007-4417-001 1
Chapter 1
1. SGI Altix 350 Quick Start Guide
This book guides a knowledgeable user through the installation, setup, and simple configuration
of most SGI Altix 350 systems.
For more detailed information, or for setup instructions for more complex Altix 350 systems,
please refer to the SGI Altix 350 User’s Guide.

2007-4417-001
1: SGI Altix 350 Quick Start Guide
Positioning and Powering an Altix 350 System
Depending on the system ordered, your Altix 350 system may have been shipped as a number of
individual chassis or mounted in a rack. This section describes positioning and powering your
system in either of these instances.
Positioning an Altix 350 System
If your Altix 350 system was shipped as a number of individual chassis, they may be placed on a
flat surface, as shown in Figure 1-1 on page 3, or placed in a rack. For instructions on mounting
Altix 350 chassis in a rack, and for information about rack positioning, refer to the SGI Altix 350
User’s Guide.

Positioning and Powering an Altix 350 System
007-4417-001 3
Powering an Altix 350 System
Plug your Altix 350 system into a suitable power outlet, as shown in Figure 1-1 (for non-racked
chassis) or Figure 1-2 (for racked chassis). Refer to the Altix 350 User’s Guide for detailed power
requirements.
Figure 1-1 Connecting an Altix 350 Non-Racked System to Power
Expansion compute module
Base compute module

4007-4417-001
1: SGI Altix 350 Quick Start Guide
Figure 1-2 Connecting an Altix 350 Racked System to Power
Power
distribution
unit (PDU)
Power
source
Components within rack
G2N-brick
G2N-brick
G2N-brick
G2N-brick
Power
adapter
CMPX
module
CMPX
module
Base Compute
module
Optional L2 controller
CMPX
module
CMPX
module
CMPX
module
CMPX
module
CMPX
module

NUMAlink™Cabling for an Altix 350 System
007-4417-001 5
NUMAlink™Cabling for an Altix 350 System
If your system was shipped from SGI®with the modules already mounted in a rack and the
NUMAlink cables preinstalled, you should proceed to “Attaching a Serial Terminal to an Altix
350 System” on page 7.
This section describes the NUMAlink cabling for some simple configurations. For instructions to
cable more complex systems, see the SGI Altix 350 User’s Guide.
Figure 1-3 shows a system with a base compute module and a CMPX module.
Figure 1-3 Cabling in a Two-module Altix 350 System
NUMAlink 0
NUMAlink 0
Base compute
module
CMPX
module
NUMAlink 1
NUMAlink 1

6007-4417-001
1: SGI Altix 350 Quick Start Guide
Figure 1-4 shows a system with a base compute module, one CMPX module, and one CPU
expansion module.
Figure 1-4 CablinginaThree-moduleAltix350System
NUMAlink 0
NUMAlink 0
Base compute
module
CMPX
module
NUMAlink 1
NUMAlink 1
NUMAlink 0
CPU
expansion
module
NUMAlink 1

Attaching a Serial Terminal to an Altix 350 System
007-4417-001 7
Attaching a Serial Terminal to an Altix 350 System
If your Altix 350 system was shipped in a rack without an optional Level 2 controller, or was
shipped as individual chassis, you should connect a serial terminal to the Level 1 controller
contained in the host system master CPU module as shown in Figure 1-5.
Figure 1-5 Connecting a Serial Terminal to an L1 Controller
Base compute
module
DB-9 serial port
connector (L1 console)
DB-9
connector
Serial terminal

8007-4417-001
1: SGI Altix 350 Quick Start Guide
If your Altix 350 system was shipped in a rack with an optional Level 2 controller, you should
connect a serial terminal to that Level 2 controller, which is located in the top of the rack as shown
in Figure 1-6 (this view shows the back of the rack).
Figure 1-6 Connecting a Serial Terminal to an L2 Controller
Console port
SGI Altix 350
system
L2 controller
Serial terminal

