Siemens Gigaset A120 User manual

1
Lombok / SEA - Taiwan en / A31008-M2401-Y701-1-7619 / Lombok.fm / 23.04.2012
Version 4, 16.09.2005
Gigaset A120/A220
The handset at a glance
1 Charge status of the batteries:
= e V U (flat to full) 
= flashes: batteries almost flat
e V U flashes: charging
2Displaykeys
3 End call key and On/Off key
4 Talk key/Handsfree key
5Control key (u)
6Directory key (press down on the
control key)
7Key 1 
network mailbox
8Star key 
Ringers on/off (press and hold);
with an open connection: switch
from pulse dialling to tone dialling
(press briefly)
9Key 0/recall key
Consultation call (flash): press and
hold
10 Hash key
Keypad lock on/off (press and
hold); toggles between upper/low-
er case and digits; inserts a dialling
pause (press and hold)
11 Microphone
(handsfree mode A220only)
A120 A220
Display keys:
Pressing a key launches the function
that appears above that key in the
display.
Please note
New messages in the calls list/
network mailbox list (¢page 6)
are indicated in the display by the
message New messages.
Display Function when pressed
INT Call other registered
handsets ¢page 7.
MENU Open main/submenu
(see menu overview
¢page 11).
“ Go back one menu level.
UScroll up/down or adjust
volume with u.
T Move cursor to left/right
with u.
˜Backspace deletes one
character at a time.
OK Confirm menu function
or save entry.
1V
11.12. 11:56
INT MENU
1
2
3
4
5
6
7
8
9
10
11
The base station at a glance
Registration/paging key: 
Search for handsets (press
briefly, "Paging" ¢page 7)
Register handsets (press and
hold ¢page 7).
ECO DECT
During a call, the level of the handset's radio signal adjusts automatically
according to the distance between the handset and base station: the shorter
the distance, the lower the signal strength (radiation).
The handset’s radio signal is switched off when it is in standby mode. The base
station, however, maintains contact with the handset with fewer radio signals.
In addition, the base station radio signals are switched off when the No Radia-
tion setting is enabled.
MENU ¤u Settings ¤OK ¤u Base ¤OK ¤u ECO DECT ¤OK
¤No Radiation ¤OK (‰= radiation switched off, icon ½in the left-hand cor-
ner of the display)
Please note
◆All registered handsets must support this feature.
◆For quick connection of incoming calls the handset repeatedly switches to
reception mode for short periods. This increases energy consumption and
therefore reduces the standby and talk times.

2
Lombok / SEA - Taiwan en / A31008-M2401-Y701-1-7619 / Lombok.fm / 23.04.2012
Version 4, 16.09.2005
Safety precautions
First steps
Check the pack contents
One Gigaset A120/A220 base station, one mains adapter, one Gigaset handset, one phone cord, two batteries, one bat-
tery cover, one user guide.
If you have purchased a model with multiple handsets, the package should contain two batteries, a battery cover and
a charging cradle with mains adapter for each additional handset.
Setting up the base station and charging cradle (if included)
◆Set up the base station at a central location on a flat, non-slip surface in your house or apartment. You can also
mount the base station and charging cradle on the wall.
◆Pay attention to the range of the base station. This is up to 300 m in unobstructed outdoor areas and up to 50 m
inside buildings.
◆The base station and charging cradle are designed for use in enclosed dry rooms in a temperature range of +5 °C to
+45 °C.
◆Care: Wipe down the base station and handset with a damp cloth (no solvents) or an antistatic cloth. Never use a
dry cloth. This can cause static.
◆The phone's feet do not usually leave any marks on surfaces. However, due to the multitude of different varnishes
and polishes used on today's furnishings, the risk of marks on the surfaces cannot be completely ruled out.
◆Never expose the telephone to the influence of heat sources, direct sunlight or other electrical devices.
◆Protect your Gigaset from moisture, dust, corrosive liquids and vapours.
Read the safety precautions and the user guide before use.
Explain their content and the potential hazards associated with using the device to your children.
Use only the power adapter supplied, as indicated on the devices.
Use only rechargeable batteries that correspond to the specification (see "Technical Data"). Never use a conven-
tional (non-rechargeable) battery or other battery types as this could result in significant health risks and per-
sonal injury. Rechargeable batteries, which are noticeably damaged, must be replaced.
Using your telephone may affect nearby medical equipment. Be aware of the technical conditions in your partic-
ular environment, e.g., doctor's surgery.
If you use a medical device (e.g., a pacemaker), please contact the device manufacturer. They will be able to
advise you regarding the susceptibility of the device to external sources of high frequency energy (for the spec-
ifications of your Gigaset product see "Technical Data").
Do not hold the rear of the handset to your ear when it is ringing or when speaker mode is activated. Otherwise
you risk serious and permanent damage to your hearing.
Your Gigaset is compatible with the majority of digital hearing aids on the market. However, perfect function with
all hearing aids cannot be guaranteed.
The phone may cause interference in analogue hearing aids (humming or whistling) or cause them to overload.
If you require assistance, please contact the hearing aid supplier.
The devices are not splashproof. For this reason do not install them in a damp environment such as bathrooms
or shower rooms.
Do not use the devices in environments with a potential explosion hazard (e.g., paint shops).
If you give your Gigaset to a third party, make sure you also give them the user guide.
Remove faulty devices from use or have them repaired by our Service team, as these could interfere with other
wireless services.
◆The device cannot be used in the event of a power failure. It is also not possible to transmit emergency calls.
◆Emergency numbers cannot be dialled if the keypad lock is activated!

