MHS400.
Motorised lift & slide system for schemes A and C.
Assembly
instructions
ASSEMBLY INSTRUCTIONS

Last update: 17.12.2014 1
Original operating instructions MHS400
1. Information ..................................................................................................................................................................................2
1.1 Technical information.........................................................................................................................................................2
1.1 Technical information ........................................................................................................................................................3
1.2 Technical information - Scheme A ....................................................................................................................................4
1.3 Scope of delivery - Scheme A ..........................................................................................................................................5
1.4 Technical information - Scheme C ....................................................................................................................................7
1.5 Scope of delivery - Scheme C ..........................................................................................................................................8
1.6 Use .................................................................................................................................................................................. 10
1.7 Safety information and hazard warnings...................................................................................................................... 11
1.8 On-site risk and hazard analysis in the planning phase ............................................................................................. 12
2. Assembly .................................................................................................................................................................................. 13
2.1 Assembly requirements................................................................................................................................................... 13
2.1 Assembly requirements .................................................................................................................................................. 14
2.2 Information about mains cable fitting ........................................................................................................................... 17
2.3 Drilled holes on the lift & slide sash .............................................................................................................................. 19
2.4 Cable fitting in the lift & slide sash ................................................................................................................................ 23
2.5 Assembly of the lift drive HA ......................................................................................................................................... 27
2.6 Assembly of the slide drive SA - Schema A .................................................................................................................. 31
2.7 Concealed mains cable fitting and connection - Scheme A ........................................................................................ 33
2.8 Assembly of the light curtain - Scheme A ..................................................................................................................... 34
2.9 Assembly of the slide drive SA - Schema C ................................................................................................................. 35
2.10 Concealed mains cable fitting and connection - Scheme C ..................................................................................... 38
2.11 Assembly of the light curtain - Scheme C ................................................................................................................... 39
2.12 Special designs ............................................................................................................................................................ 40
2.13 Finalising the assembly................................................................................................................................................. 40
3. Lift & slide profile systems........................................................................................................................................................ 41
3.1 Information about lift & slide profile systems................................................................................................................. 41
3.2 Vertical sections at the top for timber elements ............................................................................................................ 42
3.3 Vertical sections at the top for PVC elements ............................................................................................................... 44
3.4 Vertical sections at the top for aluminium elements ..................................................................................................... 51
4. Information concerning product liability................................................................................................................................. 59
5. EC declaration of incorporation ............................................................................................................................................. 60

2Last update: 17.12.2014
MHS400 Assembly instructions
1. Information
1.1 Technical information
Please read these assembly instructions carefully and in full before assembling and commissioning
the MHS400 system.
Please refer to the enclosed operating instructions for information on the commissioning and opera-
tion of the MHS400 lift & slide system.
Ventilation and convenience
The MHS400 lift & slide system from SIEGENIA .provides maximum operating convenience for straightforward opening and
closing of lift & slide sashes of scheme A and scheme C lift & slide elements. In conjunction with compatible SIEGENIA HS
portal hardware (e.g. HS-PORTAL 200, HS-PORTAL 300 and HS-PORTAL 400), it opens, closes and locks lift & slide sashes
at the touch of a button. Furthermore, the MHS400 lift & slide system can even be assembled on lift & slide elements by third-
party manufacturers and retrofitted to previously installed lift & slide elements. The MHS400 lift & slide system for secure,
convenient opening and closing of lift & slide elements also impresses with its sturdy build, high torque, quiet, short operating
times and slim, unobtrusive design. The system can be operated directly on the lift drive, via a wall switch or with the infrared
remote control included in the scope of delivery.
A profile cylinder is not required.
Application
The lift drive HA replaces the handle on the lift & slide sash. Driven by an electric motor, it unlocks and lifts the lift & slide sash
via the lift & slide hardware gear. The slide drive SA is installed horizontally at the top of the frame of the lift & slide element.
The slide drive then moves the lift & slide sash to the "OPEN" or "CLOSED" position.
For assembly on lift & slide elements with existing profile cylinders, follow the instructions. in Chapter 2, page 29 and 30.
Product description
• Contemporary, unobtrusive design in the standard colours white and silver
• Automatic locking/unlocking and moving of lift & slide sashes (lift & slide elements scheme A and C)
• Smooth start and stop
• 10-minute secure automatic night ventilation
• Programming of a limited opening width
• Special functions
• Jam protection via current limiter, so a "deadman control" is not required
• Optional additional safety possible with light curtain (MHS400-L version)
• Full opening width of lift & slide sash possible with MHS400-L
• Wheelchair-accessible design and operation in accordance with DIN 18025 and DIN 18030 possible (flat threshold re-
quired)
• For universal use, regardless of the hardware manufacturer (10 mm square)
• Simple connection via Euro plug
• Plug-and-play principle of the MHS400 lift & slide system complete set:
unpack - screw on - teach in - ready for operation
• With infrared remote control
• Simple manual operation in the event of a malfunction (e.g. power failure)

