Shuangdie SD-36VB-500W User manual

Isolation transformer
Model: SD-36VB-500W
SD-36VB-1000W
Instruction Manual
Please read the instructions carefully before use.

The transformer must be applicable to the security of power supply voltage for the
ship building and repairing, boiler manufacturing, enterprise etc. also the transformer
is provide to the 36V safely series axial-flow ventilator of SHUANGDIE Brand. The
transformer have the characteristics of a solid structure, overloading ability, safety and
durable etc.
I. Important safety instruction
Before installing or using this product, please read and save the safety instruction
below.
1. Do not expose the transformer to water, mist, snow, spray, or dust.
2. Do not use the product where there is a risk of gas or dust explosions. This product
is not ignition protected.
3. Use electric cables of the appropriate size.
4. Install the transformer in a well ventilated area.
5.Keep a clear space of 10 cm around the product for ventilation.
6. For safety purposes, the product should be installed in a heat-resistant environment.
Avoid the presence of e.g. chemicals, synthetic components, curtains or other textiles
in the immediate vicinity of the product.
7. The use of load capacity of no more than the rated capacity of the transformer,
Otherwise easily burned transformer.
II. TECHNICAL DATA
Model capacity phase Input
voltage
Frequency Output
voltage
Ambient
temperature
SD-36VB-500W
0.5KVA 3 380V~ 50Hz 36V~ -20°C to
40°C
SD-36VB-1000W
1.0KVA 3 380V~ 50Hz 36V~ -20°C to
40°C

Ⅲ.ELECTRIC SCHEMATIC DIAGRAM
1. Connect the shore cable to the terminals indicated with “INPUT”.
2. Connect the load to the terminals indicated with “OUTPUT”.
