Siemens AZL5 series User manual

Siemens AG Building Technologies Division CC1U7550.2en 18.07.2017 1/10
7550.2
Operating Instruction User level AZL5...
(LMV52...)
Legend of Operating Instruction and AZL5...
Previous level Cursor 
Cursor 
Next level Revision level
For language option, select:
Param&Display Access without password AZL5 Language
Display
Normal operation

Display 1en
Press ESC, to get into
the main menu

Display 2en
Depending on burner sequence.
Display of fault or error

Display 3en
Display 4en
For fixing the display, press .
Extended display LMV52...
Overview positions of actuator and O2 value
Display 11en

P
C
V U
U
Press ENTER,
to switch
between this
both displays
Display 12en
Press ESC, to
get into the
main
menu

Siemens AG Building Technologies Division CC1U7550.2en 18.07.2017 2/10
Menu
Normal Operation Standard display information
Status / Reset State or reset function
Operational Stat Fault History Last 21 faults
Lockout History Lat 9 lockouts
Alarm act/deact Activated / deactivated of horn in the event of an alarm
Example: Error history

Display 6en
Fault date
Eighth last fault Fault time
Diagnostic code
Error code Program phase
Start number
Load in % Current type of fuel
For fixing the display press
Selection of error history
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
OperationalStat
NormalOperation
Status/Reset
FaultHistory
LockoutHistory
Alarm act/deact

Siemens AG Building Technologies Division CC1U7550.2en 18.07.2017 3/10
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
Operation
BoilerSetpoint
SetpointW1
SetpointW2
User Maxload
User MaxLoadMod
User MaxLoadStg
Fuel
CurrentFuel
FuelSelect
Date/TimeOfDay
DisplayClock
Date
TimeOfDay
Weekday
SetClock
Date
TimeOfDay
Weekday
HoursRun
GasFiring
OilStage1/Mod
OilStage2
OilStage3
TotalHoursReset
TotalHours
SystemOnPower
StartCounter
GasStartCount
OilStartCount
TotalStartCountR
TotalStartCount
Fuel Meter
Curr Flow Rate
Volume Gas
Volume Oil
Volume Gas R
Volume Oil R
Reset Date Gas
Reset Date Oil
LockoutCounter
O2 Module
Current O2 Value
O2 Setpoint
SupplyAirTemp
FlueGasTemp
CombEfficiency
BurnerID
OptgModeSelect
InterfacePC
GatewayBASon
GatewayBASoff
Gateway status
Type of Gateway
O2Ctrl activate

Siemens AG Building Technologies Division CC1U7550.2en 18.07.2017 4/10
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
ManualOperation
SetLoad
Autom/Manual/Off

Siemens AG Building Technologies Division CC1U7550.2en 18.07.2017 5/10
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
Params & Display
BurnerControl
Configuration
ConfigFlameDet
FlameSignal
FlameSig QRI_B
FlameSig ION
ProductID
ASN
ProductionDate
SerialNumber
ParamSet Code
ParamSet Vers
SW Version
RatioControl
Autom/Manual/Off
O2Contr/Alarm
GasSettings
Control Param
PI
Tau Low-Fire
Tau High-Fire
Startmode
Adjust. Temp O2
OilSettings
Control Param
PI
Tau Low-Fire
Tau High-Fire
Startmode
Adjust. Temp O2
Process Data
CombEfficiency
ManVar O2 Ctrl
State O2 Ctrl
Air-related Load
Diag Reg State
LoadController
ControllerParam
ContrlParamList
StandardParam
P-Part (Xp)
I-Part (Tn)
D-Part (Tv)
MinActuatorStep
SW_FilterTmeCon
SetpointW1
SetpointW2
SD_ModOn
SD_ModOff
SD_Stage1On
SD_Stage1Off
SD_Stage2Off
SD_Stage3Off
ThreshStage2On

