Siemens SIPIX MO/SD ZN User manual

SIPIX MO/SD ZN
Industry Tablet PC
Operating Manual
https://support.industry.siemens.com/cs/ww/en/view/109792654
Siemens
Industry
Online
Support

Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
Germany
A5E46263338-AB
Ⓟ04/2021 Subject to change
Copyright © Siemens AG 2021.
All rights reserved
2
©Siemens 2021 All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal
safety, as well as to prevent damage to property. The notices referring to your
personal safety are highlighted in the manual by a safety alert symbol, notices
referring only to property damage have no safety alert symbol. These notices
shown below are graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper
precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper
precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not
taken.
NOTICE
indicates that property damage can result if proper precautions are not
taken.
If more than one degree of danger is present, the warning notice representing the
highest degree of danger will be used. A notice warning of injury to persons with a
safety alert symbol may also include a warning relating to property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified for the specific task in accordance with the relevant
documentation, in particular its warning notices and safety instructions. Qualified
personnel are those who, based on their training and experience, are capable of
identifying risks and avoiding potential hazards when working with these
products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the
catalog and in the relevant technical documentation. If products and
components from other manufacturers are used, these must be
recommended or approved by Siemens. Proper transport, storage,
installation, assembly, commissioning, operation and maintenance are
required to ensure that the products operate safely and without any
problems. The permissible ambient conditions must be complied with. The
information in the relevant documentation must be observed.

Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
Germany
A5E46263338-AB
Ⓟ04/2021 Subject to change
Copyright © Siemens AG 2021.
All rights reserved
3
©Siemens 2021 All rights reserved
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining
trademarks in this publication may be trademarks whose use by third parties for
their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the
hardware and software described. Since variance cannot be precluded entirely, we
cannot guarantee full consistency. However, the information in this publication is
reviewed regularly and any necessary corrections are included in subsequent
editions.
Security information
Siemens provides products and solutions with industrial security functions that
support the secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it
is necessary to implement –and continuously maintain –a holistic, state-of-the-art
industrial security concept. Siemens’ products and solutions only form one element
of such a concept.
Customer is responsible to prevent unauthorized access to its plants, systems,
machines and networks. Systems, machines and components should only be
connected to the enterprise network or the internet if and to the extent necessary
and with appropriate security measures (e.g. use of firewalls and network
segmentation) in place.
Additionally, Siemens’ guidance on appropriate security measures should be taken
into account. For more information about industrial security, please visit
https://www.siemens.com/industrialsecurity.
Siemens’ products and solutions undergo continuous development to make them
more secure. Siemens strongly recommends to apply product updates as soon as
available and to always use the latest product versions. Use of product versions
that are no longer supported, and failure to apply latest updates may increase
customer’s exposure to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial
Security RSS Feed under https://www.siemens.com/industrialsecurity.

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
4
©Siemens AG 2021 All rights reserved
Table of contents
Legal information...................................................... Fehler! Textmarke nicht definiert.
1Preface................................................................................................................ 6
2Introduction........................................................................................................ 7
2.1 SIPIX MO/SD ZN.................................................................................. 7
2.1.1 Overview............................................................................................... 7
2.1.2 Characteristics...................................................................................... 9
2.1.3 Structure of the Tablet........................................................................ 10
2.2 Scope of Delivery ............................................................................... 13
2.3 Warranty............................................................................................. 14
3Safety Information ........................................................................................... 15
3.1 General Safety Information ................................................................ 15
3.2 Notes on this User Manual................................................................. 15
3.3 Intended Use...................................................................................... 16
3.3.1 Exclusive Purpose of Use .................................................................. 16
3.3.2 Unapproved Use ................................................................................ 16
3.4 Obligations of the Operator................................................................ 16
3.5 Essential Health and Safety Requirements........................................ 17
3.6 Safety Instructions for Operation........................................................ 17
3.7 Safety Instructions for the Battery Pack............................................. 18
4Commissioning................................................................................................ 19
4.1 Preparation......................................................................................... 19
4.2 Charging the Tablet PC...................................................................... 20
4.3 Installing a SIM card (Optional).......................................................... 21
4.4 Starting the SIPIX MO/SD ZN............................................................ 24
5Basic operation of the SIPIX MO/SD ZN........................................................ 25
5.1 Overview of HotTab............................................................................ 25
5.1.1 Using Shortcuts.................................................................................. 26
5.1.2 Switching the Hardware Functions On and Off.................................. 27
5.1.3 Using the Camera .............................................................................. 28
5.1.4 Customizing the settings.................................................................... 30
5.2 Establishing a wireless connection .................................................... 31
5.2.1 Working with Wireless LAN (Wi-Fi).................................................... 31
5.2.2 Working with Wireless WAN (3G/LTE)............................................... 32
5.2.3 Working with GPS.............................................................................. 32
5.2.4 Working with Bluetooth....................................................................... 33
5.3 Using the HF RFID Reader................................................................ 34
5.4 Switching the External GPS Antenna On/Off..................................... 35
5.5 Activating/deactivating the Brightness Sensor for Display
Contrast Adjustment........................................................................... 35
5.6 Changing the Touch Screen Operation Mode.................................... 36
5.6.1 Toggle touchscreen mode.................................................................. 36
5.6.2 Switching via programmable function keys........................................ 37
6Remote Assisted Work.................................................................................... 38
6.1 Remote Service Platform (cRSP)....................................................... 38
6.2 Communication with an In-House Expert (SIPIX MO/SD ZN) .......... 39
6.2.1 Communication without Internet Connection within the company
network (Intranet) ............................................................................... 39
6.2.2 Communication with an Internet Connection via cRSP
Customer Web Portal (Internet Only with SIPIX SD ZN) ................... 44

