DRIVE axxent DK.
Concealed motion chain drive.

DRIVE axxent DK Operating Instructions
1 Last update: 9.10.14
Intended use........................................................................................................2
Improper use .......................................................................................................2
Safety Notices ....................................................................................................3
Function ..............................................................................................................4
Scope of delivery ................................................................................................4
Commissioning ...................................................................................................5
Operation ...........................................................................................................6
Maintenance .................................................................................................... 12
Technical specifications .................................................................................. 13
Liability ............................................................................................................. 14

Operating Instructions DRIVE axxent DK
Last update: 9.10.14 2
Intended use
• DRIVE axxent DK is a concealed chain drive that may only be used for the motorised tilting and the
closing of turn/tilt windows from their tilted position.
Commissioning
• DRIVE axxent DK is an incomplete machine that must not be commissioned until it has been incorpo-
rated in a power-operated window as a complete machine and has been approved in accordance
with the manufacturer's specifications.
Application and accessories
• DRIVE axxent DK is only to be used if it is in a technically sound condition, and no modifications may
be made to the unit and/or its components.
• Use DRIVE axxent DK only with original accessories from SIEGENIA.
• DRIVE axxent DK is suitable only for installation in dry rooms (protection class IP20) and permissible
operating temperatures of -20°C to +40°C.
• In the event of a fault, have DRIVE axxent DK checked and repaired by experienced specialists only.
• The system is designed only for occasional manual operation.
• Any other use is considered as improper use.
Improper use
• DRIVE axxent DK may not be used as a drive of smoke and heat heat control systems in windows.
• DRIVE axxent DK may not be used in windows that are intended as emergency exits.
• Do not use levers with lock-in position, but use only removable handle levers of theSi-line with Si-line
rose.

DRIVE axxent DK Operating Instructions
3 Last update: 9.10.14
Safety Notices
Risk of injury from falling out of open windows
›Use only stable stepladders.
›Secure yourself from falling out of the window.
›Do not hold onto open window sashes.
Parts of the body may get caught, resulting in injury
›When closing windows or portal doors, never place your hand in
the opening between the sash and the frame.
Placing objects between the sash and the frame may re-
sult in injury or property damage
›Do not place objects in the opening between the sash and the fra-
me.
Additional load on the sashes may result in
›injury or property damage
›Do not subject the sashes to additional loads.
Risk of injury from wind
›Do not allow open sashes to be blown around by the wind.
›Make sure to close and lock windows if it is windy or if there is a
draught.
Risk of injury in case of window malfunctioning!
›Do not continue to use the window if it is not working properly.
›Secure the window and have it repaired by a qualified technician
as soon as possible.

Operating Instructions DRIVE axxent DK
Last update: 9.10.14 4
Function
The DRIVE axxent DK is a concealed chain drive.
The drive can be controlled via a wall button or an optional remote control.
Scope of delivery
Item Description
1 DRIVE axxent DK
2 Clamping spring
3 Connecting line
4 Assembly Instructions
5 Operating Instructions
6 Warning sticker for windows
7 Lens (status indicator)
8 Safety sticker
9 Safety Notice
10 Power supply (optional accessorie)
1
4578 96
2
1A 1B
3
4
H47.MOTSIAU0003_0
!
18W
0,75A
24V
RED
BLACK
OUTPUT
INPUT
230V~
SOLUTIONS INSIDE
BROWN
BLUE
50/60Hz
170mA
Optional
10
2
3

DRIVE axxent DK Operating Instructions
5 Last update: 9.10.14
Commissioning
• The red LED of the DRIVE axxent DK flashes when the supply voltage is switched on.
• A referencing cycle must now be performed.
Risk of injury during referencing cycle!
The safety functions are disabled!
›Do not operate the DRIVE axxent DK if you do not have a clear view of the window!
›Ensure that other persons stay clear of the window.
Perform reference run
The reference run takes approx. 2 to 30 seconds, depending on the drive's starting position.
Press button "Close"
Close
LED flashes red Reference run starts
1. 2. 3.

