Sienna SSP-4015 User manual

Turbo & Turbo Max
Steam Presses
SSP-4015 & SSP-5015
INSTRUCTION MANUAL

2
INTRODUCTION
Thank you for choosing Sienna for your household pressing needs. With our consumers
in mind, we have created steam press products that provide an affordable way to have
a professional look without draining your wallet. You have begun the first step into
saving time and money on trips to the cleaners. Our steam press provides a clean;
quality look with a substantially larger pressing surface larger than most hand-held
irons. It boasts over 100 lbs. of even pressure to ensure sharp, long lasting creases.
Our non stick coating on our pressing plate reduces starch build-up to ease cleaning.
Our steam presses provide a locking handle making it portable and easy to store upright.
Please visit our website at www.siennadirect.com to view our whole line of Sienna
products.
Turbo
The Turbo is 8 times larger than the size of a traditional iron allowing you to press your
items in half the time. The automatic vacuum suction feature under the ironing board
sucks the steam through fabric when initiated by the burst of steam button. It features
an LED digital touch screen control panel for more customized pressing and an adjustable
steam control dial that allows you to control the amount of steam you use on your garments.
Choose between silk, polyester, wool, cotton and linen to satisfy your pressing needs. It
features a 16.91 floz water tank and can reach a maximum temperature of 419° F. It also
has an auto shut-off feature of you forget to turn off your press.
Turbo Max
The Turbo Max has all the same functionalities as the Turbo with a larger surface area
which is more than 10 times the size of a traditional iron.

3
SAFETY GUIDELINES
The Turbo (SSP-4015) and Turbo Max (SSP-5015) Steam Presses are for indoor
domestic use only. Any commercial use will void warranty. They are designed for
pressing garments and not intended for any other use.
Safety Instructions:
WARNING: Be sure to read and follow all safety instructions before using
your steam press. Proper care and maintenance will help to expand the life of
your press.
When using an electrical appliance, basic precautions should always be followed. To
reduce the risk of fire, electric shock, or injury:
• Be sure to unplug the electrical cord when appliance is not in use and while servicing.
• Do not leave the press unattended while young children, pets or infirm persons are
around.
• Be sure to place the press on a secure level surface when in use.
• Children should be supervised and cautioned that the press is not a toy and should
not be played with.
• Do not immerse the press in water or other liquids.
• Do not handle press with wet hands.
• Do not pull power cord to disconnect appliance from socket or use cord as a handle.
• Be sure to keep cord away from heat, water, and sharp edges.
• Do not use if cord or plug is damaged.
• Do not use extension cords or outlets with inadequate current carrying capacity.
• Use only as described in manual. Operating unit in any way other than recommended
may result in damage to unit or injury to operator.
• Do not disassemble unit or attempt to make any repairs yourself. Incorrect assembly or
repair could result in a risk of fire, electric shock, or injury to persons when operating.
• Stop using press if circuit breaker activates. Beware of risk of shock.
• Always allow your press to cool down for at least 30 minutes before storing in a
cool, dry place.

4
TURBO & TURBO MAX KEY FEATURES
A. FABRIC TEMPERATURE SELECTION ARROWS
B. LOCKING KNOB (USE WHEN STORING)
C. ADJUSTABLE STEAM CONTROL DIAL
D. LED ILLUMINATING LIGHT BUTTON
E. POWER ON/OFF BUTTON
F. STEAM READY LIGHT
G. HEATING INDICATOR LIGHT
H. POWER ON INDICATOR LIGHT
I. PRESSING HANDLE
J. STEAM BURST BUTTON
K. PRESSING PLATE
L. IRONING BOARD COVER
M. IRONING BOARD
N. WATER TANK
O. WATER CONTAINER
P. SPRAY BOTTLE
Q. PRESSING CUSHION D
QP O
E
A
HG F
A
430mMAX
MIN
l
430ml
430ml
B
C
K
L
M
N
I
J

