Siemens POS8.4420/109 Operator's manual

POS8.4420/109; POS8.4440/109
Room operator units
Basic Documentation
A6V11471220_en--_e
2021-09-06

2 | 70
A6V11471220_en--_e
Table of Contents
1 About this document ....................................................................................3
1.1 Revision history ...............................................................................................3
1.2 Before you start ...............................................................................................3
1.3 Reference documents .....................................................................................4
2 Product overview ..........................................................................................5
2.1 Type summary.................................................................................................5
2.1.1 Equipment combinations .................................................................5
2.2 Features ..........................................................................................................5
2.3 System topology..............................................................................................5
2.4 Mechanical design...........................................................................................6
2.5 Diagrams .........................................................................................................6
2.5.1 Connection terminals .......................................................................6
2.5.2 Connection diagrams .......................................................................7
2.6 Dimensions......................................................................................................8
3 Important information on safety and disposal ...........................................9
3.1 General regulations .........................................................................................9
3.2 Device-specific regulations..............................................................................9
3.3 Notes on EMC optimization.............................................................................9
3.4 Disposal.........................................................................................................10
4 Mounting and installation...........................................................................11
4.1 Preparation....................................................................................................11
4.2 Mounting instructions ....................................................................................12
5 Engineering..................................................................................................14
6 Commissioning ...........................................................................................36
6.1 Programming pin and service LED ...............................................................36
6.1.1 Addressing .....................................................................................36
6.1.2 Connection test ..............................................................................36
6.1.3 Reset to factory setting ..................................................................37
7 Technical data .............................................................................................38
8 Functions .....................................................................................................40
9 Operation .....................................................................................................42
9.1 Ventilation page.............................................................................................42
9.2 Temperature page.........................................................................................43
9.3 Domestic hot water page...............................................................................44
9.4 Notification page............................................................................................44
9.5 Clock page ....................................................................................................48
9.6 Scheduler settings.........................................................................................48
9.7 Standard and expert settings ........................................................................49
9.8 Standby page ................................................................................................51
10 Appendix ......................................................................................................52
10.1 Parameters....................................................................................................52
10.2 Object list.......................................................................................................52

About this document
Revision history
1
A6V11471220_en--_e
3 | 70
1 About this document
1.1 Revision history
Revision
Date
Changes
Section
e
Sep 2021
Added info for
blinking screen
Chapter 5 and
Chapter 9
d
May 2021
Added info for
POS8.4440/109
about humidity
Chapter 7
c
October 2020
Canceled
POS3.3515/100
Chapter 2.1.1
b
August, 2019
Added chapter
“Engineering” and
“Object list”
Chapter 5 and
Chapter 10
a
November, 2018
First edition
All
1.2 Before you start
The table below lists the third-party trademarks used in this document and their
legal owners. The use of trademarks is subject to international and domestic
provisions of the law.
Trademarks
Legal owner
KNX®
KNX Association, B - 1831 Brussels-Diegem Belgium
http://www.knx.org/
All product names listed in the table are registered (®) or not registered (™)
trademarks of the owner listed in the table. We forgo the labeling (e.g. using the
symbols ® and ™) of trademarks for the purposes of legibility based on the
reference in this section.
This document may be duplicated and distributed only with the express permission
of Siemens, and may be passed on only to authorized persons or companies with
the required technical knowledge.
These documents were prepared with great care.
●The contents of all documents are checked at regular intervals.
●All necessary corrections are included in subsequent versions.
●Documents are automatically amended as a consequence of modifications and
corrections to the products described.
Please make sure that you are aware of the latest document revision date.
If you find any lack of clarity while using this document, or if you have any criticisms
or suggestions, please contact the nearest branch office. Addresses for Siemens
regional companies are available at www.siemens.com/sbt.
Before using our products, it is important that you read the documents supplied
with or ordered at the same time as the products (equipment, applications, tools
etc.) carefully and in full.
We assume that persons using our products and documents are authorized and
properly trained and have the requisite technical knowledge to use our products as
intended.
Additional information on products and applications is available:
Trademarks
Copyright
Quality assurance
Document use/ request
to the reader

