Nespresso capsule systems
1SAFETY........................................................3 5FUNCTIONS................................................27
1.1 Safety instructions..............................................................3 5.1 The perfect espresso........................................................ 27
1.2 Repair instructions .............................................................3 5.2 The brewing procedure.................................................... 27
2INSTALLATION............................................4 5.3 Descaling cycle................................................................. 28
5.4 Brewing cycle sequence.................................................. 31
2.1 Installation...........................................................................4 5.5 Temperature graph........................................................... 32
2.2 Scope of delivery ................................................................4 5.6 Fluid system...................................................................... 33
3OPERATION.................................................5 5.7 Wiring and connecting diagram...................................... 34
3.1 Controls...............................................................................5 6REPAIR.......................................................35
3.2 Window with opening sensor ............................................6 6.1 General disassembly........................................................ 35
3.3 NESPRESSO® capsules.....................................................7 6.2 Replacing the display unit............................................... 37
3.4 Preparing coffee..................................................................8 6.3 Replacing the PTC heating element................................ 38
3.5 Drawing hot water.............................................................10 6.4 Removing the water tank holder ..................................... 39
3.6 Drawing steam .................................................................. 10 6.5 Installing the water tank holder....................................... 41
3.7 Frothing up or heating milk..............................................11 6.6 Replacing the heater ........................................................ 43
3.8 Preparing cappuccino and latte macchiato....................13 6.7 Replacing the NTC temperature sensor ......................... 45
3.9 Changing standard settings............................................. 14 6.8 Replacing pump................................................................ 46
3.10 Cleaning.............................................................................17 6.9 Replacing the flowmeter .................................................. 47
3.11 Descaling...........................................................................19 6.10 Replacing the electronics board ..................................... 48
4COMPONENTS...........................................21 6.11 Measuring flow rate.......................................................... 50
4.1 Flowmeter..........................................................................21 6.12 Replacing capsule cage................................................... 51
4.2 Cup heater.........................................................................22
4.3 Heater and NTC-sensor....................................................23
4.4 Brewing unit ......................................................................25
4.5 Hot water / steam nozzle ..................................................26
58300000116013_en_a – 21.08.06 Seite 1 von 61

7FAULT DIAGNOSTICS...............................52
7.1 Incoming goods inspection .............................................52
7.2 Service mode.....................................................................54
7.3 Measuring the coffee temperature ..................................55
7.4 Measuring the temperature of the cup heater ................ 56
7.5 Outgoing goods inspection .............................................57
8TECHNICAL SPECIFICATIONS ................59
8.1 Rating plate .......................................................................59
8.2 Power.................................................................................60
8.3 Temperatures ....................................................................60
8.4 Dimensions and weight.................................................... 61
8.5 Filling amounts .................................................................61
58300000116013_en_a – 21.08.06 Seite 2 von 61

1 SAFETY
1.1 Safety instructions
Danger!
►Repairs may be carried out by a qualified electrician only!
►The user may be put at considerable risk and injured by
improper repairs!
►Electric shock may occur if live components are touched
inside the appliance!
►Do not touch components in the appliance. Even the modules
can be live!
►Before commencing repairs, ALWAYS disconnect the
appliance from the power supply!
►If tests have to be conducted while the appliance is live,
ALWAYS use a residual-current-operated circuit-breaker!
►The protective conductor connection must not exceed the
standardised values! This is essential for personal safety and
appliance function!
►When repairs are complete, perform a test in accordance with
VDE 0701 or the corresponding national regulations!
►Following each repair, conduct a leak and performance test.
1.2 Repair instructions
Caution!
►NEVER attempt repairs by randomly replacing components!
►ALWAYS proceed systematically and comply with the
technical documentation for the appliance!
►Components become hot during operation. Before
commencing repairs, leave the appliance to cool down.
►As a rule, printed-circuit boards are not repaired but are
completely replaced with original spare parts. Exceptions are
documented separately.
m Risk of injury!
Do not insert fingers through the door of the capsule infeed.
The cup heater becomes hot, do not touch.
Do not switch on the appliance without the coffee outlet and
capsule holder.
m Risk of scalding!
Hot water/steam nozzle and the CAPPUCCINO/
CAFFELATTE frothing-up nozzle become very hot. Take hold
of the nozzles by the plastic parts only and do not point
towards parts of the body.
58300000116013_en_a – 21.08.06 Seite 3 von 61