5
ASSEMBLY AND USE
1) Set press on a flat, level surface.
Warning: The automatic vacuum suction will force the air thru the ironing
board and out the back of the press leaving your surface area moist and
wet. It is recommended that you place the press on a surface that will not
be affected by the moisture. For example, avoid using press on wood or
laminate surfaces where the steam and moisture may damage the finish.
NOTE: It is recommended to use a pressing stand when using your steam press.
2) Gently press handle (I) down, turn locking knob (B) to “unlock” position, then lift
handle (I) to open press. The press will automatically stay in lifted position.
3) Before plugging in the press, fill the water tank (N) using the water container (O)
provided. Slide the water tank (N) forward and pouring the water into the holes
of the tank. When finished, slide the tank back into place. Water is only necessary
when using steam burst button (J).
430m
MAXl
430ml
430ml
NOTE: When filling the water tank, distilled water is preferred, but not necessary.
NOTE: The water tank is not removable. It is designed to store any left over water
from use. Do not attempt to force it free.
4) Plug in and press power on/off button (E) located on the LED digital touch screen
control panel. A power on indicator light (H) will appear. Be sure pressing plate (K)
is in open position when unit is initially turned on.
5) Use fabric temperature selection arrows (A) to choose fabric setting. It may take a
few minutes to reach chosen temperature when decreasing or increasing settings.
NOTE: It takes approximately 12 minutes for the press to reach the linen temperature.
23

6
Warning: During initial use or after a long period of time without use, press
the steam burst button continuously for several seconds to clear pressing plate
of residual water or calcium buildup in system before use.
CAUTION: Be sure to examine garment label before selecting a fabric setting. If
you cannot determine a fabric type, select lowest setting and increase as needed. It
is best to start with the most delicate fabrics first to avoid damage to your fabric.
6) A single beep will sound once press has reached desired temperature allowing you to
start pressing. Be sure to use provided pressing cushion (Q) to flatten out gathered
areas such as sleeves, darts and yokes. If needed, use spray bottle (P) for dampening
fabric before pressing.
7) Pull down pressing handle (I) and press the pressing plate (K) and the ironing
board (M) together. Hold for a few seconds, then lift to separate the pressing plate
(K) and ironing board (M).
IMPORTANT: Press on/off button to cancel your selected pressing cycle.
8) To use steam, adjust the fabric temperature selection arrows (A) to the wool, cotton
or linen settings. The steam ready light (F) (yellow) will appear when and you will be
able to press the steam burst button (J) for steaming your garments.
9) Pull down pressing handle directly above garments about 1 to 2 inches above fabric
and press steam burst button (J). Press garment. DO NOT activate steam burst button
(J) with unit completely closed; you may damage your press. An automatic vacuum
will initiate once the steam burst button (J) is pressed and will stay on for 5 seconds
after the steam burst button (J) is released.
7

7
10) Use adjustable steam control dial (C) to control the amount of steam, low to high,
you use.
CAUTION: Do not hold down press for longer than 5 seconds. If using
steam burst button, do not fully close press down onto fabric. If you hold
down the press for too long, you may cause your garments to wrinkle because
they are too hot. If this should happen, spray down garment with water and
start over.
CAUTION: When using steam, do not hold steam button for longer than
3 seconds. If steam is used for too long, you will cause the press to drop
dramatically in temperature and will have to wait for it to reach the initial
desired setting. The drop in temperature cannot be avoided as the burst
of steam cools down the pressing plate instantly. By using steam in short
bursts, you will help to eliminate the dramatic temperature drop and thus
be able to press quicker and more efficiently.
Auto Shut-off and Auto Wake-Up:
E1: A warning beep will signal if the pressing plate is left in a closed position against
the ironing board for more than 10 seconds. The press will stop heating and the auto
shut-off feature will initiate unless the pressing plate is restored to the lifted position.
The auto wake-up feature will then kick in. In some cases, you will need to either turn
press off and then on again or unplug then re-plug the unit in to reset function.
CAUTION: Do not lock pressing plate and ironing board together as press
will begin to beep. Only lock when storing.
E2: A warning beep will signal if the press is left unattended without use for approximately
20 minutes. The press will stop heating and auto shut-off feature will engage. In order
to restore use, simply press on/off button or press temperature control buttons to reset
press.
E3: A warning beep caused by a loose thermostat inside the machine.
CAUTION: If the E3 warning occurs, unplug your press and call customer
service for warranty assistance.
Warning: During initial use or after a long period of time without use, press
the steam burst button continuously for several seconds to clear pressing
9

