SHOWTOP DK23.8A User manual

Desktop Digital Signage
Machine
User Manual

I. Product Name
II. Structural Diagram of the Product
Product Name: Desktop Digital Signage
560.0 mm
365.0 mm
23.8I NC H
41.0 mm
o
65
(Please refer to the actual product)

III. Basic Specifications and Parameters
Panel size
Display area size
Aspect ratio
Resolution
Display color
Brightness
Contrast
Visible angle
Response time
Field frequency
Theoretical service life
Power consumption
23.8 inches
528(H)*297.5(V)
16:9
3840*2160
16.7M
600cd/m2(center point, typical value)
1000:1
R/L/U/D 89/89/89/89
14ms(typical value)
60HZ
30000H
50W(max)
Chip
Memory
Built-in storage capacity
Language
Ethernet
Wi-Fi
Input interface
Output interface
ARM Cortex-A35
DDR3 2GB(built-in)
EMMC 8GB(standard configuration)
Chinese, English
100M adaptive Ethernet
Supports 2.4G 802.11 b/g/n 1T1R WLAN
LAN ×1, UART×1, USB ×2, HDMI ×2
Earphone out ×1
Display Parameters
Specification Parameters

Remote control
AAA battery
Quality Certificate
Warranty Card
User Manual
1
2PCS
1PC
1PC
1PC
12V 5A
Product Accessories
IV. Operating Environment
Operating environment
Operating temperature:
Storage temperature:
Ambient humidity:
Operating voltage:
V. Operating Environment
Warning
In a standard living environment, this product may cause certain radio interference.
In this case, the user may be required to take practical measures against such
interference.
See Annex for details.
Please note the following:
1. Intellectual Property Statement: The hardware design and software
programming of this product are protected by copyright. Unauthorized copying
of this product and the contents of the Instruction Manual will be investigated
with corresponding legal liability.
2. This is a Grade A product. In a standard living environment, this product may
cause certain radio interference. In this case, the user may be required to take
practical measures against such interference.
3. The content in this Instruction Manual is for reference only and does not
constitute any form of commitment.
4. SHOWTOP reserves the right to improve and change the product design
without prior notice.

Ⅵ. Test Report
DK23.8A
Test Report
Product Model Purpose To ensure the reliability and
practicality of the product
Shenzhen SHOWTOP Technology Co., Ltd.Prepared by
Scope of Application SHOWTOP Commercial Advertising Machine
S/N Test Item Quantity Test Requirements/Standards Test Steps Test Results
Drop
impact
test
Product weight: 9Kg≤M≤20Kg
Drop height: 30CM for corners/edges, 40CM
for top, 40CM for other sides
Drop order: 1 corner, 3 edges, 6 sides
1. Prepare qualified and verified test
equipment and drop test bench;
2. Perform operations on the
packaged device according to the
experimental requirements;
3. After the experiment, unpack the
device and check whether there is
any abnormality in appearance, and
check whether it is operating
normally after powering on. If there is
no abnormality, the test is passed
and ended.
High and low
temperature
test
Test environment:
1. 45 ±2℃50%RH 4h
2. 60±2℃30%RH 4h
3. -25±2℃ORH 4h
4. -10±2℃ ORH 4h
Test each of the above parameters for
more than 4 hours after powering on,
check whether the device is operating
normally. Test each parameter for more
than 4 hours after powering off then
powering on, and check whether the
device is operating normally
1. Prepare qualified and verified
thermostatic chamber and set the
parameters according to the
experimental
requirements/standards;
2. Place the device into the
experimental equipment for testing
according to the experimental
requirements/standards;
3. After the experiment, check
whether there is any abnormality in
the equipment. If there is no
abnormality, the test is passed and
ended.
Test condition
1) The product is not damaged after aging
for 30 minutes at ±20% of the rated
operating voltage;
2) Adjust the voltage by ±15% of the rated
operating voltage by 20V each time
(increasing or decreasing the voltage),
and check whether there are any
abnormalities in the image and sound
1. Prepare qualified and verified
voltage regulator, and set
parameters according to the
experimental
requirements/standards;
2. A professional test technican
conducts the test according to the
test requirements;
3. After the test, check whether there
is any abnormality in the equipment.
If there is no abnormality, the test is
passed and ended.
Electrical
performance
test
1. Signal source: The device works for
screen projection and playback when
connected to the network and WIFI;
2.Software version: Latest version;
3. Voltage: Rated Operating voltage;
4. Load: Two speakers working
simultaneously, with other parameters set
to factory settings;
5.Test environment: Tested at a
temperature of 40±2°C and humidity of
28%RH for more than 12 hours
1. A professional test technican tests
the machine for more than 12 hours
according to the experimental
requirements/standards;
Check whether the WIFI and network
connections are operating normally;
2. Check whether the remote control
is operating normally ;
3. Check whether the software
version is the latest version;
4. After the experiment, check
whether there is any abnormality in
the equipment. If there is no
abnormality, the test is passed and
ended.
Display test
1
2
3
4
1
1
1
1
PASS
PASS
PASS
PASS

Ⅵ. Test Report
S/N Test Item Quantity Test Requirements/Standards Test Steps Test Results
Structural
component
inspection
1. A professional test technican
inspects the hardware and structural
parts of the device according to the
inspection requirements/standards;
2. During the inspection, the device
should not have any problems other
than the standards; inspection ended
Packaging
inspection
The surface of the packaging should be
clean and tidy without obvious defects,
such as concave and convex distortions,
scratches, cracks, deformations and
burrs. The surface coating should not
blister, crack, or fall off. The text, graphics
and symbols on the outer box, and in the
Instruction Manual, etc. should be clear
and feature correct indications
1. Before packaging the device, a
professional test technician should
inspect the surface, outer box,
Instruction Manual, etc. of the device
according to the inspection
requirements/standards;
2. During the inspection, the device
should not have any problems other
than the standards; inspection ended
5
6
1
1
PASS
PASS
Metal parts should be free from rust and
other mechanical damage. The color of
the surface coating should not have any
obvious color discrepancy. The operating
switches and buttons should work flexibly
and reliably, and parts should be fastened
and not loose. There should be no
obvious installation gaps. The complete
device should have sufficient mechanical
stability
Note: The above test requirements/standards are the internal test standards of the commercial display advertising machine
industry.
ISED Statement
English: This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt R S S(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
The digital apparatus complies with Canadian CAN ICES-3 (B)/NMB-3(B).
French: Cet appareil contient des émetteurs/récepteurs exempts de licence qui sont conformes aux RSS exemptés de
licence d'Innovation, Sciences et Développement économique Canada.
L'exploitation est soumise aux deux conditions suivantes :
(1) Cet appareil ne doit pas provoquer d'interférences.
(2) Cet appareil doit accepter toute interférence, y compris les interférences susceptibles de provoquer un fonctionnement
indésirable de l'appareil.
l'appareil numérique du ciem conforme canadien peut - 3 (b) / nmb - 3 (b).
This device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with R S S 102
RF exposure, users can obtain Canadian Information on R F exposure and compliance.
cet appareil est conforme à l'exemption des limites d'évaluation courante dans la section 2.5 du cnr - 102 et conformité
avec rss 102 de l'exposition aux rf, les utilisateurs peuvent obtenir des données canadiennes sur l'exposition aux
champs rf et la conformité.
This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment.
Cet équipement est conforme aux limites d'exposition aux rayonnements du Canada établies pour un environnement non
contrôlé.
This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et votre corps.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly approved by the party.
Responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded
interface cables when connecting to computer or peripheral devices).
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
FCC Radiation Exposure Statement:
The equipment complies with F C C Radiation exposure limits set forth for uncontrolled enviroment. This equipment should
be installed and operated withminimum distance 20cm between the radiator and your body.