2 INSTALLATION
2.1 Installation
►The installation location must be level and dry.
►Protect the appliance from splash water.
►There must be a minimum filling height of 360 mm.
►Connect and operate the appliance only in accordance with
the specifications on the rating plate.
►Operate the appliance indoors and at room temperature only.
2.2 Scope of delivery
The following parts are included in delivery:
►Welcome box
►CAPPUCCINO / CAFFELATTE nozzle
►Hot water / steam nozzle
2.2.1 Welcome box
A Welcome box is included in delivery. This box contains all parts
required to start up the appliance.
(A) Ring binder with information on capsules, club and machine.
(B) 12 capsules in transparent box (1 capsule per coffee type).
(C) 1 lungo cup with saucer.
(C) 1 espresso cup with saucer.
58300000116013_en_a – 21.08.06 Seite 4 von 61

3 OPERATION
3.1 Controls
1 Control panel
a On / Standby button bIlluminated ring
c Cappuccino button dLatte macchiato button
e Small cup button fLarge cup button
g Hot water button hSteam button
i Display
2 Window with opening sensor
3 Cup heater for prewarming cups
4 Cover for water tank
5 Water tank, removable
6 Flap for steam pipe
7 Steam pipe
8 Adapter
9 Frother (for frothing and heating milk)
10 Nozzle for drawing hot water/steam
a Nozzle holder b Sleeve
c Nozzle tip
11 Drip tray, small (with float)
12 Drip tray, large (with float)
13 Capsule container
14 Coffee outlet
15 Capsule holder
16 Ledge with capsule insert and light
17 Mains switch I/O
58300000116013_en_a – 21.08.06 Seite 5 von 61

3.2 Window with opening sensor
Risk of damage!
Do not obstruct or remove the window!
Clean the window with a damp cloth. Do not use any
scouring agents.
►Set mains switch to I. The blue illuminated ring around the
Standby button lights up. The window (2) opens and closes
independently.
►Press the “Standby” button, the window (2) opens. The
appliance conducts a self-test and starts the heating-up
phase.
The window automatically closes approx. 2 min. after the last activity.
The appliance features a movement sensor. To open the window (2),
move hand in front of the window.
58300000116013_en_a – 21.08.06 Seite 6 von 61

3.3 NESPRESSO®capsules
For this appliance use NESPRESSO®capsules only. Capsules are
offered in 12 different flavours and strengths.
ATTENTION:
The NESPRESSO®capsules must not be damaged
before use.
Deformed or torn capsules may become jammed in the
appliance and damage it.
Each capsule contains exactly the correct amount of ground coffee
for one cup.
In the hermetically sealed alu-
minium capsule (A) all qualities
and flavours of the freshly
roasted coffee (B) are retained
for at least nine months.
A high-pressure pump (19 bar)
ensures that all the flavours of the
espresso develop and that a fine
crema forms.
Coffee is extracted through the membrane (C) directly to the coffee
outlet of the machine.
Order address is given in ring binder:
NESPRESSO®-Club, www.nespresso.com
Purchase capsules in Germany:
On the Internet: www.nespresso.com
By telephone [phone] (freephone)
By fax [phone] (freephone)
By post to Nespresso-Club
Postfach 19 01 61
D-40111 Düsseldorf
Germany
58300000116013_en_a – 21.08.06 Seite 7 von 61

