SIIG ID-SB0111-S1 Product information sheet

2
Introduction
The RS-232 to Bluetooth Converter is designed
to allow any RS-232 device to communicate
wirelessly. It supports baud rate of up to
921Kb/s, wireless transmission up to 300
feet and features auto pairing and selectable
Master or Slave mode.
Key Features and Benets
• Full Bluetooth 2.0 + EDR compliant
• Selectable as Slave or Master mode
• Bluetooth Class 1- 100M (300 feet)
• Baud rate: up to 921.6Kb/s
• Frequency: 2.400 to 2.4835 GHz
System Requirements
• Windows 8 (32-/64-bit) / 7 (32-/64-bit) /
Vista (32-/64-bit) / XP (32-/64-bit) / Server
2003 & 2008 (32-/64-bit) / Server 2008 R2
/ 2000

3
Package Contents
• RS-232 Serial to Bluetooth Adapter
• External Dipole Antenna
• USB Cable
• Battery power line and connector
• Quick installation guide
Layout
Figure 1
USB Connector
Power source switch
Power line
connector
Reset
DCE/DTE
switch
Status LED
Power LED
Group (G/NG)
S (slave) / M (master)
Antenna
Connector
RS-232 Serial Port

4
LED Indicators
Antenna Connector
Simply connect it to a 2.0dBi, 50 Ohms
impedance dipole antenna to support 2.4 GHz
frequency. The Antenna is changeable for high
gain Antenna. See Figure 2.
Table 1
Figure2
LED status Description
Power LED off No power supply
Power LED on Power input is equal or larger than 3.5 Volt
Power LED blinking Power input is lower than 3.5 Volt
Status LED off No pairing established
Status LED on Connection established
Status LED fast blinking
In 0.1 sec interval: Pairing (in either slave or master
mode)
In 0.3 sec interval: Discoverable (in slave mode)
Status LED slow blinking In 0.9 sec interval: Inquring (in master mode)
In 1.2 sec interval: Connecting (in master mode)

5
RS-232 Serial Port
Connect the RS-232 port into any computer or
serial device.
Reset Button
Use a tip of a pen or other sharp object to
access the reset button.
• To restore to factory default settings:
press and hold down the reset button
for over 3 seconds to get back to the
default settings:
-
Baud rate: 19200 bps
-
Data bit: 8
- Parity: none
-
Stop bit: 1
- Flow control: none
- Bluetooth PIN code is "1234"
• To disconnect and reconnect the wireless
connection: press the reset button quickly.
USB Connector
Connect USB connector with your PC by using the
included USB cable for external power supply.

6
One to one
With Bluetooth USB Dongle
Bluetooth USB Dongle
Bluetooth - master Bluetooth - slave
Bluetooth- slave
DCE/DTE Switch
Use the DCE/DTE dip switch to switch between
DCE and DTE mode. Switch to DTE mode, for
Data Terminal Equipment (PCs for example);
switch to DCE mode, for Data Communication
Equipment (Modem for example). Move the
switch in the direction of antenna for DCE, and
move it in the direction of RS-232 port for DTE.
Applications
Figure3
Figure4

7
Hardware Installation
1. Fasten the antenna to the Adapter.
2. Connect the Adapter to the serial port of
your PC or serial device.
3. Follow one method below to connect to
an external power source:
A- Use the included USB cable to connect
the Adapter's mini USB connector to a
USB port of your PC.
B- Use a Powered DB9 connector (Pin 9) as
the power supply. This is often used in
POS system.
C- Connect the included battery
power line to the Adapter's Power Line
Connector, and connect the other end
of the power line to batteries (three A /
AA / AAA batteries, or one 3~3.7VDC Li-
Polymer battery). See Figure 5.
Figure5

8
4. Switch the Power Source Switch to
"USB/Battery" when powering up the
Adapter through USB or Battery.
Switch the Power Source Switch to
"DB9-Pin9 (5V)" when powering up the
Adapter through powered DB9.
5. The Power LED shows steady red light
indicating the power is on. Once power
is conrmed, go to the next section for
COM port conguration and connection.
COM Port Conguration
1. Congure the parameters of the COM port
through HyperTerminal or other terminal
software. To configure the adapter,
initiate HyperTerminal from the Start Menu.
Note: The conguration windows below
come from software HyperTerminal. For
other terminal software, the windows
may be slightly dierent.
2. Type in "Name", then click OK. See
Figure 6.

9
Figure 6
3. Scroll to choose the COM port you are using
to connect with the Adapter, and click OK.
Name
OK
Figure 7
OK
Select the COM port
4. Conrm the parameters as the following,
then click OK. To pair two devices for an
exclusive connection between them.

10
Flow control: None
Baud rate: 19200 bps
Data bit: 8
Parity: none
Stop bit: 1
Figure 8
4. Follow the instructions in the next
section: "Master/Slave Mode Setup" to
set the Adapter mode.
5. Enable the bluetooth function of the PC,
search the Serial Adapter and make a
connection to it.
Master/Slave Mode Setup
Set the Adapter to be in "Master" mode or
"Slave" mode through terminal software-
ROLE command or DIP command.
Note: Slave mode is the default setting.