3
Lombok / SEA - Taiwan en / A31008-M2401-Y701-1-7619 / Lombok.fm / 23.04.2012
Version 4, 16.09.2005
Connecting the base station
¤First connect the mains adapter 1.
¤Then connect the telephone jack 2and insert the cables into the
cable ducts.
Please note:
◆The mains adapter must always be connected, as the phone will
not operate without mains connection.
◆Use only the mains adapter and phone cord supplied. Pin connec-
tions on telephone cables can vary.
Connecting the charging cradle (if included)
Setting up the handset for use
The display is protected by a plastic film. Please remove the protective film!
Inserting the batteries and closing the battery cover
Initial charging and discharging of the batteries
The correct charge status can only be displayed if the batteries are first fully charged and discharged.
Warning
Use only the rechargeable batteries recommended by Gigaset Communications GmbH (¢page 9), i.e. never use
conventional (non-rechargeable) batteries as this could result in significant health risks and personal injury. For
example, the batteries could explode. The phone could also malfunction or be damaged as a result of using batteries
that are not of the recommended type.
1
1
1
2
¤Connect the flat plug to the power
supply 1.
¤Plug the mains adapter into the plug
socket 2.
If you need to disconnect the plug
from the charging cradle, press the
release button 3and disconnect
the plug 4.
1
2
3
4
¤Insert the batteries with the polarity in
the correct direction.
The polarity is indicated in the battery
compartment.
¤First insert the battery cover at the top a.
¤Then press the cover buntil it clicks into place.
¤To reopen the battery cover, grip into the cavity on
the casing, then pull the battery cover in an upward
direction. a
b
6.5
h
¤Charge the handset in the base for 6.5 hours.
¤After charging, remove the handset from the base and only replace it
when the batteries are fully discharged.
Please note
The handset must only be placed in the designated Gigaset base or
charging cradle.

