Silvercrest SGBR 1500 A1 User manual

IAN 102464
ELECTRIC OVEN & GRILL SGBR 1500 A1
GRILL- UND BACKAUTOMAT
Bedienungsanleitung
ELECTRIC OVEN & GRILL
Operating instructionss MINIUUNI JA GRILLI Käyttöohje
GRILL- OCH BAKUGN
Bruksanvisning
GRILL- EN BAKAUTOMAAT
Gebruiksaanwijzing

GB/IE Operating instructions Page 1
FI Käyttöohje Sivu 15
SE Bruksanvisning Sidan 29
NL/BE Gebruiksaanwijzing Pagina 43
DE/AT/CH Bedienungsanleitung Seite 57
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Käännä ennen lukemista kuvallinen sivu esiin ja tutustu seuraavaksi laitteen kaikkiin toimintoihin.
Vik ut bildsidan och ha den till hands när du läser igenom anvisningarna och gör dig bekant med
apparatens/maskinens funktioner.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u vertrouwd met alle functies van het
apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

B
A
7
9
8
1
2
3
4
5
6
e
w
q
ztr
0

1
SGBR 1500 A1
GB
IE
Contents
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Proper use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Appliance description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Setting up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Using the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Glass door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Inserting the crumb tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Using the rotisserie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using the baking tray/rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Before first use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Operating the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Function switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Temperature control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Grilling and baking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Grilling with the rotisserie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Cleaning and care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Warranty and service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

2SGBR 1500 A1
GB
IE
Introduction
Congratulations on the purchase of your new
appliance.
You have selected a high-quality product.
The operating instructions are part of this product.
They contain important information on safety, usage
and disposal. Before using the product, familiarise
yourself with all handling and safety guidelines.
Use the product only as described and for the
range of applications specified. Please also pass
these operating instructions on to any future
owner(s).
Proper use
The automatic oven and grill is intended for the
heating, cooking and grilling of food.
This appliance is intended solely for use in private
homes. Do not use it for commercial applications.
All other uses are deemed to be improper and may
result in property damage or even in personal injury.
Package contents
♦ Electric Oven & Grill
♦ 1 baking tray
♦ 1 rack
♦ 2 tongs
♦ Rotisserie with 2 clamps
♦ 1 crumb tray
♦ Operating instructions
NOTE
Check contents for completeness and damage
immediately after unpacking. Contact Customer
Services if necessary.
Appliance description
Figure A:
1Drive
2Temperature control
3Function switch
4Timer
5Control lamp
6Glass door
7Crumb tray
8Lower heating element
9Spit fitting
Figure B:
0Tongs (baking tray or rack)
qBaking tray
wTongs (for spit)
erack
rRestrainer
tSkewer clamps
zRotisserie
Technical data
Rated voltage: 220 - 240 V ~,
50/60 Hz
Max. power consumption: 1500 W

3
SGBR 1500 A1
GB
IE
Safety instructions
DANGER – RISK OF ELECTRIC SHOCK!
► Do not open the housing of the appliance or attempt to repair it.
Doing so can lead to risks and also invalidates the warranty.
Defective appliances should be repaired by the retailer or
authorized personnel only.
► Arrange for defective power plugs and/or cables to be replaced
as soon as possible by a qualified technician or by our Customer
Service Department to avoid the risk of injury.
► Do not allow any liquids to penetrate the housing. Do not expose
the appliance to moisture and do not use it outdoors. Additionally,
do not place fluid-filled receptacles such as flower vases on the
appliance. This increases the risk of fire and of receiving an electric
shock! If liquids permeate into the housing, unplug the appliance
immediately and arrange for it to be repaired by a qualified
technician.
► Never touch the appliance, power cable or power plug with wet
hands. There is a risk of electric shock!
NEVER immerse the appliance in water or other liquids!
Risk of electrocution if residual liquids come into contact with
live components during operation.

