Sigtronics S-65S User manual

…when it counts!
Model S-65S
Headset Instructions
The S-65S series headsets are adjusted at the factory for immediate use with all
current standard radio systems in general aviation aircraft. Headsets equipped
with two plugs are the standard conguration. The headphone plug is the larger
diameter plug and should be inserted into the headphone jack (.250” standard
monaural jack). The mic plug is the smaller diameter plug and should be inserted
into the microphone jack (.206” standard microphone jack).
The headband is adjustable through a full range of motion, or the locking nuts
may be tightened to allow you to custom t the headset. Place the headset over
your head, adjust the slides up until minimum pressure is felt on the top of your
head. The headset is now properly adjusted. For maximum noise attenuation, the
clamping pressure has been set at the factory. Releasing the clamping pressure
by bending the headband is not advised, because loss of attenuation will result.
Note: If especially small (children) or large headbands are needed, they may be
ordered from Sigtronics.
The microphone boom is fully adjustable and will rotate 360 degrees for use on
the left or right side of the head. The locking screw that secures the boom to the
ear cup is factory set to insure the correct tension. Turning it will not change the
tension, because the nut on the inside of the cup will turn as well. Microphone
placement should be at the corner of the mouth, approximately ” from the
lips. The exclusive thumbscrew on the mic boom may be used to assure proper
adjustment.
When you rst connect the headset, turn the volume controls on the headset to
maximum ( full clockwise on mic side, counterclockwise on pot side ), then adjust
the listening volume with the audio control of either your radio or intercom as
appropriate. Passengers should also turn their individual headset volumes up
fully. Doing this allows for a full range of adjustment for each passenger, since
those with the most acute hearing can turn their headset volume down, if neces-
sary.
continued on back…
The headset is equipped with a stereo / monaural switch on the non-mic side ear
cup. For monaural sound or aircraft with only monaural jacks, move the switch to
the monaural position. In aircraft equipped for stereo audio, move the switch to
the stereo position.
The headset parts may be cleaned with mild soap and water using a soft cloth.
Then dry immediately. Caution: Do Not immerse any part of the headset in
water or any other liquid. Be especially careful not to allow the microphone to
become wet! Exposure to moisture may cause internal corrosion and failure and
will void your manufacturers warranty.
Cleaning will help the headset maintain its “like new” condition for many years.
WINDSCREEN
The microphone windscreen will reduce annoying wind noise and breath pops
picked up by headset microphones. It also protects the microphone element
from dirt and moisture. The windscreen should be washed regularly to maintain
hygiene and avoid clogging. Wash in warm water and mild soap. Rinse thor-
oughly and make sure it is completely dry before putting it back on.
To remove the windscreen, take out the screw that holds the microphone on the
boom and grasp the windscreen lightly along its entire length and slip it off.
Put the windscreen on the microphone by gently pulling from the open end. Do
not pull it so tightly that it stretches against the end of the microphone.
WARRANTY
Your headset is covered by a limited ve-year parts and labor warranty. Please
see the enclosed warranty card for details.
You may refer to the parts list on the reverse side, if you choose to replace parts
yourself. The parts list describes parts for this particular headset only. Parts lists
for other models are available on our Web Site or can be obtained by contacting
Sigtronics Corporation.
Sigtronics Corporation
178 East Arrow Highway
San Dimas, CA 91773
Phone: [phone]
E-mail: [e-mail]
Web Site: www.sigtronics.com

ITEM DESCRIPTIONP/N
23 FOAM, SOUND ATTN, REC COVER, 1/4 INCH100379
1 24GROMMET, 5/16 INCH, RUBBER100049 CLIP, HEADBAND GUIDE, PLASTIC100258
2 25KNOB, HEADSET VOLUME100360 CLIP, ANTI-ROTATION, YOKE, PLASTIC100393
3 26POTENTIOMETER, 2K100365 HEADBAND, METAL, SHORT100514
4 27RECEIVER, 300 OHM, STEREO100083 BRACKET, YOKE SUPPORT W/TANG100516
5 28SCREW, 4-40 X 1/4, THREAD FORMING100108 WASHER, SPRING, BOOM ADAPTER100385
6 29BOOM, ELECTRET MICROPHONE SUPPORT, SWIVEL100525 WASHER, GROOVED BOOM100408
7 30E RING, EARCUP TO YOKE RETAINER100520 CABLE, HEADSET, STEREO800012
8 31NUT, HEX, 8-32, LOCKING100524 CABLE, MIC BOOM, 12 INCH800039
9 32EARCUP, PRINTED AND DRILLED, MIC & NON MIC SIDE100531 HEADBAND, W/FOAM FILLED CUSHION800146
ITEM P/N
12 35SCREW, 8-32 X 3/8, PHIL100521 SCREW, THUMB, MIC BOOM, 2-56 X 1100532
DESCRIPTION
11 34SCREW, 8-32 X 1/2, PHIL100522 100371 MIC CABLE CLIP
13 WIRE, 3 CONDUCTOR, #24, BLACK, 28.5 INCHES100366 100402 EAR SEAL, GEL FILLED36
10 33CLIP, CROSS-OVER, WIRE, PLASTIC100362 MICROPHONE, ELECTRET, M-90800078
14 YOKE, EARCUP MOUNT100515 37 100569 STRAIN RELIEF, CABLE
SIGTRONICS
16 EAR SEAL, FOAM FILLED100369 39 100130 TERMINAL, SOLDER
17 RECEIVER MOUNT, HEADSET, STEREO100423 40 100135 WASHER
18 900084 WINDSCREEN, MIC, FOAM 41 100508 WASHER
15 KNOB, MIC BOOM ADAPTER, PLASTIC100368 38 100509 SWITCH, STEREO/MONO
19 SLIDE, YOKE BRACKET, LONG, NYLON100373 42 100530 NUT, STEREO/MONO SWITCH
20 FOAM, SOUND ATTN. NOTCHED, 1/2 INCH100374 43 100579 CLIP, CLOTHING, HEADSET CABLE
22 SCREW, 8-32 X 5/8, PHILIPS HEAD100523 OPTIONAL - HEADBAND, METAL, CHILD45 100673
21 FOAM, SOUND ATTN. REC HOLE, 1/2 INCH100376 OPTIONAL - HEADBAND, METAL, LONG44 100674
SIGTRONICS S-65S HEADSET PARTS IDENTIFICATION BREAKDOWN



 





   

    












 








 





1-4-2007
P/N 700074
