Siemens iQ 300 varioPerfect User manual

1 2 3 4 5 6
bEnd
Spin
Rinse
þWash
Programme has ended when...
... Start/Pause flashes and the bin dicator light comes
on.
Interrupting the programme
Programmes at high temper atures:
– Cool washi ng: Select Rinse/cSpin.
– Sele ct Start/Pause.
Programmes at lower tempera tures:
–Rinse/cSpin (deactivate ?c(Aqua Plus) button) or
select CEmpty.
– Sele ct Start/Pause.
Changing the programme, if ...
... you have selected the wrong p rogramme by mistake:
– Reselect the programme.
– S elect Start/Pause. The new p rogramme starts from
the beginning.
Correct installation according to the
separate Installation instructions.
Check the machine
– Never use a dama ged machine.
– Inform the after-sales servic e.
Connect the mains plug
Make sure your hands are dry .
Take hold of the plug only.
Turn the tap on
Compartment II: detergent for the main wash, water soften er,
bleach, stain remover
Sorting and loading laundry
Follow the manufacturer's c are information.
According to the informatio n on the care labels.
According to type, colour, soiling and temperatur e.
Do not exceed the maximum load –> page 7.
Observe the important information –> page 6 .
Insert large and small items of laund ry.
Close the washing machine door. Ta ke care not to trap items of laun dry
between the washing machine doo r and the rubber seal.
Add detergent and care products
Measure accordingly:
Amount of laundry, soiling, water hardness ( ask your water supply
company) and manufacture r's instructions.
Pour liquid detergent into the appropriate dispenser and place in the drum.
Your washing machine
Congratulations äyou have o pted for a modern, hi gh-quality
domestic appliance manufactur ed by Siemens. The washing
machine is distinguished by its economical water- a nd energy
consumption.
Each machine that leav es our factory has been inspected thorough ly
to ensure that it functio ns properly and is in p erfect condition.
Further information: www.siemens-hom e.com
Environmentally friendly waste disposal All packaging must be disposed of in acco rdance with
environmental guidelines.
This appliance is certified in accordance with E uropean Directive
2002/96/EEC on waste electrical and electronic eq uipment
(WEEE).
This directive provides th e framework for the EU- wide collection and
reuse of used appliances.
Intended use
Contents Page
ʋIntended use ................................................... ....................................1
ʋProgrammes ...................................................................................... .1
ʋSetting and adjusting the programme ........................................... 3
ʋWashing ........................................................................................... 3/4
ʋAfter washing ..................................................................................... .4
ʋIndividual settings .................................... ......................................5/6
ʋImportant information ........................ ............................................... 6
ʋOverview of programmes ........................................ ........................7
ʋSafety instructions ............................................................................. 8
ʋConsumption values ......................................................................... 8
ʋCare ................................................................................................. ....9
ʋInformation on the indicator lights ..................................... .............9
ʋMaintenance ... ................................................................................. 10
ʋWhat to do if... .................................................................................. 11
Protection of the environment/Conservation tips
– Always fill the washing machi ne with a maximum amount of
laundry for the relevant pr ogramme.
– Wash no rmally soiled laundry without a prewash.
– Instead of Cottons 90 °C, choose the programme
Cottons 60 °C wi th the ad ditional function jecoP erfect.
Comparable cleaning resu lt with significantly lower e nergy
consumption.
– Measure th e detergent according to the manufactur er's
instructions and water hardness .
– If the laundr y is then dried in the tumb le dryer, select the spin
speed according to t he instructions of the drye r manufacturer.
Preparation Before washing for the first time
Wash once without any l aundry –> page 9.
Setting and adjusting a programme
Spin
speed*
Programme selector Start/
Pause
Programme selector
for switching the
machine on and off
and for selecting the
programme. Can be
turned in either
direction.
Programmes
Detailed overview of programmes –> pa ge 7.
The spin speed can be selected i ndividually, irrespective of
the selected programme and p rogramme progress.
cCottons Hard-wearing fabrics
+  Prewash Hard-wearing fabrics, prewash at 30 °C
Mix D ifferent types of lau ndry
@Super 15’ Short programme
2Rinse/ cSpin Laundry washed by han d,
?c(Aqua Plus) button activated;
if only using the spin cycle, deac tivate
the button
CEmpty Drain rinsing water for c(without fin al
spin)
/ÿWool Hand/machine-washable woo l
Delicate/ Silk Delicate washable fabrics
IEasy-Care Easy-care fabrics
Additional functions and sp in
speeds –> Individual settings,
page 5.
Select Start/Pause
Washing
1
2
Washing
Detergent drawer with
compartments I,II,~Washing machine
door
Compartment ~c: fabric softe ner, starch
Compartment I: detergent for prewash
ʋFor domestic use only
ʋFor washing machine-wash able fabrics and hand-wash-
able wool in detergent solution
ʋTo be operated with cold drinking water an d commer-
cially available detergents a nd care products which are
suitable for use in washing m achines
.
– Do not leave children u nattended near the
washing machine.
– The washing machine is not to be used by
children or persons n ot familiar with the
operating instructions.
– Keep pets away from t he washing machine.
Dilute viscous fabric softener and fabric conditioner with water .
This prevents blockages.
Individual settings
ʑSpin speed in rpm/without final sp in –> m odel-dependent
Before and while the selected progra mme is running, the spin speed or (witho ut final spin,
laundry soaks in the last rinsing water) can be set. The effects depend on the programme
progress.
The maximum selectable spin s peed depends on the model a nd on which programme is
currently selected.
ʑAdditional functions –> and overview o f programmes, s ee page 7
ispeedPerfect For washing in a shorter tim e with a washing outcome com parable to
that of the standard progr amme. Maximum load –> O verview of
programmes, page 7.
jecoPerfect For saving energy with a washing performance compa rable to that of
the standard programme.
(Easy-iron) Spec ial spin sequence with subs equent fluffing. More gentle fin al spin
- residual moisture in the laundry slightly increas ed.
?c(Aqua Plus) Increased water level and addi tional rinse cycle, extended washing
time. For areas with very soft water or for further enhancing the spin
result.
ʑStart/Pause
For starting or interrupting the programme.
ʑSignal
1 step
2. Setting the
volume for...
1. Activate the
setting mode for
signal volume
Set to 1 step Press and
hold +Release
Button signals Information signals
Set to Setting the
volume**
Setting the
volume**
1 step
direct
** you may need to select the functio n several times.
1000
900
800
600
cccVisually
impaired mode*
ON-OFF
Option:
ON-OFF Set to *Short signal - fu nction on.
Long signal - funct ion off.
1 step
1000
900
800
600
ccc1000
900
800
600
ccc1000
900
800
600

