. Release the le ver and the scooter will slowly c ome to a stop and the
electromagnetic brake will be applied.
Ele ctromagne tic Brake
The brake is automatically opera ted when the control levers are released. There is a slight
delay when the scooter decelerates; this allows the scooter to come to a smooth stop.
(7) On/Off Key Switch
Insert the key in the right side of the tiller. Turn the key on and the needle arm indicator will
indicate the battery charge. There is a delay before the thumb/finger lever control can be
operated, while the controller is checking the circuits.
(8) Indicator Switch
Operates turn indicator lights.
(9) Hazard Warning Switch
A red button operates all indicators flashing.

12
FREE WHEEL OPERATION (Fig. 8)
The free wheel re lease lever (red handle) is located inside the right rear wheel. To
disengage the motor, lift up the lever (the scooter can now be pushed). To re-engage the
motor push down on the lever.
WARNING! Always re-engage the free wheeling device after use.
Failure to do so may result in injury.
Anti-tip wheels
The anti-tip wheels are located at the rear of the scooter frame. The scooter should not be
used unless the anti-tipping wheels are in place.
The original manufacturer and the importer of the scooter is not responsible for
damage or injury incurred due to improper or misuse of the scooter.
Anti-tip wheels
Circuit Break er
Freew heel
Release Lever
Fig. 8

13
STARTING TO DRIVE YOUR SCOOTER
Getting Starte d
• Select a level area with p lenty of space.
• Mount the scooter, either by lifting the arm and sliding on to the seat or rotate the seat
outwards and then rotate the seat back to face the tiller.
• Adjust the tiller and seat as described previously.
Starting Scoote r Move ment
• Ensure that you are seated in a comfortable position.
• Turn the key to the ON position.
• Your speed setting should be on 1 or 2.
• Pull your right hand finger lever, the scooter will move forward slowly. The harder you pull
the faster the scooter goes but will only reach the speed level that has been selected.
• Release the lever and the scooter will slowly come to a stop and the magnetic brake will
be applied.
Steering
Steering the scooter is light and easy. Ensure when starting off you give a wide clearance
when turning so that the rear wheels clear any obstac le that you are pass ing. When
steering through lim ited spaces such as a doorway or when turning around, turn the tiller
handles where you want to go and apply power gently. The scooter will turn very tightly, but
will still move with complete stability as long as the speed is not too high.
Reve rsing
Before reversing ensure that the area behind is free from any hazards or obstructions.
Adjus t your speed setting to a low setting before you reverse. Pull/press the left
thumb/finger lever, and steer wide of all corners and obstacles.
Dismounting
Before dismounting ensure that the key is turned to the off position.
CAUTION: Please ensure that care is exercised when entering or leaving the scooter
and that the tiller and foot rest is not used for support.

14
EXTRA GUIDELINES IN THE CONTROL OF YOUR SCOOTER
Ramps
The s tability of your scooter is governed b y several factors s uc h as the seating position, the
angle of the slope and your height and weight. When approaching an incline, do so directly
and not at an angle and whenever possible avoid making turns. When going down a ramp or slope
keep the speed settings to slow. This will ensure there is a safe controlled descent. When
the finger levers are released the scooter will slowly stop.
Safe Climbing Angle
Always follow the guidelines of the safe climbing angle shown as s hown in figu re 9.
Caution - Do not turn off the control key while the unit is in motion
Grass and Gravel
Please follow the guidelines given previously and your scooter will perform admirably over
many surfaces. Avoid long grass, loose gravel and sand.
NOTE: You should not operate your scooter in wet weather or on wet surfaces. This
may cause the motor to sort out.
Angles and weights s hown here for this sc ooter indicate the safe working angles for the
user and equipment. Any scooter used outside these parameters may be unsafe and or
cause future problems with the e lectrical sys tems
(Single user)
Fig. 9

15
BATTERIES AND BATTERY CHARGER
The Shoprider® scooter is supplied with maintenance free, sealed lead acid batteries.
Battery performance can be affected by temperature, te rrain , condition of battery, type of
battery charger, the weight o f the user, wind speed, etc. The battery level indicator is only a
guide and is most effective when the sc ooter is moving, only then is the true discharge level
displayed.
• When the scooter stops the battery level indicator may indicate full.
• An active user can use up to 30% of battery capacity o r more per day.
• Inactive users may only use 50% of battery capacity in a week.
• In both these instances the battery should be put on charge over night.
Battery Charger
The battery charger supplied is spec ial to your sc ooter, and may not be suitable for any
other power mobility product. Use only the c harger supplied with your scooter; o ther marks
of chargers may permanently damage your scooter batteries, and would void the warranty.
All the information of battery charger and its operation instruction shall be referred to the
user manual attached with the charger in its packaging paper box.
First Time Use
Prior to using your Portable scooter for the first time, you must charge the batteries fully
(refer to Battery Charging Procedures). Charging may take up to 12 hours. Charging the
batteries completely prior to first time use will benefit battery effic iency. Failure to do so may
cause damage.
Charging
To charge the batteries connect the 3-pin male plug lead into the 3 -pin female
battery-charging socket located on the tiller. Plug the A/C cord plug into the wall socket and
the other end into the charger (2-pin). Please refer to the LED indicator description based on
charging s tatus of the charger’s manual. Once the batteries are completely charged, unplug
the A/C cord from the wall then unplug the 3-pin lead from the tiller.
WARNING: Only use the original Shoprider® approved charger!
This charger is for indoor use only. DO NOT expose it to rain or water spray.
Do not leave the charger plugged into the charger port if the charger is not charging.

