Siemens C) User manual

Siemens Electric Range with
threeD (Surround)Convection®
Installation Instructions
Models: HE2224(U,C), HE2425(U,C), HE2528U
Please read instructions before using.
Important: Save these instructions.
Estufas electrica de Siemens
Instrucciones de instalación
Modelo: HE2224(U,C), HE2425(U,C), HE2528U
Favor de leer las instrucciones antes de usar.
Importante: Guarde estas instrucciones.
Cuisinières électriques Siemens
Instructions d’installation
Modèle: HE2224(U,C), HE2425(U,C), HE2528U
Merci de lire les instructions avant d'utiliser.
Important : Conserver ces instructions.

Table of Contents
Questions?
866-44SIEMENS (447-4363)
www.siemens-home.com
5551 McFadden Ave.
Huntington Beach, CA 92649
We look forward to hearing from you!
Safety ................................................................................................................... 1
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Installation ............................................................................................................ 3
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Service ............................................................................................................... 16
Before Calling Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

English 1
Important Safety
Instructions
WARNING:
If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury or death.
• Ask your dealer to recommend a qualified technician and an authorized repair
service.
• Install only per installation instructions provided in the literature package for
this range.
• Important - Save for local electrical inspector’s use.
Safety Codes and Specifications • This appliance complies with one or more of the following Standards:
• UL 858, The Standard for the Safety of Household Electric Ranges
• UL 923, The Standard for the Safety of Microwave Cooking Appliances
• UL 507, The Standard for the Safety of Electric Fans
• ANSI Z21.1-2000, The American National Standard for Household Cook-
ing Gas Appliances
• CAN/CSA-C22.2 No. 113-M1984 Fans and Ventilators
• CAN/CSA-C22.2 No. 61-M89 Household Cooking Ranges
• It is the responsibility of the owner and the installer to determine if additional
requirements and/or standards apply to specific installations.
• Be sure your appliance is properly installed and grounded by a qualified tech-
nician in accordance with the National Electrical Code ANSI/ NFPA No. 7 lat-
est edition and local electrical code requirements.
• Local codes vary. Installation, electrical connections and grounding must
comply with all applicable codes.
• This appliance has been tested in accordance with ANSI/UL 858 Standard for
Safety for Household Ranges and CAN/CSA-22.2 No. 61 National Standard
of Canada for Household Cooking Ranges. It is the responsibility of the owner
and the installer to determine if additional requirements and standards apply
in specific installations.
Equipment and Usage Safety
Requirements • Unit is heavy and requires at least two persons or proper equipment to move.
• Stepping, leaning or sitting on the doors or drawers of this range can result in
serious injuries and also cause damage to the range.
• Do not allow children to climb or play around the range. The weight of a child
on an open door may cause the range to tip, resulting in serious burns or
other injury.
• Do not store items of interest to children in the cabinets above a range or on
the backguard of a range. Children climbing on the range to reach items could
be seriously injured.
• To eliminate the risk of burns or fire by reaching over heated surface units,
cabinet storage space located above the surface units should be avoided. If
cabinet storage is provided, the risk can be reduced by installing a range hood
that projects a minimum of five inches (12.7 cm) beyond the bottom of the
cabinets.
Safety
Important Safety Instructions
READ AND SAVE THESE INSTRUCTIONS

Safety
English 2
• Remove all tape and packaging before using the range. Destroy the packag-
ing after unpacking the range. Never allow children to play with packaging
material.
• Do not repair or replace any part of the appliance unless specifically recom-
mended in the manuals. All other servicing should be done by a qualified
technician. This may reduce the risk of personal injury and damage to the
range.
• Never modify or alter the construction of a range by removing leveling legs,
panels, wire covers, anti-tip brackets/screws, or any other part of the product.
• DO NOT LIFT RANGE BY DOOR HANDLE.
• Remove the door for easier handling and installation. See ‘Removing Oven
Door’ in the Maintenance section of the Use and Care Manual.
• Do not use the warming drawer (if equipped) or oven for storage.
• Hidden surfaces may have sharp edges. Use caution when reaching behind
or under range.
Power Requirements and Electrical
Grounding Instructions • If required by the National Electrical Code (or Canadian Electrical Code), this
appliance must be installed on a separate branch circuit.
• Only a power-supply cord kit rated for this appliance and marked "for use with
ranges" shall be used.
• Before installing, turn power OFF at the service panel. Lock service panel to
prevent power from being turned ON accidentally.
• Before you plug in an electrical cord, be sure all controls are in the OFF posi-
tion.
• Know how to disconnect the power to the range at the circuit breaker or fuse
box in case of an emergency.
• Installer - show the owner the location of the circuit breaker or fuse. Mark it for
easy reference.

