Silicon Laboratories TSM1285 User manual

TSM1285 Demo Board
A 300ksps, Single-supply, 12-Bit Serial-output ADC
Page 1
© 2014 Silicon Laboratories, Inc. All rights reserved.
FEATURES
Quick and easy Interface to computer for
evaluation via Nano River Technologies
ViperBoard and USB cable
Input BNC connection
On-board +3.3V supply voltage
External power supply connection available
Fully Assembled and Tested
2in x 3in 2-layer circuit board
DESCRIPTION
The demo board for the TSM1285 is a completely
assembled and tested circuit board that can be used
for evaluating the TSM1285. For easy and quick
evaluation of the TSM1285, a Nano River Tech
ViperBoard with an onboard microcontroller and
FPGA for signal processing is available. The
ViperBoard interfaces to any computer via USB port
and a user-friendly Windows OS compatible software
is available for evaluation.
The TSM1285 – a single-supply, single-channel, 12-
bit analog-to-digital converter (ADC) - is an alternate
source for the MAX1285 and a higher-speed upgrade
to the MAX1240 and MAX1240 ADCs. The TSM1285
combines a high-bandwidth track-and-hold (T/H), a
high-speed serial digital interface, an internal +2.5V
reference, and low conversion-mode power
consumption. The TSM1285 operates from a single
+2.7V to+3.6V supply and draws less than 2.5mA at
300ksps.
Product data sheet and additional documentation can
be found at www.silabs.com.
ORDERING INFORMATION
Order Number Description
TSM1285DB TSM1285
Demo Board
TSDA-VB Nano River Tech ViperBoard
Figure 2. TSM1285 Evaluation Board
(Top View)
Figure 1. TSM1285 Evaluation Board
with Nano River Tech ViperBoard
Figure 3. TSM1285 Evaluation Board
(Bottom View)

TSM1285 Demo Board
Page 2 TSM1285-EVB Rev. 1.0
Description
The TSM1285 demo board provides an easy-to-use
scheme for evaluating the TSM1285. The default
configuration of the demo board in conjunction with
the Nano River Technologies ViperBoard is for
operation at a supply voltage of VDD =+3.3V.
The TSM1285 demo board includes a
74ALVC164245 signal level translator in order to
translate signal levels from VDD of the TSM1285 to
+3.3V signal voltage levels necessary for the
ViperBoard. The TSM1285 and the ViperBoard are
connected via an on-board 34-pin ribbon socket (X1).
A separate power supply can be used to power the
TSM1285 from +2.7V to +3.6V. If evaluating the
TSM1285 demo board without the ViperBoard, a
single power supply is needed. A BNC connector is
available for the input of the TSM1285, AIN, and it is
recommended to use a low-noise signal generator in
order to acquire optimal SNR and THD results. Refer
to Table 1. Figure 6 shows the TSM1285 demo
board schematic, Figure 2 and Figure 3 show a
picture of the top and bottom of the TSM1285 demo
board, respectively. Figure 1 shows a picture of the
TSM1285 demo board with the ViperBoard
connected.
A USB cable is used to interface the ViperBoard to a
PC with Windows Vista 32-bit/Vista 64-bit/XP/7. For
the “Touchstone ADC Evaluation Platform GUI”
user’s manual and for the necessary driver and GUI
installer files needed to successfully evaluate the
TSM1285 with the ViperBoard, please refer to
www.silabs.com.
Quick Start Procedure
Required Equipment
TSM1285 Demo Board
Nano River Tech ViperBoard
USB cable
Computer with Windows Vista 32-bit/64-bit/XP/7
ViperBoard driver and GUI software installed to
PC( refer to “Touchstone ADC Evaluation
Platform GUI” user’s manual)
Low-noise Signal Generator Stanford Research
Systems Model DS360 or better w/ BNC cable
In order to evaluate the TSM1285, jumper J2 is to be
set to position 1-2. The default configuration for J2 is
1-2. Refer to Figure 6 and Table 1. The default
configuration on the board is for VDD = +3.3V. The
following steps are to be performed:
1) Connect the TSM1285 demo board to the
ViperBoard via the 34-pin socket (X1).
2) Set the function generator frequency, amplitude,
and offset to 70kHz, 2.499VPP, and 1.25V,
respectively. Then, connect the BNC cable from
the signal generator to the BNC connector AIN on
the TSM1285 demo board. Set the output of the
signal generator to OFF.
3) To run the GUI, go to Start > All Programs >
TouchStoneEvalBoard 2.2.10 > 01 Touchstone
Evaluation App. The GUI should appear and on
the top right hand side, the status should be “PC
disconnected” and “No Type” for demo board
type. Both should be highlighted in red indicating
the ViperBoard and the TSM1285 demo board is
not connected.
4) Connect one side of the supplied USB cable to
the ViperBoard USB connector. Connect the
other side to a USB port on the PC. After
approximately three seconds, the status on the
GUI screen will switch to “PC Connected” and
“TSM1285” indicating the ViperBoard and the
TSM1285 demo board were recognized
successfully by the software. The green LED on
the TSM1285 demo board should be ON and the
green LED on the ViperBoard, D2, should be ON.
Use the default sampling rate of 300kSPS and an
FFT length of 8192.
5) Turn on the signal generator. On the GUI screen,
click on “continuous” in the sampling section, and
monitor the results on the screen. The top plot
shows a samples vs code plot and the bottom
plot is an FFT plot. The SNR and THD values
should be approximately 70dB and –80dB,
respectively. Please refer to Figure 4 for an
example of what the results should look like. In
this case, the SNR and THD values are 69dB and
-85dB, respectively.
Additional Functions
6) As shown in the TSM1285 ADC section, a
shutdown control function is available. If the
“shutdown” button is selected when sampling in
continuous mode, the TSM1285 will be in
shutdown mode and no additional conversions

