Interface modules IM 153-4 PN and IM
153-2 HF
___________________
___________________
SIMATIC
ET 200M
Interface modules IM 153-4 PN and
IM 153-2 HF
Product Information
12/2013
A5E02714952
-04
Introduction
1
Product information
2

Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E02714952-04
Ⓟ
01/2014 Technical data subject to change
Copyright © Siemens AG 2012 - 2013.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Interface modules IM 153-4 PN and IM 153-2 HF
Product Information, 12/2013, A5E02714952-04 3
Table of contents
1 Introduction............................................................................................................................................. 5
2 Product information................................................................................................................................. 7
2.1 Supplement to the sections............................................................................................................7
2.2 The new functions for the IM 153-4 .............................................................................................10

Table of contents
Interface modules IM 153-4 PN and IM 153-2 HF
4Product Information, 12/2013, A5E02714952-04

Interface modules IM 153-4 PN and IM 153-2 HF
Product Information, 12/2013, A5E02714952-04 5
Introduction
1
Overview
This product information applies to:
●IM 153-4 PN interface module
–6ES7153-4AA01-0XB0, as of firmware version 4.x
–6ES7153-4BA00-0XB0, as of firmware version 4.x
●IM 153-2 HF interface module
–6ES7153-2BA02-0XB0
–6ES7153-2BA82-0XB0
Supplement to the ET 200M operating instructions
This product information is a supplement to the ET 200M
(http://support.automation.siemens.com/WW/view/en/1142798) operating instructions.
IM 153-4AA0x
The following changes have been made:
Property
6ES7153-4AA01-0XB0
6ES7153-4BA00-0XB0
Shared Device
×
×
Media redundancy
×
×
Isochronous real-time communication
IRT option "high performance"
× ×
F modules
—
×
Connection to H-CPUs with system
redundancy
— ×
HART modules
—
×

Introduction
Interface modules IM 153-4 PN and IM 153-2 HF
6Product Information, 12/2013, A5E02714952-04
Configuration with STEP 7 or GSD
You can configure the ET 200M using the above-named 6ES7153-4AA01-0XB0/6ES7153-
4BA00-0XB0 under STEP 7 V5.5 (with HSP 214 or HSP 213) or a GSD file.
You can find the GSD file at Internet
(http://support.automation.siemens.com/WW/view/en/25057900).
The F modules of the 6ES7153-4BA00-0XB0 can only be configured with STEP 7.
You can configure the HART modules
●6ES7331-7TF01-0AB0
●6ES7331-7TB00-0AB0
●6ES7332-8TF01-0AB0
●6ES7332-5TB00-0AB0
with STEP 7 V5.5 SP3 and SIMATIC PDM V8.0 SP2 (HART on PROFINET).
IM 153-2BAx2
The following changes have been made to the technical specifications of the 6ES7153-
2BAx2-0XB0 as of product version 02:
Voltage, Currents, Potentials
Current consumption from 24 V max. 600 mA (for 6ES7153-2BAx2, product version 01)
max. 620 mA (for 6ES7153-2BAx2, product version 02)

Interface modules IM 153-4 PN and IM 153-2 HF
Product Information, 12/2013, A5E02714952-04 7
Product information
2
2.1
Supplement to the sections
Supplement to the ET 200M operating instructions
This section lists all of the supplements to the sections of the ET 200M operating
instructions.
Supplement to section 3.5.4: Arrangement of the modules for the function "Change During Operation"
and/or "Redundancy"
IM 153-2BA02 and IM 153-2BA82
: Maximum 12 signal modules, FMs and CPs can be
plugged next to the IM 153-2BA02 and IM 153-2BA82.
Supplement to section 7.7: Replace modules with the function "Change During Operation"
New sequence for the individual steps for "Removing a module"
When removing modules with "Module Change During Operation" proceed as follows:
1. Switch off the voltage.
2. Open the front door (3).
3. Unlock the front connector and remove it.
–With 20-pin front connector: To do this, use one hand to press down the unlocking
button (4) and use your other hand to remove the front connector via the gripping
surface (4a).
–With 40-pin front connector: Release the fixing screw in the center of the front
connector. Use the gripping surface to pull out the front connector.
4. Loosen the fixing screw(s) on the module (1).
5. Swing the module out.
6. Pull the labeling strips out of the module (5).