11
ROLE Command
1. Type ROLE=M to set the Adapter to the
master role. (Type ROLE=S to set back to
the default.)
Figure9
Figure10
2. Press Enter to see "OK". This means the
setup is successful.
DIP Command
1. The default is DIP=N. Type DIP=Y to turn
on the function of the DIP switch, then
you can manually adjust the S/M switch
to change it to master or slave mode.
Figure 11

12
Group Mode Setup
The adapter is in N/G mode by default. The
adapter can be set to G mode if you have
more than two RS-232 Serial to Bluetooth
Adapters, meaning this adapter is able to
perform single to multiple transmission.
Follow the steps to set the adapter to Group
mode by terminal software:
Type DIP=Y to turn on the function of the DIP
switch.
After the function of DIP switch has turned on,
you can adjust the switch to "G".

13
Setup commands reference table
Refer to the following table for more applications:
Note: Use all capital or all lowercase letters,
do not mix, when typing the commands.
Command Value Description
<<< Set the local adapter change the data mode into command
mode.
<<<
Switch the data mode to the command.
The time interval between each character will be more than the
time: [500ms] "<" [500ms] "<" [500ms] "<" [1500ms]
<<<= ?Inquire the current setting.
(Default) YTurn on the "<<<" command
NTurn off the "<<<" command
>>>
Set the remote adapter change the data mode into command
mode from the local adapter in connecting status. The
command is available after 500 ms when data transferring
finished.
>>>
Switch the remote adapter from the data mode to the command.
The time interval between each character will be more than the
time: [1 sec] ">" [1 sec] ">" [1 sec] ">" [2 sec]
>>>= ?Inquire the setting status of the ">>>" command.
(Default) YTurn on the ">>>" command
NTurn off the ">>>" command

14
ADDRESS= Used to display the Bluetooth address of t he local adapter.
?Inquire the Bluetooth address of the local adapter.
AT
Check the connection status between control terminal and the
RS-232 adapter. Response: "ERROR" when the connection is not
correct.
AT Test the RS-232 status when first connect the adapter with the
controller.
AUTO=
Used to enable/disable auto-connection feature. It's available
only when the adapter is in master mode.
The command is available when DIP=N. The system will not
restart after the change.
YThe Master role adapter will connect the latest paired Bluetooth
device automatically.
(Default) NThe user will connect the Bluetooth device manually.
?Inquire the current setting.
BAUD= Used to specify the baud rate of COM port. The command will
have 200ms delay.
1200 1200 bps
2400 2400 bps
4800 4800 bps
9600 9600 bps
(Default) 19200 19200 bps
38400 38400 bps
57600 57600 bps
115200 115200 bps
230400 230400 bps
460800 460800 bps
921600 921600 bps
RRestore the default settings. (Baud rate= 19200bps)
?Inquire the current baud rate.

15
CONNEC-
T=
Used to establish a connection manually. It is available only
when the adapter is in the master mode.
DEVICE Connect the adapter to a specified Bluetooth manually. It's
available only when "DEVICE=xxxxxxxxxxxx" is executed.
1~8 Connect the adapter to a Bluetooth device in the Environment
which found by "SEARCH=?"
xxxxxx-
xxxxxx
Connect the remote adapter by typing the MAC address directly
without searching.
?Display the MAC address of the latest paired device.
YRecover the latest connection in the command mode.
NDisconnect the two adapters in the command mode.
PConnect the previous connected adapter.
DEFAULT= Used to detect the Voltage of the power supply and set the alert
value of low power.
YRestore the default settings (e.g. 19200bps)
The command will restart the system for 1 second.
DETECT= Used to detect the Voltage of the power supply and set the alert
value of low power.
(Default) NDisable the Voltage detection.
YEnable the Voltage detection.
RRestore the default value (3.5 Volt)
xx Setup the range of Voltage detection from 3.0 to 3.7 Volt. The
"X" indicates the number.
?Inquire the setting status.
DEVICE=
For security purpose, this command is used to specify a unique
remote Bluetooth serial adapter to be connected. In the master
role, the adapter pairs and connects with the designated remote
slave address. If the adapter is in the slave mode, this command
is a filter used to accept the inquiry of the master device.
xxxxxx-
xxxxxx "xxxxxxxxxxxx" is a string of 12 hexadecimal digits.

