SIGLENT TECHNOLOGIES SDG1000X Series User manual

SDG1000X Service Manual I
SDG1000X Series
Function/Arbitrary Waveform Generator
Service Manual
SM0201X-E01B

Guaranty and Declaration
Copyright
SIGLENT TECHNOLOGIES CO., LTD. All Rights Reserved.
Trademark Information
SIGLENT is the registered trademark of SIGLENT TECHNOLOGIES CO.,
LTD
Declaration
⚫SIGLENT products are protected by patent law in and outside of P.R.C.
⚫SIGLENT reserves the right to modify or change parts of or all the
specifications or pricing policies at company’s sole decision.
⚫Information in this publication replaces all previously corresponding
material.
⚫Any form of copying, extracting or translating the contents of this manual is
not allowed without the permission of SIGLENT.
⚫SIGLENT will not be responsible for losses caused by either incidental or
consequential in connection with the furnishing, use or performance of this
manual as well as any information contained.
Product Certification
SIGLENT guarantees this product conforms to the national and industrial
standards in China as well as the ISO9001: 2008 standard and the ISO14001:
2004 standard. Other international standard conformance certification is in
progress.

SDG1000X_ServiceManual_SM0201X-E01B.docx
III
General Safety Summary
Carefully read the following safety precautions to avoid any personal injuries or damages
to the instrument and any product connected to it. To avoid potential hazards, please use
the instrument as specified.
Only qualified technical personnel should service this instrument.
Avoid fire or open flame.
Use properly rated power line connections.
Use only the specified power line which has been approved by your local regulatory agency.
Ground the Instrument.
The instrument is grounded through the protective ground conductor of the power line. To
avoid electric shock, the ground conductor must be connected to the earth ground. Make
sure the instrument is grounded correctly before connecting its input or output terminals.
Connect the signal wire correctly.
The potential of the signal wire ground is equal to the earth, therefore do not connect the
signal wire to a high voltage. Do not touch the exposed contacts or components.
Observe all terminal ratings.
To avoid fire or electric shock, please observe all ratings and label instructions on the
instrument. Before connecting the instrument, please read the manual carefully to gain
more information about the ratings.
Do not operate with suspected failures.
If you suspect that the product is damaged, please allow only qualified service personnel
to troubleshoot and repair it.
Avoid circuit or wire exposure.
Do not touch exposed contacts or components when the power is on.
Do not operate in wet/damp conditions.
Do not operate in an explosive atmosphere.
Keep the surface of the instrument clean and dry.
Safety Terms and Symbols
Terms used on the instrument. Terms may appear on the instrument:
DANGER: Indicates an injury or hazard that may immediately happen.
WARNING: Indicates an injury or hazard that may not immediately happen.
CAUTION: Indicates that a potential damage to the instrument or other property might
occur.
Symbols used on the instrument. Symbols may appear on the instrument:
Hazardous Protective Warning Chassis Power
Voltage Earth Ground Ground Switch

Catalog
Guaranty and Declaration....................................................................................................II
General Safety Summary ...................................................................................................III
Overview of this Document................................................................................................ VI
The SDG1000X Series Generator at a Glance ............................................................... VIII
The Front Panel at a Glance.............................................................................................. IX
The Rear Panel at a Glance ............................................................................................. XII
Chapter 1 Quick Start ...................................................................................................13
To Prepare the Generator for Use .....................................................................................14
To Adjust the Carrying Handle............................................................................................15
To Set the Output Frequency..............................................................................................16
To Set the Output Amplitude...............................................................................................18
To Set the DC offset.............................................................................................................19
To Set the Duty Cycle of a Square Waveform..................................................................21
To Set the Symmetry of a Ramp Waveform.....................................................................23
To Generate a Pulse Waveform .........................................................................................25
To Generate a Noise Waveform.........................................................................................28
To Set the DC Voltage .........................................................................................................30
To Output a Built-In Arbitrary Waveform ...........................................................................32
To Use the Built-In Help System ........................................................................................34
Chapter 2 Performance Verification..............................................................................35
Performance Verification Test.............................................................................................35
DC Output Verification.........................................................................................36
AC Amplitude Verification....................................................................................37
Frequency Response Verification .......................................................................38
Chapter 3 Assembly Procedures..................................................................................39
Security Consideration.........................................................................................................39
List of Modules......................................................................................................................40
Required Tools ......................................................................................................................40
Disassembly Procedures.....................................................................................................41
Chapter 4 Troubleshooting...........................................................................................46
ESD Precautions ..................................................................................................................46
Required Equipment ............................................................................................................46
Channel Board Drawing ......................................................................................................47
Main Board Drawing ............................................................................................................48
Check the Power Supply.....................................................................................................49
Check the Channel Board...................................................................................................51
Voltage Checking ................................................................................................51
25 MHz Clock Source Checking .........................................................................52
FPGA Checking...................................................................................................52
Connector Checking............................................................................................52
Check the Main Board .........................................................................................................53
Voltage Verification..............................................................................................53