3.4 Preparing coffee
To ensure a successful coffee, prewarm the cups on the cup heater or
fill the cups with hot water and rinse out.
The appliance must be switched
on and ready to use.
Ready is displayed.
►If the window is closed,
open by moving hand in
front of the window.
►Insert NESPRESSO®
capsule with the mem-
brane face down into the
capsule infeed.
►Place a prewarmed cup
under the coffee outlet.
►Press “on” button (e) or (f) .
The cup is filled. The coffee
outlet is automatically stopped
when the programmed amount of
liquid has run through.
Then Ready is displayed again.
The used capsule is automatically emptied into the capsule container.
If the “on” buttons (e) or (f) are pressed during the infeed process or
during the ejection of a capsule, this has no effect on function.
3.4.1 Preparing coffee immediately after drawing steam
If coffee is drawn immediately
after drawing steam with the “on”
button (e) or (f), the appliance
automatically cools down
beforehand. The appliance gives
off steam in intervals and only
then does coffee run out of the
coffee outlet.
3.4.2 Stopping the coffee outlet prematurely
While coffee is being drawn,
press the “on” button (e) or (f)
again:
The coffee brewing process is
stopped.
3.4.3 Additional volume of liquid
Press the “on” button (e) or (f)
again within four seconds after
the coffee has stopped running
out:
The same amount of water is
conveyed a second time through
the same capsule.
58300000116013_en_a – 21.08.06 Seite 8 von 61

3.4.4 Capsule ejection
At the end of the brewing cycle the capsules are emptied into the
capsule container.
If the capsule container is filled up to the indicating limit, no more
coffee can be brewed. (Capacity approx. 10–12 capsules)
Empty capsules is displayed.
►Pull drip trays with
capsule container (A)
forwards out of the
appliance.
►Empty trays and capsule
container and reinsert.
When the drip tray is removed
and there is no capsule container,
Check container
is displayed.
Coffee brewing is not possible if
this display is indicated.
As long as Check container is displayed, the thermal block does
not heat. The solenoid valve remains closed.
3.4.5 Permanently changing the amount of liquid
The preset amount for a small or
a large coffee can be changed
permanently.
►Insert capsule with the
membrane face down into
the capsule infeed.
►Place a cup or glass
under the coffee outlet.
►Press “on” button (e) or (f)
for at least 3 sec. and
hold down until the
required amount has run
through.
The amounts of liquid can be
changed again at any time.
3.4.5.1 Standard filling amounts
Small cup 40 ml
Large cup 100 ml
Filling amounts between 20 ml and 300 ml can be programmed for
each cup.
58300000116013_en_a – 21.08.06 Seite 9 von 61

3.5 Drawing hot water
Risk of burns!
The nozzle becomes very hot. Take hold of the nozzle by
the plastic part only.
►Connect the steam nozzle
to the adapter (A) on the
steam pipe and lock the
nozzle by rotating it.
►Place a glass or a cup
under the steam nozzle.
►Press “hot water” button
(g).
Hot water runs out of the steam
nozzle. The hot water temperature
is at least 72 °C.
►To stop drawing hot water,
press the “hot water” button
(g) again.
Wait is displayed briefly and switches back to Ready after a cooling-
down phase.
3.6 Drawing steam
Risk of scalding!
Steam is very hot. It may cause liquid to splash.
►Screw the steam nozzle
onto the adapter (A) on the
steam pipe
►Press the steam button
(h).
The thermal block is heated to
steam temperature (~140 °C).
The display flashes alternately
between Steam and Wait.
As soon as the display flashes
alternately between Steam and
Ready, steam can be drawn.
►Insert the steam nozzle
deep into the liquid but do
not touch the bottom of the
vessel.
►Press the steam button (h) to start drawing steam.
►To stop drawing steam, press the steam button (h) again.
The appliance automatically cools down after approx. 2 minutes.
Then the appliance is ready to use.
58300000116013_en_a – 21.08.06 Seite 10 von 61
