Signature Design by Ashley P421-600 User manual

Customer Service866-319-0809 Page 1of 11
THISBOOKLETCONTAINSIMPORTANT INFORMATION
KEEPFOR FUTURE REFERENCE
PLEASE READ
PRODUCTASSEMBLY
INSTRUCTIONS
Signature Design by Ashley
Ashley #P421-600

DONOTRETURNTOTHESTORE
Roomsolutionsby Ashley wantsto helpyou. This
productiscoveredbyamanufacturer'slimited
warranty. Intheeventthat you noticepartsaremissing
ordamaged,haveawarranty questionoryou have
assemblyquestions, contactthe
RoomsolutionsbyAshleybrandcustomerservice at:
PhoneNumber:866-319-0809
Fax Number:800-477-0103
Purchase date:____________________SerialNumber:____________________
Please save and attach your sales receipttothis AssemblyInstruction Booklet
CUSTOMERSERVICEINFORMATION
Customer Service866-319-0809 Page 2of 11

CAREANDCLEANINGINSTRUCTIONS
Congratulationson thepurchaseofyournewproduct.Propercareandcleaningwillextendthelifeofyour
purchase.Toensureyourproductmaintainsitsfinishand quality:
•Useasoft,cleancloththatwillnotscratchthesurface whendusting
•Cleanonlywith aslightlydamp cloth
•Do not usechemicalbasedproductsorsolvents
•Liquidspillsshould beremovedimmediately
•Directsunlight mayfadeoraltercolorofwoodfinishes
ASSEMBLYINSTRUCTIONS
WARNING! Thisunit mustbeassembledin theordershown. Failuretodosomayresult in damageto the
partsorimpedefunction oftheunit.
GeneralInstructions
•ReadallAssemblyInstructionspriorto assemblingtheproduct
•Makesureyouhaveallpartsbeforebeginning assembly
•Toavoiddamage,assembletheproductonanon-abrasivesurface suchas acarpet
•Werecommend using twopeopletoassembletheunit
•Waituntilallsteps arecompletedbeforetightening bolts
•Makesureallscrews,nuts,andboltsaretightenedbeforeproductis used
Customer Service866-319-0809 Page 3of 11

ASSEMBLYPARTSLIST
PartNumber:A
Quantity: 1
Description:Seat Panel
PartNumber:B
Quantity: 4
Description:Leg
PartNumber:C
Quantity: 2
Description:Base
PartNumber:D
Quantity: 1
Description:Stretcher
PartNumber:E
Quantity: 1
Description:SeatCushion
Customer Service866-319-0809 Page 4of 11
PartNumber:G
Quantity: 4
Description:1/4in FlatWasher
PartNumber:H
Quantity: 8
Description:1/4inx95mmScrew
PartNumber:L
Quantity: 1
Description:Allen Wrench
PartNumber:F
Quantity: 4
Description:1/4inx75mmAllenBolt
PartNumber:J
Quantity: 4
Description:1/4inx80mmScrew
PartNumber:M
Quantity: 1
Description:OpenWrench
PartNumber:K
Quantity: 4
Description:1/4inLockNut

ASSEMBLYINSTRUCTIONS
Customer Service866-319-0809 Page 5of 11

ASSEMBLYINSTRUCTIONS
Customer Service866-319-0809 Page 6of 11
Step1-Aligntheholes in theBase(C)withtheholesinthe Legs (B). Install screw(H)andfully
tightenthemusingAllenwrench(L).
*Repeatstep 1 toassembletheremaining Base(C)andLegs(B).
Step2-Aligntheholes in theLegs(B)withtheholesinthe Stretchers(D). Install screw(J)using
Allen wrench(L).Donotfullytighten.

ASSEMBLYINSTRUCTIONS
Customer Service866-319-0809 Page 7of 11
Step3-Place the seatpanel(A)topsidedownonasmoothandprotective surface,placelegs(B)
onbottomof the seatpanel,aligntheholes intheLegs(B)withtheholes in theframe of
seatpanel, Install bolt(F),flat washer(G)andscrew(F)andlock nut(K),using
Allenwrench(L) andopenwrench(M). Donotfullytighten.
Step4-Turnthe benchoverandfullytightenthebolts using Allenwrench(L)and
open wrench(M).

ASSEMBLYINSTRUCTIONS
Customer Service866-319-0809 Page 8of 11
Step5-Placetheseatcushion(H)ontheseat board(B), secure the seat cushiontothe bench
slatsbyconnectingthestrapsasshowntocomplete the assembly.

REPLACEMENTPARTSLIST
Customer Service866-319-0809 Page 9of 11
Part
Number ReplacementPart
Number Description Quantity
4
2
1
1
1
2
3
R75918
R75919
R75920
Leg(295x70x40mm)
Base(325x90x40mm)
Stretcher(975x50x25mm)
1/4inx75mm Allen Bolt(4)
1/4in LockWasher(4)
1/4in FlatWasher(4)
4R70575 D6.5xD16mmFlatWasher(4)
1/4in LockNut(4)
1/4inx80mm Screw(4)
1/4inx95mm Screw(8)
1/4inch Open Wrench(1)
5mm Allen Wrench(1)

REPLACEMENTPARTSDRAWING
Customer Service866-319-0809 Page 10 of 11
AssemblyHardwarePack
12
3
4
(H)1/4"x95mm
8pcs
(F) 1/4"x75mm
4pcs
(G)1/4"x80mm
4pcs
(L) 5mm
1pc
(J)1/4"
4pcs
(K)1/4"x8mm
4pcs
(M) 1/4"
1pc

Quantity
R75918R75919 R75920 R70575
REPLACEMENTPARTSDRAWING
PleaseincludeacopyofyouroriginalreceiptalongwiththiscompletedParts Order Formand either:
Mailto:AshleyFurnitureIndustries, LLC.
Parts Dept. /CorporateBuilding
OneAshleyWay
Arcadia, WI54612(or)
Emailto: [e-mail] (or)
Faxto: 800-477-0103
FIELDSMARKEDWITHAN ASTERISK (*)AREREQUIREDTOCOMPLETE YOUR ORDER
*YourName_____________________________*DaytimePhone:________________________________
*Address:_______________________________ HomePhone:___________________________________
_______________________________________ Cell Phone:____________________________________
_______________________________________ Email:________________________________________
*City:_____________________*State:________
*Zip Code:_________________
Model#: Ashley#P421-600 *Serial#:___________________________(foundon backorbottom ofunit)
Purchasedfrom:___________________________ *DateofPurchase:______________________________
ReasonforPartsOrder(CircleOne):
MissingPart(s)ScratchedBroken
PartsRequested:
Customer Service866-319-0809 Page 11 of 11