SDG1000X_ServiceManual_SM0201X-E01B.docx
V
Main Board Clock Verification .............................................................................53
ARM CPU System Verification............................................................................54
Connector Verification .........................................................................................54
Quick Guide for General Failures ......................................................................................55
Chapter 5 Maintenance.................................................................................................56
Maintenance Summary........................................................................................................56
Repackaging for Shipment..................................................................................................56
Contact SIGLENT.................................................................................................................57

Overview of this Document
This document is for the SDG1000X Series Function/Arbitrary Waveform
Generators, which will be mostly referred to “the generator” for short in the
following text. The main contents described in this manual are:
The SDG1000X Series Generator at a Glance
This part introduces the main technology characteristics for the SDG1000X
generator.
The Front Panel at a Glance
This section introduces briefly all of the buttons and the knob on the front panel.
The Rear Panel at a Glance
This section introduces the available ports and connectors located on the rear
panel.
Quick Start
Chapter 1 describes prepare the generator for use and helps you get familiar
with a few of its front-panel features.
Calibration
Chapter 2 Performance verification
Assembly Procedures
Chapter 3 provides disassembly procedures to help in gaining an
understanding of the structure of the generator in preparing to install or replace
any needed modules, or troubleshoot faults that might be encountered during
operation.
Troubleshooting
Chapter 4 provides troubleshooting procedures for the internal circuit boards,
as well as a quick guide for solving general problems. Before any operation,
please read the ESD Precautions to avoid personal injury or damage to the
generator.
Maintenance
Chapter 5 provides information on maintenance, daily care and unpacking
inspection of the instrument. Contact information is included at the end of the
chapter in case more support is required.

SDG1000X_ServiceManual_SM0201X-E01B.docx
VII
The Different SDG1000X Models Addressed by this Manual
All the description for function and performance in this document are according
to the SDG1062X series generator, and apply to other models. The SDG1000X
series contains the following models:
Type
Bandwidth
Channels
SDG1032X
30 MHz
2
SDG1062X
60 MHz
2

SDG1000X_ServiceManual_SM0201X-E01B.
docx
VIII
The SDG1000X Series Generator at a Glance
SIGLENT’s SDG1000X is a series of dual-channel function/arbitrary waveform
generators with specifications that include up to 60 MHz maximum bandwidth,
150 MSa/s sampling rate and 14-bit vertical resolution. The proprietary
EasyPulse techniques help to solve the weaknesses inherent in traditional DDS
generators when generating pulse waveforms, and the special square
generator is capable of generating square waveforms up to 60 MHz in
frequency with low jitter. With these advantages, the SDG1000X can provide
users with a variety of high fidelity / low jitter signals while meeting the growing
requirements of a wide range of complex and varied applications.
Characteristics
The powerful feature set for the SDG1000X generator family includes:
Dual-channel，with bandwidth up to 60MHz，and amplitude up to 20Vpp
150 MSa/s sampling rate, 14-bit vertical resolution，and 16 kpts waveform length
Innovative EasyPulse technology, capable of generating lower-jitter Pulse waveforms,
brings a wide range and extremely high precision in pulse width and rise/fall times
adjustment
Special circuit for Square wave function, can generate Square waves up to 60 MHz
with jitter less than 300 ps+0.05 ppm of period
Plenty of analog and digital modulation types: AM、DSB-AM、FM、PM、FSK、ASK、
PSK and PWM
Sweep and Burst function
High precision Frequency Counter
Standard interfaces: USB Host, USB Device（USBTMC）, LAN（VXI-11）
Optional interface: GPIB
Note: All the specifications described in this manual refer to the SDG1062X.