English 3
Before You Begin
Tools and Parts Needed • 50 Amp Power Supply Cord Kit (not necessary for Canadian installations)
• Measuring Tape
• Phillips Head Screwdriver
• 1-1/4” (31.8 mm) Wrench
•Pencil
• T-20 Torx Screwdriver
• Screws (2) and Anchors (2) for Anti-Tip Bracket (style will vary depending on
mounting surface)
•Level
• Drill and Drill Bit
• Safety Gloves and Goggles
• Tape (optional)
• Cloth or Cardboard (optional - to protect floor)
Additional Parts Needed For Hard
Wire Installations • Flexible Conduit (for Hard Wire Installation Only)
• Torque Wrench (for Hard Wire Installation Only)
•Note:
Power Supply Cord Kit not necessary for Hard Wire Installations
Parts Included • Anti-Tip Bracket
• Terminal Lugs (for use with Hard Wire Installations) (not necessary for Cana-
dian installations)
Cabinet Requirements This unit is designed for installation near adjacent walls and projecting surfaces
constructed of combustible materials. Allow a minimum of 30 inches (76.2 cm)
between cabinets where range is to be installed (0.47” (12 mm) clearance from
range sidewall to cabinet required in Canada).
Required Clearances These clearance instructions were determined using Standard American cabinets.
Standard base cabinets measure 36 inch (91.4 cm) high x 24 inch (60.9 cm) deep.
Cabinets over the cooking surface and cabinets adjacent to those over the cook-
Installation
Figure 1: Cabinet Clearances
30” (76.2 cm) Minimum
between cabinets

Installation
English 4
ing surface measure 13 inches (33 cm) deep from backwall. If nonstandard cabi-
nets are used, care should be taken to alter dimensions accordingly.
Note:
Some cabinet finishes cannot survive the temperatures allowed by
U.L.for appliances, particularly self-cleaning ovens; the cabinets may
discolor or stain. This is most noticeable with laminated cabinets.
From cooktop to materials above:
There must be a minimum clearance of 30 inches (76.2 cm) between the top of
the cooking surface and the bottom of an unprotected wood or metal cabinet.
24 inches (61 cm) is acceptable when the bottom of the wood or metal cabinet is
protected by:
(a) not less than 1/4 inch (6.35 mm) of flame retardant material which must
be covered with
(b) not less than No. 28 MSG sheet metal, 0.015 inch (.381 mm) stainless
steel’ or 0.024 inch (.601 mm) aluminum or copper.
From range walls to adjacent materials, see Figure 2: Cooktop Clearances:
No clearance is required from unit walls to adjacent vertical combustible walls on
rear, right or left. Clearance from range top to adjacent vertical walls must be at
least 4” (10.2 cm).
Figure 2: Cooktop Clearances
30in (76.2 cm)
min. centered
30in (76.2 cm) min.
4in (10.2 cm)
min
4in
(10.2 cm
)
min
no clearance required (12 mm clearance from
range sidewall to cabinet required in Canada.)

Installation
English 5
Electrical Requirements The electrical outlet must be located in the shaded space in Figure 3: Electrical
Outlet Placement.
Verify that wiring to house is adequate.
Contact your local utility company to verify that the present electric service to your
home is adequate. In some instances, the size of the wiring to the house and ser-
vice switch must be increased to handle the electrical load demanded by the
range.
Verify that wiring inside house is adequate.
Most wiring codes require a separate circuit with separate disconnect switch and
fuses either in the main entrance panel or in a separate switch and fuse box. Most
local building regulations and codes require that electrical wiring be done by
licensed electricians. Be sure to install your range according to the electric codes
in place in your region.
General Information Ranges are dual rated for use on either 120/240 VAC or 120/208 VAC. See
Table 1, “Electrical Specifications,” on page 6 for power ratings and circuit breaker
sizes based upon the supply voltage for each model.
We recommend that the range be installed with a UL approved power cord set
(not supplied). The electrical rating of the power cord set must be 120/240 volt, 50
amperes minimum. The power cord set shall be marked “For Use with Ranges.”
Always use a new power cord. Alternatively, the range can also be hard wired
using the terminal lugs included in the literature pack. If using this connection,
flexible conduit must also be used (not supplied).
We recommend a 50 AMP, 60 Hz, 4 wire circuit; However, the NEC (National
Electric Code) allows for some ranges to be installed on a 40 AMP circuit. Refer to
your local electric code requirements in order to determine the required amper-
age. Always choose a range power cord set that is rated for the circuit. In compli-
ance with the NEC, a separate circuit is also recommended.
Note:
In Canada, the range is shipped from the factory with the range cord
already installed.
Figure 3: Electrical Outlet Placement
21” (533.4 mm)
30”
(762 mm)
7 1/2”
(190.5 mm)
3 1/2”
(88.9 mm)
4 1/2”
(114.3 mm)
4 1/2”
(114.3 mm)