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
5
©Siemens AG 2021 All rights reserved
6.3 Communication with the Siemens Service Center (SIPIX SD
ZN)...................................................................................................... 53
6.3.1 Service Agreements and Remote Service Tickets............................. 53
6.3.2 Overview of steps............................................................................... 54
6.3.3 Arranging a Service Call with Siemens Remote Services ................. 54
6.3.4 Conducting an Audio/Video Conference............................................ 56
6.3.5 Communication via desktop sharing .................................................. 57
6.4 Expansion of communication through data glasses with Android
operating system................................................................................ 58
6.4.1 Preparations....................................................................................... 58
6.4.2 Setting up a Network Connection....................................................... 59
6.4.3 Setting up a connection using data goggles ...................................... 60
6.5 Operation of the SIPIX RC Video/Audio App..................................... 61
6.5.1 Overview of SIPIX RC Views ............................................................. 61
6.5.2 Operating the Expert View ................................................................. 62
6.5.3 Operating the Remote View............................................................... 72
6.5.4 Operating the BT View....................................................................... 77
7Service and maintenance ............................................................................... 80
7.1 Maintenance....................................................................................... 80
7.2 Cleaning ............................................................................................. 81
7.3 Maintenance intervals ........................................................................ 82
7.4 Storage............................................................................................... 82
7.5 Battery................................................................................................ 83
7.5.1 Battery Replacement During Operation............................................. 83
7.5.2 Installing and Removing the Battery .................................................. 84
8Recycling and disposal................................................................................... 86
9Error messages and solutions....................................................................... 87
9.1 Error Messages of the Application "SIPIX RC2"................................ 87
9.2 Error Messages of the SIPIX Tablet................................................... 87
10 Technical Specifications................................................................................. 89
11 Appendix .......................................................................................................... 91
11.1 Service and support ........................................................................... 91
11.2 Industry Mall....................................................................................... 92

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
6
©Siemens AG 2021 All rights reserved
1 Preface
Purpose of the manual
This document provides support in commissioning, configuring, and operating the
SIPIX SD ZN tablet.
Key contents
The following key issues are addressed in this document:
•What is SIPIX MO/SD ZN used for?
•How is the SIPIX MO/SD ZN commissioned?
•How is the SIPIX MO/SD ZN configured?
•What options does the SIPIX MO/SD ZN offer for mobile maintenance and
commissioning?
•How can the SIPIX MO/SD ZN be used for remote services and augmented
reality functions?
Application
This document is valid for SIPIX MO/SD ZN with the following components:
–SSL VPN client for cRSP V1.5.3
–TightVNC V2.8.5
–SIPIX RC V2.0
–HotTab V50.1.22
–Simatic PDM V9.1 SP4
SIPIX in Industry Online Support
In addition to this manual, we offer the following Industry Online Support
(https://support.industry.siemens.com) and our Expertise:
•https://support.industry.siemens.com/cs/sc/4811/remote-services-for-process-
instrumentation-?lc=de-WW
•https://support.industry.siemens.com/cs/products?mfn=ps&pnid=28672&lc=de-
WW
•Notifications that constantly provide you with the latest product information