4
Lombok / SEA - Taiwan en / A31008-M2401-Y701-1-7619 / Lombok.fm / 23.04.2012
Version 4, 16.09.2005
Setting the date and time
Set the date and time so that the correct date and time can be assigned to incoming calls, and so that the alarm can be
used.
MENU ¤u Settings ¤OK ¤Date/Time ¤OK ¤Date ¤~(enter the day, month and year in 6-digit format)
¤OK ¤Time ¤~(enter hours and minutes in 4-digit format) ¤OK (display message: Saved)
¤a(press and hold to return to idle status)
When entering the time and date, you can move the position of an entry to the left or right by pressing the control key
uup or down.
Activating/deactivating the handset
Press and hold the akey to activate or deactivate the handset. If you place a deactivated handset in the base station
or charging cradle, it will automatically activate after approx. 30 seconds.
If you remove the handset from the base station/charging cradle, the display turns off briefly.
Making calls
Making external calls and ending calls
External calls are calls using the public telephone network.
~(Enter the phone number) ¤b.
The phone number is dialled. (Or you can first press and hold talk key b[dial tone] and then enter the number.) During
the call you can adjust the earpiece volume using tand set the volume with u.
End the call/cancel dialling: Press the end call key a.
You can automatically insert a network provider dialling code before any phone number (¢page 5).
Accepting a call
Press the talk key bto accept the call.
When Auto Answer is activated (see menu overview ¢page 11), simply remove the handset from the base station/
charging cradle.
Calling Line Identification
When you get a call, the caller's number will be displayed on your handset; the caller's name will be displayed if it is
stored in the directory.
Please note
◆The handset is pre-registered with the base. If you have purchased a model with multiple handsets, all hand-
sets will already be registered with the base. You do not need to register the handset again. The internal handset
number appears in the top left of the display, e.g. 1(¢page 1).
However, if a handset is not registered with the base (Register HS or Put into base is displayed), please register
the handset manually (¢page 7).
◆If you have purchased multiple devices, you can upgrade your Gigaset to a cordless PABX by registering all
A120/A220 handsets at the same base (¢page 7).
◆After the first battery charge and discharge, you may place your handset in the charger after every call.
◆Always repeat the charging and discharging procedure if you remove the batteries from the handset and rein-
sert them.
◆The batteries may warm up during charging. This is not dangerous.
◆After a while, the charge capacity of the batteries will decrease for technical reasons.
Please note
If your phone receives the date and time during calling line display (e.g., via your network provider, a router or PABXs),
you can specify whether this data should be copied to your phone:
¤Press the key sequence: MENU ¤P#Q5#MI
The following is displayed; 
the current setting flashes:
¤Press one of the following keys to specify, when this data should be copied to your phone:
QNever
or 1Once, in case the date/time is not set on your phone 
or 2Always
Your selection is displayed (e.g. 2):
¤Press the display key OK.
973 SET: [0]
973 SET: [2]

5
Lombok / SEA - Taiwan en / A31008-M2401-Y701-1-7619 / Lombok.fm / 23.04.2012
Version 4, 16.09.2005
Prerequisites:
1 You have asked your network provider for the caller's number (CLIP) to be displayed on your handset screen.
2 The caller has asked the network provider for his/her number to be identified (CLI).
External call appears in the display if you have not requested CLIP, Withheld appears if the caller has withheld CLI, and
Unavailable appears if CLI has not been requested.
Handsfree operation (Gigaset A220 only)
In handsfree mode, you activate the loudspeaker so that you can hear the caller without having to hold the handset to
your ear. During a call activate or deactivate handsfree mode by pressing the handsfree key d.
For instructions on adjusting the handsfree mode volume see menu overview ¢page 11.
Automatic network provider preselection
You can store a call-by-call number (preselection number), which is automatically placed in front of numbers when you
dial them. If, for example, you wish to make international calls via special network providers, you can save the relevant
dialling code here.
In the "With Preselect" list, specify the dialling codes or the first digits of the dialling codes that you wish to assign to the
preselection number.
In the "Without Presel" list, enter any exceptions to the "With Preselect" list.
Enter preselection number via menu (¢page 11). 
Permanently deactivating preselection: Delete the preselection number with ˜.
Temporarily cancelling preselection:
(press and hold) ¤MENU ¤qPreselect off ¤OK ¤~(enter number) or s(use number from directory)
¤The number is dialled without Preselection.
Using the directory and lists
Directory
To open the directory: press control key s.
You can save up to 50 (A120) or 80 (A220) phone numbers (max. 22 digits) with corresponding names (max. 14 charac-
ters). 
Enter letters/characters ¢page 9.
Storing the first number in the directory
s¤New Entry? ¤OK ¤~(enter number) ¤OK ¤~ (enter name) ¤OK
Storing further numbers in the directory
s¤MENU ¤New Entry ¤OK ¤~(enter number) ¤OK ¤~ (enter name) ¤OK
Selecting a directory entry
Open the directory with s.You have the following options:
◆Use uto scroll through the entries until the required name is selected.
◆Enter the first character of the name and scroll to the entry with u, if required.
Dialling with the directory
s¤u(select entry) ¤b
Using other functions
s¤u(select entry) ¤MENU
The following functions can be selected with u: New Entry/Show Number/Edit Entry/Use Number/Delete Entry/
Send Entry/Delete List/Send List/Shortcut
Sending the directory to another handset
Prerequisites:
◆The sending and receiving handsets must both be registered to the same base station.
◆The other handset and the base station can send and receive directory entries.
Example:
Presel. Number 0999
With Preselect 08
Without Presel 081
084
Phone number Dialled number
07112345 ¤07112345
08912345 ¤0999 08912345
08412345 ¤08412345
All numbers that start with 08,
except for 081 and 084, are
dialled with the preselection
number 0999.
b