Important information
Protecting the laundr y and the machine
– Empty pockets.
– Look out for m etal items (paperclips, etc.).
– Wash d elicates in a laundry bag (tights, curtains, u nderwired bras).
– Fasten zips , do up any buttons.
– Brush san d out of pockets and col lars.
– Remove c urtain fittings or place in the laundry b ag.
Laundry with varying deg rees of soiling
Wash new items of c lothing separately.
light Do not prewash. If requir ed, choose the additional fun ction
ispeedPerfect.
Pretreat any stains as nec essary.
intense Do not load as much laundry.
Choose a programme with Prewash .
Soaking Load laund ry of the same colou r
Pour soaking agent/detergent into compartment II in ac cordance with the manufactur er's
instructions. Turn the programme selector to cCottons cold and select S tart/Pause.
After approx. 10 minutes, pr ess Start/Pause, to pause the programm e. Once the required
soaking time has elapsed, pr ess Start/Pause, again to continue th e programme, or select
a different programme .
Starching Laundry mu st not be treated with fabric softener
Starching is possible in all w ash programmes if liquid star ch is used. Pour starch i nto the
fabric softener compartment in accordance with the manufacturer's instructions ~(rinse first
if necessary).
Dyeing/bleaching
Dye should only be used in normal household quantities. Salt may damage stainless steel.
Always follow the dye ma nufacturer's instructions. Do not use the washing machine for
bleaching clothes.
All buttons are sensitive and
need only to be touched
lightly.
If you press and hold the s pin
speed button, the applianc e
automatically cycles through
the setting options.
Additional
functions
3
Drum
Control panel
Service flap
Status
indicator
Removing the washing
Open the washing machine door and remove the washing.
If (without final spin) is active: Tu rn the programme
selector to CEmpty or select the spin s peed.
Select Start/Pause.
– Remove any foreig n objects - risk of rusting.
– Leave the washi ng machine door and detergent
drawer open so that any residu al water can
evaporate.
Turning the tap off
Not required for Aqua-Stop models – > refer to installation
instructions
Switching off
Turn the programme selector to Off .
(*model-dependent)

7
Overview of programmes –> refer to the table of consumption values on page 8 and notes on page 6.
Programmes °C max. Type of laundry Additional functions; information
cCottons cold, 40, 60, 90 °C 7 kg/
4 kg*
Hard-wearing fabrics, heat-resista nt fabrics made of cotton or linen ispeedPerfect*, jecoPerfect, (Easy-iron), ?c(Aqua Plus)
+