Product information
2.1 Supplement to the sections
Interface modules IM 153-4 PN and IM 153-2 HF
8Product Information, 12/2013, A5E02714952-04
Supplement to section 7.10.4: Update of the IM 153-2Bxx1
Configuration as IM 153-2Bxx1
The firmware update is created separately with each IM 153-2.
The IM 153-2 is integrated in the PCS 7 project.
Procedure
1. Open the SIMATIC Manager.
2. In the component view, select the SIMATC station in which the IM 153-2 is located.
3. Double-click on the "Hardware" object in the detail window.
HW Config opens.
4. Select the IM 153-2 with the firmware you want to update.
5. Select the menu command
Target system > Update Firmware
.
The "Update Firmware" dialog box opens.
6. Make the settings according to the following table.
7. Click the "Run" button. The firmware update is performed.
Setting
Action
Location of the
firmware file
Specify the folder in the "Firmware file" group, in which you have saved the file for updating the
firmware.
Activate the "new"
firmware
Use the "Activate firmware after download" check box to specify the time at which the "new"
firmware should be activated:
•Select the "Activate firmware after download" option if the IM 153-2 should automatically
perform a RESET upon successful download of the new firmware. The new firmware in then
active after restart.
•Clear the "Activate firmware after download" option if the IM 153-2 no RESET should be
performed upon successful download of the new firmware. The new firmware then only
becomes active after the supply voltage has been switched off.
In the redundant system with PROFIBUS DP
Following the firmware update of the active IM 153-2, the subsequent "RESET" automatically
switches between the two IM 153-2.
Supplement to section 8.2: Time stamping the input signals with IM 153-2
Rules
You can also use following digital input modules: 6ES7 321-7EH00-0AB0 (1 ms)
Supplement to section 8.4: Redundancy:
Rules for arranging fault-tolerant station components
In a fault-tolerant station, the following conditions must be met for the ET 200M:
Redundantly used modules (DP slave interface modules IM 153-2) must be identical, i.e.
they must have the same order number and the same product version or firmware version.

Product information
2.1 Supplement to the sections
Interface modules IM 153-4 PN and IM 153-2 HF
Product Information, 12/2013, A5E02714952-04 9
Supplement to section 9.1.3.1: Structure of the slave diagnostics
If you have not performed the configuration with GSD, there are no module status and
channel-related diagnostics blocks for the IM 153-1AA03.
Figure 2-1 Structuring of the slave diagnostics new

Product information
2.2 The new functions for the IM 153-4
Interface modules IM 153-4 PN and IM 153-2 HF
10 Product Information, 12/2013, A5E02714952-04
Error in section 10.1 Pollutant concentration
This sentence is correct: The ET 200M distributed I/O system satisfies the requirements of
the standard ISA-71.04 serverity level G1;G2;G3.
2.2
The new functions for the IM 153-4
Media redundancy
Function for ensuring the network and system availability. Redundant transmission links (ring
topology) ensure that an alternative communication path is made available if a transmission
link fails.
You can find additional information in the STEP 7 online help and the PROFINET system
description (http://support.automation.siemens.com/WW/view/en/19292127) manual.
Shared Device
The "Shared Device" function allows the submodules of an IO device to be divided up
among different IO controllers.
The following conditions apply for an ET200M if it is to be operated as a shared device.
You can find additional information in the STEP 7 online help and the PROFINET system
description (http://support.automation.siemens.com/WW/view/en/19292127) manual.
The following applies to the ET 200M:
●If an IO controller fails, the entire IO device outputs substitute values. This means that not
only do the IO modules of the failing IO controller output substitute values, but also the IO
modules of the intact IO controller.
●Since the outputs of an IO module cannot separately output substitute values, in the
shared device environment the I/O will only output process values if both IO controllers
are in RUN.
As soon as an IO controller is in STOP mode, the outputs of that IO module that are
subscribed by the other IO controller will therefore output substitute values. This fact must
be taken into account, for example, for the STEP 7 functions, "Modify" and "Force". With
the STEP 7 "Modify" and "Force" functions, a CPU in STOP mode will be reported as
being in RUN mode. This releases the modules that are assigned to the other controller
that is still in RUN.