Last update: 17.12.2014 3
Assembly instructions MHS400
1.1 Technical information
Fields of application and product benefits
• For universal use with HS-PORTAL elements, scheme A and C
• Simple assembly on almost all profile systems and materials
• Versions for DIN left and DIN right
• Easy to retrofit to almost all profile and hardware systems (fittings do not have to be changed and no complicated profile milling
is required)
• Paint finish in all RAL and NCS colours subject to additional charge
• Suitable for max. sash weight of 400 kg incl. glass pane (opening scheme A and C)
• Scheme A: Inside frame width (RIB) 1775 mm – 6666 mm with symmetrical split
(installation on asymmetrical elements on request)
• Scheme C: Total inside frame width (RIB) 3550 mm – 13332 mm
• Short assembly time due to pre-assembled drive
• Space required at top of frame only approx. 45 mm. The slide drive SA can be pushed down (dependent on profile) if space
is at a premium.
• Gear square: 10 mm, length 40 mm
• Useful accessories available (e.g. through hole jig MHS400, catch jig MHS400 and profile cylinder covers, etc.)
Features
• Automatic teach-in and calibration of the lift & slide sash with reference run on first operation of the MHS400 lift & slide system
• High level of functional reliability: Tested with 400 kg for more than 20,000 switching cycles
• Simple cable fitting with cable holders in the fitting groove of the lift & slide sash
• Powered via 230 V AC power supply (alternating current) / 24 V DC (direct current),
- power supply is integrated in slide drive SA
• Plug-and-play for retrofitting: cable (scheme A = 5 m, scheme C = 3.5 - 5 m long) and Euro plug
Specifications table
Power supply scheme A 120 - 240 V AC, 22 W
Power supply scheme C 120 - 240 V AC, 48 W
Internal operating voltage 24 V DC (power supply integrated in slide drive SA)
Max. displacement force during slide opera-
tion
Approx. 50 N (depending on sash weight and slide resistance)
Max. torque at square Approx. 25 Nm
Traverse speed Approx. 150 mm/s
Operating time lift drive HA Approx. 7 s
Temperature range -5 °C to +50 °C
Jam protection Via electronic overload cut-off device (current limiter in accordance with
standard) Optional light curtain
Degree of protection IP 20 for dry locations
Connection to AC mains power supply (at fac-
tory)
Euro plug, 5 m cable length
Permanent connection to AC mains power
supply (by customer)
(concealed in-wall fitting of mains cable)
Cable 5 x 1.5 mm
2flexible
(all-pole mains isolation required)
Terminals For max. 2.5 mm2supply line

4Last update: 17.12.2014
MHS400 Assembly instructions
1.2 Technical information - Scheme A
Product overview - Scheme A
Size range - Scheme A
* For other sash heights (on request), note the special cable length
Dimension drawing - Scheme A
Inside frame width (RIB) size 1 1775 mm to 2753 mm
Inside frame width (RIB) size 2 2754 mm to 4058 mm
Inside frame width (RIB) size 3 4059 mm to 6666 mm
Sash height* (standard for HS-PORTAL) 1175 mm to 2675 mm
Sash weight HS-PORTAL 200 max. 200 kg
Sash weight HS-PORTAL 300 max. 300 kg
Sash weight HS-PORTAL 400 max. 400 kg
Max. permissible sash weight for MHS400 lift & slide drive max. 400 kg
Backset (gear) HS-PORTAL 200 27.5 mm
Backset (gear) HS-PORTAL 300 37.5 mm
Slide drive SA
Catch base Cover cap for catch
base
Lift drive HA
Cover profile for slide drive SA
Infrared
remote control
Emergency operating
Cover cap SA Cover cap SA
==
RIB (measure with cover)
Slide drive SA
Other cowl lengths (on request)
1