About this document
Reference documents
1
4 | 70
A6V11471220_en--_e
●On the intranet (for Siemens employees only) at
https://workspace.sbt.siemens.com/content/00001123/default.aspx
●At your next Siemens branch office www.siemens.com/sbt or at your system
suppliers.
●From the support team in the headquarters fieldsupport-
[email protected]om if no local contact is available.
Siemens assumes no liability to the extent allowed under the law for any losses
resulting from a failure to comply with the aforementioned points or for the
improper compliance of the same.
1.3 Reference documents
Ref.
Document title
Document number
[1]
Data sheet
A6V11519429
[2]
Mounting instructions
A6V10733764

Product overview
Type summary
2
A6V11471220_en--_e
5 | 70
2 Product overview
2.1 Type summary
Product
number
Stock number
Feature
LCD
display
with
backlight
Minimal
order
size
Temperature
sensor
Humidity
sensor
POS8.4420/109
S55625-H422-A100
Yes
No
Yes
20
POS8.4440/109
S55625-H444-A100
Yes
Yes
Yes
20
2.1.1 Equipment combinations
Type
Type no.
Document ID
Description
Controller
POS3.5715/100
A6V11417931
For HVAC controlling,
switching and monitoring
functions
2.2 Features
●Measurement of room temperature (POS8.4420/109)
●Measurement of room temperature and humidity (POS8.4440/109)
●Keys to adjust the room temperature setpoint, ventilation, domestic hot water,
scheduler settings depending on the controller application
●LCD display of room temperature, operating modes, humidity (only for
POS8.4440/109), scheduler, notification, and clock setting
●Operation with 8 pushbuttons
●2-wire interface to the controller through KNX PL-Link
●Power supply of the room operator unit over KNX PL-Link
●LCD display with backlight
2.3 System topology
A6V11471220Z01
QBM97
POS9
POS8.44 QMX3.P
POL903.00
POS3.xx15

Product overview
Mechanical design
2
6 | 70
A6V11471220_en--_e
2.4 Mechanical design
1
Gasket for panel mounting
4
KNX PL-Link bus connector
2
Base plate with
●screw holes for all common conduit
boxes
●guide channels for wiring from center,
up, or bottom
5
Jack connector for tool connection
3
Room operator unit
2.5 Diagrams
2.5.1 Connection terminals
KNX PL-Link plug
Connector
Pin
Description
+
KNX PL-Link (positive)
-
KNX PL-Link (negative)
To find the location of the KNX PL-Link plug, refer to Mechanical design
NOTICE! Users can choose either pair of the pins to connect.
NOTICE
Wires are NOT interchangeable!
The device is protected against faulty wiring, but communications does not work
on interchanged wires. The KNX / KNX PL-Link bus MUST NOT be connected to
the tool plug, only the tool.

Product overview
Diagrams
2
A6V11471220_en--_e
7 | 70
Tool plug
Connector
Pin
Description
+
KNX PL-Link (positive)
-
KNX PL-Link (negative)
2.5.2 Connection diagrams
Operation
R1
The device - room operating unit (POS8.44xx)
N1
The controller - room automation station
Twisted pair

Product overview
Dimensions
2
8 | 70
A6V11471220_en--_e
2.6 Dimensions
Unit: mm
Fig. 1: Dimensions for housing
Fig. 2: Dimensions for mounting

