Siemens Building Technologies 74 319 0824 0 a G1211 05.01.2011 1/3
74 319 0824 0
G1211
de Montage, Einbaulage en Mounting, mounting position
fr Montage, positions de montage nl Montage
it Montaggio, installazione es Montaje, posición de montaje
de Montagehinweise en Mounting notes fr Indication pour le montage
nl Montage aanwijzingen it Indicazioni di montaggio es Notas de montaje
de
Montageort möglichst trocken und staubfrei / x min. 350 mm Freiraum für
Freie Sicht in das Gerät (Verstellen, Kontrolle der Einstellungen)
Ausbauen resp. Einbauen / Öffnen des Gerätes (Begrenzungstemperatur)
en
Mounting location dry and dust-free / x min. 350 mm clearance for
clear view (adjustments, checking settings)
Removal or mounting / opening (limiter temperatur)
fr
Lieu de montage le moins humide et poussiéreux possible / x min. 350 mm de place libre pour
Bonne accessibilité à l'appareil (réglage, contrôle des réglages en vigueur)
Démontage et remontage / ouverture de l'appareil (réglage des consignes)
nl
Montageplaats droog en stofvrij / x min. 350 mm vrije ruimte voor
Vrij zicht in het apparaat (instellen, controleren huidige instelling)
In- resp. uitbouwen / openen van het apparaat (gewenste waarde instelling)
it
Posto per l’installazione possibilmente asciutto e senza polvere / xmin. 350 mm di spazio per
Accedere all’apparecchio (impostazione e controllo)
Montaggio e smontaggio del termostato / apertura e impostazione della temperatura desiderata
es
Lugar de montaje seco y libre de polvo / x mín. 350 mm de espacio libre para
Visualización clara (ajustes, verificación de ajustes existentes)
Retirada o montaje / Apertura (ajustes de consigna)
de Installationsanleitung für autorisiertes Personal Thermostaten
en Installation Instructions for authorized personnel Thermostats
fr Instructions d’installation pour personnel qualifié Thermostats
nl Installatie-aanwijzing voor bevoegd personeel Thermostats
it Istruzioni di montaggio per personale autorizzato Termostati
es Instrucciones de montaje para personal autorizado Termostatos
RAG-ST.1
RAG-TW.1
RAG-ST.1 RAG-TW.1
de Produktionsdatum: Jahr/Monat/Tag/Version
en Date of production: Year/Month/Day/Version
.fr.Date de production: année/mois/jour/Versione
nl. Productiedatum: Jaar/Maand/Dag/Versie
.it. Data di produzione: Anno/Mese/Giorno/Versione
es Fecha de Producción: Año/Mes/Día/Versión
2/3 05.01.2011 G1211 74 319 0824 0 a Siemens Building Technologies
de Abgasrohrmontage en Flue gas duct mounting fr Montage sur tuyau d’échappement
nl Schoorsteen-/ rookgasbuis montage it Montaggio per canna fumaria es Montaje en conducto de humos
de Geräte öffnen en Opening the unit de Einstellen der Begrenzungstemperatur
fr Ouverture de l’appareil nl Apparaat openen en Adjusting the of the limiter temperature
it Apertura apparecchio es Apertura de la unidad fr Réglage des consignes de température
nl Instellen van de gewenste temperatuur waarde
it Impostazione della temperatura
es Adjuste de las consignas de temperatura
°C
°C
de Verdrahtung en Wiring fr Câblage nl Bedrading it Cablaggio es Cableado
Solid
wire
Stran-
ded wi-
re
2.
1.
1.
2
1.
Install Deinstall
1.
2.
2.
1.
Siemens Building Technologies 74 319 0824 0 a G1211 05.01.2011 3/3
de Verdrahtung en Wiring de Entriegelung en Reseting
fr Câblage nl Bedrading fr Verrouillage nl Reset
it Cablaggio es Cableado it Ripristino (reset) es Reajuste
de
•Spannungsbereich: AC 24...250 V (0,1…16 A)
•Elektrische Anschlüsse und Schutzleiter:
Push-in* Klemmen für Leiter: 0,75...2,5 mm2
•Verschmutzungsgrad: (2)
•Bemessung-Stossspannung: 2,5 kV
•Kein elektronisches Gerät
•Schutzrohrlänge: 150 mm
•Standards, Normen: CE, DIN
•Produktenorm: EN 14 597
(ATW 1218)
(ASTB 1217)
en
•Rated voltage: AC 24...250 V (0.1…16 A)
•Electrical connections and protective earth:
Push-in* terminals for wire: 0,75...2,5 mm2
•Degree of pollution: (2)
•Rated impulse voltage: 2,5 kV
•Device without electronics
•Protection pocket length: 150 mm
•Standards: CE, DIN
•Product standards : EN 14 597
(ATW 1218)
(ASTB 1217)
fr
•Plage de tension: AC 24...250 V (0.1…16 A)
•Raccordement électrique et fil de protection:
bornes automatiques pour fil: 0,75...2,5 mm2
•Degré d'encrassement: (2)
•Tension assignée de tenue aux chocs: 2,5 kV
•Appareil sans électronique
•Longueur gaine de protection: 150 mm
•Normes et standards: CE. DIN
•Normes pour produits: EN 14 597
(ATW 1218)
(ASTB 1217)
nl
•Spanningsbereik: AC 24...250 V (0.1…16 A)
•Elektrische aansluiting en aarding:
Push-in* klemmen voor draden: 0,75...2,5 mm2
•Vervuilingsgraad: (2)
•Nominale piekspanning: 2,5 kV
•Regelaar bevat geen electronica
•Beschermhulslengte 150 mm
•Standaards en normen: CE, DIN
•Productnorm: EN 14 597
(ATW 1218)
(ASTB 1217)
it
•Tensione d’alimentatione: AC 24...250 V (0.1…16 A)
•Collegamento elettrico e di protezione:
Morsetti a pressione cavo: 0,75...2,5 mm2
•Grado d‘inquinamento: (2)
•Tensione impulsiva nominale: 2,5 kV
•Dispositivo non elettronico
•Lunghezza guaina: 150 mm
•Norme e omologazioni: CE, DIN
•Norma prodotto: EN 14 597
(ATW 1218)
(ASTB 1217)
es
•Rango de alimentación: AC 24...250 V (0.1…16 A)
•Conexiones eléctricas y conductor protector:
Bornas de presión para cable: 0,75...2,5 mm2
•Grado de polución: (2)
•Tensión media por impulso: 2,5 kV
•Sin dispositivo electrónico
•Longitud vaina de protección:150 mm
•Estándares: CE, DIN
•Estándares del producto: EN 14 597
(ATW 1218)
(ASTB 1217)
*Push In is a patented connection technology designed by Weidmüller, Germany’s leading manufacturer of electrical connection technologies.
2010 Siemens Switzerland Ltd.
RAG-ST.1 RAG-TW.1 RAG-ST.1
