Silvercrest hd camcorder with hdmi connection User manual

SCAZ 5.00 A1 Table of Contents
English - 1
Table of Contents
Important Notice 6
Safety Instructions......................................................................................6
Children and Persons with Disabilities ......................................................8
Charger and Rechargeable Battery ..........................................................8
Cables........................................................................................................9
Repair and Maintenance .......................................................................... 10
Intended Use............................................................................................10
Conformity Notice.....................................................................................11
Disposal of Old Devices ...........................................................................11
Introduction 12
Package Contents.................................................................................... 12
Controls and buttons ................................................................................ 13
Front........................................................................................................13
Rear Panel..............................................................................................13
Left Panel................................................................................................14
Right Panel .............................................................................................14
Top.......................................................................................................... 15
Bottom.....................................................................................................15
Opening the Display................................................................................. 16
Getting Started......................................................................................... 17
Charging the Battery by Using the Charger ............................................17

Table of Contents SCAZ 5.00 A1
2 -English
Charging the Battery while Inserted in the Camcorder ........................... 19
Inserting the Battery................................................................................ 20
Inserting the SD Card ............................................................................. 21
Write-Protecting the Memory Card ......................................................... 24
Switching the Camcorder On and Off ..................................................... 25
Switching the Operating Mode................................................................ 25
The Touch-Sensitive Display .................................................................. 25
Setting the Menu Language.................................................................... 26
Setting Date and Time............................................................................ 26
Recording 27
Recording Videos .................................................................................... 27
The Video Mode Display......................................................................... 28
Macro Mode............................................................................................. 30
Manual Focus .......................................................................................... 30
Locking the Auto Focus ........................................................................... 30
Capturing Pictures ................................................................................... 31
The Photo Mode Display ........................................................................ 32
Video Lamp.............................................................................................. 34
Playback 35
Playing Back Video Clips......................................................................... 35
Playing Back Photos................................................................................ 38
The Menus 40
The Main Menu........................................................................................ 40

SCAZ 5.00 A1 Table of Contents
English - 3
Main Menu Icons.....................................................................................41
Date/Time ............................................................................................... 42
Beep........................................................................................................ 42
Auto PowerOff......................................................................................... 42
TV standard ............................................................................................ 43
Format..................................................................................................... 43
Default.....................................................................................................44
Language................................................................................................ 45
Frequency............................................................................................... 45
Video Menu..............................................................................................46
White Balance.........................................................................................47
Resolution...............................................................................................47
Effect....................................................................................................... 48
Night Mode.............................................................................................. 49
Quality.....................................................................................................50
Video Playback Menu ..............................................................................50
Video Playback Menu Icons....................................................................51
Deleting A Video Recording....................................................................51
Deleting all video recordings ...................................................................52
Protect..................................................................................................... 53
Autoplay.................................................................................................. 53
Photo Menu.............................................................................................. 54
Photo Menu Icons ...................................................................................54
White Balance.........................................................................................55
Resolution...............................................................................................55
Effect....................................................................................................... 56

Table of Contents SCAZ 5.00 A1
4 -English
Night Mode ............................................................................................. 56
Selftimer ................................................................................................. 56
Quality .................................................................................................... 57
Photo Playback Menu.............................................................................. 57
Delete one picture .................................................................................. 58
Delete all pictures ................................................................................... 58
Protect .................................................................................................... 58
Autoplay.................................................................................................. 58
Connectors and Sockets 59
Viewing Recordings on a Television Screen............................................ 59
Connecting via the HDMI Cable ............................................................. 59
Connecting via the USB/AV Cable ......................................................... 60
Transferring Recordings to the Computer................................................ 60
Using the USB port................................................................................. 61
Using a Card Reader .............................................................................. 62
Software 63
System Requirements ............................................................................. 63
Installing the Software ............................................................................. 63
Uninstalling the Software ........................................................................ 64
The Main Dialog....................................................................................... 64
Select language...................................................................................... 65
Editing Recordings................................................................................... 65
Viewing Recordings................................................................................ 65
Importing Recordings.............................................................................. 66

SCAZ 5.00 A1 Table of Contents
English - 5
Selecting the Navigation View................................................................. 67
Preview Window ..................................................................................... 68
Toolbar..................................................................................................... 69
Import...................................................................................................... 69
Merge videos ..........................................................................................69
Creating an AVCHD Disk ........................................................................ 70
Cutting Video Clips ................................................................................. 71
Upload to YouTube ................................................................................. 71
Upload to Facebook................................................................................ 71
Photo Album ...........................................................................................72
Album page............................................................................................. 72
Appendix 73
Technical Specifications........................................................................... 73
Warranty Information................................................................................ 75
Declaration of Conformity....................................................................... 228

