Tennsco DWR-4218 Instruction Manual

GENERAL SAFETY INFORMATION
Some parts may have sharp edges. CARE must be taken when handling various pieces to avoid injury.
For safety, wear a pair of work gloves when assembling or performing any maintenance on products.
LIMITED WARRANTY
Tennsco warrants goods purchased hereunder to be free of defects in materials and workmanship for a period of one (1) year from the date of shipment, hereunder. This warranty shall not apply in
the event goods are damaged as a result of misuse, abuse, neglect, accident, improper application, modication or repair by persons not authorized by Seller, where goods are damaged during
shipment, or where the date stamps on the goods have been defaced, modied or removed. UNLESS CONSIDERED UNENFORCEABLE OR UNLAWFUL UNDER APPLICABLE LAW:
a. ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO WARRANTIES OR MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY EXCLUDED:
b. BUYERS REMEDY, IF ANY, FOR ANY DEFECTIVE GOODS SHALL BE LIMITED TO A REFUND BY SELLER OR REPLACEMENT OF THE GOODS AT SELLER’S OPTION, AND SHALL IN NO
EVENT INCLUDE DAMAGES OF ANY KIND, WHETHER INCIDENTAL, CONSEQUENTIAL OR OTHERWISE.
NO GOODS ACCEPTED FOR RETURN WITHOUT PRIOR APPROVAL. Seller shall have the right to inspect any goods claimed to be defective at Buyers place of business or require Buyer to return the
goods to Seller for inspection on Seller’s premises. Transportation charges covering returned goods will be borne by Seller only if such goods are proven to be defective, are covered by this warranty
and are returned within the warranty period stated above.
ASSEMBLY INSTRUCTIONS & PARTS MANUAL
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE
Standard Storage Cabinet with File Drawer
Preassembled Model DWR-4218
Tennsco LLC., Dickson, TN 37056-1888 • [phone]
LOAD CAPACITIES PER SHELF LEVEL
36w x 18d 200 lbs.
UNIT SIZE WEIGHT CAPACITY
EVENLY DISTRIBUTED
PK-2330918

REPLACEMENT PARTS
REF. NO. DESCRIPTION
1 Shelf 1 301
2 Left Door 1 086LD
3 Right Door 1 086RD
4 Locking Recessed Handle 1 RH-1
5 Locking Cam* 1 059LC
6 Cam Retainer* 1 944CR
7 Locking Bar Set 1 086LB
8 Lock Bar Guide Inserts 2 944GI
9 Drawer 1 4218DWR
10 Hanging Folder Rod 1 36HF-DWR
11 Cam Lock 1 CL-1
12 Optional Dividers (not shown above) -- 5AD
13 Optional Cross Rods (not shown above) -- CR15
QTY. PART NO.
1. To move the shelf, using your
hands apply pressure to the
underside of the shelf and
tap it off the tabs.
2. Place the shelf at the desired
level. Insert the shelf edges
into the tabs at the new
location. Be sure that the
shelf is securely tted into the
tabs at all points of contact.
3. The cabinet must be level
in order for the doors to
close properly. Levelers may
be adjusted by placing the
nut driver through the hole
in each end of the sill and
adjusting the leveling screw.
Ref.
No. 1
Ref.
No. 2
Ref.
No. 3
NOTE: Additional hardware may be included for replacement purposes.
Tennsco makes every effort to ensure that all units ship complete with all parts and arrive undamaged.
However, should your unit contain missing or damaged parts, please contact your purchase location.
Insert hex head driver
through hole (above) to
adjust leveler (below).
Ref.
No. 4
Ref.
No. 5

Ref.
No. 6

Ref.
No. 7

Ref.
No. 8

Ref.
No. 9
*Included in Ref. No. 4, recessed handle with keys (Part No. RH-1). May be ordered alone or as part of the full hardware set.


Ref.
No. 10

Ref.
No. 11
49B233