Operating Instructions DRIVE axxent DK
Last update: 9.10.14 6
Operation
Operation - opening the window
Operation - opening the window for a 10-min. ventilation period
Press button "Open"
Press button "Open" twice, and the window will close after 10 minutes.
Open LED lights green
1x
1. 2. 3. 10 mm/sec
Open
2x
1. 2. 3.
4.
LED lights
green
LED lights
red
LED flashes
green

DRIVE axxent DK Operating Instructions
7 Last update: 9.10.14
Operation - closing the window
Remote control
Up to 5 windows with DRIVE axxent DK can be operated by one remote control.
Press button "Close"
1. Button assignment
Close LED lights red 5 mm/sec
1. 2. 3.
Close (closing)
Open (tilt)
Not assigned
Open (tilt)
10-min. ventilation
Window 1
all Windows
Window 2
Window 3
Window 4
Window 5
Button window 1 to 5 =
remote control of the corre-
sponding window with
DRIVE axxent DK

Operating Instructions DRIVE axxent DK
Last update: 9.10.14 8
Teaching the remote control
Buttons 1 to 5 windows can be assigned to one window fitted with DRIVE axxent DK.
1. Press buttons 1, 2, 3 and 5 within a period of 3 seconds.
2. LED lights green.
3. Select window 1 to 5
4. LED goes out after 10 seconds
2.
1.
3.
4.

DRIVE axxent DK Operating Instructions
9 Last update: 9.10.14
Deleting windows from remote control
Safety functions
• If the maximum permissible force of 150 N is exceeded when closing, e.g. due to wind load, the
drive will return to its starting position.
• The drive will attempt to close the window again after 60, with the LED flashing red/green. If the
second attempt fails, the window will remain open with the LED flashing red.
• Check window for obstructions and remove them, if required. Press button "Close" again.
1. Press buttons 1, 2, 3 and 4 within a period of 3 seconds.
2. LED lights green.
3. Wait until LED goes out
The remote control is now ready for a new teach-in procedure.
2.
1.
3.

Operating Instructions DRIVE axxent DK
Last update: 9.10.14 10
Manual operation of open window
Be sure to always observe this operating sequence!
1. Insert the handle into the rose, the lever must be in vertical position.
2. Close window manually by pushing it into closed position.
3. Move the window handle lever into locked position, ensuring that the lever points vertically
downward.
4. Move the window handle lever into turn position.
• When the window is closed again and locked, the drive must be connected. Press button "Close".
The drive is then reconnected. All functions are then available again.
• If the drive is not reconnected, then the drive cannot be controlled. When pressing button "Open"
for 3 seconds, the drive will open and then return to its starting position.
• Remove handle and close the rose after manual operation.
1.
3.
2.

DRIVE axxent DK Operating Instructions
11 Last update: 9.10.14
Manual operation of the closed window
Be sure to always observe this operating sequence!
1. Insert the handle into the rose, the lever must be in a 45°-position.
2. Shift window handle lever fully into locked position, ensuring that the lever points vertically
downward.
3. This is necessary because the drive must first be disconnected from the fitting.
4. Only then can the window be turned open by a 90°-turn of the handle and opening of the
window.
5. Turn the handle lever back into the closed position after closing the window.
• When the window is closed again and locked, the drive must be connected. Press button "Close".
The drive is then reconnected. All functions are then available again.
• If the drive is not reconnected, then the drive cannot be controlled. When pressing button "Open"
for 3 seconds, the drive will open and then return to its starting position.
• Remove handle and close the rose after manual operation.
1. 2.