Prewash 40 °C
IEasy-Care cold, 40, 60 °C
3 kg
Easy-care fabrics made of cotton , linen, synthetic fibres or blended fabrics ispeedPerfect, jecoPerfect, (Easy-i ron),?c(Aqua Plus)
Mix 40 °C Fabrics m ade of cotton or easy-care fabrics ispeedPerfect, jecoPerfect, (Easy-i ron),?c(Aqua Plus);
different types of laundry can be washed together
Delicate/Silk cold
2 kg
For delicate, washable fabrics , e.g. made of silk, satin, synthetic fibres or blended fabrics (e.g. cur - tains) ispeedPerfect, jecoPerfec t, (Easy-iron), ?c(Aqua Plus):
No spin between rinse cycles
/ÿWool cold, 30 °C Handäor machine-washable fabrics ma de of wool or
containing wool
Particularly gentle wash programme to prevent shrinkage of laun- dry. Longer programme breaks (fab rics rest in the detergent solu- tion)
@Super 15’ 3 0 °C Easy-care fabrics made of cotton , linen, synthetic
fibres or blended fabrics
Short programme, approx. 15 minutes, suitable for lightly soiled laund ry
Additional programmes 2Rinse/ cSpin, CEmpt y
*Reduced load for additional ispeedPerfect fun ction
As a short programme,Mix 40 °C,with a maximum spin speed, i s ideal.
Programmes without prewash - add detergent to com partment II, programmes with prewash - distribute the detergent between compartments Iand II.
0811 / 9000697726 *697726* WM08E161HK
WM10E161HK ...
Siemens-Electrogeräte GmbH
Carl-Wery-Str. 34
81739 München / Deutschland
8
Safety instructions
– Read the instruction m anual and installation instructions and a ll other information enclosed
with the washing machin e and act accordingly.
– Retain the documents for subsequent use.
Risk of electric shock – Never pull the cable to disconnect the mains plu g.
– Never insert/disconnect the ma ins plug with damp hands.
Danger to life For worn-out appliances:
– Disconnect the m ains plug.
– Sever the m ains cable and discard alon g with the plug.
– Destroy the lock on the w ashing machine door. Th is will prevent
children from locking themsel ves in and risking their lives.
Danger of suffocation – Keep packagin g, film and packaging p arts out of the reach of
children.
Risk of poisoning – Keep detergents and care products out of the reach of chil dren.
Risk of explosion – Items of laundr y pretreated with cleaning agents containing
solvents, e.g. stain remover/cleaning s olvent may cause an
explosion after being loaded into the wa shing machine.
Rinse items of laundry th oroughly by hand beforeha nd.
Risk of injury – The wa shing machine door can become v ery hot.
– Be careful when dra ining hot detergent solution.
– Do no t climb onto the washing machine.
– Do not lean on the open washing machine d oor.
– Do no t reach into the d rum if it is still rotating.
– B e careful when opening the deterge nt drawer while the machine
is in operation.
Consumption values
Programme Additional function Load Electricity con-
sumption** Water** Programme
duration**
cCottons 40 °C 7 kg 0.69 kWh 60 l 2:36 h
cCottons 60 °C 7 kg 1.33 kWh 60 l 2:39 h
cCottons 60 ºC jecoPerfect*7 kg 1.05kWh 51 l 3:08 h
cCottons 90 °C 7 kg 2.00kW h 64 l 2:47 h
IEasy-Care 40 °C 3 kg 0.55 kWh 55 l 1:37 h
Mix 40 °C 3 kg 0.48 kWh 32 l 1:03 h
/ÿWool cold 2 kg 0.10 kWh 39 l 0:40 h
/ÿWool 30 °C 2 kg 0.19 kWh 39 l 0:40 h
* Programme setting with maximum spin speed for testing ac cording to or in accordance with IEC 60 456.
** The values deviate f rom the indicated values depending on wa ter pressure, water hardness, water inlet t emperature, room tempera-
ture, type and amount of washing and degree o fs oiling, utillised detergent, fluctuations in the mains voltage and selected a dditional
functions.
9
Care
Before washing for the first time
Do not load any laundry into th e machine. Turn on the tap.
Add the following to compar tment II:
– approx. 1 litr e water
– detergent ( dosage according to the manufacturer's instruction s for light soiling and the
appropriate degree of water hardnes s)
Set the programme selecto r to IEasy-Care 60 °C and select Start/Re load. At the end of
the programme, turn the programme selector to Off.
Machine housing, control panel
– Wipe with a soft, damp cloth.
– Do not use any abrasive cloths, scourers or cleaning agents (stainless steel c leaners).
– Remove detergent and cle aning agent residue immediately.
– Do not clean with a jet of water.
Cleaning the detergent drawer...
...if it contains detergent or fabr ic softener residues.
1. Pull out, press insert d own, remove draw completely.
2. To remove the insert: pre ss the insert upwards from below with your
finger.
3. Clean the detergen t dispenser tray and insert with wa ter and a brush and
dry it.
4. Attach the insert and engage (connect the cyl inder to the guide pin).
5. Push in the deterge nt drawer.
Leave the detergent drawer op en so that any residual water c an
evaporate.
Drum
Leave the washing machine doo r open so that the drum can dry out.
Rust stains - use chlorine-free c leaning agent, not steel wool.
Descaling Ensure t here is no laundry in the machine
Descale the appliance according to th e descaler manufacturer's instructions. This sh ould not
be necessary if the correct dosag e of detergent is used.
Information on the indicator lights model-dependent
A signal sounds and indicator lights for the spin speed flash:
¤
¤
¤
¤
¤
Close the washing
machine door properly;
laundry may be caught.
¤
¤
¤
¤
¤
Detergent solution pum p
blocked; Clean the
detergent solution pump
–> page 10.
Drainage hose/waste pipe
blocked; Clean the drain age
hose at the siphon
–> page 10.
¤
¤
¤
¤
¤
Open the tap compl etely,
supply hose kinked or
trapped;
Clean the filter
–> page 10,
Water pressure too low.
¤
¤
¤
¤
¤
Motor fault. Call the after-
sales service. ¤
¤
¤
¤
¤
Water in the base tub,
appliance leaking. Call the
after-sales service.
–Risk of electric shock. Disc onnect the
mains plug.
–Risk of explosion. No solvents .
10
Maintenance
Detergent solution pump
Turn the programme selector to Off a nd disconnect the mains plug.
1. Open and remove the servi ce flap.
2. For models with a drainage hose: Remove the draina geh ose from the retainer and pull it
from the housing. Remove the c ontainer.
Remove the sealing cap, allow the detergent solution to flow o ut.
Replace the sealing cap and p lace the drainage hose in the retainer.
2* For models without a drainage hose: Caref ully unscrew the pump cover until the
detergent solution begins to flow out. When the service flap is half full, close the pump cover
and empty the service flap. Repea t the above steps until all the detergent solution has
completely drained out.
3. Carefully unscrew the pump cover (residual water).
4. Clean the interior, pump cover threa d and pump housing (the impeller in the detergent
solution pump must r otate).
5. Replace the pump cover an d screw it in place tightly.
6. Place the service flap back on and close.
To prevent unused detergent fro m flowing straight into the drain during the next was h:Pou r 1 litre of water into
compartment II and start the CEmpty p rogramme.
Drainage hose at the siphon
Turn the programme selector to Off a nd disconnect the mains plug.
1. Loosen the hose clam p, carefully remove the drainage hose (residual water).
2. Clean the drainage hose and siphon connecting piece.
3. Reattach the drainag e hose and secure the connection with the hose cla mp.
Filter in the water supply
Risk of electric shock.
Do not immerse the HydroSafe safety device in water (contains a nelec tric valve).
Reduce the water pressure in the supply hose:
1. Turn off the tap.
2. Select any p rogramme (except for 2Rinse/ cSpin// CEmpty).
3. Select Start/Pause. Let the pr ogramme run for approximately 40 seconds.
4. Turn the programm e selector to Off. Disconnect the mains plug.
5. Clean the filter:
Disconnect the hose from the tap.
Clean the filter using a small b rush.
and/or for Standard and Aqua- Secure models:
Remove the hose on the rear of the appliance,
Remove the filter with pliers and clean.
6. Connect the hose an d check for leaks.
–Risk of scalding.
Allow the detergent s olution to cool down.
– T urn off the tap.
11
What to do if...
ʑWater is leaking out. – Attach/replace the drainage hose correctly.
– Tighten the screw con nection of the supply hose.
ʑNo water supply.
Detergent not dispensed.
–Start/Pause not selected?
– Tap not tu rned on?
– Filter blocked? Clean the filter –> page 10.
– Supply hose kinked or trapped?
ʑWashing machine door
cannot be opened.
– Safety function active . Wait approx. 2 minutes.
–(without final spin) selected? –> page 3, 4.
ʑProgramme does not
start.
–Start/Pause selected?
– Washing machine door clo sed?
ʑDetergent solution is not
drained.
–(without final spin) selected? –> page 3, 4.
– Clean the detergent solution pump –> p age 10.
– Clean the waste pipe an d/or drainage hose.
ʑWater not visible in the
drum.
– Not a fault - w ater below the visible are a.
ʑUnsatisfactory spin
result.
Laundry wet/too damp.
– Not a fault - the unbala nced-load detection system has cancelled
the spin cycle because of uneven distribution of the laundry.
Distribute small and l arge items of laundry ev enly inside the drum.
–(Easy-iron) selected –> page 5.
– Too low a sp eed selected? –> page 5 .
ʑSpin cycle performed
several times.
– Not a fault - unbalanced load detectio n system adjusts the
imbalance.
ʑResidual water in the
compartment for care
products.
– Not a fault - the action of the care product is not affected.
– Clean the insert if necessary –> page 9.
ʑOdour formation in the
washing machine.
– Run programme cCottons 90 °C without laundry. U se
standard detergent.
ʑþü(Wash) display lamp
flashes. Foam may
be coming out of th e
detergent drawer.
– Too much detergent used? Mix 1 tabl espoon of fabric softener
with ½ litre of water and pour into dispenser II (not for outdoor
and down-filled textiles!).
– Reduce the detergent d osage for the next wash cycle.
ʑIntense noise formation,
vibrations and “walking”
during the spin cycle .
– Are the appliance feet fixed?
Secure the appliance feet –> Insta llation instructions.
– Transportation safety d evices removed?
Remove the transportation s afety devices –> Installation
instructions.
ʑNoises during spin an d
drain cycles.
– Clean detergent-solution pump –> page 10.
ʑThe indicator lights do
not function during
operation.
– Power cut?
– Fuses tripped? Reset/c hange the fuse.
– If the fault occu rs repeatedly, call the a fter-sales service.
ʑProgramme sequence
longer than usual.
– Not a fault - unbalanced load detectio n system adjusts
imbalance by repeatedly dist ributing the laundry.
– Not a fault - foam detection system active - add s an additional
rinse cycle.
ʑDetergent residues on
the laundry.
– Occasionally, ph osphate-free detergents contain water-insoluble
residues.
– Select R inse/cSpin or brush out the laundry after wa shing.
If you cannot correct a fault y ourself (switching on/off) or a repai r is required:
– Turn the programme sele ctor to Off and remove the mains plu g from the socket.
– Turn off the water supply a nd call the after-sales service –> Installation instructions.
Instruction manual
Washing
machine
Observe the safety
instructions on
page 8.
en
Read these instructions an d the separate installation
instructions before oper ating the washing machine.