Installation
English 6
For installations other than those in Canada, install the strain relief and connect
the range cord (or wire conductors) as described in the following steps.
* Varies by location. Refer to local electric code.
Installation Procedure
Installation Tips • Tape warming drawer or storage drawer shut to keep it from opening while
installing the range.
• During installation, place a portion of the box or a piece of cloth under the
range to protect floors.
• To make range lighter and easier to handle, remove door (see instructions in
Use and Care manual).
Install Ventilation We strongly recommend the installation of a ventilation hood above this range.
For most kitchens a certified hood rating of not less than 300 CFM is recom-
mended. The range hood must be installed according to instructions furnished
with the hood.
Prepare Walls and Floor Seal any holes in the walls or floor. Remove any obstructions (extra electrical or
gas connections, etc.) so that range will rest against wall properly.
Prepare Range Place range in front of cabinets where it is to be installed. Remove any packaging.
Install Strain Relief WARNING:
The strain relief provided with your range cord must be properly
installed.
Place strain relief in knockout below terminal block. See Figure 4: Electrical Con-
nection and Strain Relief Knockout Panel Locations. Feed range cord through
hole and strain relief up to terminal block. Allow for slack in the cord between the
strain relief and terminal block. Once cord length/ slack has been adjusted, attach
strain relief per instructions included with strain relief.
Tip:
The knockout panel (below the terminal block) can be removed from
the range to install the strain relief: Remove panel from range, install
strain relief in panel and reattach. DO NOT remove entire range back
panel.
Table 1: Electrical Specifications
Check data plate for kW rating. Reference kW rating in table to determine
amperage requirements.
kW Rating AMPS Required
At 120/240 Volts: At 120/208 Volts: US Models: Canadian Models:
12.3 9.2 40 or 50*
12.6 9.5 40 or 50* 50
13.5 10.2 50

Installation
English 7
Connect Electric There are four possible electrical connections:
1. Four (4) wire range cord
2. Three (3) wire range cord
3. Four (4) wire flexible conduit connection (hard wire)
4. Three (3) wire flexible conduit connection (hard wire)
The four wire range cord connection is the recommended method, but where local
codes permit, three wire connections are also acceptable.
As an alternative to the range cord, the appliance can also be hard wired with
either a three or four wire connection. In this case, the terminal lugs supplied must
be used.
Always verify that your chosen connection complies with all applicable codes.
Table 1, “Electrical Specifications,” on page 6.
WARNING:
To prevent electrical shock, the grounding prong on the range cord
should not be cut or removed under any circumstances. It must be
plugged into a matching grounding type receptacle and connected to a
correctly polarized 240- Volt circuit. If there is any doubt as to whether
the wall receptacle is properly grounded, have it checked by a qualified
electrician.
WARNING:
Risk of Electric Shock or Fire. Frame grounded to neutral through a
ground strap. Grounding through the neutral conductor is prohibited for
new branch-circuit installations (1996 NEC), mobile homes, and recre-
ational vehicles, or in an area where local codes prohibit grounding
through the neutral conductor.
For installations where grounding through the neutral conductor is prohibited, (a)
disconnect the link from the neutral, (b) use grounding terminal or lead to ground
unit, (c) connect neutral terminal to lead branch circuit neutral in usual manner
Figure 4: Electrical Connection and Strain Relief Knockout Panel Locations
Feed range cord through strain
relief in knockout panel here.
Electrical connection
(found behind terminal block cover)