4SGBR 1500 A1
GB
IE
WARNING – RISK OF INJURY!
► This appliance may be used by children of the age of 8 years or
more and by persons with reduced physical, sensory or mental
capabilities or lack of experience and/or knowledge if they are
being supervised or have been instructed with regard to the safe
use of the appliance and have understood the potential risks.
► Children must not use the appliance as a plaything.
► Cleaning and user maintenance must not be performed by children
unless they are older than 8 years of age and are supervised.
► Children younger than 8 years of age must be kept away from
the appliance and the power cable.
► Route the power cable in such a way that no one can tread on it
or trip over it.
► Never touch the glass door or the housing during use, these can
get very hot. Use oven gloves or something similar to open the
glass door to avoid being burnt!
► Never touch the heating elements or the viewing window when
the appliance is in use, or before it has cooled down completely.
Do not reach into the cooking chamber when the appliance is in
use. Wait until the appliance has cooled down. Otherwise, you
could be burnt.
► Allow the appliance to cool down after use before transporting it.
► Always use oven gloves or a pot holder if you need to take hold
of the appliance.
Caution! Hot surface!

5
SGBR 1500 A1
GB
IE
CAUTION – PROPERTY DAMAGE!
► Do not use an external timer switch or a separate remote control
system to operate the appliance.
► Never leave the appliance unattended during operation.
► Ensure that the appliance, the power cable and the plug do not
come into contact with heat sources such as hotplates or naked
flames.
► Only operate the appliance with the original accessories supplied.
► Do not kink or crush the mains cable.
► To disconnect, always remove the plug itself from the mains
power socket, do not pull on the power cable.
► When the appliance is in use, ensure that there are no easily
inflammable materials in the immediate vicinity (e.g. dishcloths,
oven cloths, etc.).
► Never dry textiles or other objects on or above the appliance.
This increases the risk of fire!

6SGBR 1500 A1
GB
IE
Setting up
WARNING! RISK OF FIRE!
► Never place the appliance beneath wall cup-
boards or next to curtains, cupboard walls or
other flammable objects.
► Always ensure a minimum distance between
the appliance and hanging cupboards, ceilings,
walls or similar of at least 10 cm above the
appliance and 5 cm at the sides. For this
reason the appliance may not be used, for
example, in cupboards or similar. Otherwise
there is likely to be insufficient ventilation for
the appliance, which could cause a fire or
damage.
► Always place the appliance on a heat-resistant
surface. Failure to do so increases the risk of
fire or of it being damaged. The area under
the bottom can discolour and be damaged.
Additionally, if placed on a soft upper surface,
the appliance could cause permanent damage
to it due to pressure indentations.
DANGER – ELECTRIC SHOCK!
► Do not place the appliance immediately ad-
jacent to sources of water, e.g. sinks or basins,
or in damp cellar areas. Otherwise, there is
a risk of receiving an electric shock.
■ Place the appliance on a solid, level and heat-
resistant surface (e.g. stainless steel worktops
or natural stone worktops such as granite).
Ensure there is sufficient ventilation around the
appliance.
■ Clean all components as described in the
section “Cleaning and care”.
Using the appliance
Glass door
ATTENTION! DAMAGE TO PROPERTY!
► Do not lean on the glass door 6. Do not
place any objects on the glass door 6.
This can cause damage to the hinges.
■ If you are cooking especially fatty foodstuffs, this
can result in increased smoke production. In this
case, do not close the glass door 6 completely;
instead, leave it slightly open:
The glass door 6has a latching position so that
it remains open a little: if you carefully push the
glass door 6closed, it clicks into this position
shortly before closing completely.
Inserting the crumb tray
■ Push the crumb tray 7under the lower heating
element 8so that it rests flat on the bottom of
the appliance.

7
SGBR 1500 A1
GB
IE
Using the rotisserie
WARNING! RISK OF INJURY!
► Always use the tongs w to insert the hot rotis-
serie zinto the appliance or to remove it.
■ You can use the two skewer clamps tto fix the
food onto the rotisserie z. Loosen the restrainer r
on the skewer clamps t, push them so that the
food is fixed firmly in between the clamps and
then screw the restrainer rtight again.
■ First push the end of the rotisserie zwithout the
notch into the drive 1(Figure 1):
Fig. 1: Push the rotisserie zinto the drive 1.
■ Then insert the other end of the rotisserie zwith
the deep groove in the spit fitting 9(Figure 2):
Fig. 2: Insert the rotisserie zin the spit fitting 9.
NOTE
► Always slide the baking tray qinto the lower
rail when you use the rotisserie z.
This will collect any drips.
■ To remove the hot rotisserie z, grip with
the hooks at the end of the tongs winto the
recesses on the rotisserie z(Figure 3):
Fig. 3: Hooking the tongs wonto the rotisserie z
■ First lift the left-hand side of the rotisserie zout
of the spit fitting 9and then pull the rotisserie z
from the drive 1.