1 2
bEnd
Spin
Rinse
þWash bcc?cCCorrect installation according to the
separate Installation instructions.
Check the machine
– Never use a damaged machine.
– Inform the after-sales service.
Connect the mains plug
Make sure your hands are dry.
Take hold of the plug only.
Turn the tap on
Compartment II: detergent for the main wash, water softener,
bleach, stain remover
Close the washing machine door. Take care not to trap
Pour liquid detergent into the appropriate dispense
Your washing machine
Congratulations äyou have opted for a modern, high-quality
domestic appliance manufactured by Siemens. The washing
machine is distinguished by its economical water- and energy
consumption.
Each machine that leaves our factory has been inspected thoroughly
to ensure that it functions properly and is in perfect condition.
Further information: www.siemens-home.com
Environmentally friendly waste disposal All packaging must be disposed of in accordance with
environmental guidelines.
This appliance is certified in accordance with European Directive
2002/96/EEC on waste electrical and electronic equipment
(WEEE).
This directive provides the framework for the EU-wide collection and
reuse of used appliances.
Intended use
Contents Page
ʋIntended use .......................................................................................1
ʋProgrammes .......................................................................................1
ʋSetting and adjusting the programme ...........................................3
ʋWashing ...........................................................................................3/4
ʋAfter washing ......................................................................................4
ʋIndividual settings ..........................................................................5/6
ʋImportant information ....................................................................... 6
ʋOverview of programmes ................................................................ 7
ʋSafety instructions .............................................................................8
ʋConsumption values .........................................................................8
ʋCare .....................................................................................................9
ʋInformation on the indicator lights ..................................................9
ʋMaintenance .................................................................................... 10
ʋWhat to do if... .................................................................................. 11
Protection of the environment/Conservation tips
– Always fill the washing machine with a maximum amount of
laundry for the relevant programme.
– Wash normally soiled laundry without a prewash.
– Instead of Cottons 90 °C, choose the programme
Cottons 60 °C with the additional function jecoPerfect.
Comparable cleaning result with significantly lower energy
consumption.
– Measure the detergent according to the manufacturer's
instructions and water hardness.
– If the laundry is then dried in the tumble dryer, select the spin
speed according to the instructions of the dryer manufacturer.
Preparation
Spin
speed*
Programme selector
Programme selector
for switching the
machine on and off
and for selecting the
programme. Can be
turned in either
direction.
Programmes
Detailed overview of programmes –> page 7.
The spin speed can be selected individually, irrespective of
the selected programme and programme progress.
cCottons Hard-wearing fabrics
+  Prewash Hard-wearing fabrics, prewash at 30 °C
Mix Different types of laundry
@Super 15’ Short programme
2Rinse/ cSpin Laundry washed by hand,
?c(Aqua Plus) button activated;
if only using the spin cycle, deactivate
the button
CEmpty Drain rinsing water for c(without final
spin)
/ÿWool Hand/machine-washable wool
Delicate/ Silk Delicate washable fabrics
IEasy-Care Easy-care fabrics ~Compartment ~c: fabric softener, starch
Compartment I: detergent for prewash
ʋFor domestic use only
ʋFor washing machine-washable fabrics and hand-wash-
able wool in detergent solution
ʋTo be operated with cold drinking water and commer-
cially available detergents and care products which are
suitable for use in washing machines
.
– Do not leave children unattended near the
washing machine.
– The washing machine is not to be used by
children or persons not familiar with the
operating instructions.
– Keep pets away from the washing machine.
ʑʑij?cʑʑ
ccccccccc
ic~
All buttons are sensitive and
need only to be touched
lightly.
If you press and hold the spin
speed button, the appliance
automatically cycles through
the setting options.
Additional
functions
Status
indicator C(*model-dependent)

