1. Disconnect AC power before servicing.
2. Refer to wiring diagram for proper connections.
3. All servicing should be performed by qualified personnel.
4. Consult your local building code for approved wiring and installation.
5. Do not use this equipment for other than intended use.
6. Do not let power cords touch hot surfaces.
7. Mount and secure the fixture at a location and height to avoid ready access
and tampering by unauthorized persons.
8. The use of accessory equipment is not recommended by the manufacturer
and may cause an unsafe condition.
9. Suitable for wet locations. See product label for temperature limitations.
IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
1
WIRE ACCESS 5/8" DIA
2 1/2"
2 3/4"
1 3/8"
(2) #6-32 X 3/8
SET SCREW
(2) DIA 3/16" MOUNT
SCREW LOCATIONS
ITEM
QTY
P/N DESCRIPTION
1
1
346300
BASE
2
1
346400
HOUSING
3 1 346201 GASKET
(2) # 8-32 x 1/2
CANOPY MOUNT SCREW
POLARIZED
CONNECTOR
PIGTAIL
BL RB
LOW VOLTAGE
SUPPLY WIRING
(2) # 6-32 x 3/8
SET SCREW
MULLION
TOP MOUNT
(OPTION)
SIDE MOUNT
Fig. 1
2
1
3
BRANCH CIRCUIT
INPUT/ OUTPUT 24 VDC
WIRING THROUGH
MULLION AWG #16 - 20
MUE
J-
BOX
SUITABLE FOR WET LOCATIONS
AMBIENT TEMPERATURE LIMITS:
Standard "BB" models: -20º C to +40º C
Remote models: -40º C to +50º C
Fixture Assembly
1. See Fig 1. Drill 7/8” dia access hole in the mullion beam at center of fixture location, together with
screw mount holes as shown. See Table 1 on Pg. 2 for wire size and length. Route supply wiring through
mullion, through Gasket (3) and Base (1). Position Base (set screws on upper edge), and attach base to
mullion with two #8-32 screws. Check that gasket is even with base and properly seated, and tighten
screws evenly.
2. Attach lamp plug connecter pigtail to supply wiring with wire nuts. MAINTAIN COLOR CODES AT
CONNECTOR.
3. Carefully insert wire nuts through gasket into mullion, avoiding damage to edges of gasket, to maintain
a watertight seal.
4. Connect Lamp Plug to pigtail connector and carefully insert the plug assembly through the gasket
entrance hole. Line up and place Housing into position on the base, hold in place and tighten two #6-32
set screws to lock.
5. Turn AC power ON with battery connected at the CBS to check operation.
KEY
B- BLACK: COMMON: 12/24 VDC NEG -
R- RED: EMERGENCY: 24VDC POS +
BL- BLUE: SECURITY/ NIGHT LIGHTING: 24 VDC POS +
LED Mullion Mount Emergency Light
Remote Series MUE-RE
Moonlite LED™
Emergency & Security Light
REV 02.17.03
INSTALLATION INSTRUCTIONS AND OWNER'S MANUAL