SDG1000X_ServiceManual_SM0201X-E01B.docx
IX
The Front Panel at a Glance
3. Screen Display
10. Waveform Option
Area
4. Numeric Keyboard
5. Knob
1.Power Switch
11. Menu Keys
2.USB Host
6. Arrow Keys
7. CH1/CH2 Control/Output Port
9. Function Keys
8. Channel Select Key

SDG1000X_ServiceManual_SM0201X-E01B.
docx
X
The User Interface at a Glance
SDG1000X can only display parameters and waveform for one channel at a
time. The picture below shows the interface when CH1 is selected and AM
modulation of a sine wave function is selected. The information displayed may
vary depending on the function selected.
1. Waveform Display Area
Displays the currently selected waveform of each channel.
2. Channel Status Bar
Indicates the selected status and output configuration of the channels.
3. Basic Waveform Parameters Area
Shows the current waveform’s parameters for the selected channel. Press
Parameter and select the corresponding softkey to highlight the parameter
to configure. Then use number keys or knob to change the parameter value.
4. Channel Parameters Area
Displays the load and output settings of the currently selected channel.
Load ----Value of the output load, as selected by the user.
Press Utility → Output → Load, then use the softkeys, number keys or knob
to change the parameter value; or continue pressing the corresponding
4
3
8 7 6 5
1 2

SDG1000X_ServiceManual_SM0201X-E01B.docx
XI
output key for two second to switch between High Impedance and 50 Ω.
High Impedance: display HiZ.
Load: display impedance value (the default is 50 Ω and the range is 50 Ω to
100 kΩ).
Note: This setting does not actually change the instrument’s output
impedance of 50 Ω but rather is used to maintain amplitude accuracy into
different load values.
Output ----Channel output state.
After pressing corresponding channel output control port, the current
channel can be turned on/off.
5. LAN Status Icon
The SDG1000X will show different prompt messages based on the current
network status.
This mark indicates LAN connection is successful.
This mark indicates there is no LAN connection or LAN connection is
unsuccessful.
6. Mode Icon
The SDG1000X will show different prompt messages based on the current
choosing status of the mode.
This mark indicates current mode is Phase-locked.
This mark indicates current mode is Independent.
7. Menu
Shows the menu corresponding to the displayed function. For example,
Figure 4 shows the parameters of “AM modulation”.
8. Modulation Parameters Area
Shows the parameters of the current modulation function. After selecting the
corresponding menu, use number keys or knob to change the parameter
value.

SDG1000X_ServiceManual_SM0201X-E01B.
docx
XII
The Rear Panel at a Glance
WARNING: For protection from electric shock, the grounding power cord must
not be defeated. If only a two-contact electrical outlet is available, connect the
instrument’s chassis ground screw (see above) to a good earth ground.
Aux In/Out
10 MHz Clock Input/Output
Earth Terminal
LAN Interface
USB Device
AC Power Supply Input
Counter
Aux In/Out

SDG1000X_ServiceManual_SM0201X-E01B.docx
13
Chapter 1Quick Start
One of the first things you will want to do with your generator is to become
acquainted with the front panel. We have written the exercises in this chapter
to prepare the instrument for use and help you get familiar with some of its front-
panel operations. This chapter is divided into the following sections:
⚫To Prepare the Generator for Use
⚫To Adjust the Carrying Handle
⚫To Set the Output Frequency
⚫To Set the Output Amplitude
⚫To Set a DC Offset Voltage
⚫To Set the Duty Cycle of a Square Waveform
⚫To Set the Symmetry of a Ramp Waveform
⚫To Configure a Pulse Waveform
⚫To Configure a Noise Waveform
⚫To Set the DC Voltage
⚫To Output a Built-In Arbitrary Waveform
⚫To Use the Built-In Help System