Product information
2.2 The new functions for the IM 153-4
Interface modules IM 153-4 PN and IM 153-2 HF
Product Information, 12/2013, A5E02714952-04 11
Configuration as Shared Device
"IM153-4 PN ST as of V3.0 Shared Device" or "IM153-4 PN HF as of V3.0 Shared Device"
must be used for the configuration of shared device. The remaining configuration is done in
the usual way.
When configuring as a Shared Device, the OB 83 must be integrated into the block list,
because the transition from STOP to RUN will generate so-called "Return of submodule"
alarms. The alarms are intercepted by the OB 83, otherwise the CPU would go into STOP.
Both IO controllers that share the device must be in "RUN" in order for the IM 153-4 PN to be
able to send data to the I/O.
See also STEP 7 documentation
(http://support.automation.siemens.com/WW/view/en/10805384/133300).
Isochronous real-time communication
Synchronized communication protocol for cyclic exchange of IRT data between PROFINET
devices. A reserved bandwidth within the send clock is available for the IRT data. The
reserved bandwidth ensures that the IRT data can be transmitted at reserved, synchronized
intervals while remaining uninfluenced by another greater network load (for example, TCP/IP
communication or additional real time communication).
The IRT option "high flexibility" permits simple planning and expansion of the system.
Topological configuration is not required.
The "high performance" IRT option requires a configuration of the topology.
Note
IO controller as a sync master for IRT communication with the option "high performance"
We recommend also operating the IO controller as a Sync
-Master if you configure the IRT
communication with the option "high performance".
Otherwise, IRT and RT configured IO devices may fail if the sync master fails.
You can find additional information about configuring synchronized PROFINET devices in
Sync domains in the STEP 7 online help and in the PROFINET system description
(http://support.automation.siemens.com/WW/view/en/19292127) manual.
Fail-safe signal modules (only 6ES7153-4BA00-0XB0)
The following fail-safe signal modules can be used with the 6ES7153-4BA00-0XB0 interface
module:
Module
Order no.
As of product
version
SM 326; DI 24 x DC 24V
6ES7326-1BK02-0AB0
1
SM 336; F-AI 6 x 0/4 ... 20 mA HART
6ES7336-4GE00-0AB0
1
SM 326; F-DO 10 x DC 24V/2A PP
6ES7326-2BF10-0AB0
1
SM 326; DO 8 x DC 24V/2A PM
6ES7326-2BF41-0AB0
1
A safety protector is no longer required for these modules.

Product information
2.2 The new functions for the IM 153-4
Interface modules IM 153-4 PN and IM 153-2 HF
12 Product Information, 12/2013, A5E02714952-04
SM 322 DO 16 x DC 24V/0,5 A, 6ES7322-8BH10-0AA0
You can also use the SM 322 DO 16 x DC 24V/0,5 A 6ES7322-8BH10-0AA0 module with
the 6ES7153-4BA00-0XB0.
Connection to H-CPU (6ES7153-4BA00-0XB0 only)
In the case of system redundancy, you can connect the 6ES7153-4BA00-0XB0 to the
following S7-400 CPUs:
CPU
Order no.
As of firmware version
CPU 412-5H PN/DP
6ES7412-5HK06-0AB0
V6
CPU 414-5H PN/DP
6ES7414-5HM06-0AB0
V6
CPU 416-5H PN/DP
6ES7416-5HS06-0AB0
V6
CPU 417-5H PN/DP
6ES7417-5HT06-0AB0
V6
With these CPUs, the 6ES7153-4BA00-0XB0 can participate in system redundancy.
Requirements of 6ES7153-4BA00-0XB0:
●The 6ES7153-4BA00-0XB0 can be configured as a system redundancy device with a
STEP 7 version as of V5.5.2 HF1.
●The connection settings (transmission medium/duplex) must be set to full duplex.
You can find examples for system redundancy in the Fault-tolerant S7-400H systems
(http://support.automation.siemens.com/WW/view/en/53385282) manual.

Product information
2.2 The new functions for the IM 153-4
Interface modules IM 153-4 PN and IM 153-2 HF
Product Information, 12/2013, A5E02714952-04 13
Principle for fastening PROFINET cable with cable ties
The following describes how to fasten PROFINET cables with cable holders. The cable
holders are available as accessories.
1. Screw the cable holder onto the interface module.
2. Insert the PROFINET cable.

Product information
2.2 The new functions for the IM 153-4
Interface modules IM 153-4 PN and IM 153-2 HF
14 Product Information, 12/2013, A5E02714952-04
3. Connect the PROFINET cable to the cable holder using the cable tie.
