Larson Electronics GVP-EMG-48-2L-LED User manual

GVP-EMG-48-2L-LED
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 1of 3
56 Watt Vapor Proof LED 4 Foot Light for Outdoor Applications
Emergency Battery Backup - Failsafe
Instruction Manual
Thank you for your purchase of the Larson Electronics GVP-EMG-48-2L-LED.
WARNING:
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CRITICAL SAFETY INSTRUCTIONS:
•INSTALLATION SHOULD ONLY BECONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY
RELEVANT LOCAL BUILDING CODES.
•RISK OFFIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL
SYSTEMS. IFNOTQUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.
•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.
•TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP
OBJECTS. SUITABLE FOR DAMP LOCATIONS.
IMPORTANT
READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. THE GVP-EMG-48-2L-LED MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL
CODE AND ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.
WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS
PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,
CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.
RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.
RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.
WARNING:
USER SHOULD BE TRAINED IN THE PROPER USE AND MAINTENANCE OF THIS DEVICE. THIS LINE
CORD IS INTENDED TO ALLOW OPERATORS TO EXTEND POWER TO EQUIPMENT WHEN STATIONARY OUTLETS ARE NOT
READILY AVAILABLE.
IMPROPER USE OF THIS CORD, PLUG, AND RECEPTACLE CAN LEAD TO SERIOUS INJURIES OR DEATH TO
PERSONNEL.
PERIODIC INSPECTION OF THE CORD IS NECESSARY.
THE CORD MUST BE ROUTINELY CHECKED FOR CUTS, BREAKS, OR ANY SEVERE ABRASIONS, AND IF ANY ARE FOUND,
THE CORD MUST BE REPLACED BEFORE RESUMING USE.
The Larson Electronics GVP-EMG-48-2L-LED is similar to our popular explosion proof LED fixtures and provides an LED alternative to
fluorescent fixtures that provides longer lamp life and higher performance. These 2 LED tube lamp fixtures produce more output with
longer lamp life and are vapor proof and impact/ vibration resistant. Please note that this unit is vapor proof and not approved for use in
hazardous locations.
WIRING
Standard pigtail(flying leads) wiring
We strongly encourage a licensed electrician install this product,in all locations especially in outdoor areas
where weatherproofing may be required. Universal voltage driver permits operation at 120V - 277V AC, 50 or 60Hz
except those factory ordered with low voltage 12V to 24V AC/DC.

GVP-EMG-48-2L-LED
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 2of 3
Warning: Check product label for correct input voltage!
Attach supply line wires to the appropriate light fixture wires as shown
in thediagram on the next page.
Secure each pair of wires according to the diagram. Utilize ajunction box or similar device and take
precautionary steps for weatherproofing all connectionsif installed in alocation where water may come in
contact with the unit. Ensurethe unit is properly grounded and that wiring is done according to all local and national
electrical/building codes.
Low Voltage DC
Connect power to power supply outputting low voltage between 12-24 VoltsDC. This variable voltage allows greater
versatility without affecting light output. Ensure deutsch connectors are properly connected (If applicable)
LIGHT ASSEMBLY
1. Turn off the power at the main fuse or breaker box.
2. Thread wires through wire gland and back cover wire hole.
3. Connect the wires to the wire terminal L to L, N to N then fasten the wire gland.
4. Attach to the LED tubes to the lamp holder.
5. Put the tube fixing board in the back cover, fixing poles through the board’s holes. Then turn around the head of
fixing poles 90° to fix the board to back cover.
6. Use the lens and back cover clips to attach lens to back cover.
7. Use the wall fixing clips to fix the light fixture to the wall.
8. Turn on power at main fuse breaker box.

GVP-EMG-48-2L-LED
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 3of 3
EMERGENCY BACKUP WIRING
1. Black - AC Power IN
2. White - AC Power IN
3. Battery +
4. Temp Sense +
5. Battery —
6. Orange - LED +
7. Red - Driver in +
8. Blue Driver in —
9. Red/White - LED light engine +
10. Black/White - LED light engine —
11. Green/Yellow - Ground
12. These instructions are general recommended instructions. All installations should be done by qualified personnel,
properly trained and in accordance with the National Electrical Code and any local regulations.
MAINTENANCE
Caution: To avoid personal injury, disconnect power to the light and allow the unit to cool down before
performing maintenance.
Warning: No user serviceable parts inside of fixture. Risk of electric shock. Removal of the lens will void
the warranty.
1. Perform visual, mechanical and electrical inspections on a regular basis. We recommend routine
checks to be made on a yearly basis. Frequency of use and environment should determine this. It is
recommended to follow an Electrical Preventive Maintenance Program as described in NFPA 70B:
Recommended practice for Electrical Equipment.
2. The lens should be cleaned periodically as needed to ensure continued photometric performance.
Clean the lens with a damp, non-abrasive, lint-free cloth. If not sufficient, use mild soap or a liquid
cleaner.
3. Inspect the cooling fins on the luminaire to ensure that they are free of any obstructions or
contamination (i.e. excessive dust build-up). Clean with a non-abrasive cloth if needed.
4. Do not operate if the lens is cracked or damaged. All fasteners should be properly seated.
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of
children when not in use.Inspect for good working condition prior to storage and before re-use.
REPLACEMENT PARTS
The GVP-EMG-48-2L-LED is designed to provide years of reliable performance. Should the need for replacement parts
arise, please contact Larson Electronics.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
[e-mail] OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
NOTE: When the light enters Emergency Mode and is running off the battery, only one bulb in the fixture will
light up.