16
MAINTENANCE
Lubrication
At six-month inte rvals you should lubric ate the following parts with a light oil or similar
lubricant:
• Seat pivot post.
• Seat release lever pinion.
• Wheel bearings.
• Axle of s cooter.
CAUTION – DO NOT USE WD40 TO LUBRICATE PARTS!! DO NOT LUBRICATE
TRANSAXLE/GEAR BOX!! In the event of any difficulties please consult your dealer.
Cle aning
Your scooter s hould be cleaned as required however as with all electrical equipment you
must ensure that extreme care is used to not water damage e any sensitive pa rts.
Read the following warnings
• Only use a soft damp cloth.
• Never use a hose to wash your scooter.
• Do Not use abrasive cleaning products – Mild detergents only should be used. .
Whee ls and T ires
The wheels of your scooter have split rims. This allows any punctures to be repaired easily.
To change the wheels remove the center 13 mm bolt and slide the wheel off its axles. Take
care not to lose the drive key on the rear wheels. When changing a tire you must deflate the
tire first. Remove the four bolts to split the rim if required. Ensure that when refitting the
wheel the retaining bolt is fitted with a locking washer (with drive key for the rear wheel).
Tire p ressure is recommended to be kept at 30 psi on the rear tires and 25 psi on the front.
Note when refitting the tube a sm all amount of air in the tube w ill prevent the tube from
pinching when reassembling the split rim.
Caution: On the tire it states maximu m tire pressure is 50psi. This is a maximum tire
pressure and the tires should never be inflate d to this pressure.
Attention: T ires should be maintained at the correct pressure note d above to e nsure
even wear and ride comfort.

17
TROUBLE SHOOTING GUIDE
Circuit Breaker
Your scooter is fitted with the latest in electronic controls that are programmed to protect
the electrical system from abnormal overloads. Fitted for e xtra protection is a circuit breaker,
should there be a situation that your scooter stops for no apparent reason please check
that the circuit breaker has not popped out. The circuit breaker can be found under the rear
chassis cover access ible through a port hole under the seat.
Check List
If your scooter fails to operate, please check the following:
• Unit is switched on.
• All plugs and connectors are firmly fixed.
• Battery level shows full c harge.
• Drive/Freewheel devic e is in the d rive position.
If the free wheel device has been operated with the scooter left s witched on, then the
scooter will not opera te until the ignition key has been switched off and then on again.
Please consult your dealer if your scooter does not run after checking these points.
Ple ase consult your selling Shoprider provide r if your scooter does not run after
checking these points.

18
TECHNICAL SPECIFICATIONS
Model Name TE-889SLF
Overall Dimensions: L1 x W x H mm(in) 1300(51) x 610(24) x 1310(52
)
Front Pneumatic Tire Diameter pcs x in 2 x 13
Rear Pneumatic Tire Diameter pcs x in 2 x 13
Suggested User Weight
(on the Level Road) Kg(lb) 136(300)
Total Weight (w/ Batteries, Basket,
Seat) Kg(lb) 116(255)
Battery Capacity _V_Ah x Pcs 12V 50Ah x 2
Charger V_Amp Off Board, 8A
Output Power of Motor (Reference
Only) W(Hp) 1230(1.65)
Max. Speed2 Kph(mph) 13(8.1)
Safe Climbing Angle Degree(%) Fig. 9
Range3 per charge
(Battery Capacity) Km(mile) 37~40(23~25)
***ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE***
1. To include the anti-tip wheels
2. Driver weight may exceed weight of the unit; although the speed must be reduced when
turning.
3. The actual driving range varies with the factors shown below:
a) the weight of occupant
b) battery conditions
c) type of charger
d) ambient temperature
e) the way of driving
f) terrain
g) the wind speed
h) etc.

19
Notes

20
Disclaimer
Congratulations on receiving the Scooter.
This scooter is not intended to be used by individuals with physical limitations that could
prevent the user from operating the scooter safely. SHOPRIDER® disclaims all
responsibility for any personal in jury or property damage, which may occur as a result of
improper or unsafe use of its products. Mechanical or electrical defects will be dealt with on
a c ontingenc y liability basis.
Warranty is only va lid when genuine SHOPRIDER® parts are used. All m odifications on
the scooter, unless approved and authorized by SHO PRIDER® will automatically
invalidate the warranties. Standard warranty does not extend to consumable items and
parties other than the original user.
The preceding guidelines are intended to assist you in the safe operation of this scooter. If
you should have any questions about the correct operation of the
scooter, please c ontact your authorized SHOPRIDER ® provider.
Provider Stamp
Serial No.:
P/N:
