IBASE Technology SI-313-DC User manual

SI-313
Digital Signage Player
User’s Manual
Version 1.0
(May 2017)

ii
SI-313 User Manual
Copyright
©2017 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system, translated
into any language or transmitted in any form or by any means, electronic, mechanical,
photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
(hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products described in
this document without prior notice. Every effort has been made to ensure the information in
the document is correct; however, IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from
misapplication or inability to use the product or the information contained herein, nor for any
infringements of rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

SI-313 User Manual
iii
Compliance
In a domestic environment, this product may cause radio interference in which case
users may be required to take adequate measures.
This product has been tested and found to comply with the limits for a Class B
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications.
WEEE
This product must not be disposed of as normal household waste, in
accordance with the EU directive of for waste electrical and electronic
equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by
returning it to a municipal recycling collection point. Check local
regulations for disposal of electronic products.
Green IBASE
This product is compliant with the current RoHS restrictions and
prohibits use of the following substances in concentrations exceeding
0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by
weight (100 ppm).
•Lead (Pb)
•Mercury (Hg)
•Cadmium (Cd)
•Hexavalent chromium (Cr6+)
•Polybrominated biphenyls (PBB)
•Polybrominated diphenyl ether (PBDE)

iv
SI-313 User Manual
Important Safety Information
Carefully read the precautions before using the device.
Environmental conditions:
•Lay the device horizontally on a stable and solid surface in case the device may
fall, causing serious damage.
•Leave plenty of space around the device and do not block the openings for
ventilation. NEVER DROP OR INSERT ANY OBJECTS OF ANY KIND INTO
THE VENTIILATION OPENINGS.
•Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the device for ventilation.
NEVER INSERT OBJECTS OF ANY KIND INTO THE VENTILATIN OPENINGS.
•Use this product in environments with ambient temperatures between 0˚C and
45˚C.
•DO NOT LEAVE THIS DEVICE IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY IS BELOW -20°C OR ABOVE 80°C. This
could damage the device. The device must be used in a controlled environment.
Care for your IBASE products:
•Before cleaning the device, turn it off and unplug all cables such as power in case
a small amount of electrical current may still flow.
•Use neutral cleaning agents or diluted alcohol to clean the device chassis with a
cloth. Then wipe the chassis with a dry cloth.
•Vacuum the dust with a computer vacuum cleaner to prevent the air vent or slots
from being clogged.
WARNING
Attention during use:
•Do not use this product near water.
•Do not spill water or any other liquids on your device.
•Do not place heavy objects on the top of the device.
•Operate this device from the type of power indicated on the marking label. If you
are not sure of the type of power available, consult your distributor or local
power company.
•Do not walk on the power cord or allow anything to rest on it.
•If you use an extension cord, make sure that the total ampere rating of the
product plugged into the extension cord does not exceed its limits.
Avoid Disassembly
You are not suggested to disassemble, repair or make any modification to the device.
Disassembly, modification, or any attempt at repair could generate hazards and
cause damage to the device, even bodily injury or property damage, and will void any
warranty.

SI-313 User Manual
v
CAUTION
Danger of explosion if internal lithium-ion battery is replaced by an incorrect type.
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Warranty Policy
•IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of shipment
cannot be ascertained, the product serial numbers can be used to determine
the approximate shipping date.
•3rd-party parts:
12-month (1-year) warranty from delivery for the 3rd-party parts that are not
manufactured by IBASE, such as CPU, CPU cooler, memory, storage devices,
power adapter, panel and touchscreen.
＊PRODUCTS, HOWEVER, THAT FAIL DUE TO MISUSE, ACCIDENT,
IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL BE
TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL BE BILLED
FOR REPAIR AND SHIPPING CHARGES.
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information about
the product.
2. If you need any further assistance from your distributor or sales representative,
prepare the following information of your product and elaborate upon the
problem.
•Product model name
•Product serial number
•Detailed description of the problem
•The error messages in text or in screenshots if there is any
•The arrangement of the peripherals
•Software in use (such as OS and application software, including the version
numbers)
3. If repair service is required, you can download the RMA form at
http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and
contact your distributor or sales representative.

vi
SI-313 User Manual
Table of Contents
Compliance....................................................................................................iii
Important Safety Information.......................................................................iv
WARNING ......................................................................................................iv
CAUTION ........................................................................................................v
Warranty Policy..............................................................................................v
Technical Support & Services ......................................................................v
Chapter 1 General Information................................................................1
1.1 Introduction.............................................................................................2
1.2 Features..................................................................................................2
1.3 Packing List ............................................................................................3
1.4 Optional Accessories ..............................................................................3
1.5 Specifications..........................................................................................4
1.6 Overview.................................................................................................6
1.7 Dimensions.............................................................................................8
Chapter 2 Hardware Installation & Motherboard Information ..............9
2.1 Essential Installations Before You Begin...............................................10
2.1.1 Memory Installation ................................................................10
2.1.2 Mini PCIe & M.2 Network Cards Installation ...........................11
2.1.3 WiFi / 3G / 4G Antenna Installation.........................................12
2.1.4 Wall Mount Installation............................................................13
2.2Setting the Jumpers..............................................................................15
2.2.1 How to Set Jumpers ...............................................................15
2.3 Jumper & Connector Locations on Motherboard...................................16
2.4 Jumpers Quick Reference.....................................................................18
2.4.1 CMOS Data Clearance (JP1)...............................................18
2.4.2 ATX / AT Power Mode Connector (JP2)...............................19
2.5 Connectors Quick Reference................................................................20
2.5.1 Power Button (SW1) ............................................................21
2.5.2 EDID Clearance Button (SW2).............................................21
2.5.3 LED Indicators for Power & HDD (LED4, LED5) ..................22
2.5.4 DC Power Input (CN1).........................................................22
2.5.5 HDMI 2.0 Port (CN2, CN3, CN4)..........................................23

SI-313 User Manual
vii
2.5.6 LAN Port (CN5)....................................................................23
2.5.7 Dual USB 3.0 Ports (CN6)....................................................23
2.5.8 Dual USB 2.0 Ports (CN7)....................................................24
2.5.9 COM1 RS-232 Port (CN8)....................................................24
2.5.10 Audio Jack (CN9, CN10)......................................................25
2.5.11 CPU Fan Power Connector (J1)...........................................25
2.5.12 USB 2.0 Ports Header (J2)...................................................26
2.5.13 COM2 RS-232 Port (J3).......................................................26
2.5.14 System Function Connector (J4)..........................................27
2.5.15 NGFF M.2 Connector (J6, J13)............................................27
2.5.16 SIM Card Socket (J8)...........................................................28
2.5.17 Mini PCIe Connector (J10)...................................................28
2.5.18 DDR4 SO-DIMM (J11, J12)..................................................28
2.5.19 Digital I/O Connector (J19)...................................................29
Chapter 3 Driver Installation .................................................................30
3.1 Introduction...........................................................................................31
3.2 AMD Merlin Falcon Graphics Drivers Installation ..................................31
3.3 HD Audio Driver Installation..................................................................32
3.4 LAN Driver Installation ..........................................................................33
Chapter 4 BIOS Setup............................................................................34
4.1 Introduction...........................................................................................35
4.2 BIOS Setup...........................................................................................35
4.3 Main Settings........................................................................................36
4.4 Advanced Settings................................................................................37
4.4.1 IDE Configuration...................................................................38
4.4.2 ACPI Shutdown Temperature.................................................38
4.4.3 iSMART Controller..................................................................39
4.4.4 Super IO Configuration...........................................................40
4.4.5 Hardware Monitor...................................................................41
4.4.6 CPU Configuration..................................................................42
4.4.7 SATA Configuration................................................................43
4.4.8 CSM Configuration.................................................................44
4.4.9 USB Configuration..................................................................45
4.5 Chipset Settings....................................................................................46
4.5.1 South Bridge...........................................................................47
4.5.2 North Bridge...........................................................................48
4.6 Security Settings...................................................................................49
4.7 Boot Settings.........................................................................................50
4.8 Save & Exit Settings..............................................................................51

viii
SI-313 User Manual
Appendix ......................................................................................................52
A. I/O Port Address Map............................................................................53
B. Interrupt Request Lines (IRQ)...............................................................56
C. Watchdog Timer Configuration..............................................................57

1
Chapter 1
General Information
The information provided in this chapter includes:
•Features
•Packing List
•Specifications
•Optional Accessories
•Overview
•Dimensions

2
SI-313 User Manual
1.1 Introduction
SI-313, a product code of IBASE digital signage player series, is a mid-range
system with iSMART and capable of auto-scheduling for general applications.
It is designed with the feature of segregated flow ventilation. The device is
powered by the AMD 3rd Gen. Embedded R-Series SOC APU, and outputs
through HDMI 4K ultra high definition video playback at 60 Hz. The device is
able to be operated at the ambient operating temperature ranging from 0 ~ 45
°C, and even lower from -20 ~ 80 °C for storage.
1.2 Features
•iSMART for auto-scheduler and power resume
•AMD 3rd Gen. Embedded R-series SOC APU, up to 35W
•Integrated next-generation AMD RadeonTM HD GPU
•AMD Eyefinity video wall display configuration
•Display via HDMI 2.0 (3 ports) for 4K at 60 Hz with EDID emulation
•Gigabit Ethernet & RS-232 COM port
•Dual DDR4 SO-DIMM, 2133 MHz at 1.2V, expandable up to 32 GB
•SIM card slot
•WiFi networks, Bluetooth
•Options of 4G LTE or TV tuner
•Segregated flow ventilation design

General Information
SI-313 User Manual
3
1
1.3 Packing List
Your SI-313-N package should include the items listed below. If any of the
items below is missing, contact the distributor or the dealer from whom you
purchased the product.
•SI-313 Digital Signage Player (with Rack Mount Kit) x 1
•Power Adapter x 1
•Power Cord x 1
•HDMI Cable Holder x 1
•Screws for HDMI Cable Holder x 2
•Screws for Rack Mount Kit x 4
•Disk (including drivers and this user manual) x 1
1.4 Optional Accessories
IBASE provide optional accessories as follows. Please contact us or your
dealer if you need any.
•WiFi Cable Kit

4
SI-313 User Manual
1.5 Specifications
Product
SI-313
System
Mainboard
MBD313
Operating
System
Windows 7 / 8 / 10 / Linux
CPU
AMD 3rd Gen. Embedded R-Series SoC APU (FP4 BGA)
CPU Clock (Max/Base): 2.7GHz / 3.6 GHz
Chipset
AMD integrated SoC
Cache
Up to 4 MB
Memory
2 x DDR4 SO-DIMM 4GB 2133 MHz, dual channel, expandable
up to 32GB
Graphics
Next-gen. AMD RadeonTM HD GPU integrated
Super I/O
Fintek F81846AD
Storage
•1 x NGFF M.2 (3042) B key
•1 x NGFF M.2 (2280) M key
Power
Requirement
12V DC-in
Power Supply
150W power adapter
Wireless
WiFi module 802.11 a/b/g/n (Optional)
Watchdog
Watchdog Timer 256 segments, 0, 1, 2…255 sec/min
iSMART
V3.2
System Fan
1 x CPU fan
Chassis
Aluminum and SGCC, black & white
Mounting
Standard system bracket
Slim design with wall mount holes
Dimensions
(W x H x D)
215.6 x 33 x 150 mm (8.49” x 1.3” x 5.9”)
Net Weight
1.55 kg (3.42 lb)
Certificate
CE, FCC Class B, UL, CCC

General Information
SI-313 User Manual
5
1
I/O Ports
HDMI
3 x HDMI 2.0, choose either way:
•Use 2 ports for 4K (3840 x 2160) display at 60 Hz (via
HDMI 2.0)
(If 3 displays are connected, the resolutions will be 4K, 4K,
1080p per the sequence of connection.)
•Use 3 port for 4K (3840 x 2160) display at 30 Hz (via
HDMI1.4)
LAN
1 x GbE RJ45 LAN port
Serial
•1x RJ45 for COM1 RS-232 port
•1 x on-board pin-header for COM2 RS-232 port
USB
•2 x USB 3.0
•2 x USB 2.0
Audio Jack
•1 x Line-Out
•1 x Microphone Input
Power Jack
1 x DC-in power jack
Expansion
•1 x M.2 (3042) B Key with PCIe (x2) for storage / WiFi / BT /
4G LTE options
•1 x M.2 (2280) M Key with SATA
•1 x Mini-PCIe (x1) for WiFi / BT / TV tuner / 4G LTE options
•1 x SIM card slot
Environment
Temperature
•Operating: 0 ~ 45 °C (32 ~ 113 °F)
•Storage: --20 ~ 80 °C (-4 ~ 176 °F)
Relative
Humidity
10 ~ 90% (non-condensing)
Vibration
Protection
M.2: Operating, random vibration 5 grms (5~500Hz)
All specifications are subject to change without prior notice.

6
SI-313 User Manual
1.6 Overview
Top View
Oblique View

General Information
SI-313 User Manual
7
1
I/O View
No.
Name
No.
Name
1
DC Power Input
8
Audio Line-Out
2
HDMI 2.0 Port
9
Microphone Input
3
EDID Clearance Button*
10
Power Button
4
LAN Port
11
LED Indicator for Power
5
USB 3.0
12
LED Indicator for HDD
6
USB 2.0
13
Mounting Kit
7
COM Port
14
Antenna Hole
*Be sure to press the EDID Clearance Button shortly so as to clear the EDID
register if any connected display/monitor is unable to be recognized, or
when the image displayed cannot not be resampled to fit the screen.

8
SI-313 User Manual
1.7 Dimensions
Unit: mm

9
Chapter 2
Hardware Installation &
Motherboard Information
The information provided in this chapter includes:
•Essential installations before you begin
•Information and locations of connectors

10
SI-313 User Manual
2.1 Essential Installations Before You Begin
2.1.1 Memory Installation
There are two SO-DIMM DDR4 memory slots inside SI-313 for a maximum
total memory of 32 GB. To install the modules, locate the memory slot on the
board and perform the following steps:
1. Align the key of the memory module with that on the memory slot and
insert the module slantwise.
2. Gently push the module in an upright position until the clips of the slot
close to hold the module in place when the module touches the bottom of
the slot.
To remove the module, press the clips outwards with both hands.

Motherboard Information
SI-313 User Manual
11
2
2.1.2 Mini PCIe & M.2 Network Cards Installation
1. Align the key of the mini PCIe card to the Mini PCIe interface, and insert
the card slantwise.
(Insert the M.2 network card in the same way.)
2. Push the mini PCIe card down, fix it with 2 screws.
(Fix the M.2 network card with a screw.)
Mini PCIe:
M.2:

12
SI-313 User Manual
2.1.3 WiFi / 3G / 4G Antenna Installation
Thread the WiFi / 3G / 4G antenna extension cable through an antenna hole
of the front I/O cover and fasten the antenna as shown below. Then apply
adhesive to the edge of the hex nut behind the front I/O cover to prevent the
extension cable from falling if the cable becomes loose.
1. Thread and fasten the hex nut and the
washer. Then install the antenna.
2. Apply adhesive around here.
Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC).
