Siemens Gigaset A 110 User manual

1
Gigaset A110 s
Special features of the A 110
◆Notepad
◆Pen holder with STABILO rollerball pen. The pen is available in all good
stationery and office supplies shops
◆Ringer off key
◆Handset volume and ringer volume setting via function key
Star key
- Answer a call
- Initiate dialling
Last number
redial key End call key
- Hold down:
on/off
- End call
- Cancel function
- Enter the menu
- Confirm input
(save)
Microphone
Battery charging
status
Display
(display screen)
= Battery flat
UBattery fully charged
flashing: Battery almost
flat
0 1 2 3 4 5 6 7 8 9
U
Hold down:
R key function (flash)
Ringer off key
Key 0
Hold down: Temporarily
switch to DTMF dialling
Set/OK key Function key
In idle status:
-Directory
- Caller list
In lists: Scroll
When the telephone is
ringing: Set ringer volume
During a call:
Set handset volume
Entering numbers and letters:
Delete function
Talk key
Activate/deactivate ringer
Ú
ß
Û
Display symbols
- Ringer off
- New entry in
caller list
-Entering
numbers/letters:
the fkey deletes
the character to the left
of the cursor
Special characters:
nHash (#)
RRecall key
Coloured label
Ontario.fm Seite 1 Freitag, 28. November 2003 2:35 14

2
A31008- A110- J100- 1- 7619
Version: 28.11.2003
Issued by
Information and Communication mobile
Schlavenhorst 88
D-46395 Bocholt
© Siemens AG 2003
All rights reserved. Subject to availability.
Right of modification reserved.
Printed in Germany
Siemens Aktiengesellschaft
http://www.my-siemens.com
Order No.: A31008-A110-J100-1-7619
Version: 28.11.2003
Ontario.fm Seite 2 Freitag, 28. November 2003 2:35 14

3
Safety precautions
Not all of the functions described in this manual are available in all countries.
WRead this manual and the safety precautions carefully before use.
Explain their content to your children, and the potential hazards
associated with using the telephone.
Only use the power supply unit supplied as indicated on the
underside of the base.
Insert only approved rechargeable batteries of the same type!
i. e. Never use ordinary (non-rechargeable) batteries as they may
pose a health hazard or cause injury.
Insert rechargeable batteries ensuring correct polarity (symbols are
marked in the
handset battery compartment).
The operation of medical appliances may be affected. Be aware of
the technical conditions within the particular environment (e.g.
doctor's practice).
The handset may cause an intrusive "hum" in hearing aids. Do not
hold the handset against your ear while it is ringing (incoming call).
Do not install the phone in a bathroom or shower room. The handset
and base station are not splash proof (see page 13).
Do not use the phone in environments subject to an explosion
hazard (e. g. auto paint shops).
If you give your telephone to someone else, make sure you also give
them the operating manual.
Dispose of the batteries and phone in accordance with
environmental regulations.
!
$
‹
ƒ
Ontario.fm Seite 3 Freitag, 28. November 2003 2:35 14

4
Setting up the telephone for use
Connecting the base station
◆Insert the round jack on the mains cable into the socket on the
underside of the base.
◆Position cable in the cable recess (for strain relief).
◆Plug the power supply unit into your power outlet.
◆Insert the square jack on the telephone cable supplied into the socket
on the underside of the base.
◆Position cable in the cable recess.
◆Plug the telephone jack into the phone socket.
i
◆Only use the power supply unit supplied as indicated on the
underside of the device.
◆If you buy another cable, ensure that it has the correct
assignment.
Germany: 3-4 assignment of telephone lead/EURO CTR37.
◆Keep the power supply unit plugged in at all times to ensure
your phone is ready for use whenever you need it.
Power supply unit
with mains cable
(220/230 V)
Phone jack with
phone cord
Ontario.fm Seite 4 Freitag, 28. November 2003 2:35 14

5
Setting up the handset for use
The display is protected by a plastic film. Remove the protective plastic film!
Remove the coloured label from the bag containing the batteries and stick it
to the top of the handset (see illustration on page 1).
Inserting the batteries
◆To open the battery compartment, press the clip on the compartment
cover inwards and lift off the cover.
◆Insert the batteries ensuring correct polarity (see figure on left).
◆To close, replace the battery compartment cover as shown and then close
it until it locks into place.
Registering the handset on the base
In order for you to be able to make calls, you must register the handset on the
base.
The display shows "*--*--*". Now place the handset on the base with the
display facing forwards, the display shows REGISTER HS. After around one
minute the handset is registered on the base. The idle display is shown (only
battery symbol and the internal number of the handset in the top left).
If "automatic registration" has not been successful after approx. 1 minute, it is
necessary to either remove the handset from the base for approx. 5 seconds
and then replace it or to register the handset manually (see page 10).
i
◆Only insert rechargeable batteries of the same type, as
recommended by Siemens on see page 14, i. e. Never use
ordinary (non-rechargeable) batteries as they may pose a
health hazard or cause injury.
◆Do not use a non-Siemens charging unit as this could damage
the batteries.
Ontario.fm Seite 5 Freitag, 28. November 2003 2:35 14