Important information on safety and disposal
General regulations
3
A6V11471220_en--_e
9 | 70
3 Important information on safety and
disposal
This section explains general and system-specific regulations for mains and
operating voltages. It includes important information for your safety and the safety
of the entire plant.
3.1 General regulations
Comply with the following general regulations during engineering and execution:
●Electrical and mains power regulations for the given country.
●Other applicable, national regulations.
●Building installation regulations for the given country.
●Regulations of the utility company.
●Diagrams, cable lists, dispositions, specifications, and orders by the customer
or authorized engineering office.
●Third-party regulations, for example, by the general contractor or building
owner.
The electrical safety for building automation and control systems by Siemens is
essentially based on safely separating low voltage from mains voltage.
3.2 Device-specific regulations
Note permissible line lengths and topologies when planning and installing
controllers and field devices featuring KNX bus connection. Make sure the bus
supply complies with the KNX standard.
The device is maintenance free. Only the manufacturer can maintain the device.
3.3 Notes on EMC optimization
When setting up cable ducts, separate strongly interfering cables from susceptible
entities.
●Interfering cables: Motor cables especially from motors supplied by inverters,
energy-supplying cables.
●Susceptible entities: Control cables, low voltage cables, interface cables, LAN
cables, digital and analog signal cables.
●Both types of cables can be in the same cable duct, but in separate
compartments.
●If no three-sided, closed duct with separating wall is available, the interfering
cables must be separated by at least 150 mm from the others or placed in
separate ducts.
●Crossings of strongly interfering cables with possibly susceptible entities must
be at a right angle.
●In rare cases, signal and interfering power cables may be run in parallel,
resulting in a high interference risk.
It is recommended to use unscreened cables. Comply with the manufacturer's
installation recommendations for selecting unscreened cables. In general,
unshielded twisted pair cables have sufficient EMC properties for technical
building applications (including data applications) and do not require coupling to
surrounding earth.
KNX bus supply
Maintenance
Cable ducts
Cable types
Separate cables
Unscreened cables

Important information on safety and disposal
Disposal
3
10 | 70
A6V11471220_en--_e
3.4 Disposal
The device is considered an electronic device for disposal in
accordance with European Directive and may not be disposed of as
domestic waste.
●Use only designated channels for disposing the devices.
●Comply with all local and currently applicable laws and
regulations.

Mounting and installation
Preparation
4
A6V11471220_en--_e
11 | 70
4 Mounting and installation
Comply with the following notes as well as the Mounting instructions
(A6V10733764) to mount the room operation unit.
4.1 Preparation
Check the package contents for visible signs of transport damage and for
completeness.
Do not install parts damaged during shipment. Contact your Siemens
representative in the event of damaged parts.
Note the information in the data sheet of these operating instructions before
installing the device:
●Climatic ambient conditions
●Protection classes
●The devices are suitable for wall mounting and panel mounting.
●Recommended height: 1.50 m above the floor.
●Do not mount the devices in recesses, shelves, behind curtains or doors, or
above or near heat sources.
●Avoid direct solar radiation and drafts.
●Seal the conduit box or the installation tube if any, as air currents can affect
sensor readings.
●Adhere to allowed ambient conditions.
Check package contents
Check operating
conditions
Check locations

Mounting and installation
Mounting instructions
4
12 | 70
A6V11471220_en--_e
4.2 Mounting instructions
●Mounting instructions A6V10733764 are enclosed with the devices.
●Remove the breakout on the housing before putting the cable into the gaining
channel.
●If 4-wire cables are used for daisy chain wiring, remove the cable coating, as it
will not fit in the gaining channel.
●Keep a distance of at least 20 mm from the base plate to any object above the
base plate such as cable ducts to snap the device cover onto the base plate.
Mounting instructions
Wall mounting
Cable ducts on the wall
Panel mounting

Mounting and installation
Mounting instructions
4
A6V11471220_en--_e
13 | 70
Dismounting/service

Engineering
5
14 | 70
A6V11471220_en--_e
5 Engineering
Management Data
Process Data
UHD (User HVAC Display)
Configuration Data
ObjectType
OutsideSensorZone Value (U8Z8)
390
TempOutsideEff
IR.ind
TempOutsideEff
TempRoomEff