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
7
©Siemens AG 2021 All rights reserved
2 Introduction
2.1 SIPIX MO/SD ZN
2.1.1 Overview
The SIPIX MO/SD ZN from Siemens is a robust and highly flexible industrial tablet
PC for harsh environments and is your reliable mobile companion for every service
call! Handy, powerful, and with a protected design, it can be optimally used for on-
site maintenance, inspections, and service operations. Thanks to its varied
functions, the SIPIX MO/SD ZN is the perfect companion for maintenance
technicians, operating personnel, engineers, and project managers in the field and
in industry.
With its diverse functions, it offers the right support in every situation. You can
contact a subject matter expert via videoconference or transmit important data
about the device status for diagnostic purposes. The two variants, SIPIX MO ZN
and SIPIX SD ZN, give you the possibility to choose the service level that suits
your needs:
•The SIPIX MO ZN can be used to establish an internal real-time audio/video
connection to an in-house expert via the integrated web server. An Internet
connection, as with similar audio/video conferencing solutions, is not
mandatory.
•The SIPIX SD ZN is based on the SIPIX MO and is complemented by the
connection to the secure high-availability Siemens Remote Platform cRSP.
This gives you access to the centrally available expertise of the SIEMENS
Service Center at any time and from any location, and also allows you to
integrate your own and third-party experts. The standard application here is
remote access to field devices via the Simatic PDM software. By adding
compatible third-party tools to the SIPIX SD ZN, it is also possible to access
other service items in a system.

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
8
©Siemens AG 2021 All rights reserved
Two independent VPN channels enable the remote expert and the on-site service
technician to exchange information either by desktop sharing or by transmitting a
real-time video stream. Among other things, communication via audio, live chat,
drawing of notes on the camera image (AR functions), etc., are also possible. This
allows the remote expert to conveniently and easily guide the on-site expert
through the service process.
Modern interfaces enable the exchange of information with other devices in your
company system. The device communicates wirelessly via Wi-Fi and Bluetooth.
To optimize its use in industrial environments, the powerful 10.1 inch tablet PC can
be combined with a wide range of accessories. For example, the connection of
data glasses enables a service technician to work hands-free on field devices or
other service objects. The selective switch between the tablet and glasses view
creates optimal conditions for assisted work.

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
9
©Siemens AG 2021 All rights reserved
Highlights
•Real Time Audio/Video Collaboration (SIPIX RC) pre-installed as decentralized
web server
•High robustness (military specification MIL-STD-2106)
•Encrypted end-to-end communication
•High availability of the Siemens Remote Platform cRSP (99.99%)
•Certified in accordance with TÜV/CERT
•Functionally extendable (e.g., by using data goggles)
Advantages
The use of the SIPIX SD series offers various advantages, both for the expert with
remote access and for the service technician onsite:
•Secure remote access to the SIPIX SD ZN
•An on-site service technician without specific knowledge of process
instrumentation can be supported in a timely manner by a remote expert.
•Several experts can simultaneously access a SIPIX MO/SD ZN via Desktop
Sharing
•Training of a service field engineer aided by an expert during the service
assignment (training on the job).
2.1.2 Characteristics
The following table contains an overview of the features:
Configuration
Execution
Display
10.1" with 1920 x 1200 pixel resolution
Processor
Intel® Pentium N4200 1.10 GHz, up to 2.50 GHz
with Turbo Boost technology
Working memory
4 GB LPDDR4 (up to 8 GB)
RAM
128 GB SSD
Expandable up to 512 GB through Micro SDXC Card
Slot
Graphic
Intel® HD Graphics 504
Operating system
Windows 10 Enterprise LTSC (64-bit)
WLAN
802.11 a/b/g/n/ac
Bluetooth
Bluetooth 5.0
GNSS
GPS, GLONASS
WWAN
Optional 4G/ LTE or 3G
Detailed information can be found in the "Technical data" section.