Last update: 17.12.2014 5
Assembly instructions MHS400
1.3 Scope of delivery - Scheme A
Ordering data and part list - Scheme A
* Full set consisting of lift & slide drive, infrared remote control and emergency key
Item Qty Description Colour Material number
23 1 Add. infrared remote control (incl. batteries) - GZFB0020-025010
24 1 Catch jig MHS400 - GABB0010-0E5010
25 1 Through hole jig MHS400 - GABB0020-0E5010
26 1 Rose lock RAL 9003 white GZRS0010-096010
Silver ~ RAL 9006 GZRS0010-025010
27 1 Rose lock cover RAL 9003 white GZRA0010-096010
Silver ~ RAL 9006 GZRA0010-025010
Accessories list - Scheme A (not included in scope of delivery)
Qty Description RIB in mm Colour Material number
1 *MHS400 lift & slide system size 1
(must be ordered using special order form)
1775 - 2753 RAL 9003 white GMHS0010-000010
Silver ~ RAL 9006
1 *MHS400 lift & slide system size 2
(must be ordered using special order form)
2754 - 4058 RAL 9003 white GMHS0020-000010
Silver ~ RAL 9006
1 *MHS400 lift & slide system size 3
(must be ordered using special order form)
4059 - 6666 RAL 9003 white GMHS0030-000010
Silver ~ RAL 9006
Item Qty Contents of slide drive SA box Version
1 1 Slide drive SA Including 24 V power supply
2 1 Catch On slide drive SA
3 1 Catch base For lift & slide sash top
4 1 Packer (2.5, 5, 8 or 10 mm thick depending on profile system) For catch on lift & slide sash top
5 1 Cover cap M For catch
6 1 Cover profile SA For slide drive SA
7 1 Cover cap SA left For cover profile SA
8 1 Cover cap SA right For cover profile SA
9 1 Cable sash (flat ribbon cable, 6-wire) For slide drive SA - lift drive HA
10 12 Cable holder Clip-on or screw-on
11 1 Mains cable with Euro plug On slide drive SA, 5 m cable length
12 1 Terminal board For connecting light curtain, only with
MHS400-L
13 1 Assembly and operating instructions
Item Qty Contents of lift drive HA box
14 1 Lift drive HA
15 1 Fixing plate HA For lift drive HA
16 1 Cover cap HA top For lift drive HA
17 1 Cover cap HA bottom For lift drive HA
18 4 Fixing screws M5 x 10 mm (incl. washers) For fixing plate lift drive HA
19 2 Fixing screws M4 x 25 mm (incl. washers) For cover cap HA top
20 1 Fixing screw M5 x 19 mm with square nut M5 For cover cap HA bottom
21 1 Emergency operating handle Hexagon socket screw key WAF 8
Item Qty Contents of infrared remote control box
22 1 Infrared remote control Including 2 batteries, type: AAA, micro or
LR03

6Last update: 17.12.2014
MHS400 Assembly instructions
Component and accessories overview - Scheme A
Scope of delivery of individual components Accessories (not included in scope of delivery)
11 1
2
3
45
78
10
10
22
9
16
15
14
19
18
17
13
20
21
18
24
25
23
27 26
12
6

Last update: 17.12.2014 7
Assembly instructions MHS400
1.4 Technical information - Scheme C
Product overview - Scheme C
Size range - Scheme C
* For other sash heights (on request), note the special cable length
Dimension drawing - Scheme C
Inside frame width (RIB) size 1 (size 1 each slide drive = RIB/2) 3550 mm to 5506 mm
Inside frame width (RIB) size 2 (size 2 each slide drive = RIB/2) 5507 mm to 8116 mm
Inside frame width (RIB) size 3 (size 3 each slide drive = RIB/2) 8117 mm to 13332 mm
Sash height* (standard for HS-PORTAL) 1175 mm to 2675 mm
Sash weight HS-PORTAL 200 max. 200 kg
Sash weight HS-PORTAL 300 max. 300 kg
Sash weight HS-PORTAL 400 max. 400 kg
Max. permissible sash weight for MHS400 lift & slide drive max. 400 kg
Backset (gear) HS-PORTAL 200 27.5 mm
Backset (gear) HS-PORTAL 300 37.5 mm
2 slide drives SA
2 catch bases 2 cover caps for catch bases
2 lift drives SA
2 cover profiles for slide
drives SA
Profile connector
Infrared
remote control
Emergency operating
Cover cap SA Cover cap SA
A= RIB (measure with cover)1
Dimension 1= Inside frame Dimension 2= Inside frame
As far as centre of sash outer edge As far as centre of sash outer edge
Other cowl lengths (on request)
Cable
outlet
(for
selection)
Slide drive SA left
Cable
outlet
(for
selection)
Slide drive SA right