Operating Instructions DRIVE axxent DK
Last update: 9.10.14 12
Emergency release in case of power failure or if drive cannot be
disconnected
Maintenance
The DRIVE axxent DK and any fittings installed in the window must be serviced and checked at least
once per year by a qualified professional.
Insert card as shown and operate handle lever
1.
2.
Position of LED

DRIVE axxent DK Operating Instructions
13 Last update: 9.10.14
Technical specifications
Window material timber, plastic or aluminium
Installation location in window on top, horizontal
Sash outer dimensions (sash rebate dimension) (sash width):
Areas of timber and plastic TITAN AF (sash rebate dimension)
Area of aluminium stay LM 4200 size 20 (sash width)
Area of aluminium stay LM 4200 size 35 (sash width)
min. 850 mm - max. 1560 mm
min. 835 mm - max. 980 mm
min. 981 mm - max. 1600 mm
Opening width of stays:
Areas of timber and plastic TITAN AF
Area of aluminium stay LM 4200 Gr. 20
Area of aluminium stay LM 4200 Gr. 35
max. 150 mm
max. 120 mm
max. 150 mm
Sash weight
max. 130 kg (observe the correspond-
ing application range diagrams)
Supply voltage 24 V, 0,6 A
Electronic overload protection
Supplied connecting line 2 pieces 2 x 0.8 mm, length 2.5 m
Opening speed approx. 10 mm per second
Duration of opening motion approx. 25 seconds
Closing speed max. 5 mm per second
Opening and closing force at drive rod max. 700 N (corresponds to
approx. 8 Nm manual levertorque)
Closing force of tilt window sash (reduced) max. 150 N
Protection class IP20 for dry locations
Permissible operating temperature -20°C to +40°C
Tested with 30000 operating cycles (double
stroke including locking)

Operating Instructions DRIVE axxent DK
Last update: 9.10.14 14
Liability
Intended use
Any use or application of this product that is not in accordance with its intended purpose, or any
adaptation of or modification to the product and its associated components for which our express
consent has not been obtained, are strictly prohibited. We are not liable for any damage to material
or persons if this stipulation is not observed.
Product liability
Provided that they are correctly installed and handled, our products are subject to warranty for 1
year after receipt of goods by companies (according to our general terms and conditions), or as
otherwise agreed, and for 2 years for end consumers according to statutory law. As part of our
ongoing improvements, we reserve the right to replace individual components or entire products.
Consequential losses resulting from a failing in the unit are excluded from the warranty within the
limits of the law. The warranty shall become void if modifications that are unauthorized by us or have
not been described in this documentation are made to the product and/or individual components,
or if the product and/or individual components is/are dismantled or partly dismantled.
Exclusion of liability
The product and its components are subject to stringent quality controls. As a result, they function
reliably and safely when used correctly. Our liability for consequential losses and/or claims for da-
mages is excluded, except in the case of wilful misconduct or gross negligence, or where we are
responsible for injury to life, limb or health. Strict liability under the German Product Liability Act (Pro-
dukthaftungsgesetz) remains unaffected. Liability for the culpable violation of significant contractual
obligations also remains unaffected; liability in this case is limited to losses that are specific to the
contract and that could have been foreseen. The above regulations do not imply a change in the
burden of proof to the detriment of the consumer.

Contact your dealer:
Head Office:
Industriestraße 1–3
57234 Wilnsdorf
GERMANY
Phone: [phone]
Telefax: [phone]
[e-mail]
www.siegenia.com
SIEGENIA worldwide:
Austria Phone: [phone]
Belarus Phone: [phone]
Benelux Phone: [phone]
China Phone: [phone]
France Phone: [phone]
Germany Phone: [phone]
Great Britain Phone: [phone]
Hungary Phone: [phone]
Italy Phone: [phone]
Poland Phone: [phone]
Russia Phone: [phone]
South Korea Phone: [phone]
Switzerland Phone: [phone]
Turkey Phone: [phone]
Ukraine Phone: [phone]
You can find address details for our
international sites at: www.siegenia.com
H47.MOTS002EN/2