6
Charging batteries
Leave the handset in the base for approx. five hours to charge the batteries.
Your unit is now ready to use and you can make calls.
After initial charging, you can return your handset to the base after every call.
Charging is controlled electronically. This ensures optimum battery charging
without overloading. The batteries heat up during charging. This is normal
and not dangerous. The battery charging status is correctly displayed only
after uninterrupted charging/discharging. You should therefore avoid opening
the battery compartment unnecessarily. The battery charge capacity
decreases after a few years for technical reasons some time.
Making calls
Calling and ending calls
~(Enter the number), press c(talk key).
To end the call: Press a (end call key).
You can also press the talk key cfirst and then enter the number – each
digit is dialled immediately.
You can use the end call key ato cancel dialling.
Answering a call
Your telephone rings (ringer) and the talk key flashes.
cPress the (talk key).
Last number redial
Your handset automatically saves the last five telephone numbers dialled. If
names have been saved for these numbers in the directory, then these names
will be displayed.
jOpen the last number redial list.
sSelect the desired entry.
cPress the talk key – the telephone number is dialled.
Ontario.fm Seite 6 Freitag, 28. November 2003 2:35 14

7
Calling Line Identification (CLIP)
When you receive a call, the caller's telephone number is displayed in the
display.
Preconditions:
1. You have asked your network provider to display the caller’s telephone
number in your display (CLIP).
2. The caller has asked the network provider for his number to be identified
(CLIR).
Directory
In the directory, you can store up to 20 telephone numbers (max. 22 digits)
and the associated names (max. 12 characters).
Save new entry
Dialling with the directory
iYou may have to pay a charge to use calling line identification.
Please ask your network provider for details.
hOpen the directory.
sg Scroll to entry <NEW?> and confirm.
~g Enter phone number and confirm.
~g Enter the name and confirm.
The display SAVED appears and you hear the
confirmation tone.
hOpen the directory.
sScroll to the desired entry.
cPress the talk key. The phone number is dialled.
Ontario.fm Seite 7 Freitag, 28. November 2003 2:35 14

8
Editing an entry
Deleting an entry
Caller list
The caller list contains the last 10 missed calls. If it includes new entries
the Ûsymbol flashes in idle status.
Dialling from caller list or deleting an entry
New entries in the caller list are indicated by the jsymbol in the top left of the
display. At the end of the list, "----ESC----" is displayed.
hOpen the directory.
sg Select desired entry and confirm.
~Edit the telephone number as required.
gConfirm entry.
~Edit the telephone number as required.
gConfirm the entry, the display SAVED appears and you
hear the confirmation tone.
hOpen the directory.
sSelect the desired entry.
gHold down the key, DELETE? is displayed.
gConfirm the entry, DELETED is displayed and you hear
the confirmation tone.
fOpen caller list.
sSelect the desired entry.
cDial the number.
or ...
gHold down. The entry is deleted.
or ...
aExit the caller list.
Ontario.fm Seite 8 Freitag, 28. November 2003 2:35 14

9
Cutting into an external call
At least two handsets are registered on the base. You are conducting an
external call. An internal party can can cut into this call and take part in the
conversation. This is indicated by a signal tone.
Precondition: The BARGE IN function is activated (idle status: On).
Activating/deactivating the function
Cutting in
Precondition: A handset is conducting an external call.
cPress the talk key.
gOpen the menu.
[______________________________________________]
sBARGE IN gConfirm (On = ´).
aPress end call key.
cPress the talk key. You are linked into the
call. The display of both handsets shows
CONFERENCE.
aEnding a conference: Press end call key.
iOnly one handset can cut into an external call.
Ontario.fm Seite 9 Freitag, 28. November 2003 2:35 14

10
Manually registering Gigaset A 11 handsets.
You can register up to three Gigaset A 11 handsets on your Gigaset A 110.
However, internal calls between the handsets are not possible.
Gigaset A 11 handset on Gigaset A 110 base
Manual registration is necessary if
◆automatic registration was unsuccessful,
◆the handset supplied has been replaced.
Step 1:
Step 2:
Place handset on the base.
After registration, the handset reverts to idle status and you hear the
confirmation tone.
Gigaset A 11 handset on other GAP bases
Step 1:
Set the base to a status where it is ready for registration (see operating manual
for the base).
Step 2:
After registration the handset reverts to idle status.
gOpen the menu.
[______________________________________________]
sREGISTER HS gSelect the menu item and confirm.
[______________________________________________]
BASE gConfirm. The display shows
"*--*--*".
gOpen the menu.
[______________________________________________]
sREGISTER HS gSelect the menu item and confirm.
[______________________________________________]
sGAP 1 gSelect the menu item and confirm.
"PIN" appears in the display.
Enter the registration PIN for the
GAP base that is ready for registration
(e.g. "0000").
gConfirm entry.