3 4
bþProgramme has ended when...
... Start/Pause flashes and the bindicator light comes
on.
Interrupting the programme
Programmes at high temperatures:
– Cool washing: Select Rinse/cSpin.
– Select Start/Pause.
Programmes at lower temperatures:
–Rinse/cSpin (deactivate ?c(Aqua Plus) button) or
select CEmpty.
– Select Start/Pause.
Changing the programme, if ...
... you have selected the wrong programme by mistake:
– Reselect the programme.
– Select Start/Pause. The new programme starts from
the beginning.
Sorting and loading laundry
Follow the manufacturer's care information.
According to the information on the care labels.
According to type, colour, soiling and temperature.
Do not exceed the maximum load –> page 7.
Observe the important information –> page 6.
Insert large and small items of laundry.
Close the washing machine door. Take care not to trap items of laundry
between the washing machine door and the rubber seal.
Add detergent and care products
Measure accordingly:
Amount of laundry, soiling, water hardness (ask your water supply
company) and manufacturer's instructions.
Pour liquid detergent into the appropriate dispenser and place in the drum.
äʋʋʋʋʋʋʋʋʋʋʋʋʋʋjBefore washing for the first time
Wash once without any laundry –> page 9.
Setting and adjusting a programme
Start/
Pause
c

@2c?cCc/ÿIAdditional functions and spin
speeds –> Individual settings,
page 5.
Select Start/Pause
Washing
1
2
Washing
Detergent drawer with
compartments I,II,~Washing machine
door
~cʋʋʋ
Dilute viscous fabric softener and fabric conditioner with water.
This prevents blockages.
ʑʑij?cʑʑ
ccccccccc
ic~
All buttons are sensitive and
need only to be touched
If you press and hold the spin
speed button, the appliance
automatically cycles through
the setting options.
Additional
functions
3
Drum
Control panel
Service flap
Removing the washing
Open the washing machine door and remove the washing.
If (without final spin) is active: Turn the programme
selector to CEmpty or select the spin speed.
Select Start/Pause.
– Remove any foreign objects - risk of rusting.
– Leave the washing machine door and detergent
drawer open so that any residual water can
evaporate.
Turning the tap off
Not required for Aqua-Stop models –> refer to installation
instructions
Switching off
Turn the programme selector to Off.