8Last update: 17.12.2014
MHS400 Assembly instructions
1.5 Scope of delivery - Scheme C
Ordering data and part list - Scheme C
* Set consisting of 2 lift & slide drives, 1 infrared remote control incl. wall holder and emergency key
Accessories list - Scheme C (not included in scope of delivery)
Qty Size by slide drive Size range in mm Colour Material number
1 MHS400 lift & slide system size 1
(1 slide drive each on left and right)
2812 – 5506 RAL 9003 white GMHS0040-000010*
(must be ordered using
special order form)
Silver ~ RAL 9006
1 MHS400 lift & slide system size 2
(1 slide drive each on left and right)
5507 – 8116 RAL 9003 white
Silver ~ RAL 9006
1 MHS400 lift & slide system size 3
(1 slide drive each on left and right)
8117 – 13332 RAL 9003 white
Silver ~ RAL 9006
Item Qty Contents of slide drive SA box Version
1 2 Slide drive SA Including 24 V power supply
2 2 Catch For slide drive SA
3 2 Catch base For lift & slide sash top
4 2 Packer (2.5, 5, 8, 10 mm thick depending on profile system) For catch on lift & slide sash top
5 2 Cover cap M For catch
6 1 Cover profile SA (total length up to 7000 mm) For slide drive SA
2 Cover profile SA with profile connector total length > 7000 mm
7 1 Cover cap SA left For cover profile SA
8 1 Cover cap SA right For cover profile SA
9 2 Cable sash (flat ribbon cable, 6-wire) For slide drive SA - lift drive HA
10 24 Cable holder Clip-on or screw-on
11 1 Mains cable with Euro plug On slide drive SA, cable length 3.5 - 5 m
12 1 Terminal board For connecting light curtain, only with
MHS400-L
13 1 Assembly and operating instructions
Item Qty Contents of lift drives HA box
14 2 Lift drive HA
15 2 Fixing plate HA For lift drives HA
16 2 Cover cap HA top For lift drives HA
17 2 Cover cap HA bottom For lift drives HA
18 8 Fixing screws M5 x 10 mm (incl. washers) For fixing plates lift drives HA
19 4 Fixing screws M4 x 25 mm (incl. washers) For cover caps HA top
20 2 Fixing screw M5 x 19 mm with square nut M5 For cover caps HA bottom
21 1 Emergency operating handle Hexagon socket screw key WAF 8
Item Qty Contents of infrared remote control box
22 1 Infrared remote control Including 2 batteries, type: AAA, micro or
LR03
Item Qty Description Colour Material number
23 1 Add. infrared remote control (incl. batteries) - GZFB0020-025010
24 1 Catch jig MHS400 - GABB0010-0E5010
25 1 Through hole jig MHS400 - GABB0020-0E5010
26 1 Rose lock RAL 9003 white GZRS0010-096010
Silver ~ RAL 9006 GZRS0010-025010
27 1 Rose lock cover RAL 9003 white GZRA0010-096010
Silver ~ RAL 9006 GZRA0010-025010

Last update: 17.12.2014 9
Assembly instructions MHS400
Component and accessories overview - Scheme C (by lift & slide sash)
* Use profile connectors to connect the cover profiles (SA) on the left and right at and above total length of 7000 mm.
Scope of delivery of individual components Accessories (not included in scope of delivery)
11
1
2
3
45
78
10
10
22
9
16
15
14
19
18
17
13
20
21
18
24
25
23
27 26
12
6
6*