6
Lombok / SEA - Taiwan en / A31008-M2401-Y701-1-7619 / Lombok.fm / 23.04.2012
Version 4, 16.09.2005
s¤u(select entry) ¤MENU ¤uSend Entry/Send List ¤OK
¤~(enter the internal number of the receiving handset) ¤OK
Using shortcut keys
You can assign directory entries to the keys 2–9:
s¤u(select entry) ¤MENU ¤uShortcut ¤OK
¤u(select key) ¤OK or ~(press the key you want to assign the entry to)
To dial, press and hold the required shortcut key.
Last number redial list
This list contains the ten last dialled numbers.
Dialling from the last number redial list
b(press briefly)¤u (select entry) ¤b
Managing entries in the last number redial list
b(press briefly)¤u (select entry) ¤MENU
The following functions can be selected with u: Use Number/Copy to Dir./Delete Entry/Delete List
Calls list/network mailbox list
Press MENU ¤Messages ¤OK, to open the list overview. If you have new messages, only lists with new messages are
displayed. Scroll through the lists by pressing u.
An advisory tone sounds as soon as a new entry appears in the calls list/network mailbox list. New messages appears
in the display.
Calls list
Prerequisites: CLIP (¢page 4)
Depending on the type of list set, the calls list contains (¢page 11) answered calls and missed calls.
Depending on the type of list set, all numbers of the last 25 incoming calls are saved or just the missed calls are saved.
Open the calls list
MENU ¤Messages ¤OK ¤u CallsList
The calls list is displayed as follows:
Number of new entries + number of old, read entries 
Press OK to open the list.
The last incoming call is displayed. If necessary, use uto select another entry.
Using other functions
u(select entry) ¤MENU
The following functions can be selected with u: Delete Entry/Copy to Dir./Date/Time/Status/Delete List
Calling back a caller from the calls list
MENU ¤Messages ¤CallsList 01+02 ¤OK ¤u(select entry) ¤b
Network mailbox list
You can use these lists to listen to messages on the network mailbox (¢page 6).
Setting a different language
You can change the language for the voice prompt and default announcement.
MENU ¤u Answer Machine ¤OK ¤u Language ¤OK ¤u(select language) ¤OK
Network mailbox
The network mailbox is the answering machine in your provider's telephone network. More information is available from
your provider. You cannot use the network mailbox unless you have requested it from your provider.
In order to use the network mailbox quickly and easily via the network mailbox list (¢page 6), the menu (¢page 11)
and to use fast access via key 1 (¢page 1), you will need to enter the number in your phone:
MENU ¤u Answer Machine ¤OK ¤u Net Mailbox ¤~(enter number) ¤OK
Please note
If calls are saved in the network mailbox, you will receive a message if the appropriate settings have been made
(depending on your network provider).
CallsList 01+02