Installation
English 8
(when the appliance is to be connected by means of a cord kit, use 4-conductor
cord for this purpose)
Use only cord kits rated 125/250 volts (minimum), 50 amperes and labeled “For
Use with Ranges”. Strain relief provided with cord must be installed per instruc-
tions included with cord.
Four Wire Range Cord Connection
(Recommended Method) 1. Disconnect electrical power at breaker box.
2. Remove the terminal block cover to expose the terminal block
4. Remove TOP nut, star washer, and round washer from each post.
Note:
DO NOT remove last round washer, last nut or internal wiring leads.
5. Remove screw from bottom end of ground strap.
Figure 5: Grounding Options
Figure 3: Four Wire Connection

Installation
English 9
6. Remove ground strap from CENTER post, rotate so that wide end is at TOP
and attach wide end to range through hole below junction box. Attach GREEN
wire on TOP of ground strap. Tighten Screw.
8. Attach RED wire, round washer, star washer and nut IN THIS ORDER to
LEFT post.
9. Attach WHITE wire, round washer, star washer and nut IN THIS ORDER to
CENTER post.
10. Attach BLACK wire, round washer, star washer and nut IN THIS ORDER to
RIGHT post.
12. Tighten all connections securely and replace terminal block cover.
13. Properly secure strain relief. See “Install Strain Relief” on page 6.
Note:
DO NOT plug in range at this time.
Three Wire Range Cord Connection The Four Wire Connection (above) is preferred, but where local codes and ordi-
nances permit grounding through neutral and where conversion to four wire is
impractical, the unit may be connected to the power supply via a three wire con-
nection.
1. Disconnect electrical power at breaker box.
Figure 7: Four Wire Range Cord Connection - Ground Strap and Wire
Figure 11: Four Wire Range Cord Connection (continued)
ground strap
green ground screw
ground wire
red white black

Installation
English 10
2. Remove the terminal block cover to expose the terminal block.
4. Remove TOP nut, star washer, and round washer from each post.
Note:
DO NOT remove last round washer, last nut or internal wiring leads.
5. Attach WHITE wire, round washer, star washer and nut IN THIS ORDER on
TOP of ground strap on CENTER post.
6. Attach RED wire, round washer, star washer and nut IN THIS ORDER to
LEFT post.
7. Attach BLACK wire, round washer, star washer and nut IN THIS ORDER to
RIGHT post.
9. Tighten all connections securely and replace terminal block cover.
11. Properly secure strain relief. See “Install Strain Relief” on page 6.
Figure 3: Terminal Block
Figure 8: Three Wire Connection
Figure 10: Completed Three Wire Range Cord Connection
red white
black
ground strap
green ground screw

Installation
English 11
Note:
DO NOT plug in range at this time.
Four Wire Flexible Conduit Connec-
tion 1. Disconnect electrical power at the breaker box.
2. Remove the terminal block cover to expose the terminal block.
3. Remove the TOP nut, star washer, and round washer from each post.
Note:
DO NOT remove last round washer, last nut or internal wire leads.
4. Remove screw from bottom end of ground strap.
5. Remove ground strap from CENTER post. Discard ground strap.
6. Attach one terminal lug (included) through hole below terminal block using
ground screw.
7. Place one terminal lug (included) on each post. Replace the star washer and
round washer and secure with 20 inch pounds of torque.
8. Strip 3/8 inches (9.53 mm) of insulation from the end of each wire.
10. Insert the insulated grounding wire into the lug below the terminal block.
11. Insert stripped end of WHITE wire into the CENTER lug. Secure the clamping
screw.
13. Insert stripped end of RED wire into the LEFT lug. Secure clamping screw.
14. Insert BLACK wire into the RIGHT lug. Secure clamping screw.
15. Tighten each clamping screw with the appropriate torque. See Table 2.
Figure 9: Wire Stripping
Figure 12: Attaching Wire to Terminal Lug
Table 2: Appropriate Torque Levels for Aluminum or Copper Wire
Gauge Torque (in./lbs.) Torque (Nm)
6353.95
8252.82
3/8 “
lug
clamping screw
wire