Siemens AG Building Technologies Division CC1U7550.2en 18.07.2017 6/10
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
ThreshStage3On
ColdStart
Temp ColdStart
Configuration
LC_OptgMode
Adaption
StartAdaption
AdaptionLoad
SW Version
AZL
Times
Sum/WinterTime
Time EU/US
Language
DateFormat
PhysicalUnits
eBUS
Address
SendCycleBU
Modbus
Address
Baudrate
Parity
Timeout
Lokal / Remote
Remote Mode
W3
Display Contrast
ProductID
ASN
ProductionDate
SerialNumber
ParamSet Code
ParamSet Vers
SW Version
Actuators
ProductID
1 AirActuator
ASN
ProductionDate
SerialNumber
ParamSet Code
ParamSet Vers
2 GasActuat(Oil)
ASN
ProductionDate
SerialNumber
ParamSet Code
ParamSet Vers
3 OilActuator
ASN
ProductionDate
SerialNumber
ParamSet Code
ParamSet Vers

Siemens AG Building Technologies Division CC1U7550.2en 18.07.2017 7/10
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
4 AuxActuator
ASN
ProductionDate
SerialNumber
ParamSet Code
ParamSet Vers
5 AuxActuator2
ASN
ProductionDate
SerialNumber
ParamSet Code
ParamSet Vers
6 AuxActuator3
ASN
ProductionDate
SerialNumber
ParamSet Code
ParamSet Vers
SW Version
1 AirActuator
2 GasActuat(Oil)
3 OilActuator
4 AuxActuator
5 AuxActuator2
6 AuxActuator3
VSD Module
Configuration
Speed
AbsoluteSpeed
Process Data
Max Stat Dev
Max Dyn Dev
Num Dev >0.3%
Num Dev >0.5%
Absolute Speed
ProductID
ASN
ProductionDate
SerialNumber
ParamSet Code
ParamSet Vers
SW Version
O2 Module
Process Data
Actual O2 Value
O2 Setpoint
SupplyAirTemp
FlueGasTemp
CombEfficiency
QGO SensorTemp
QGO HeatingLoad
QGO Resistance
ProductID
ASN
ProductionDate
SerialNumber

Siemens AG Building Technologies Division CC1U7550.2en 18.07.2017 8/10
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
ParamSet Code
ParamSet Vers
SW Version
Flue Gas Recirc.
actTmpFGR-sensor
SystemConfig
LC_OptgMode
HoursRun
GasFiring
OilStage1/Mod
OilStage2
OilStage3
TotalHoursReset
TotalHours
SystemOnPower
Reset
GasFiring
OilStage1/Mod
OilStage2
OilStage3
TotalHoursReset
StartCounter
GasStartCount
OilStartCount
TotalStartCountR
TotalStartCount
Reset
GasStartCount
OilStartCount
TotalStartCountR
Fuel Meter
Curr Flow Rate
Volume Gas
Volume Oil
Volume Gas R
Volume Oil R
Reset DateGas
Reset DateOil

Siemens AG Building Technologies Division CC1U7550.2en 18.07.2017 9/10
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
Updating
ParamBackup
BackupInfo
Date
TimeOfDay
BU included?
AZL included?
LC included?
ACT1 included?
ACT2 included?
ACT3 included?
ACT4 included?
ACT5 included?
ACT6 included?
VSD included?
O2 included?
PW Login
SafetyCheckFunct
SLT Test
SLT-Testload Mod
SLT-Testload Stg
Use of TÜV test function must be carried out by qualified staff!

Siemens AG Building Technologies Division CC1U7550.2en 18.07.2017 10/10
Required information of service purpose
Plant:
Burner data:
Burner management system LMV52...
ASN Production data Software version
Burner control
Load controller
AZL5...
Air actuator
Gas actuator
Oil actuator
Auxiliary actuator
Lockout history
No. Date Time Code Diagnostic
code Error phase Startup Load Fuel Description of fault
1
2
3
4
5
6
7
8
9
2017 Siemens AG Building Technologies Division, Berliner Ring 23, D-76437 Rastatt
Subject to change!