10 Last update: 17.12.2014
MHS400 Assembly instructions
1.6 Use
Individual drive
An individual drive for lift & slide elements in DIN left or DIN right is supplied (in accordance with the information supplied
on the special order form for the MHS400 lift & slide system for either scheme A or scheme C at the time of placing the order).
230 V alternating current connection
The MHS400 lift & slide system is connected to the 230 V AC mains power supply with a connecting cable (scheme A = 5
m, scheme C = 3.5 - 5 m long) with Euro plug. All-pole safety isolation is required if the customer is fitting the mains cable.
Information for initial commissioning
When you operate the unit for the first time, you must carry out a reference run as well as a calibration and teach-in run in
order to determine the lift & slide element size and the displacement forces (see operating instructions).
Activating the MHS400 system
The drive is designed for elements with opening scheme A or C lift & slide function. The MHS400 lift & slide system can be
operated almost entirely with the button on the lift drive HA. The infrared remote control supplied enables convenient oper-
ation of the lift & slide sash. A wall switch or key button can also be used for operation. The infrared remote control can be
programmed individually (taught in) and used in parallel with other means of control at all times. The drive of the MHS400
lift & slide system can be stopped at any time with the "Stop" button on the infrared remote control.
Group control of multiple MHS400 systems
The infrared remote control can control up to 5 drive groups separately. With scheme C, each lift & slide sash can also be
controlled individually. To achieve this, several MHS400 lift & slide systems are taught in to the required group in set-up mode
(see operating instructions). Up to 8 remote controls can be taught in for each drive.
Lift & slide sash positions
(see also operating instructions)
Limited opening width
The lift & slide sash can be moved to an intermediate setting freely selected and programmed by the user by pressing the
corresponding button on the infrared remote control or the button on the lift drive HA.
10-minute automatic night ventilation
The lift & slide sash can be moved to the secure night ventilation position (HS-PORTAL only) and automatically closed and
locked after 10 minutes by pressing the corresponding button on the remote control or the button on the lift drive HA. Excep-
tion for equipment with a light curtain: if an object moves into the path of the lift & slide sash, the lift & slide sash is stopped.
Safety slow speed mode and jam protection
The slide drive SA features an electronic cut-off function for when an obstacle is hit. For increased safety in the area around
the crush edges, the lift & slide sash traverses the last 500 mm at reduced speed. If the lift & slide sash hits an obstacle, the
direction of travel is reversed and the lift & slide sash moves in the opposite direction for approx. 4 seconds.
Function Corresponding lift & slide sash position
"OPEN" Unlocked and fully open
Intermediate position User-defined, limited opening width
10-minute night ventilation 10-minute night ventilation position (locked in locking bolt/locking part)
"CLOSED" Closed and locked (reference setting)

Last update: 17.12.2014 11
Assembly instructions MHS400
Light curtain for additional safety requirements
It is possible to integrate a light curtain with the slide drive SA (MHS400-L) to increase safety during travel. If an object moves
into the path of the lift & slide sash, the lift & slide sash is stopped immediately.
Information about manual operation
In the event of a malfunction (e.g. power failure), the lift & slide sash can be unlocked and opened manually with an emer-
gency operating handle at the lift drive HA. The lower cover cap on the lift drive HA must be removed for this purpose. The
motor gear is unlocked by pressing the release knob on the lift drive HA. The lift & slide sash can then be lifted manually with
the emergency operating handle (hexagon socket screw key WAF 8) and then moved by hand.
1.7 Safety information and hazard warnings
You must follow the safety instructions!
Risk of injury or fatal injury. Hands, arms, legs and feet can get trapped and/or
crushed in systems driven by an electric motor.
›Make sure that no parts of the body or objects are within the shearing and closing area of the system.
›Particularly when lowering lift & slide elements, make sure that no parts of the body or objects are under the lift & slide
sash.
›Do not leave children unattended near a lift & slide element.
Risk of injury or death due to electrical shock or fire. Systems driven by an elec-
tric motor can overheat and cause fire.
›Insert the Euro plug of the standard connecting cable only into a suitable 230 V AC socket.
›Only a qualified electrician may perform any work on the 230 V AC mains power supply that is required in order to
connect the unit.
›Current local regulations (such as VDE 0100 of the VDE in Germany) must be observed.
›Relevant country-specific regulations must be strictly followed for all work on the voltage supply system or building wiring
system.
›All-pole safety isolation is required when the mains cable is fitted on-site because the power supply does not have a sep-
arate line disconnector.
›The concealed mains supply lines to the MHS400 lift & slide system must be connected in branch boxes; these branch
boxes must be easily accessible for maintenance.
›When cleaning the lift & slide sash and the drives, make sure that no liquid gets inside the MHS400 lift & slide system as
this could damage the electronics.
›The unit must be checked by a specialist in the event of a fault.
Injuries caused by falling objects
›Please do not put or place objects on top of the MHS400.