TSM1285 Demo Board
TSM1285-EVB Rev. 1.0 Page 3
will occur. To de-assert the shutdown function,
press the button again and the conversions will
resume. Figure 5 shows what the GUI looks like
when the shutdown control function is enabled.
7) A shutdown between conversions function is
available by selecting the “Shutdown between
conversions” box. Refer to Figure 4. When
performing a continuous conversion, press the
“shutdown” button and then select the
“Shutdown between conversions” box. The
samples vs code and the FFT plot will update
after every conversion.
8) To perform a single conversion, press the “single”
button in the sampling section.
9) For details on the evaluation platform GUI, refer
to the “Touchstone ADC Evaluation Platform GUI”
user’s manual at: www.silabs.com.
.
Figure 4. TSM1285 Response with GUI
Sampling section
TSM1285 ADC section
Samples vs Code plot
FFT plot

TSM1285 Demo Board
Page 4 TSM1285-EVB Rev. 1.0
.
Figure 5. TSM1285 Shutdown Control Enabled

TSM1285 Demo Board
TSM1285-EVB Rev. 1.0 Page 5
Evaluation with TSM1285
Demo Board Only
Required Equipment
TSM1285 Demo Board
DC Power Supply
Low-noise Signal Generator Stanford Research
Systems Model DS360 or better w/ BNC cable
Ammeter
In order to evaluate the TSM1285 using the TSM1285
demo board only, additional input signals for the CS




SCLK and SHDN









pins will be necessary along with an
oscilloscope to monitor the inputs and output. The
following steps are to be performed:
1) Set the voltage of the power supply between
+2.7V and +3.6V and turn it off. Connect the
positive terminal of the DC power supply to pin 12
labeled as “3.3V” on X1, and the ground terminal
to pin 2 labeled as “GND”. Refer to Figure 6.
2) Timing signals for the TSM1285 input signals
AIN, CS




, SHDN









, and SCLK should be set
according to the desired measurement based
while following the product datasheet
specifications. Refer to the TSM1285 product
data sheet “Description of Operation” for details.
Access to these pins is available through the 34-
pin socket, X1, labeled as “SCLK”, “CS




",
"SHDN"










, and “DOUT”. The corresponding pins on
X1 are 10, 8, 4, and 6, respectively.
3) To measure the supply current of the TSM1285,
place jumper J2 to position 2-3. Then, apply an
external power supply to J1. An ammeter can
now be connected in series with the power supply
for a supply current measurement of the
TSM1285. The supply current should be less
than 650µA. Please refer to Figure 6 and table 1.
Figure 6. TSM1285 Evaluation Board Circuit

TSM1285 Demo Board
Page 6 TSM1285-EVB Rev. 1.0
DESIGNATION QTY DESCRIPTION
C4, C10, C11 3 0.1µF ±10%
capacitor (0603)
C12, C13, 2 10µF ±10%
capacitor
(SMD6032)
C5, C6 2 4.7µF ±10%
capacitor
(SMD6032)
C2 1 100pF ±10%
capacitor (0603)
R16 1 150Ω± 1% (0603)
R15 1 1kΩ± 1% (0402)
LED 1 Green LED (0603)
AIN 1 BNC connector
J1 1 2-pin terminal
block
X1 1 34-pin socket
U2 1 74ALVC164245
translating
transceiver
J2 1 Jumper
U3 1 TSM1285
Table 2. Component list
J1 J2 X1 External
Power
Supplies
TSM1285DB w/
Nano River Tech
ViperBoard
NA 1-2 (VDD = 3.3V
only) 34-pin socket
0
+2.7V
to
+3.6V 2-3 1
TSM1285 Only
NA 1-2 Apply +2.7 to
+3.6V to pin 12 1
TSM1285 Only
(Supply Current
Measurement)
+2.7V
to
+3.6V 2-3 NA 1
Table 1. J1, J2, and X1 connections

TSM1285 Demo Board
Silicon Laboratories, Inc. Page 7
400 West Cesar Chavez, Austin, TX 78701 TSM1285-EVB Rev. 1.0
[phone] ▪www.silabs.com
Figure 6. Top Layer Component View
Figure 7. Top Layer Trace View
Figure 8. Bottom Layer #1 Figure 9. Bottom Layer #2