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
10
©Siemens AG 2021 All rights reserved
2.1.3 Structure of the Tablet
In this section, you will find a component description.
Front
Position
Name
Description
1
10.1" Touch screen
Display
2
Digital microphone with noise
reduction
Use in video recording and communication
3
Front camera
2 megapixel webcam
4
LED indications
The LED indicators show the following status: RF
communication, memory, battery status, power status.
5
I/O cover
I/O port protection
6
Fn1
Programmable function
7
Menu key
HotTab quick access
8
On/off button
Switches the tablet on/off

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
11
©Siemens AG 2021 All rights reserved
LED indicators
Icon
Name
Description
RF communication
Green –Wi-Fi/BT/WWAN/GPS enabled
Hard disk activity
indicator
Flashing green –hard disk activity
No light –Hard disk idle
Battery level
Orange: AC adapter is plugged in and charging.
Flashing green: AC adapter is plugged in and the battery is
fully charged.
Red: Low battery level (<10%)
Red flashing: Battery is replaced during operation.
No light: Battery is in use and battery level >10%
Status indicator
Blue: The tablet is switched on
No light: Tablet is OFF
Left and right side
Position
Name
Description
9
Micro HDMI
HDMI output to external display/screen
10
Clear CMOS
Hardware reset button
11
MicroSD Card Reader
Port for MicroSD cards
12
USB 3.0
Type C
High-speed USB port for connecting USB devices, such as USB
flash drive, mouse, keyboard, printer, etc.
13
USB 3.0
Type A
The USB 3.0 port is used to connect USB devices such as USB
drive, mouse, keyboard, printer, external camera, etc.
14
Microphone input/
Line out
Connector for headset or headphones (microphone is only
supported for a 3.5 mm 4-pin headset)
15
Power connection
Connection for DC power supply

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
12
©Siemens AG 2021 All rights reserved
Back side
Position
Name
Description
16
RFID Reader
RFID reader for reading RFID tags
17
Additional port
Connections to additional devices possible
(USB2.0 x 1, RS232 x 1).
18
Camera flash
LED camera flash
19
Rear camera
8MP autofocus camera. Takes photos and videos.
20
Battery eject slider
Slider to open the battery slot.
21
Slot for the stylus
Storage for the stylus
22
Battery lock slider
Locking the battery after inserting it.
23
Loudspeaker
Audio output
24
3G/LTE
Module/SIM card slot
Service window for inserting the micro-SIM card. Also
allows access to the 3G /LTE module.
25
Fn2 key
Programmable function key
26
Button for brightness/volume
control.
Brightness/volume control.
(+) Up, (-) Down.
27
Battery
7 Standard battery: 7.4 V, typ. 5140 mAh Li- Polymer
battery (2S1P)
Long-term battery: 7.4 V, typ. 10280 mAh Li-Polymer
battery (2S2P, optional as accessory)

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
13
©Siemens AG 2021 All rights reserved
Upper and lower side
Position
Name
Description
28
Barcode (optional)
Barcode scanner for reading 1D/2D barcodes
29
Kensington lock
Connection for Kensington lock.
30
Docking plug
Docking port
2.2 Scope of Delivery
Hardware
The following components are included in the scope of delivery:
•1x SIPIX MO/SD ZN Tablet PC:
•1 x Lithium polymer battery, type BS101
•1 x stylus
•1 x hand strap
•1 x charging power supply
•1 x charging power supply (EU)
•1 x charging power supply (US)
•1 x spare cover for interface
•1x manual
•1 x short manual with safety instructions
•VR Glasses (Optional)

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
14
©Siemens AG 2021 All rights reserved
On-board software components
The pre-installed software components and their settings are optimally matched, so
that they are executable together on your system. This is verified in particular
through system testing and is ensured throughout the entire life cycle.
The following software components are pre-installed on the SIPIX SD ZN:
•SIPIX RC:
Video/audio collaboration app
•SIMATIC PDM
Configuration tool for field devices
•Tight VNC
Desktop sharing software
•cRSP SSL VPN
Client for connection to Siemens remote platform
•Registration at the Siemens Remote Platform cRSP (SIPIX SD ZN only)
2.3 Warranty
WARNING
No changes or conversions may be carried out without the written permission of
SIEMENS AG.
If unspecified components are used, explosion protection is no longer guaranteed. It
cannot be guaranteed that externally procured parts have been designed and
manufactured in a way that meets the load and safety requirements.
Before modifications or conversions, contact manufacturer and obtain approval. Only use
original spare and wear parts.
Note
SIEMENS AG assumes the complete warranty only and exclusively for the spare
parts ordered from SIEMENS AG.
In principle, our "General Terms and Conditions of Sales and Supply" apply. These
are available to the operator at the latest since conclusion of the contract. Warranty
and liability claims for personal injury and damage to property are excluded if they
are attributable to one or more of the following causes:
•Improper use of the Tablet PCs.
•Improper handling.
•Not observing the instructions in the user manual and the brief instructions
regarding transport, storage, commissioning, operation and maintenance.
•Arbitrary structural changes.
•Incorrectly performed repairs.
•Disasters caused by foreign bodies and force majeure.