56
bþbcc?cC/Pause. The new programme starts from
äʋʋʋʋʋʋʋʋʋʋʋʋʋʋjc

@2c?cCc/ÿI~~cʋʋʋIndividual settings
ʑSpin speed in rpm/without final spin –> model-dependent
Before and while the selected programme is running, the spin speed or (without final spin,
laundry soaks in the last rinsing water) can be set. The effects depend on the programme
progress.
The maximum selectable spin speed depends on the model and on which programme is
currently selected.
ʑAdditional functions –> and overview of programmes, see page 7
ispeedPerfect For washing in a shorter time with a washing outcome comparable to
that of the standard programme. Maximum load –> Overview of
programmes, page 7.
jecoPerfect For saving energy with a washing performance comparable to that of
the standard programme.
(Easy-iron) Special spin sequence with subsequent fluffing. More gentle final spin
- residual moisture in the laundry slightly increased.
?c(Aqua Plus) Increased water level and additional rinse cycle, extended washing
time. For areas with very soft water or for further enhancing the spin
result.
ʑStart/Pause
For starting or interrupting the programme.
ʑSignal
1 step
2. Setting the
volume for...
1. Activate the
setting mode for
signal volume
Set to 1 step Press and
hold +Release
Button signals Information signals
Set to Setting the
volume**
Setting the
volume**
1 step
direct
** you may need to select the function several times.
1000
900
800
600
cccVisually
impaired mode*
ON-OFF
Option:
ON-OFF Set to *Short signal - function on.
Long signal - function off.
1 step
1000
900
800
600
ccc1000
900
800
600
ccc1000
900
800
600

Important information
Protecting the laundry and the machine
– Empty pockets.
– Look out for metal items (paperclips, etc.).
– Wash delicates in a laundry bag (tights, curtains, underwired bras).
– Fasten zips, do up any buttons.
– Brush sand out of pockets and collars.
– Remove curtain fittings or place in the laundry bag.
Laundry with varying degrees of soiling
Wash new items of clothing separately.
light Do not prewash. If required, choose the additional function
ispeedPerfect.
Pretreat any stains as necessary.
intense Do not load as much laundry.
Choose a programme with Prewash.
Soaking Load laundry of the same colour
Pour soaking agent/detergent into compartment II in accordance with the manufacturer's
instructions. Turn the programme selector to cCottons cold and select Start/Pause.
After approx. 10 minutes, press Start/Pause, to pause the programme. Once the required
soaking time has elapsed, press Start/Pause, again to continue the programme, or select
a different programme.
Starching Laundry must not be treated with fabric softener
Starching is possible in all wash programmes if liquid starch is used. Pour starch into the
fabric softener compartment in accordance with the manufacturer's instructions ~(rinse first
if necessary).
Dyeing/bleaching
Dye should only be used in normal household quantities. Salt may damage stainless steel.
Always follow the dye manufacturer's instructions. Do not use the washing machine for
bleaching clothes.
g.
C– Leave the washing machine door and detergent
–> refer to installation

7
Overview of programmes –> refer to the table of consumption values on page 8 and notes on page 6.
Programmes °C max. Type of laundry Additional functions; information
cCottons cold, 40, 60, 90 °C 7 kg/
4 kg*
Hard-wearing fabrics, heat-resistant fabrics made of cotton or linen ispeedPerfect*, jecoPerfect, (Easy-iron), ?c(Aqua Plus)
+