7
Lombok / SEA - Taiwan en / A31008-M2401-Y701-1-7619 / Lombok.fm / 23.04.2012
Version 4, 16.09.2005
Locating a handset ("Paging")
You can locate your handset using the base.
¤Briefly press the registration/paging key on the base (¢page 1).
All handsets will ring at the same time ("paging"), even if the ringers are switched off.
Ending paging: Briefly press the registration/paging key on the base (¢page 1) or press the talk key bor the end call
key aon the handset.
Registering handsets manually
You can register up to four handsets on your base station. Each additional handset must be registered on the base sta-
tion in order for it to work properly!
Registration takes approx. 1 minute. Handsets are assigned the lowest available internal number (1-4). If the internal
numbers 1–4 are already assigned to other devices, the number 4 will be overwritten.
De-registering handsets
You can de-register all other registered handsets from each of the registered Gigaset handsets.
MENU ¤u Settings ¤OK ¤u Handset ¤OK ¤u De-register HS ¤u Select the internal party you wish to de-
register. The handset you are currently using is indicated by <.¤OK ¤Enter the base system PIN (default setting: 0000)
¤OK
Using multiple handsets
Making internal calls
Internal calls are free calls to other handsets that are registered to the same base station.
2 handsets are registered
Press the display key INT, the other handset is called.
More than 2 handsets are registered
Calling a specific handset
INT ¤~(1...4, enter internal number of the handset) or
INT ¤u(Select the internal party) ¤OK or b¤the handset is called
Calling all handsets ("group call")
INT ¤Por INT ¤u Call all ¤OK or b¤all handsets are called
When a participant answers you can speak to them. To end the call, press a.
Internal consultation call/connecting a call
You are in conversation with an external participant. Press the INT display key and call one or all handsets. The external
participant hears the hold music. When the internal participant answers: If necessary, announce the external call.
Either press the end call key a(the call is transferred to the internal participant), or
press the display key ”. You are reconnected with the external participant.
When transferring a call you can also press the end call key abefore the internal participant answers.
Listening in to an external call
You are conducting an external call. An internal participant can listen in on this call and take part in the conversation
(conference). Prerequisite: The Listening in function must be activated.
Activating/deactivating listening in
MENU ¤u Settings ¤OK ¤u Base ¤OK ¤u Listening in ¤OK (‰= on)
1) On the handset
MENU ¤u Settings ¤OK ¤u Handset ¤OK ¤u Register HS ¤Enter the base system PIN (default setting: 0000)
¤OK ¤Registering is displayed.
2) On the base
Within 60 seconds, press and hold the registration/paging key on the base (¢page 1) for approx. 3 seconds.

8
Lombok / SEA - Taiwan en / A31008-M2401-Y701-1-7619 / Lombok.fm / 23.04.2012
Version 4, 16.09.2005
Internal listening in (conference)
You want to listen in to an existing external call. Press and hold the bkey. You can listen in to the call. All participants
hear a signal tone.
To end: press the end call key a. All participants hear a signal tone.
If the first internal participant presses the end call key a, the handset that has "listened in" remains connected to the
external participant.
Setting the alarm clock
Activating/deactivating the alarm clock
MENU ¤u Alarm Clock ¤OK ¤Activation ¤OK (‰= on)
When activated: ¤~ (Set the wake-up time) ¤OK
When the alarm clock rings, press any key to switch it off for 24 hours. If the alarm clock is set, the wake-up icon lwill
appear on the screen and the wake-up time will be displayed instead of the date.
Setting the wake-up time
MENU ¤u Alarm Clock ¤OK ¤u Wake-up time ¤OK
Enter the wake-up time in hours and minutes, then press OK.
Phone settings
For details on how to make audio settings, see menu overview ¢page 11.
For details on how to set the system PIN on the base station, see the menu overview ¢page 11.
Changing the display language
MENU ¤u Settings ¤OK ¤u Handset ¤OK ¤u Language ¤OK ¤u (select language) ¤OK
The current language is indicated by ‰.
If you accidentally choose a language you do not understand:
MENU ¤521 (press the keys one after the other) ¤u(select language) ¤OK
Activating/deactivating music on hold
You can make it so that your external participant hears music in case of internal recall and during call transfer.
MENU ¤P#Q5#1M ¤The number for the current setting flashes: 
0= off; 1= on ¤enter number ¤OK.
Repeater mode
With a repeater you can increase the range of your base station. You will need to activate repeater mode (¢page 11).
Repeater mode and No Radiation mode (¢page 11) cancel each other out.
Resetting the handset
You can reset individual settings and changes that you have made. Entries in the directory, the calls list and the handset's
registration to the base station will be retained.
MENU ¤u Settings ¤OK ¤u Handset ¤OK ¤u Reset Handset ¤OK ¤Reset? ¤OK
Cancel the reset with a.
Restoring the base station
When restoring factory settings the No Radiation mode is deactivated, individual settings are reset and all lists are
deleted.
The date and time are retained.
Resetting the base via the menu
Handsets are still registered, the system PIN is not reset.
MENU ¤u Settings ¤OK ¤u Base ¤OK ¤u Base Reset ¤OK ¤Reset? ¤OK
Resetting the base using the key on the base
All handsets are de-registered and the system PIN is reset to the original code 0000.
Carry out the following steps: Remove the mains cable from the base. Hold down the registration/paging key on the
base (¢page 1) and reconnect the power cable to the base at the same time. Hold the key down for at least 5 seconds.