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
15
©Siemens AG 2021 All rights reserved
3 Safety Information
3.1 General Safety Information
•Do not change or charge a battery in a potentially explosive area.
•General legal regulations or directives on occupational safety, accident
prevention regulations, and environmental protection laws must be observed,
such as the operational safety ordinance (BetrSichV) or applicable national
regulations.
•Wear suitable clothing and footwear in view of the risk of dangerous
electrostatic charges.
•Avoid heat effects outside the specified temperature range.
•Protect the device from external influences! Do not expose the unit to corrosive
liquids, vapors or spray mist!
•In the event that the device malfunctions or the housing is damaged,
immediately remove it from the potentially explosive area and move it to a safe
place.
3.2 Notes on this User Manual
Read carefully before commissioning the devices:
The user manual contains important notes, safety instructions and test certificates
required for the proper functioning of the device during operation.
The user manual is intended for all persons involved in the commissioning,
handling and maintenance of the product. When carrying out this work, the
applicable directives and standards for areas with gas and dust atmospheres
(99/92/EG, EN 60079-17, EN 60079-19, IEC 60079-17, IEC 60079-19) must be
observed.
Knowledge of the safety and warning instructions in this user manual and their
strict observance are essential for safe commissioning and handling. Accidents,
injuries and damage to property can be avoided by careful handling and consistent
adherence to the instructions.
The illustrations in this user manual are intended to illustrate the information and
descriptions. Due to the different requirements of the respective application,
SIEMENS AG cannot assume any responsibility or liability for the actual use of the
products on the basis of these examples and illustrations.
SIEMENS AG reserves the right to make technical changes at any time.
SIEMENS AG is under no circumstances responsible or liable for indirect or
consequential damages resulting from the use, application or application of this
user manual.

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
16
©Siemens AG 2021 All rights reserved
3.3 Intended Use
3.3.1 Exclusive Purpose of Use
The tablet PC series SIPIX MO/SD is a hand-held electrical device and is designed
for mobile receiving, processing, and/or transmission of data within hazardous
areas.
The permissible operating data of the device used must be observed.
3.3.2 Unapproved Use
Any other use is not intended and can lead to damage and accidents. The
manufacturer is not liable for any use beyond the exclusive purpose.
3.4 Obligations of the Operator
The operator undertakes to only allow persons to work with the Tablet PCs who:
•are familiar with the basic safety and accident prevention regulations and have
been instructed in the use of the Tablet PC,
•have read and understood the documentation, the safety section and the
warnings.
The operator checks that the safety and accident prevention regulations valid for
the respective application are complied with.

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
17
©Siemens AG 2021 All rights reserved
3.5 Essential Health and Safety Requirements
Contact your local health and safety representative to ensure that you are familiar
with your company's safety regulations to protect employees in the workplace.
Ergonomic Recommendations
Consider the following recommendations for daily work at the workplace:
•Avoid unilateral, repetitive movements.
•Posture should be neutral.
•Avoid using up a lot of energy.
•Keep objects that are frequently used in the functional reach space.
•Adjust the working height to the body size and type of work.
•Sufficient space must be provided for body movements.
•Set up objects so that they do not oscillate.
•Avoid applying direct pressure.
•Pay attention to adjustable tables and seats.
•Make sure you have a suitable working environment.
•Workflows should be optimized.
•When performing repetitive tasks, switch between the left and right hand as
often as possible.
3.6 Safety Instructions for Operation
Maintenance
For electrical systems, the relevant installation and operating regulations must be
observed (e.g., RL 99/92/EG, RL 94/9/EG, Industrial safety regulations or the
nationally applicable regulations EN 60079-14, IEC 60079-14 and the DIN VDE
0100 series).
Observe the national waste disposal regulations for disposal.
Maintenance
If the unit is operated correctly, in compliance with the installation instructions and
surrounding conditions, no continuous maintenance is required.
See Section 7.
Inspection
According to EN/IEC 60079-17 and EN/IEC 60079-19, the operator of electrical
systems in potentially explosive areas is obliged to have them checked for proper
condition by a qualified electrician.