12 Last update: 17.12.2014
MHS400 Assembly instructions
1.8 On-site risk and hazard analysis in the planning phase
In order to assess the potential hazards of a power-operated window and to take the appropriate protective measures, you
must assess risks in the planning phase. A risk analysis provides you with all the information needed to assess risks and make
decisions concerning the safety of the window elements. With the MHS400 lift & slide system, there are areas on the lift &
slide element where crushing and shearing may occur. You must carry out a risk and hazard analysis during the planning
phase in accordance with VFF data sheet KB.01 and the current Machinery Directive relating to the safety equipment and
installation situation as appropriate for the individual property and conditions of use (e.g. in case of persons requiring special
protection or commercial properties).
This analysis, which
• takes into account the protective measures necessary in the planning phase
• must be carried out before start-up
• provides information based on the individual installation situation and users on how to install the window system in such a way
as to exclude or at least minimise possible hazards
• draws attention to possible residual risks
The following points are to be checked:
• Public or non-public area (private or industrial property)
• Installation location
• Users (authorised users, persons in need of protection or trained personnel)
• Special structural conditions
• Type of access control
• Requirements for added safety can be met with a light curtain (MHS400-L).
Instructions for assembly and installation
All work in connection with the assembly and commissioning of the MHS400 lift & slide system must be carried out by suitably
trained personnel and specialist companies. The applicable regulations governing mechanical and electrical work must be
complied with and the safety instructions in our product documentation must be followed. Please read these assembly instruc-
tions carefully and in full before assembling and commissioning the MHS400 lift & slide system. For visual assistance, you
can also request the "MHS400 assembly video" DVD (H4008.2622DE/EN).
Observe the warnings and specific hazard information. Contraventions may lead to our warranty and product liability being
rendered null and void. Once the MHS400 lift & slide system has been assembled, the operating instructions supplied with
it MUST be handed over to the user and the user/owner of the building must be briefed accordingly.
• Use flexible supply lines (run conduit tubes if necessary).
• When fitting cables, avoid damaging the cables by crushing, bending or stretching them.
• The concealed mains supply lines running to the MHS400 lift & slide system must be connected in branch boxes (these branch
boxes must be easily accessible for maintenance).
• Protect the MHS400 lift & slide system against contamination by site material and humidity.
• The hardware components must be securely fixed in place.
• Connect to the mains supply only after you have tested for proper mechanical function.
• Observe the applicable processing guidelines from the profile manufacturer.
To avoid personal injury, it is important to observe the safety precautions provided in these instructions and make sure that
these instructions are accessible at all times.
Cooperation between trades and interfaces
In the context of project management, the work of the various trades must be carefully coordinated. If SIEGENIA components
are being connected to third-party installations or SIEGENIA are being combined with parts by other manufacturers (e.g.
drives and controls), technical compatibility must be verified in advance by authorised personnel. For data collation purpos-
es, the technical data sheets and the latest versions of the operating instructions must be handed over to the trades involved
when work commences.

Last update: 17.12.2014 13
Assembly instructions MHS400
2. Assembly
2.1 Assembly requirements
General information about assembly
The following description of the assembly process is a recommendation from SIEGENIA and describes the major steps in-
volved. The specific details of the assembly process are determined, amongst other factors, by the lift & slide element used,
by the production process and by the window manufacturer's equipment and facilities.
Preparations for assembly
The MHS400 system must always be installed by an experienced and qualified window specialist, in accordance with the
installation and planning documents issued by SIEGENIA. If you have any questions about installation, please contact the
head of the relevant department at SIEGENIA or your window specialist. Other technical questions should be directed to
SIEGENIA: Tel. [phone]
Before commencing assembly work and commissioning involving the MHS400 system, be sure to read the safety infor-
mation and hazard warnings on page 11.
Note: It must be possible to access and disassemble the slide drive SA at all times should maintenance and service work
be required (curtain rods, lamps, ceiling covers, roller shutter housings, etc. must not hinder disassembly); see the information
about the installation situation on page 40.
Tools required (not included in scope of delivery)
• Drill
• Ø 3 mm, Ø 7 mm and Ø 10 mm plus Ø 15 mm timber or metal drill
• Phillips screwdriver (size 2)
• 1 screwdriver bit 90 mm long
• 2 screw clamps
• Folding rule
• Router (for timber elements)
• Between 2 and 4 assembly racks
• Watch with second hand or stop watch
Recommendation: The fixing plate HA of the lift drive HA can be used to mark the drilled holes for the cable outlet and the
fixing holes on the lift & slide sash (see page 14 and 21). For straightforward and accurate positioning or fixing of the catch
on the lift & slide sash, SIEGENIA recommends using the catch jig MHS400 (accessory).
Materials required (not included in scope of delivery)
Additional screws for fixing the fixing plate HA (15) to the lift & slide sash (see page 27), as well as for the slide drive SA
(1) and the catch (2) on the upper sash frame of the lift & slide sash must be provided by the customer (see page 32 and 35):
For component: Scheme Type of screw
A C
Number of units
(depending on
RIB)*
for timber and PVC elements
screw
for aluminium elements
flow-drill screw
Slide drive SA* (1) 10 - 25 20 - 50 St 4.1 x 38 mm M4 x 18 mm
Catch (2) for lift & slide sash 2 4 St 4.1 x 38 mm M4 x 18 mm
Fixing plate HA (15) 4 - 6 8 - 12 St 4.1 x 19 mm M4 x 18 mm
Cable holder (10) in sash groove 6 12 St 4.1 x 19 mm M4 x 18 mm
Note: All screwing points must be pre-drilled to Ø 3 mm. The length of the fixing screws for PVC elements must be sufficient
to penetrate deep enough into the reinforcing material to ensure a sufficient hold. Materials for lining the slide drive SA (PVC
plates, for example) must be provided by the customer for certain lift & slide profile systems (see Chapter 3).