8
plate of residual water or calcium buildup in system before use.
NOTE: Some garments have details such as darts, curved seams, and shoulder pads
which should not be pressed flat. Use pressing cushion provided for use in these areas.
Warning: Do not attempt to lower the pressing plate to its lowest position
or lock the press with the pressing cushion in between. You may damage your
press by doing so.
BASIC IRONING
Tablecloth:
Fold the length of fabric in either half or thirds and place on
the ironing board.
Accordion pleat the length on the ironing board and move
the pleated item into the large open space behind the ironing
board.
Move the tablecloth towards you, then press.
Continue moving forward until the entire item is pressed.
To store, fold it, place it on the ironing board and close the
press. Apply minimal pressure. If necessary, refold the
tablecloth to press any areas that were hanging off the
sides of the ironing board. Repeat the pressing procedure.
Hint: Use the same method for most large items, such as duvet covers, bed sheets,
pillowcases, table runners, towels, blankets, quilts, etc.
Pants:
Waistband- Place the top of pants on the press. Press the
pressing board down over the pants to the ironing board.
If using pressing cushion, place the waistband of the pants
around the board on top of cushion. Arrange pleats. Rotate
pants to press entire waistband.
Side Pockets- Slide pockets over the pressing cushion over
the pressing board then press.

9
Crotch Area- Place the inside of the crotch area on the
board facing up. Align with the slanted left side of the
board. Press.
Legs- Place top of pant leg half way on the ironing board.
Press front crease. Then, place bottom of the pant leg half
way on the ironing board. Allow the hem or cuff to hang
off the end of the board. Press. Follow the same method for
pressing back crease.
Note: The hems of the pants can be pressed by placing them both on the ironing board
and applying a small amount of pressure.
Shirt and Blouses:
Yoke- Arrange the shoulders around the slanted left side of the board. Let the collar
hang off the edge. Press.
Cuffs- Place the cuffs and plackets around the edges of the ironing cushion. Arrange
any pleats. Press.
Sleeves- Place the garment to the left side of the press
with the collar towards you. Place the first sleeve on the
ironing board with the curve of the garment fitted to the
slanted left side of the board (the second sleeve will lay in
front of the press off the board). Press. Remove first sleeve
and place second sleeve on the board. Press.
Body- Put the sleeves together and fold the shirt in half. Place it at the back of the
ironing board away from you, extending the sleeves behind the board on the right. Bring
the shirt front with the buttons forward first. With your right hand, hold the collar so that
the curved edge of the neck opening is flat against the ironing board. Do not release the
collar until you have lowered the pressing plate. Press. Keep pulling the shirt forward until
you have worked the whole way around.
Collar- Place the collar on the board, spray and press. Fold
the collar in half, spray then press.
Shirt Tail- Button the garment and place shirt tail squarely
on the ironing board. Press. Hang the shirt on a hanger, or
fold it. It is a good idea to let it cool before folding. Use the
ironing cushion to retouch any area.
Hint: Use this same procedure on other fitted garments such as blouses, fitted shirts,
jackets, etc.
T-shirt:
Place t-shirt flat on the ironing board. Depending on shape, begin with the sleeves.
Note: If your t-shirt has rhinestones or an application on it, press with decorated side

