MODEL A96F LINE MATCHING TRANSFORMER
This transformer connects microphones with an XLR-type connector
to the 3.5 mm (1/8 in.) inputs found on camcorders and other recording
devices. It increases the signal level from the microphone, provides a
balanced input, and prevents distortion due to the d.c. bias typically
found in camcorder microphone inputs.
IMPEDANCE SELECTION
The A96F can be modified for microphones rated at 150 W. This
modification is only necessary if the output level from the A96F is
insufficient for your recording device. Use the following steps:
1. Access the wiring in the XLR plug element of the A96F by loosen-
ing the screw and sliding the plug from the case.
2. Unsolder the RED lead from pin 2. Insulate the bare wire at the end
of the lead with the insulator from the YELLOW lead.
3. Solder the YELLOW lead to pin 2.
4. Rotate the plug element three turns to twist the leads and replace
the element in the housing. Replace the screw.

2
TROUBLESHOOTING
1. Unscrew the housing from the miniature plug on the
A96F to expose the wires inside the connector.
2. Use wire clippers to cut and remove the wire between the tip
and ring leads (see figure below). Make sure to remove the
wire completely from between the leads so that there is no
contact between the tip and ring.
3. Reassemble the plug.
If the microphone still does not work, contact Shure Application
Engineering at 1-800-516-2525. Please have the camcorder user's
guide available.
Ë
Ë
ËË
RING
TIP
Remove wire here

3
SPECIFICATIONS
Frequency Response
20 to 20,000 Hz ± 2 dB
Impedance
Low impedance: 600 W (supplied) or 150 W
Medium impedance: 2,500 W
DC Resistance
Low impedance: 600 Wwinding: 56 W
150 Wwinding: 28 W
Medium impedance: Open Circuit
Voltage Ratio 600 W150 W
Low impedance to medium impedance: +6 dB +12 dB
Maximum Recommended Input Levels
Source Winding Maximum
Impedance Being Driven Level
150 W150 W0.5 V
600 W600 W1.0 V
2,500 W2,500 W2.0 V
Case
Full magnetic shield, steel with gray enamel finish
Dimensions
19 mm (3/4 in.) diameter; 89 mm (3 1/2 in.) long

4
GUARANTEE
This Shure product is guaranteed in normal use to be free from
electrical and mechanical defects for a period of two years from date
of purchase. Please retain proof of purchase date. This guarantee
includes all parts and labor, and is in lieu of any and all other guar-
antees or warranties, express or implied. There shall be no recovery
for any consequential or incidental damages.
SHIPPING INSTRUCTIONS
Carefully repack the unit, have it insured, and return it prepaid to:
Shure Incorporated
Attention: Service Department
5800 W. Touhy Avenue
Niles, Illinois 60714-4608
If outside the U.S.A., return the unit to your dealer or Authorized
Shure Service Center for repair. The unit will be returned to you
prepaid.