14 Last update: 17.12.2014
MHS400 Assembly instructions
2.1 Assembly requirements
Positioning the MHS400 system on the lift & slide element - Scheme A
Risk of mechanical defects if the MHS400 system is put into operation unassem-
bled.
›You must assemble the MHS400 system first before putting it into operation.
• When operating the MHS400 system for the first time, you must carry out a reference run as well as a calibration and teach-
in run which determines the traverse path and the traverse forces of the lift & slide sash automatically (see operating instruc-
tions).
• Prior to assembly, clarify how the MHS400 system is to be controlled in addition to using the infrared remote control supplied
with it (using components provided by the customer, for example, such as wall or key switches (not included in the scope of
delivery)).
Through hole jig MHS400 and catch jig
MHS400
SIEGENIA recommends the jigs shown here (ac-
cessories) for the drilled holes (cable feed-through
and catch on lift & slide sash).
Fixing plate HA
The fixing plate shown here can be used to
mark the drilled holes on the lift & slide
sash.

Last update: 17.12.2014 15
Assembly instructions MHS400
Positioning the MHS400 system on the lift & slide element - Scheme C
Risk of mechanical defects if the MHS400 system is put into operation unassem-
bled.
›You must assemble the MHS400 system first before putting it into operation.
• When operating the MHS400 system for the first time, you must carry out a reference run as well as a calibration and teach-
in run which determines the traverse path and the traverse forces of the lift & slide sash automatically (see operating instruc-
tions).
• Prior to assembly, clarify how the MHS400 system is to be controlled in addition to using the infrared remote control supplied
with it (using components provided by the customer, for example, such as wall or key switches (not included in the scope of
delivery)).
Through hole jig MHS400 and catch jig
MHS400
SIEGENIA recommends the jigs shown here (ac-
cessories) for the drilled holes (cable feed-through
and catch on lift & slide sash).
Fixing plate HA
The fixing plate shown here can be used
to mark the drilled holes on the lift & slide
sash.