Powering and Booting an Altix 350 System from a Serial Terminal
007-4417-001 9
Powering and Booting an Altix 350 System from a Serial Terminal
The power up procedure varies, depending on whether your serial terminal is connected directly
to an L1 system controller or the optional L2 system controller. Refer to the appropriate section
below.
Powering and Booting From an L1 System Controller
Use the following steps to connect your Altix 350 system via serial cable to the L1 controller (see
Figure 1-5):
1. Attach a serial cable to the lowest compute node in the system using the following:
• Serial DB9 Female to Female cable P/N 018-0691-001
• The settings for the L1 serial port are as follows:
Baud rate 38400
8 data bits
1 stop bit
No parity
RTS/CTS flow control (hardware flow control)
2. Attach the other end of the cable to a PC serial port with “cu” or other similar terminal
emulation program.
3. On the PC enter the following command.
cu -l ttyS0 -s 38400
This assumes the tty device on the PC is ttyS0.
There should be a “connected” response.
Hit return again and you should get a L1 prompt:
001c01-L1>

10 007-4417-001
1: SGI Altix 350 Quick Start Guide
4. From the L1 prompt enter the command “cfg”
This should return a list of all the modules in the system.
001-L2>cfg
L2 137.38.68.26: - 001 (LOCAL)
L1 137.38.68.26:0:0 - 001c01
L1 137.38.68.26:0:1 - 001c03
L1 137.38.68.26:0:5 - 001c05
001c04-L1>
5. If all the modules in your system are not seen, check the NUMAlink cabling, also insure that
the L1 is powered on all modules.
6. To power up the system, enter the L1 command “pwr u”
001c01-L1>pwr u
001c01-L1>
7. When the L1 prompt returns, enter a “cntrl d” to break in to the console.
This will show the output of the power on boot process.
This will get you to a EFI SHELL prompt.

Powering and Booting an Altix 350 System from a Serial Terminal
007-4417-001 11
Powering and Booting From an L2 System Controller
Use the following steps to connect your Altix 350 system via serial cable to an optional L2
controller (see Figure 1-6):
1. Attach a serial cable to the lowest compute node in the system using the following:
• Serial DB9 Female to Female cable P/N 018-0691-001
• The settings for the L2 serial port are as follows:
Baud rate 38400
8 data bits
1 stop bit
No parity
RTS/CTS flow control (hardware flow control)
2. Attach the other end of the cable to a PC serial port with “cu” or other similar terminal
emulation program.
3. On the PC enter the following command.
cu -l ttyS0 -s 38400
This assumes the tty device on the PC is ttyS0.
There should be a “connected” response.
Hit return again and you should get a L2 prompt:
001-L2>
1. From the L2 prompt enter the command “cfg”
This should return a list of all the modules in the system.
001-L2>cfg
:0 - 001c01
:1 - 001c03
:5 - 001c05
001-L2>
2. If all the modules in your system are not seen, check the NUMAlink cabling, also insure that
the L1 is powered on all modules.

12 007-4417-001
1: SGI Altix 350 Quick Start Guide
3. To power up the system, enter the L2 command “pwr u”
001-L2>pwr u
001-L2>
4. When the L2 prompt returns, enter a “cntrl d” to break in to the console.
This will show the output of the power on boot process.
This will get you to a EFI SHELL prompt.
Connecting the L2 Controller to a Local Ethernet Network
The L2 controller can be configured with a static IP address or the L2 controller will obtain an IP
address from a DHCP server on the network.
Use the following steps to configure your optional L2 controller with a static IP address:
Step 1 can be omitted if the L2 controller will use DHCP.
1. From the L2 prompt, enter the command “ip”
001-L2>ip aaa.bb.cc.ddd 255.255.255.0 aaa.bb.cc.255
The first sting is the system IP address. Contact your network administrator for your system
IP address. The second string is netmask, and the third string is the broadcast address. The
first three sections of the broadcast address are the same as the system IP address.
2. Assign the system name using the command “sysname”
001-L2>sysname (your system name)
3. To prevent L2s from different systems from communicating with each other, enable the multi
system option “msys”
001-L2>msys on
4. Finally, reboot the L2 controller.
001-L2>reboot_l2