Engineering
5
A6V11471220_en--_e
15 | 70
Parameters required to realize the full function:
Management Data
Process Data
UHD (User HVAC Display)
Configuration Data
ObjectType
BuildingZone
Room
Subzone Value (U8Z8)
Value (U8Z8)
Value (U8Z8)
390
TempRoomEff
IR.ind
Management Data
Process Data
UHD (User HVAC Display)
Configuration Data
ObjectType
BuildingZone
Room
Subzone Value (U8Z8)
Value (U8Z8)
Value (U8Z8)
390
HumRelRoomEff
IR.ind
HumRelRoomEff

Engineering
5
16 | 70
A6V11471220_en--_e
Property
name
Property
identifier
Property
access
LTE service
Description
KNX
Datapoint
Type (DPT)
Interface
Object Type
1
R
---
390 = UHD
DPT_PropData
Type (DPT_ID
= 7.010)
TempOutsideEf
f
OTS.155
----
IR.ind
Process Data
Input
DPT_TempHV
ACAbs_Z
local copy *)
155
R
---
Diagnostic
Value
TempRoomEff
RTS.155
----
IR.ind
Process Data
Input
DPT_TempHV
ACAbs_Z
local copy *)
157
R
---
Diagnostic
Value
HumRelRoomE
ff
RRHS.155
----
IR.ind
Process Data
Input
DPT_RelValue
_Z
local copy *)
172
R
---
Diagnostic
Value
BuildingZone
101
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Room
102
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Subzone
103
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
OutsideSensor
Zone
104
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Parameters required to realize the full function:
SARB HVAC Room Unit
User HVAC RoomSettings UHRS
RoomGroup 24.6.1
HVACModeUserLimit
HVACModeUser
HVACModeUserEff
Management Data
UHRS Configuration Data
UHRS Discovery & Diagnostic Data
Geographical Zone 24.6.1
HVACModeUserLocked
User HVAC Display UHD
RoomGroup 24.6.1
HVACModeEff
Management Data
UHD Configuration Data
UHD Discovery & Diagnostic Data
Geographical Zone 24.6.1
TxtRefHVACModeEffWhy TxtRef [1..n]
HVACModeEffWhy
LTE IR (Auto)
LTE IR (Auto)
LTE W (false)
LTE W (Auto;
Comfort; Eco)
LTE IR(PreComf)
LTE IR (16)
….. …..
….. …..
Device Configuration
Data TxtCatalog
-…
- Life Safety
- Equipm Protect
-…
-…
- Manual Control
- Scheduler
-...
Setting of HVAC Mode

Engineering
5
A6V11471220_en--_e
17 | 70
Property
name
Property
identifier
Property
access
LTE service
Description
KNX
Datapoint
Type (DPT)
Interface
Object Type
1
R
---
384 = UHRS
DPT_PropData
Type (DPT_ID
= 7.010)
HVACModeUs
er
55
R
IR.req
Process Data
Output
DPT_HVACMo
de_Z
HVACModeUs
erLocked
156
R/W
W.ind
Process Data
Input
DPT_Bool
HVACModeUs
erEff
RSMHD.57
----
IR.ind
Process Data
Input
DPT_HVACMo
de_Z
local copy *)
157
R
---
Diagnostic
Value
BuildingZone
101
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Room
102
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Subzone
103
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Property
name
Property
identifier
Property
access
LTE service
Description
KNX
Datapoint
Type (DPT)
Interface
Object Type
1
R
---
390 = UHD
DPT_PropData
Type (DPT_ID
= 7.010)
HVACModeEff
RSMHD.51
----
IR.ind
Process Data
Input
DPT_HVACMo
de_Z
local copy *)
163
R
---
Diagnostic
Value
BuildingZone
101
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Room
102
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Subzone
103
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Unoccupied mode