Important Notice SCAZ 5.00 A1
6 -English
Important Notice
This icon denotes important information for the safe
operation of the product and the user’s safety.
This icon denotes further information on the topic.
Safety Instructions
Before you use this device for the first time, please read the following
notes in this manual and heed all warnings, even if you are familiar
with handling electronic devices. Always check that the product works
correctly.
Keep this manual with the instructions in a safe place for future
reference.
If you sell the device or pass it on, it is essential that you also hand
over this manual.
Do not try to open the housing or reassemble the product. You are at
risk of receiving an electric shock. Maintenance and repairs should
only be carried out by qualified technicians.
Do not look at the sun or other sources of intense light. Doing so may
damage your eyesight.
Keep the device away from water and other liquids. Do not operate the
device with wet hands and do not use it in rain or snow. Dampness can
cause danger through fire or electric shock.
Keep the device out of the reach of children and animals to avoid
accidents or damage.

SCAZ 5.00 A1 Important Notice
English - 7
Switch the device off immediately if you notice it emitting smoke or
strange noises. Contact customer service. Never try to repair the
device yourself.
Only use the supplied charger cradle Scope DJ04V20500A or the USB
interface cable to recharge the product battery.
Only use this device with the supplied rechargeable battery (NP120) in
order to avoid overheating, deformation of the cover, fire, electric
shocks, explosion and other dangers.
Unplug the power cord from the mains outlet before you remove the
rechargeable battery from the charger or separate the charger from the
power cord.
In the event of a defect in the product or its accessories, unplug the
power cord from the mains immediately.
Also, when there is the possibility of thunderstorms, unplug the power
cord from the wall outlet.
Never try to heat, disassemble or short-circuit the rechargeable
battery. Do not throw the rechargeable battery into fire.
Warning:
Notice concerning separation from the mains
The supplied charger consumes electrical energy even if there is no
battery inserted. You should therefore disconnect the charger from the
wall outlet when not using it. In order to completely disconnect the charger
from the mains, unplug the power cord from the wall outlet. The wall outlet
where the device is connected must be easy to access so that the power
cord can be pulled out quickly in case of emergency. Unplug the power
cord from the mains when you will not be using it for a long while (e.g.
when going on holiday) in order to avoid the danger of fire. Do not hold the
power cord with wet hands.
The device is not for use in rooms with a high temperature or humidity and
must be kept free of dust. Position the device on a stable, flat surface and
do not place any objects on the device.

Important Notice SCAZ 5.00 A1
8 -English
Always make sure that:
no direct heat sources (e.g. heating) affect the device;
no direct sunlight or bright artificial light reaches the device;
contact with spray and dripping water and abrasive liquids must be
avoided and the device should never be operated near water, and it
must especially never be immersed (do not place any objects filled with
liquids such as vases or drinks near the device);
do not place any fire sources (e.g. burning candles) on or near the
device;
no foreign bodies enter the device;
the device must not be subject to any great temperature changes as
this may cause moisture through condensation;
the device should not be subject to excessive shock and vibrations.
Children and Persons with Disabilities
Do not allow children or persons with disabilities to use electrical devices
when not under supervision. They may not comprehend the presence of
potential risks. Rechargeable batteries and small parts represent potential
choking hazards. Keep batteries out of reach of children. If a rechargeable
battery is swallowed, seek medical help immediately. Keep all packaging
away from children as this may cause suffocation.
Charger and Rechargeable Battery
Insert the rechargeable battery with the correct polarity. Never throw a
rechargeable battery into fire. Remove the rechargeable battery when the
device is not to be used for a long time.
Danger of Explosion!
Improper use may cause explosions and danger to life. Only replace the
rechargeable battery with an equivalent or a type recommended by the

SCAZ 5.00 A1 Important Notice
English - 9
manufacturer. Never replace any batteries in an explosion-sensitive
environment. While inserting or removing the batteries a spark may be
produced causing an explosion. Explosion-sensitive areas will normally
(but not always) be labelled. These include fuel storage areas such as
below deck on a boat, fuel line or tank areas, environments where the air
contains inflammable substances (e.g. cereals, dust or metal powder, etc.)
and any areas where you should normally switch off your car engine.
Respect the environment. Old rechargeable batteries do not belong in with
domestic waste. They must be handed in to a collection point for waste
batteries.
Cables
Always hold cables by the plug and never pull on the cable itself. Never
hold the power cord with wet hands as this may cause a short circuit or
electric shock. Never place the device, heavy objects or furniture on the
cable and take care that the cord does not become trapped, especially at
the plug and sockets. Never tie knots in the cable and do not tie it together
with other cables. All cables should be positioned so that nobody can trip
over them or be obstructed by them. A damaged power cord can cause a
fire or an electric shock. Inspect the power cord from time to time. Do not
use an adapter plug or extension cable that does not meet the required
safety standards.