9
Lombok / SEA - Taiwan en / A31008-M2401-Y701-1-7619 / Lombok.fm / 23.04.2012
Version 4, 16.09.2005
Operating the base station on the PABX/router
Operating on the router
When operating the Gigaset on an analogue port of a router you can reduce problems with echoes by activating the
Echo mode (¢page 11). If you have no problems with echoes, this function should be deactivated.
Operating on the PABX
The following settings are only necessary when your PABX requires them; see the user guide for your PABX.
When entering the digits, enter them slowly one after the other.
Changing the dialling mode
MENU ¤P#Q5#1N ¤The number for the set dialling mode flashes: 0 = touch tone dialling (DTMF);
1= dial pulsing (DP) ¤enter number ¤OK.
Setting recall
MENU ¤P#Q5#1Q ¤The number for the current recall flashes: 0= 80 ms; 1= 100 ms; 2= 120 ms;
3= 400 ms; 4= 250 ms; 5= 300 ms; 6 = 600 ms; 7= 800 ms ¤enter number ¤OK.
Changing pause after line seizure
You can set the length of the pause inserted between pressing the talk key and sending the phone number.
MENU ¤P#Q5#1L ¤The number for the current pause length flashes: 1= 1 sec.; 2= 3 sec.; 3= 7 sec.
¤enter number ¤OK.
Changing the pause after the recall key
MENU ¤P#Q5#12 ¤The number for the current pause length flashes: 1= 800 ms; 2= 1600 ms;
3 = 3200 ms ¤enter number ¤OK.
Appendix
Entering letters/characters
Specifications
Batteries
Technology: Nickel-metal-hydride (NiMH); Size: AAA (Micro, HR03); Voltage: 1.2 V; Capacity: 450 - 1000 mAh
General specifications
Standard characters
Press the relevant key the number
of times indicated.
Briefly press the hash key #to
switch from "Abc" to "123" mode,
from "123" to "abc" mode and from
"abc" to "Abc" mode.
DECT standard is supported
GAP standard is supported
Range up to 300 m outdoors, up to 50 m indoors
Base station power supply 230 V ~/50 Hz
Environmental conditions in operation +5 °C to +45 °C, 20% to 75% relative humidity
Base station power consumption A120/A220
In standby mode
– Handset in base station
– Handset outside base station ca. 1.0 W ca. 0.8 W
During a call ca. 1.0 W
b
1) Space
1x 2x 3x 4x 5x 6x 7x 8x 9x 10x 11x 12x 13x 14x 15x
11£$¥¤
2abc2äáàâãç
Idef3ëéèê
4ghi4ïíìî
5jkl5
Lmno6öñóòôõ
Mpqr s 7ß
Ntuv8üúùû
Owx y z 9 ÿ ýæø å
Q.,?!0+-:¿¡"’;_
P*/()<=>%
##@\ &§
1)