Engineering
5
18 | 70
A6V11471220_en--_e
Parameters required to realize the full function:
Property
name
Property
identifier
Property
access
LTE service
Description
KNX
Datapoint
Type (DPT)
Interface
Object Type
1
R
---
391 = UPS
DPT_PropData
Type
(DPT_ID =
7.010)
PresenceStatu
s
51
R/W
IR.req
Process Data
Output
DPT_Occupan
cy
PresenceStatu
sLocked
155
R/W
W.ind
Process Data
Input
DPT_Bool
PresenceStatu
sEff
UPS.156
----
IR.ind
Process Data
Input
DPT_Occupan
cy
local copy *)
201
R
---
Diagnostic
Value
BuildingZone
101
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Room
102
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Building Automation Device
BA-Model
PL-Link Data Acquisition
Management Data
UPS (User Presence Switch)
Configuration Data
ObjectType
BuildingZone
Room
Subzone Value (U8Z8)
Value (U8Z8)
Value (U8Z8)
391
PresenceStatusLocked
PresenceStatusEffWhy
PresenceStatus
PresenceStatusEff IR.req
IR.ind
BA-Binary-Calculated-Value
Transforms
Binary transform BA → KNX
f(PresentValue)
Inactive-Text unoccupied
Active-Text
Tracking-Value 1
I/O-Address PL-1:PR=UPS.
PresenceStatus;
GEO=24.6.1;
BA-Binary-Process-Value
-
-
-
-
1
2
3
4
5
6
7
-
-
-
Priority-Array
-
-
-
-
8
9
10
11
12
13
14
-
-
-
15
16 1
-
Status-Flags:
Overridden
Out-of-Service
Fault
In-Alarm
Relinquish-Default
Inactive-Text unoccupied
Active-Text
Present-Value 1
Reliability No-fault
I/O-Address PL-1:PR=UPS.
PresenceStatusEff;
GEO=24.6.1;
0
Present-Priority 16
Out-of-Service false
false
false
false
false
Complex transform BA -> KNX
f(Present-Priority) or f(Why-Indication)
Binary transform KNX → BA
f(PresenceStatus);
Status-Flags:
Overridden
Out-of-Service
Fault
In-Alarm
Reliability No-fault
Out-of-Service false
false
false
false
false
Update-Count 267
Event-State normal
PrioThreshPresenceStatusLocked Value (N8Z8)
W.req
IR.req
Transform:
if PresPrioBA < PrioThreshPresenceStatusLocked
PresenceStatusLocked := true
else
PresenceStatusLocked := false
endif
Event-State normal
occupied
occupied
Why-Indication[16] x
Complex transform BA -> KNX
f(Present-Priority, PrioThreshPresenceStatusLocked)
Transform: dependent on support by
firmware and control progs:
PresenceStatusEffWhy contains either the
numerical value of Present-Priority or
(Why-Indication + offset)
Present-Value 1