16 Last update: 17.12.2014
MHS400 Assembly instructions
Before you can carry out work on the lift & slide sash (drilling and fitting cables), it must first be removed from the lift & slide
frame. Before drilling the required holes on the lift & slide sash, you must remove the handle, the recessed pull handle and
the hardware gear. To ensure trouble-free operation of the MHS400 system, the following requirements must be met:
Requirements to be met by the lift & slide element
• The lift & slide element must not be warped.
• The lift & slide element must be installed vertically plumb in the reveal.
• The threshold must be properly and sufficiently supported — especially for wide or heavy lift & slide elements (e.g. 400 kg).
• To avoid the risk of the connection cable getting crushed in the sash groove, the locking bolt or the locking part for
night ventilation must always be installed at the bottom on the locking side (see the latest assembly instructions for
more information).
• The lift & slide sash must lock into the locking bolts or locking parts evenly.
• The fitting of the cable in the lift & slide sash must be checked prior to assembly. The lift & slide sash must be prepared for op-
timum cable fitting in the fitting groove.
• In cases of retrofitting involving existing lift & slide elements, a visual inspection must be carried out before starting work.
• For scheme A, the concealed mains cable guide must always be located on the horizontal top section of the lift & slide frame
near the locking side.
• For scheme C, the concealed mains cable guide can be located on the outside of the lift & slide frame on either
the left-hand side or the right-hand side.
Requirements to be met by the hardware
• In order for the MHS400 system to function properly, a compatible lift & slide fitting for opening scheme A or C with 10 mm
square striker packer must be installed in the gear (e.g. HS-PORTAL 200, HS-PORTAL 300 or HS-PORTAL 400).
• You can find detailed specifications for size ranges and sash weights in the relevant assembly instructions (e.g. assembly in-
structions for HS-PORTAL 200, HS-PORTAL 300 or HS-PORTAL 400).
• The MHS400 system can only be assembled if the lift & slide hardware gear or the sash hardware has been installed in ad-
vance.
• The hardware must be able to run smoothly (be in unrestricted working order). The maximum torque on the handle must not
exceed 25 Nm.
Requirements to be met by the drive
Risk of mechanical defects if the MHS400 system is put into operation with lift &
slide elements that are not able to move freely.
›Do not put the MHS400 system into operation if the smooth running of the lift & slide element cannot be ensured.
• The MHS400 has not been tested as a locking unit in accordance with ENV 1627-1630.
• The drive must be protected from dust and dirt during the entire assembly and installation phase.

Last update: 17.12.2014 17
Assembly instructions MHS400
2.2 Information about mains cable fitting
Important information for safety and assembly
The fitting of the mains cable is determined by the prevailing conditions on site. There are two assembly options:
Option A — Surface-mounted fitting of mains cable
The MHS400 system is delivered as standard with a 5 m long mains cable for scheme A and a 3.5 - 5 m long mains cable
for scheme C (depending on the width of the element). The cable outlet for scheme A is always at the top of the slide drive
SA on the locking side (Fig. 1); for scheme C, it can be located on the outside of the slide drive SA on either the left-hand
side or the right-hand side. A notch for the cable outlet must be made on the cover cap SA of the cover profile SA (see Fig.
2). A suitable mains socket must be located near the cable outlet. It is recommended to feed the mains cable through an
appropriate installation duct.
1
2
Cover cap SA delivered
with punched groove
for cable outlet aperture
notch
Using a suitable tool
(pliers or similar), carefully
remove the cable outlet
aperture notch.
Cable outlet aperture
notch
for mains cable

18 Last update: 17.12.2014
MHS400 Assembly instructions
Option B — Concealed fitting of mains cable
If the customer is responsible for the concealed fitting of the mains cable for the slide drive SA and the connection of the slide
drive SA (in the power supply for scheme A, in the 5-pin socket for scheme C), this work must be carried out by a qualified
electrician. In the case of mains cable fitting for lift & slide elements which have not yet been installed (e.g. new build and
renovation projects), a flexible cable (5 x 1.5 mm2incl. connection) for wall and key switches must be provided by the cus-
tomer and fed concealed through the top section of the lift & slide frame (Fig. 3).
3
Drilled holes for the cable inlet and outlet (each approx. Ø 10 mm) must be made for this purpose, with the centre of each
hole being positioned approx. 7 mm away from the inside frame edge (Fig. 4). All-pole safety isolation is required if the
customer is fitting the mains cable. The isolated end of the mains cable must be located inside the power supply housing
(scheme A) or 5-pin socket (scheme C). The connection to the slide drive is made in accordance with the wiring diagram (see
page 33 and 38). In the mounting angle for the slide drive SA, there is a sufficiently dimensioned recess for the cable outlet
on the lift & slide frame profile for scheme A (Fig. 5). The mounting angle for scheme C does not have a recess for the cable
outlet (Fig. 6). Concealed mains cable fitting to the slide drive SA is through the top edge of the frame on the locking side.
5
56
4
Y
7 mm
Bottom edge of lift & slide frame (without cover)
Dimension Y = 15 mm for timber and PVC elements
Dimension Y = central in relation to hollow section in the case of
Frame
inside edge
Mains cable outlet Ø 10 mm
(drill and deburr)
Mains cable outlet Ø 10 mm
(drill and deburr)
Recess in
mounting angle
Mains cable
inlet
Ø 10 mm
Mains cable
inlet
Ø 10 mm
Scheme A Scheme C
For information about concealed mains cable fitting and connection, see page 33 and 38.