16
RRestore the status in which the adapter can connect with any
remote address.
?Inquiry the designated address that can be paired and connected.
DIP= Set the DIP switch function.
?Inquire the setting status of the DIP switch function.
YTurn on the function of the DIP switch. The "ROLE" and "AUTO"
command are not available to set the "Master" or "Slave".
(Default) NTurn off the function of the DIP switch. The "ROLE" and "AUTO"
command are available when the DIP=N.
DISCOVER-
=
Used to specify whether the adapter can be discovered or
connected by remote devices.
This command is available only when the adapter is in the slave
role.
N
The adapter enters the undiscoverable mode. If a pair has been
made, the original connection can be resumed. But other remote
master device cannot discover this adapter.
(Default) YThe adapter enters the discoverable mode.
?Inquire the current setting.
ECHO= This command is used to specify whether the adapter echoes
characters received from the UART back to the DTE/DCE.
NCommand characters received from the UART are not echoed
back to the DTE/DCE.
(Default) YCommand characters received from the UART are echoed back to
the DTE/DCE.
?Inquire the current setting.
FLOW=
This command enable or disable flow control signals (CTS/RTS)
of the UART port. Note: the setting is not affected by DEFAULT.
The command will need 1 second delay.
(Default) NDisable flow control.
YEnable flow control.
?Inquire the current setting

17
NAME=
Used to specify a name for the adapter.
You can specify a friendly name using 0 to 9, A to Z, a to z,
space and -, which are all valid characters. (Note: Using Space or
- as first or last space isn't permitted.) The default name is "Serial
Adapter".
(Default) Serial
Adapter Default device name
xx....xx "xx...xx" is a character string with the length from 2 to 30.
RRestore the default settings name="Serial Adapter".
?Inquire the name of the local adapter.
PARITY= This command is used to specify parity bit setting of COM port.
The command will need 200 ms delay.
(Default) NNone parity bit
OOdd parity
EEven parity
?Inquire the current setting.
PIN=
Used to designate a PIN. The default PIN is "1234". Paired
adapters should have the same PIN. This command is used to
designate a PIN. The default PIN is "1234" and the digits should
not be less than 4. Paired adapters should have the same PIN.
The PIN can be set up with combinations of numbers, English
characters or both.
(Default) 1234
xx....xx "xx....xx" is a 4~16 digit string or English character (with capital
or lower case characters)
NCancel authentication by PIN.
RRestore the default settings PIN="1234".
?Inquire the current PIN.
PROMPT=
Used to decide whether result messages are prompted when
Setup commands are executed. The result messages are:
OK/ERROR for command execution, or
CONNECT/DISCONNECT/Try Connect Device for connection
status.

18
(Default) YPrompt result messages.
NDon't prompt result messages.
?Inquire the current setting.
RECONNE-
CT= Used to re-connect the lost link for the Master adapter.
?Inquire the current setting.
(Default) NRe-connect is disable
YRe-connect is Enable
ROLE=
Used to specify whether the adapter is in the master or slave
role. If the device role is changed, the adapter will reboot and
all paired addresses will be cleared. The command is available
when the adapter is in DIP=N status. The command will have
1 second delay.
MSet the adapter to the master role.
(Default) SSet the adapter to the slave role.
?Inquire the current role of the adapter.
RSSI= Received signal strength indication.
?
Display the strength of signal received in command mode
when connected.
1. Strong: RSSI>-9
2. Medium:-9>RSSI>-20
3.Weak:RSSI<-20
SEARCH=
Used to search for any Bluetooth device in the environment
within one minute. If any device is found, its name and its 12-
digit-address will be listed. The search ends with a message
"Inquiry ends. xx device(s) found." This command is available
only when the adaptor is in the master role by manual.
?Inquire Bluetooth devices in the environment, listing 8 devices
maximum
STATUS= Inquire all the current setting of the adapter.
YInquire the inner temperature of the IC in centigrade
?Display the current setting of the adapter

19
STOP= Used to specify one or two stop bits of COM port. (Will have
200ms delay.)
(Default) 1One stop bit.
2Two stop bits.
?Inquire the current setting.
VERSION= Used to inquire the firmware version.
?Inquire the version codes.
Command is not available under following status:
1ROLE=S SEARCH=? , CONNECT=?, CONNECT=P ,
CONNECT=xxxxxxxxxxxx , CONNECT=DEVICE
2AUTO=Y SEARCH=? , CONNECT=? , CONNECT=P ,
CONNECT=xxxxxxxxxxxx , CONNECT=DEVICE
3DIP=Y ROLE=M, ROLE=S , AUTO=Y , AUTO=N
,DISCOVER=Y,DISCOVER=N
4<<< SEARCH=? , CONNECT=? , CONNECT=P ,
CONNECT=xxxxxxxxxxxx , CONNECT=DEVICE
5>>> SEARCH=? , CONNECT=? , CONNECT=P ,
CONNECT=xxxxxxxxxxxx , CONNECT=DEVICE
6Not connection RSSI=? , CONNECT=Y , CONNECT=N
Pin Assignment

20
DSR/DTR Connection
Pin Signal DTE
Direction
DCE
Direction Description
1CD Input Output Not connected
2TxD Output Input Transmitting data
3RxD Input Output Receiving data
4DSR Input Output Contact manufacturer for set up
5GND N/A N/A Signal ground
6DTR Output Input Contact manufacturer for set up
7CTS Input Output Clear to send
8RTS Output Input Request to send (Default)
9Vcc Input Input Power supply (5VDC, 1.5A Max.)