Installation
English 12
16. Properly secure flexible conduit at knockout on angle and at supply side junc-
tion box. The wiring is now complete.
Note:
DO NOT plug in range at this time.
Three Wire Flexible Conduit Con-
nection The Four Wire Connection is preferred, but where local codes and ordinances
permit grounding through neutral and/or conversion to four wire is impractical, unit
may be connected to the power supply via a three wire connection.
1. Disconnect electrical power at the breaker box.
2. Remove the terminal block cover to expose the terminal block.
4. Remove the TOP nut, star washer, and round washer from each post.
Note:
DO NOT remove last round washer, last nut or internal wire leads.
5. Place one terminal lug (packaged with this manual) on each post. Replace the
star washer and round washer and secure with 20 inch pounds of torque.
6. Strip 3/8 (9.53 mm) inches of insulation from the end of each wire.
Figure 17: Completed Four Wire Flexible Conduit Connection
red wire
white wire
green
ground
screw black wire
green ground wire
Figure 3: Terminal Block
Figure 7: Wire Stripping
3/8 “

Installation
English 13
8. Insert stripped end of WHITE wire into the CENTER lug on TOP of the ground
strap. Secure the clamping screw.
10. Insert stripped end of RED wire into the LEFT lug. Secure clamping screw.
11. Insert stripped end of BLACK wire into the RIGHT lug. Secure clamping
screw.
12. Tighten each clamping screw with the appropriate torque. See Table 3.
13. Properly secure flexible conduit at knockout panel on range and at supply
side junction box. The wiring is now complete.
Note:
DO NOT plug in range at this time.
Anti-tip Bracket
Attach anti-tip bracket to floor WARNING
RANGE TIPPING HAZARD
All ranges can tip and injury could result. To prevent accidental tipping
of the range, attach it to the floor by installing the Anti-Tip Device sup-
plied.
Figure 9: Attaching Wire to Terminal Lug
Table 3: Appropriate Torque Levels for Aluminum or Copper Wire
Gauge Torque (in./lbs.) Torque (Nm)
6353.95
8252.82
Figure 14: Completed Three Wire Flexible Conduit Connection
lug
clamping screw
wire
green ground screw

Installation
English 14
• A risk of tip-over may exist if the appliance is not installed in accordance with
these instructions.
• If the range is pulled away from the wall for cleaning, service, or any other rea-
son, insure that the Anti-Tip Device is properly reengaged when the range is
pushed back against the wall. In the event of abnormal usage (such as a person
standing, sitting, or leaning on an open door), failure to take this precaution could
result in tipping of the range. Personal injury might result from spilled hot liquids or
from the range itself.
1. Adjust height of range and level by rotating the adjustable leg supports on the
bottom of the range, using 1-1/4 inch (31.75 mm) wrench. See Figure 2:
Adjusting the Leg Support.
3. Measure to locate bracket position as shown in Figure 4: Anti-tip Bracket
Location.
5. Secure bracket with 2 screws (not included) that are adequate for mounting
surface. (i.e.; for wood floor use wood screws for concrete floor use concrete
anchors and screws).
Complete the Installation 1. Move range close enough to the opening to plug into the receptacle.
2. Slide range into position insuring that the left back leg slides under the anti-tip
bracket. Range will sit 3/4” (19.05 mm) away from back wall when properly
installed.
3. Carefully tip range forward to insure that the anti-tip bracket engages the
range back brace and prevents tip-over.
4. Turn on electrical power. Check range for proper operation as described in
Use and Care Manual.
Figure 2: Adjusting the Leg Support
Figure 4: Anti-tip Bracket Location
adjustable leg
wrench
drawer
flush against
cabinet wall
floor
cabinet wall
rearwall
anti-tippin g
device
9/16" (14.29 mm)
from rear wall to center of screw hole

Installation
English 15
CAUTION:
If the display flashes and beeps, the polarity of the wiring may be reversed.
Reversed polarity can damage the range and can result in electrical shock haz-
ard. Immediately switch off power at the breaker and return to “Connect Electric”
on page 7.

English 16
Before Calling
Service
See Use and Care Manual for troubleshooting information. Refer to the Warranty
in the Use and Care Manual.
To reach a service representative, see the contact information at the front of the
manual. Please be prepared with the information printed on your product data
plate when calling.
Product Data Plate The data plate shows the model and serial number. Refer to the data plate on the
appliance when requesting service. It is located on the frame near the drawer.
Open the drawer to view it.
Service
Figure 5: Data Plate
Data Plate