Important Notice SCAZ 5.00 A1
10 -English
Repair and Maintenance
Repairs are required when this device has been damaged in any way: for
example, when the charger or the housing of the SCAZ 5.00 A1 is
damaged, when liquid or objects have entered the device, when the
product has been exposed to rain or moisture, when the product does not
work normally or if the product has been dropped. If you notice any
smoke, unusual noise or strange smells, switch off the device immediately
and unplug the power cord from the power supply. If this occurs the device
should no longer be used and should be inspected by authorized service
personnel. Please contact qualified personnel when servicing is needed.
Intended Use
Your camcorder is a Consumer Electronics device and is designed for
recording and playing back videos and pictures only. Any use other than
that mentioned above does not correspond to the intended use. The
device may only be used for private use, not industrial or commercial use.
In its default configuration, this product has not been designed for medical,
lifesaving, rescue or life-maintaining purposes.
This device fulfils all that relates to CE Conformity, relevant standards and
Directives. Any changes to the equipment other than those recommended
by the manufacturer may lead to these directives no longer being met.
Only use the accessories recommended by the manufacturer. If you are
not using the device within the Republic of Germany, you must observe
the regulations and laws in the country of use.

SCAZ 5.00 A1 Important Notice
English - 11
Conformity Notice
This device and its supplied accessories have been tested
and approved for compliance with the basic and other
relevant requirements of the EMC Directive 2004/108/EC,
as well as the Low-voltage Directive 2006/95/EC. The
corresponding Declaration of Conformity can be found at the
end of this User's Manual.
Disposal of Old Devices
Devices marked with this symbol are subject to the
European Directive 2002/96/EC. All electric and electronic
devices must be disposed of separately from household
waste at official disposal centres.
Avoid hazards to the environment and dangers to your personal health by
disposing of the device properly. For further information about proper
disposal, contact your local government, disposal bodies or the shop
where you bought the device.
Recycle the packaging material properly too. Cardboard packaging can be
taken to paper recycling containers or public collection points for recycling.
Any film or plastic contained in the packaging should be taken to your
public collection points for disposal.
Respect the environment. Old batteries do not belong in with domestic
waste. They must be handed in to a collection point for waste batteries.

Introduction SCAZ 5.00 A1
12 -English
Introduction
Package Contents
Camcorder SCAZ 5.00 A1
2 rechargeable batteries
Roofer Technology Co., Ltd. NP120
Charger Scope DJ04V20500A
Power Cable
USB/AV cable
HDMI cable
SD memory card, 4GB (not illustrated)
CD-ROM (not shown)
Bag (not illustrated)
User's manual (not shown)

SCAZ 5.00 A1 Introduction
English - 13
Controls and buttons
Front
1Lens
2 Self-timer indicator
3 Video lamp
Rear Panel
4 Power indicator
5 Navigation button
6 HDMI input, USB
and AV port,
charger DC in
7 Mode selection
switch
8 RECORD button

Introduction SCAZ 5.00 A1
14 -English
Left Panel
9 Microphone
10 Video lamp button
11 Display button
12 Menu button
13 PLAY button
14 Memory card
compartment
15 On/Off button
Right Panel
16 Hand strap
17 Battery
compartment

SCAZ 5.00 A1 Introduction
English - 15
Top
18 Speakers
19 Battery
compartment lock
20 Zoom swivel
button
21 Picture (photo)
shutter button
Bottom
22 Memory card
compartment
23 Tripod mount

Introduction SCAZ 5.00 A1
16 -English
Opening the Display
Open the display and then rotate it according to your needs.
You can also rotate the display so it faces the front. In this case, the
picture orientation will be adjusted automatically.
The rotated display can be folded completely until it touches the camera
housing.

SCAZ 5.00 A1 Introduction
English - 17
Getting Started
The camcorder is powered by a rechargeable Lithium-Ion (NP120) battery.
On delivery, the battery is not charged. Please charge the battery before
first use of the device.
To operate the camera, use only the rechargeable
Lithium-Ion battery NP120.
Charging the Battery by Using the Charger
Insert the rechargeable battery in the charger cradle Scope DJ04V20500A
so that the contacts [+] and [-] correspond to the rechargeable battery and
charging tray markings.

Introduction SCAZ 5.00 A1
18 -English
Make sure that the battery clicks into place on the charger. Next connect
the power cord to the charger and plug the power cord to a wall outlet.
Remove the rechargeable battery from the camera when
the device is not to be used for a long time.
During charging, the rechargeable battery and charging
device will become warm. This is not a malfunction.
The status indicator of the charging cradle will light orange whilst the
battery is charging. When the charging process is completed, the status
indicator will light green. You can then insert the rechargeable battery into
the camcorder. Depending on the charge level, the charging cycle can
take up to 3 hours.
If, after inserting the rechargeable battery, the indicator
remains green, this means the rechargeable battery is
already charged or it is not correctly inserted. In this case,
check the polarity.