10
face down on the board or turn it inside out.
Pleated Skirt:
Place pressing cushion under waistband and press. Rotate skirt until entire waistband is
pressed.
Slip the skirt over the board. Arrange the pleats. Press. Pleats may need to be pinned
to the ironing board cover. Do not use plastic head pins when using the press. Rotate
skirt until all pleats are pressed.
Jacket:
Sleeves without creases- Fold the sleeve on the seam line and place the seam line flat
on the board. Allow the top edge of the sleeve to hang off the edge of the board. Press.
Lapels- Place lapels flat, diagonally on the ironing board. Press. Use ironing cushion if
needed.
Ties and Ribbons:
Place the tie lengthwise on the board. Press. You can also
place them horizontally on the board and close the press
them pull tie or ribbon through it.
Embroidery items:
Place garment face down on ironing board to reduce wear and prevent damage.
If needed, place a towel over the garment then press. This will protect stitching,
rhinestones, etc.
CAUTION: When ironing embroidered, stitched items or garments with
rhinestones, sample an area to see if the steam or heat will affect the area
and proceed with caution.
STORING AND MAINTENANCE
CAUTION: Prior to storing or maintaining your steam press, isolate the unit
by removing the cord from the power socket and avoid immersing the unit in
water.
1) Water may be left in water tank reservoir; however, it is recommended that if the
machine will be stored for a long period of time, any left over water in the unit
should be drained by pressing the steam burst button before the end of use until
the water tank is emptied.
2) Wait approximately 30 minutes for press to cool down before storing. Once cooled,
lower the pressing plate onto the ironing board; pull down pressing handle completely,
then turn locking knob to “locked” position.
3) Wipe steamer with soft cloth when/if necessary.
4) Store in a cool, dry place.

11
CLEANING
1) Fill water tank using water container provided.
2) Place the pressing cushion in the center of the ironing board.
430m
MAXl
430ml
430ml
3) Place a clean towel over the pressing cushion and the ironing board.
4) Set the fabric temperature selection control to the highest setting (Linen). When
the steam light illuminates, gently lower the pressing plate onto the pressing
cushion.
5) Press the steam burst button 6 to 7 times. Be careful to avoid touching the hot
metal surfaces and avoid leaving hands under ironing pressing when using the
steam burst button.
12
4
5

12
6) Once the pressing plate has cooled down you can clean the surface with a damp
cloth. DO NOT use any abrasives on the pressing plate. This pressing plate has a
non-stick coating that will assist in cleaning.
7) The ironing board cover is removable and can be rinsed with mild detergent
and warm water. You may purchase replacement covers on our website at:
www.siennadirect.com.
Product Specs:
TURBO TURBO MAX
Voltage supply: 120, 60 Hz Voltage supply: 120, 60 Hz
Output: 1600 W Output: 1600 W
Water capacity: 16.91 floz Water capacity: 16.91 floz
Cord: 7 ft. Cord: 7 ft.
Weight: 29.75 lbs. Weight: 36.4 lbs.
CUSTOMER SUPPORT
For problems with your steam press, please refer to Troubleshooting guide.
Additional inquiries should be directed to our Customer Service department by
calling 1-888-574-3662 or by
e-mail to: [email protected].
7

13
TROUBLESHOOTING
CAUTION: Prior to using or maintaining your steam press, isolate the unit
by removing the cord from the power socket.
PROBLEM SOLUTION
LED is not on
• Ensure press power cord is correctly plugged into a 120V
AC power outlet only.
• Ensure circuit breaker is operational.
• Try operating press from another power outlet.
No heat
• Make sure temperature has been selected.
• Pressing plate has been left in raised position for more than
20 minutes and automatic shut-off has engaged.
No steam
• Water may be low, refill water tank.
• Temperature setting is too low to activate steam. Select
a higher temperature and wait for ready light to illuminate
before steaming.
Buttons are not working
properly
• Unplug the unit from the power outlet for 5 minutes then
plug back in.
E1 Warning
• The pressing plate and ironing board have been held
together for too long. Separate the plate from the board
and either unplug your unit then plug back in or turn the
press off then on again to restart the unit.
E2 Warning
• Automatic shut off feature warning. If the press is left for
too long unused, a beep and warning will appear. After 20
minutes of no use, the press will automatically shut off.
E3 Warning • There is a loose wire in the thermostat. Unplug your press
and call customer service.
Steam burst output is
weak
• Pressing plate needs to be cleaned. Refer to cleaning section
of the manual for proper procedure.

