Cooper Lighting Neo-Ray 752 User manual

NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
752 COOPER LIGHTING
RECESSED
FENESTRA
254
252
154
152
SEMI INDIRECT
DIRECT-INDIRECT
Construction
20-gauge steel housing.
Shielding
Perforated metal panels backed by a white acrylic
diffuser.
Electrical
120, 277, 347 or Universal Voltage electronic ballast.
Fixtures and electrical components certified to UL
and CUL standards.
Finish
Durable, low gloss, white, powder coated acrylic
finish.
Mounting
Recessed.
ORDERING INFORMATION:
Sample number: 252R-2T5-ETG-1EB-SI-EM
Series
152=1’X2’ 154=1’x4’ 252=2’x2’ 254=2’x4’
Options 2
A=Air Return T=Tannenbaum Reflector
C=Chicago Plenum
Mounting
R=Recessed
Number of Lamps (per cross section) (not included)
1=1 Lamp 2=2 Lamps (T5 only available with 2 lamps)
Lamp Type
T5 T5HO BX40W BX50W
Ceiling Type
ETG=Exposed T-Grid STG=Slot T-Grid
SR=Sheet Rock (Flanged)
Voltage 1
1=120V 2=277V 3=347V U=Universal
Ballast
EB=Electronic Ballast (Standard) DB=Dimming Ballast
Switching
SI=Single Switching DU=Dual Switching
Emergency
EM=Emergency Pack (Consult Factory)
1 Due to various constraints, some options may not be combined with others.
2 Can be left blank or more than one option may be available, consult factory.
• Ambient light distribution.
• Narrow 4” diam. drop center
basket design.
• Optimized for T5 lamping.
• Low direct glare illumination.
• High fixture efficiencies,
range from 70% to 80%.
• Housings fit all ceiling types
with ultra minimal exposed
trim.
• Tannenbaum ribbed
aluminum reflector option
available.
• Air return and Chicago
plenum options available.
24" [610mm]
1-31/32" [50mm]
3" [76mm]
12" [305mm]
STANDARD LUMINAIRE PLAN – VIEW – VIEW
24" x 24"
(610mm x 610mm)
(1 or 2 Lamps)
24" x 48"
(610mm x 1219mm)
(1 or 2 Lamps)
MOUNTING INFORMATION
Tannenbaum Reflector
254/252
154/152
12" x 48"
(305mm x 1219mm)
(2 Lamps)
12" x 24"
(305mm x 610mm)
(2 Lamps)
252 254
152 154
NEO-RAY™