10
Lombok / SEA - Taiwan en / A31008-M2401-Y701-1-7619 / Lombok.fm / 23.04.2012
Version 4, 16.09.2005
Questions and answers
If you have any queries about the use of your telephone, visit our website at www.gigaset.com/service 
for 24-hour support. The table below contains a list of common problems and possible solutions.
Contact with liquid
If the handset should come into contact with liquid:
◆Switch the handset off and remove the batteries immediately.
◆Allow the liquid to drain from the handset.
◆Pat all parts dry, then with the battery compartment open and the keypad facing down place the handset in a dry,
warm place for at least 72 hours (not in a microwave, oven etc.).
◆Do not switch on the handset again until it is completely dry.
When it has fully dried out, you will normally be able to use it again.
Service (Customer Care)
We offer you support that is fast and tailored to your specific needs!
Our Online Support on the Internet: www.gigaset.com/service
For more information on aftersales service, please refer to your local warranty card. In some countries repair and replace
services are impossible where the products are not sold through our authorised dealers.
Environment
Our environmental mission statement
We, Gigaset Communications GmbH, bear social responsibility and are actively committed to a better world. Our ideas,
technologies and actions serve people, society and the environment. The aim of our global activity is to secure sustain-
able life resources for humanity. We are committed to a responsibility for our products that comprises their entire life
cycle. The environmental impact of products, including their manufacture, procurement, distribution, utilisation, service
and disposal, are already evaluated during product and process design.
Further information on environmentally friendly products and processes is available on the Internet at
www.gigaset.com.
Environmental management system
Gigaset Communications GmbH is certified pursuant to the international standards ISO 14001 and ISO 9001.
ISO 14001 (Environment): Certified since September 2007 by TüV SÜD Management Service GmbH.
ISO 9001 (Quality): Certified since 17/02/1994 by TüV SÜD Management Service GmbH.
Disposal
Batteries should not be disposed of in general household waste. Observe the local waste disposal regulations, details of
which can be obtained from your local authority.
All electrical and electronic equipment must be disposed of separately from general household waste using the sites
designated by local authorities.
If a product displays this symbol of a crossed-out rubbish bin, the product is subject to European Directive
2002/96/EC.
The appropriate disposal and separate collection of used equipment serve to prevent potential harm to the
environment and to health. They are a precondition for the re-use and recycling of used electrical and elec-
tronic equipment. For further information on disposing of your used equipment, please contact your local authority or
your refuse collection service.
Problem Cause Solution
Nothing appears in
thedisplay. The handset is not switched on.
The batteries are flat.
Press the end call key afor approx. 5 seconds
or place the handset in the base station.
Charge or replace the batteries.
No wireless connection
to the base station,
Base flashes in the display.
The handset is outside the range of
the base station.
The handset is not registered.
The base station is not turned on.
Move the handset closer to the base station.
Register the handset ¢page 7.
Check the mains connector on the base station
¢page 3.
You cannot hear a ringer/
dialling tone from the fixed
line network.
The phone cord supplied has not
been used or has been replaced by a
new cord with the wrong jack connec-
tions.
Please always use the phone cord supplied or
ensure that the pin connections are correct
when purchasing from a retailer: 3-4 assignment
of telephone leads/EURO CTR37.
Error tone sounds after sys-
tem PIN prompt.
PIN forgotten.
The system PIN you have entered is
incorrect. Reset the system PIN to the default 0000
¢page 8.
All handsets are de-registered. All settings are
reset. All lists are deleted.
!

11
Lombok / SEA - Taiwan en / A31008-M2401-Y701-1-7619 / Lombok.fm / 23.04.2012
Version 4, 16.09.2005
Menu overview
Your phone has an extensive range of features. These are offered in the form of menus.
To select a function while the phone is in idle status, press MENU (open menu), use the control key uto scroll to the
function you require and press OK to confirm.
To return to idle status: press and hold the akey.
Not all of the functions described in this user guide are available in all countries.
Messages ¢page 6
Alarm Clock
Activation ¢page 8
Wake-up time ¢page 8
Audio Settings
Handset Volume 
(Gigaset A120) Can be set to one of 5 levels.
Handset Volume
(Gigaset A220) Earpiece/Speaker
Ringer Volume 5 levels + "crescendo" available.
Ringer Melody External Calls/Internal Calls/Alarm Clock
AdvisoryTones On/off
Battery Low On/off
Ring Tones On/off
Answer Machine
Play Messages Playing back messages on the network mailbox ¢page 6.
Net Mailbox ¢page 6
Language * ¢page 6
Settings
Date/Time ¢page 4
Handset Language ¢page 8
Auto Answer ¢page 4
Register HS ¢page 7
De-register HS ¢page 7
Reset Handset ¢page 8
Base Call list type Missed Calls/All Calls ¢page 6
System PIN Change System-PIN (default: 0000)
Base Reset ¢page 8
Additional Repeater ¢page 8
Echo mode see "Operating on the router" ¢page 9
ECO DECT
¢page 1 No Radiation on/off
Listening in ¢page 7
Preselection Presel. Number/With Preselect/Without Presel ¢page 5

12
Lombok / SEA - Taiwan en / A31008-M2401-Y701-1-7619 / Lombok.fm / 23.04.2012
Version 4, 16.09.2005
© Gigaset Communications GmbH 2012
Subject to availability.
All rights reserved. Rights of modification reserved.
www.gigaset.com
This user guide is made from 100% recycled paper.
Issued by
Gigaset Communications GmbH
Frankenstr. 2a
D-46395 Bocholt
Version: 20.04.2012

Gigaset Communications GmbH
Frankenstr. 2a, D-46395 Bocholt
Subject to availability.
www.gigaset.com
© Gigaset Communications GmbH 2012
All rights reserved.