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
18
©Siemens AG 2021 All rights reserved
Repairs
Repairs to explosion-proof equipment may only be carried out using original spare
parts in accordance with the state of the art, manufacturer's specifications and
through authorized experts. The applicable directives must be observed.
Commissioning
Before entry into service, make sure that all components and documentation are
available.
3.7 Safety Instructions for the Battery Pack
•Do not disassemble, modify, or insert sharp objects into the battery pack. This
could result in electrolyte leakage, intense heat generation, ignition, or failure.
•Do not short the positive (+) and negative (-) terminals of the battery. This
could result in severe heat generation, ignition, or failure. When carrying or
storing the device, do not place the battery pack with objects that are sensitive
to electricity.
•Do not subject the battery to shocks by dropping or strong pressure. This could
result in electrolyte leakage, intense heat generation, ignition, or battery failure.
•Only charge the battery in the manner described in this manual. Failure to
charge the battery as described herein could result in electrolyte leakage,
excessive heat generation, ignition, or failure.
•If the battery pack is damaged, it must be replaced with a new battery.
Continued use of a damaged battery may result in excessive heat generation,
ignition, or battery failure.
•Do not expose the battery pack to overheating or intense heat (e.g., next to an
open fire, direct sunlight). This could result in severe heat generation, ignition,
or failure.
•Do not use the battery pack with other products. The battery pack is
rechargeable and intended only for this specific product. If used with another
product, it may cause electrolyte leakage, intense heat generation, ignition, or
failure.
•Do not operate the product with batteries other than the specified type.
•Immediately take the device out of operation if the battery swells or looks
swollen or defective. Do not attempt to recharge the battery or continue to use
the device. Damaged or leaking batteries must not be used. Do not allow
leaking battery fluid to come into contact with eyes, skin, or clothing.

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
19
©Siemens AG 2021 All rights reserved
4 Commissioning
4.1 Preparation
Unpack delivery unit
Please observe the following points when unpacking:
•It is advisable not to dispose of the original packing material. Keep it in case
you need to transport it again.
•Keep the enclosed documentation provided with the delivery. They are
required for initial commissioning and are part of the product.
•Before unpacking, check whether the security seal is intact. Please contact
Technical Support if the seal is broken.
•Check the packaging and the package contents for visible transport damage.
•Check the delivery for completeness (see section on "Scope of Delivery").
•Inform your local Siemens sales point of any transport damage or irregularity
you may notice.
Check delivery unit before operation
Before putting the device into operation, check for the following requirements:
•Is there no damage to the display, scanner window and housing?
•Are all covers closed as prescribed?
•Is the battery correctly inserted and locked?
•Is the micro SD card specified for the Tablet PC?
•Is the SIM card inserted correctly?

Table of contents
SIPIX MO/SD ZN
Entry-ID: 109792654, 04/2021
20
©Siemens AG 2021 All rights reserved
4.2 Charging the Tablet PC
The tablet can be powered either by AC supply voltage or via a battery. When
switching on the tablet for the first time, it should be connected to an AC supply
voltage until fully charged (battery LED indicator lights up green).
CAUTION
Use only the AC adapter supplied with the tablet PC. Using other AC adapters
may damage the tablet PC and the battery.
To connect a tablet to the AC network:
1. Open the I/O protection cover by pulling the latch.
2. Plug the DC cable of the AC adapter into the connector socket of the tablet PC.
3. Plug the AC power cord into the AC adapter.
4. Plug the AC power cord into the AC outlet.
The LED display of the battery shows different states:
Color/Light
Description
Orange
The AC adapter is plugged in and the battery is charging.
Green
The AC adapter is plugged in and the battery is fully charged.
Continuous
red light
Battery level low (<10%)
Flashing red
Battery is replaced during operation
No light
Battery is in operation and charged (>10%)