Prewash 40 °C
IEasy-Care cold, 40, 60 °C
3 kg
Easy-care fabrics made of cotton, linen, synthetic fibres or blended fabrics ispeedPerfect, jecoPerfect, (Easy-iron), ?c(Aqua Plus)
Mix 40 °C Fabrics made of cotton or easy-care fabrics ispeedPerfect, jecoPerfect, (Easy-iron), ?c(Aqua Plus);
different types of laundry can be washed together
Delicate/Silk cold
2 kg
For delicate, washable fabrics, e.g. made of silk, satin, synthetic fibres or blended fabrics (e.g. cur- tains) ispeedPerfect, jecoPerfect, (Easy-iron), ?c(Aqua Plus):
No spin between rinse cycles
/ÿWool cold, 30 °C Handäor machine-washable fabrics made of wool or
containing wool
Particularly gentle wash programme to prevent shrinkage of laun- dry. Longer programme breaks (fabrics rest in the detergent solu- tion)
@Super 15’ 30 °C Easy-care fabrics made of cotton, linen, synthetic
fibres or blended fabrics
Short programme, approx. 15 minutes, suitable for lightly soiled laundry
Additional programmes 2Rinse/ cSpin, CEmpty
*Reduced load for additional ispeedPerfect function
As a short programme,Mix 40 °C,with a maximum spin speed, is ideal.
Programmes without prewash - add detergent to compartment II, programmes with prewash - distribute the detergent between compartments Iand II.
0811 / 9000697726 *697726* WM08E161HK
WM10E161HK ...
Siemens-Electrogeräte GmbH
Carl-Wery-Str. 34
81739 München / Deutschland
8
Safety instructions
– Read the instruction manual and installation instructions and all other information enclosed
with the washing machine and act accordingly.
– Retain the documents for subsequent use.
Risk of electric shock – Never pull the cable to disconnect the mains plug.
– Never insert/disconnect the mains plug with damp hands.
Danger to life For worn-out appliances:
– Disconnect the mains plug.
– Sever the mains cable and discard along with the plug.
– Destroy the lock on the washing machine door. This will prevent
children from locking themselves in and risking their lives.
Danger of suffocation – Keep packaging, film and packaging parts out of the reach of
children.
Risk of poisoning – Keep detergents and care products out of the reach of children.
Risk of explosion – Items of laundry pretreated with cleaning agents containing
solvents, e.g. stain remover/cleaning solvent may cause an
explosion after being loaded into the washing machine.
Rinse items of laundry thoroughly by hand beforehand.
Risk of injury – The washing machine door can become very hot.
– Be careful when draining hot detergent solution.
– Do not climb onto the washing machine.
– Do not lean on the open washing machine door.
– Do not reach into the drum if it is still rotating.
– Be careful when opening the detergent drawer while the machine
is in operation.
Consumption values
Programme Additional function Load Electricity con-
sumption** Water** Programme duration**
cCottons 40 °C 7 kg 0.69 kWh 60 l 2:36 h
cCottons 60 °C 7 kg 1.33 kWh 60 l 2:39 h
cCottons 60 ºC jecoPerfect*7 kg 1.05 kWh 51 l 3:08 h
cCottons 90 °C 7 kg 2.00 kWh 64 l 2:47 h
IEasy-Care 40 °C 3 kg 0.55 kWh 55 l 1:37 h
Mix 40 °C 3 kg 0.48 kWh 32 l 1:03 h
/ÿWool cold 2 kg 0.10 kWh 39 l 0:40 h
/ÿWool 30 °C 2 kg 0.19 kWh 39 l 0:40 h
* Programme setting with maximum spin speed for testing according to or in accordance with IEC 60 456.
** The values deviate from the indicated values depending on water pressure, water hardness, water inlet temperature, room tempera-
ture, type and amount of washing and degree of soiling, utillised detergent, fluctuations in the mains voltage and selected additional
functions.
I
C2cCʑʑʑʑʑʑʑʑʑʑcʑþüʑʑʑʑʑc

cij?c

Iij?cij?cij?c/ÿä@2cCi
cccjcI/ÿ/ÿ
9
Care
Before washing for the first time
Do not load any laundry into the machine. Turn on the tap.
Add the following to compartment II:
– approx. 1 litre water
– detergent (dosage according to the manufacturer's instructions for light soiling and the
appropriate degree of water hardness)
Set the programme selector to IEasy-Care 60 °C and select Start/Reload. At the end of
the programme, turn the programme selector to Off.
Machine housing, control panel
– Wipe with a soft, damp cloth.
– Do not use any abrasive cloths, scourers or cleaning agents (stainless steel cleaners).
– Remove detergent and cleaning agent residue immediately.
– Do not clean with a jet of water.
Cleaning the detergent drawer...
...if it contains detergent or fabric softener residues.
1. Pull out, press insert down, remove draw completely.
2. To remove the insert: press the insert upwards from below with your
finger.
3. Clean the detergent dispenser tray and insert with water and a brush and
dry it.
4. Attach the insert and engage (connect the cylinder to the guide pin).
5. Push in the detergent drawer.
Leave the detergent drawer open so that any residual water can
evaporate.
Drum
Leave the washing machine door open so that the drum can dry out.
Rust stains - use chlorine-free cleaning agent, not steel wool.
Descaling Ensure there is no laundry in the machine
Descale the appliance according to the descaler manufacturer's instructions. This should not
be necessary if the correct dosage of detergent is used.
Information on the indicator lights model-dependent
A signal sounds and indicator lights for the spin speed flash:
¤
¤
¤
¤
¤
Close the washing
machine door properly;
laundry may be caught.
¤
¤
¤
¤
¤
Detergent solution pump
blocked; Clean the
detergent solution pump
–> page 10.
Drainage hose/waste pipe
blocked; Clean the drainage
hose at the siphon
–> page 10.
¤
¤
¤
¤
¤
Open the tap completely,
supply hose kinked or
trapped;
Clean the filter
–> page 10,
Water pressure too low.
¤
¤
¤
¤
¤
Motor fault. Call the after-
sales service. ¤
¤
¤
¤
¤
Water in the base tub,
appliance leaking. Call the
after-sales service.
–Risk of electric shock. Disconnect the
mains plug.
–Risk of explosion. No solvents.
10
Maintenance
Detergent solution pump
Turn the programme selector to Off and disconnect the mains plug.
1. Open and remove the service flap.
2. For models with a drainage hose: Remove the drainage hose from the retainer and pull it
from the housing. Remove the container.
Remove the sealing cap, allow the detergent solution to flow out.
Replace the sealing cap and place the drainage hose in the retainer.
2* For models without a drainage hose: Carefully unscrew the pump cover until the
detergent solution begins to flow out. When the service flap is half full, close the pump cover
and empty the service flap. Repeat the above steps until all the detergent solution has
completely drained out.
3. Carefully unscrew the pump cover (residual water).
4. Clean the interior, pump cover thread and pump housing (the impeller in the detergent
solution pump must rotate).
5. Replace the pump cover and screw it in place tightly.
6. Place the service flap back on and close.
To prevent unused detergent from flowing straight into the drain during the next wash: Pour 1 litre of water into
compartment II and start the CEmpty programme.
Drainage hose at the siphon
Turn the programme selector to Off and disconnect the mains plug.
1. Loosen the hose clamp, carefully remove the drainage hose (residual water).
2. Clean the drainage hose and siphon connecting piece.
3. Reattach the drainage hose and secure the connection with the hose clamp.
Filter in the water supply
Risk of electric shock.
Do not immerse the HydroSafe safety device in water (contains an electric valve).
Reduce the water pressure in the supply hose:
1. Turn off the tap.
2. Select any programme (except for 2Rinse/ cSpin// CEmpty).
3. Select Start/Pause. Let the programme run for approximately 40 seconds.
4. Turn the programme selector to Off. Disconnect the mains plug.
5. Clean the filter:
Disconnect the hose from the tap.
Clean the filter using a small brush.
and/or for Standard and Aqua-Secure models:
Remove the hose on the rear of the appliance,
Remove the filter with pliers and clean.
6. Connect the hose and check for leaks.
–Risk of scalding.
Allow the detergent solution to cool down.
– Turn off the tap.
ʑʑʑʑʑʑʑʑʑʑcʑþüʑʑʑʑʑc