14
ONE YEAR LIMITED WARRANTY
Our Sienna product warranty extends only to the original customer purchaser
of the product. It is warranted by the manufacturer to be free from all
defects in materials or workmanship for a period of one year from the date
of original purchase. This warranty is subject to the following conditions,
exclusions and exceptions.
Exclusions:
This warranty does not cover normal wear and tear of parts and does not
apply to any product that has been tampered with or used for commercial
purposes. This warranty does not cover damage cause by misuse, abuse
or negligent handling or damage due to mishandling in transit or shipping.
This warranty does not cover damage or defects caused by or resulting from
repairs, service or alterations to the product or any of its parts, which have
been performed by a repair person not authorized by the manufacturer. This
warranty is effective only if the product is purchased and operated in the
USA, and does not extend to any units which have been used in violation of
written instructions furnished by the manufacturer, or to units which have had
the serial number removed, altered, defaced or rendered illegible.
Performance:
During the limited warranty period, the manufacturer will, at its option, repair
or replace free of charge a defective product or part that is covered by this
warranty. As a matter of warranty policy, the manufacturer will not refund
the purchase price. A repaired or replacement product will be covered by this
warranty for the balance of the initial one year warranty period.
To contact Customer Service:
Write: Anvid Products, Inc.
1401-1499 Greenville Rd.
Livermore, CA 94550
E-mail: [email protected]
Call: 1-888-5SIENNA (1-888-574-3662)
Please refer to your product name and model number when contacting
Customer Service.

15
Customer Service will give you further instructions for returning a defective product.
When returning a defective product, carefully pack the item to avoid damage in
shipping, the manufacturer cannot assume responsibility for loss or damage during
incoming shipment. Be sure to include the following items with your product: any
accessories related to the product, completed warranty form, and a copy of your sales
receipt or other proof of purchase to determine warranty status. C.O.D. shipments
cannot be accepted.
Limitations of Remedies: No representative or person is authorized to assume for
the manufacturer any other liability in connection with the sale of our products. This
limited warranty is not transferable and any sale, transfer or other disposition of the
product voids this limited warranty. There shall be no claims for defects or failure of
performance or product failure under any theory of tort, contract or commercial law
including, but not limited to, negligence, gross negligence, strict liability, breach of
warranty and breach of contract.
ANY IMPLIED WARRANTIES, OBLIGATIONS, OR LIABILITIES, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION
OF THIS WARRANTY. Some states do not allow limitations on how long an implied
warranty lasts, so the above limitations may not apply to you.
REPAIR OR REPLACEMENT SHALL BE THE SOLE REMEDY OF THE
PURCHASER UNDER THIS LIMITED WARRANTY, AND IN NO EVENT SHALL
THE MANUFACTURER BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES, LOSSES OR EXPENSES YOU MAY INCUR IN
CONNECTION WITH YOUR PURCHASE OR USE OF THE PRODUCT OR FOR
ANY BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED,
WHATSOEVER. Some states do not allow exclusion or limitation of special, incidental,
or consequential damages, so the above limitation may not apply to you. This limited
warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the US. To prevent possible harm to
the environment or human health from uncontrolled waste disposal, we
recommend recycling it responsibly to promote the sustainable reuse of
material resources. To dispose of your used device, please contact your
local city for proper disposal locations.
Copyright © 2015 Anvid Products, Inc. Made in China ●Printed in China

16