SDG1000X_ServiceManual_SM0201X-E01B.
docx
14
To Prepare the Generator for Use
1. Check the list of accessories
Accessories supplied with the instrument are listed below. If anything is missing
or damaged, please contact your nearest SIGLENT Sales Office.
⚫Quick Start Guide
⚫Certification of compliance
⚫A Guaranty Card
⚫A CD (EasyWave software, Datasheet and User Manual)
⚫A power cord designed for use in the destination country
⚫A USB cable
2. Connect the power cord and turn on the generator
The instrument runs a short power-on self-test, which takes several seconds.
The generator powers up in the sine wave function at 1 kHz with an amplitude
of 4 V peak-to-peak (CH1). At power-on, the Output connector is disabled. To
enable the Output connector, press the Output key.
If the generator does not turn on, verify that the power cord is firmly connected
to the power socket on the rear panel (the power-line voltage is automatically
sensed at power-on). Also, make sure that the generator is connected to a
power source that is energized.
Then, verify that the generator is turned on.
Note: If the power-on self-test fails, the generator may stop and display a black
screen. For solutions, please contact the nearest SIGLENT sales office or
return the generator to SIGLENT for service.

SDG1000X_ServiceManual_SM0201X-E01B.docx
15
To Adjust the Carrying Handle
To adjust the position, grasp the handle by the sides and pull outward. Then,
rotate the handle to the desired position.
Pull the handle ahead for easy carrying
Pull the handle down

SDG1000X_ServiceManual_SM0201X-E01B.
docx
16
To Set the Output Frequency
The following steps explain change the frequency to 20 KHz.
1. Press the Parameter softkey
Press the Parameter softkey to enter the parameter set interface. The waveform
parameters including Frequency/Period, Amplitude/HighLevel, Offset/LowLevel
and Phase are ready to modify using the numeric keypad.
2. Press the Frequency/Period softkey
The displayed frequency is either the power-on value or the frequency
previously selected. When changing the function, the same frequency is used
if the current value is valid for the new waveform. To set the period, press the
softkey again to switch to the period parameter
3. Input the desired frequency
Use the digital keypad to input the value directly, enter the value “20”.

SDG1000X_ServiceManual_SM0201X-E01B.docx
17
Then press the corresponding softkey to select the desired unit. For example,
press kHz.
Note: The desired numerical value can be modified using the knob and
direction keys.

SDG1000X_ServiceManual_SM0201X-E01B.
docx
18
To Set the Output Amplitude
The following steps describe how to change the amplitude to 8 Vpp.
1. Press the Amplitude/HighLevel softkey
The displayed amplitude is either the power-on value or the amplitude
previously selected. When changing the function, the same amplitude is used
if the current value is valid for the new waveform. To set the HighLevel for the
waveform, press the softkey again to switch to the HighLevel parameter.
2. Input the desired amplitude
Use the digital keypad to input the value directly, enter the value “8”.
Then press the corresponding softkey to select the desired unit. For example,
press Vpp.

SDG1000X_ServiceManual_SM0201X-E01B.docx
19
To Set the DC offset
The following steps describe how to change offset to 1 Vdc.
1. Press the Offset/LowLevel softkey
The displayed offset is either the power-on value or the offset previously
selected. When changing the function, the same offset is used if the current
value is valid for the new waveform. To set the LowLevel for the waveform,
press the softkey again to switch to the LowLevel parameter.
2. Input the desired offset
Use the digital keypad to input the value directly, enter the value “1”.
Then press the corresponding softkey to select the desired unit. For example,
press Vdc.

SDG1000X_ServiceManual_SM0201X-E01B.
docx
20
Note: The desired numerical value can be modified using the knob and
direction keys.