cij?c

Iij?cij?cij?c/ÿä@2cCi
cccjcI/ÿ/ÿIC2cC
11
What to do if...
ʑWater is leaking out. – Attach/replace the drainage hose correctly.
– Tighten the screw connection of the supply hose.
ʑNo water supply.
Detergent not dispensed.
–Start/Pause not selected?
– Tap not turned on?
– Filter blocked? Clean the filter –> page 10.
– Supply hose kinked or trapped?
ʑWashing machine door
cannot be opened.
– Safety function active. Wait approx. 2 minutes.
–(without final spin) selected? –> page 3, 4.
ʑProgramme does not
start.
–Start/Pause selected?
– Washing machine door closed?
ʑDetergent solution is not
drained.
–(without final spin) selected? –> page 3, 4.
– Clean the detergent solution pump –> page 10.
– Clean the waste pipe and/or drainage hose.
ʑWater not visible in the
drum.
– Not a fault - water below the visible area.
ʑUnsatisfactory spin
result.
Laundry wet/too damp.
– Not a fault - the unbalanced-load detection system has cancelled
the spin cycle because of uneven distribution of the laundry.
Distribute small and large items of laundry evenly inside the drum.
–(Easy-iron) selected –> page 5.
– Too low a speed selected? –> page 5.
ʑSpin cycle performed
several times.
– Not a fault - unbalanced load detection system adjusts the
imbalance.
ʑResidual water in the
compartment for care
products.
– Not a fault - the action of the care product is not affected.
– Clean the insert if necessary –> page 9.
ʑOdour formation in the
washing machine.
– Run programme cCottons 90 °C without laundry. Use
standard detergent.
ʑþü(Wash) display lamp
flashes. Foam may
be coming out of the
detergent drawer.
– Too much detergent used? Mix 1 tablespoon of fabric softener
with ½ litre of water and pour into dispenser II (not for outdoor
and down-filled textiles!).
– Reduce the detergent dosage for the next wash cycle.
ʑIntense noise formation,
vibrations and “walking”
during the spin cycle.
– Are the appliance feet fixed?
Secure the appliance feet –> Installation instructions.
– Transportation safety devices removed?
Remove the transportation safety devices –> Installation
instructions.
ʑNoises during spin and
drain cycles.
– Clean detergent-solution pump –> page 10.
ʑThe indicator lights do
not function during
operation.
– Power cut?
– Fuses tripped? Reset/change the fuse.
– If the fault occurs repeatedly, call the after-sales service.
ʑProgramme sequence
longer than usual.
– Not a fault - unbalanced load detection system adjusts
imbalance by repeatedly distributing the laundry.
– Not a fault - foam detection system active - adds an additional
rinse cycle.
ʑDetergent residues on
the laundry.
– Occasionally, phosphate-free detergents contain water-insoluble
residues.
– Select Rinse/cSpin or brush out the laundry after washing.
If you cannot correct a fault yourself (switching on/off) or a repair is required:
– Turn the programme selector to Off and remove the mains plug from the socket.
– Turn off the water supply and call the after-sales service –> Installation instructions.
Instruction manual
Washing
machine
Observe the safety
instructions on
page 8.
en
Read these instructions and the separate installation
instructions before operating the washing machine.