Engineering
5
A6V11471220_en--_e
19 | 70
Parameters required to realize the full function:
Building Automation Device
PL-Link Data Acquisition Fan Speed Setpoint Manager FSSM
FSSM Configuration Data
Geographical Zone 24.6.1
PrioThreshFanSpeedUserLocked 7
Room Group 24.6.1
LTE IR (Auto)
LTE IR (33.3%)
LTE IR (Auto)
LTE W (false)
LTE IR (8)
LTE W (0%)
BA-Model
Room Control Room 1
Analog-Proc-Value FanSpeedEff
represent
FanSpeedEff
FanSpeedUserEff
FanSpeedUserLocked
FanSpeedEffWhy
FanSpeedUserMinIN
FanSpeedUser
PrioDirectControl 8
LTE W (100%)
FanSpeedUserMaxIN
PL-Link RU-B Room Unit
User FanSpeed Settings UFS
RoomGroup 24.6.1
FanSpeedUserMinIN
FanSpeedUser
FanSpeedUserEff
UFS Configuration Data
UFS Discovery & Diagnostic Data
FanSpeedUserLocked
User HVAC Display UHD
RoomGroup 24.6.1
FanSpeedEff
Management Data
UHD Discovery & Diagnostic Data
FanSpeedEffWhy
LTE IR (...)
FanSpeedUserMaxIN
represent
Config-Property-Client Property_W (3)
TmpFanModeRemainTime
Management Data
FanBoostReq
KitchenHoodReq
FirePlaceReq
LTE IR (Trigger)
LTE IR (Trigger)
LTE IR (Trigger)
TmpFanModeRemainTime
LTE IR (15min)
TmpFanMode
LTE IR (FirePlace)
UFS Configuration Data
[cASA-4.2-100-N]
new optional UFS
output process signals
for temporary HRV fan
operation
}{
FanBoostReq
ResetTmpFanReq LTE IR (Trigger)
LTE IR (Trigger)
FirePlaceReq
LTE IR (Trigger)
KitchenHoodReq
LTE IR (Trigger)
ResetTmpFanReq
LTE IR (Trigger)
LTE IR (Auto) LTE IR (33.3%)
[cASA-4.2-100-N]
new optional UHD
input process signals
for temporary HRV fan
operation
NumberOfSteps
LTE IR (15min)
LTE IR (Auto)
LTE W (false)
TmpFanMode LTE IR (FirePlace)
[cASA-4.2-100-N]
new optional FSSM
input process signals
for temporary HRV fan
operation
{}[cASA-4.2-100-N]
new optional FSSM
output process signals
for temporary HRV fan
operation
represent
Analog-Calc-Value ManualFanSpeed
Binary-Calc-Value ResetTmpFanRequest
Binary-Calc-Value KitchenHoodRequest
Binary-Calc-Value FirePlaceRequest
Binary-Calc-Value FanBoostRequest
PL-1:PR=FSSM.
FanBoostReq;
GEO=24.6.1;
I/O-Address
Present-Value Active
Update-Count n
Binary-Calc-Value ManualFanMode
Multistate-Proc-Value TemporaryFanMode
PL-1:PR=FSSM.
TmpFanMode;
GEO=24.6.1;
I/O-Address
Present-Value FirePlaceMode
None
FanBoostMode
FirePlaceMode
KitchenHoodMode
State-Text
Analog-Proc-Value TemporaryFanRemainTime
PL-1:PR=FSSM.
TmpFanMode
RemainTime;
GEO=24.6.1;
I/O-Address
Present-Value 15 min
represent represent
RU Device Object
Configuration Data
EnableFanBoostOp true
EnableFirePlaceOp true
EnableKitchenHoodOp true
[cASA-4.2-100-N]
parameters to enable/
disable operation of
temporary fan modes
at runtime
Temporary mode

Engineering
5
20 | 70
A6V11471220_en--_e
Property
name
Property
identifier
Property
access
LTE service
Description
KNX
Datapoint
Type (DPT)
Interface
Object Type
1
R
---
390 = UHD
DPT_PropData
Type (DPT_ID
= 7.010)
TmpFanMode
FSSM.166
----
IR.ind
Process Data
Input
DPT_TmpFan
Mode
local copy *)
208
R
---
Diagnostic
Value
TmpFanModeR
emainTime
FSSM.167
----
IR.ind
Process Data
Input
DPT_TimePeri
odMin
local copy *)
209
R
---
Diagnostic
Value
BuildingZone
101
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Room
102
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Subzone
103
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Property
name
Property
identifier
Property
access
LTE service
Description
KNX
Datapoint
Type (DPT)
Interface
Object Type
1
R
---
393 = UFS
DPT_PropData
Type (DPT_ID
= 7.010)
FanBoostReq
162
R
IR.req
Process Data
Output
DPT_Trigger
FirePlaceReq
163
R
IR.req
Process Data
Output
DPT_Trigger
KitchenHoodR
eq
164
R
IR.req
Process Data
Output
DPT_Trigger
ResetTmpFan
Req
165
R
IR.req
Process Data
Output
DPT_Trigger
FanBoostProlo
ngTime
166
R
IR.req
Process Data
Output
DPT_TimePeri
odMin
FirePlaceProlo
ngTime
167
R
IR.req
Process Data
Output
DPT_TimePeri
odMin
BuildingZone
101
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Room
102
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Subzone
103
R/W
---
Configuration
Data
DPT_UCountV
alue8_Z
Temperature setpoint