8SGBR 1500 A1
GB
IE
Using the baking tray/rack
WARNING! RISK OF INJURY!
► Always use the tongs 0to insert the hot
baking tray q/the hot rack einto the appli-
ance or to remove it.
■ Push the baking tray q/the rack einto one of
the 3 rails in the cooking chamber of the appliance.
ATTENTION! DAMAGE TO PROPERTY!
► Never place the baking tray q/the rack e
directly onto the heating elements 8.
■ To remove the hot baking tray qor the rack e,
hook the tongs 0onto them as follows:
Fig. 4: Hooking the tongs 0onto the rack e
Fig. 5: Hooking the tongs 0onto the baking
tray q
Before first use
1) Insert the plug into a mains power socket.
2) Turn the temperature control 2clockwise to
the maximum temperature (to the stop).
3) Turn the function switch 3to “upper and
lower heat” .
4) Open the glass door 6leave this open for this
operation.
5) Remove any installed accessories from the
cooking chamber.
6) Turn the timer 4to 20 minutes.
NOTE
► The first time the appliance heats up, a
small amount of smoke and odour may be
generated due to production-related residue.
This is normal and is completely harmless.
Provide sufficient ventilation by opening a
window, for example.
The appliance switches off automatically
after 20 minutes.
If you want to interrupt the heating process
prematurely, turn the temperature control 2
counter-clockwise to the stop and set the
timer 4to “OFF - 0”.
7) Allow the appliance to cool down, then clean
the appliance as described in the chapter
“Cleaning and care”.
The appliance is now ready for use.

9
SGBR 1500 A1
GB
IE
Operating the appliance
Function switch
You can switch on the appliance with the function
switch 3, and also set 5 different functions:
Symbol Meaning
"Upper heat"
e.g. to gratinate
"Lower heat"
e.g. for baking
"Upper & lower heat"
e.g. for baking a pizza
"Upper & lower heat/hot air/
rotisserie"
e.g. to roast poultry
"Upper & lower heat/hot air"
e.g. to reheat rolls
OFF "OFF" the appliance is
switched off.
Temperature control
Use the temperature control 2to set the desired
temperature.
■ If you set the temperature for the functions
“Upper heat” , “Lower heat” or “Upper
& lower heat” use the scale marked with “
”.
■ If you set the temperature for the functions
“Upper & lower heat/hot air/rotisserie”
or “Upper & lower heat/hot air” use the
scale marked with “ ”.
Timer
User the timer 4to set the cooking time.
■ Set the timer 4to the desired cooking time.
After expiry of the set time a signal tone sounds
and the appliance stops heating.
If the function “Upper & lower heat/hot air/
rotisserie” is selected, the rotisserie z
will also stop turning.
Grilling and baking
1) Put the crumb tray 7into the appliance.
2) Remove the rack eand baking tray qfrom
the appliance. If required, cover these with
baking paper or lightly grease the baking tray q
with suitable baking fat.
NOTE
► Depending on the meal, the oven must be
preheated. Refer to the guidelines in the
respective recipe. Preheating is useful for:
–very short baking times,
–crisp crusts,
–sensitive meals that require a constant
temperature, such as soufflés.
► If no preheating is required, skip step 3).
3) Allow the appliance to heat up for approx.
10 minutes (depending on the temperature
setting) to the required temperature:
–Select the required temperature using the
temperature control 2. Ensure that you use
the correct scale (see chapter “Temperature
control”).
–Select the required function with the function
switch 3.

10 SGBR 1500 A1
GB
IE
NOTE
► As a general rule, if you are baking or grilling
with hot air you can dispense with a preheating
of the grilling/cooking space.
–Use the timer 4to set the preheat time
(approx. 10 minutes).
–Close the glass door 6.
4) Once the warm-up period is finished, place
the foodstuffs on the rack eor the baking
tray qand slide it in on one of the rails.
Ensure that there is sufficient space between
the foodstuffs and the inner walls/heating
elements of the appliance.
NOTE
► If you wish to prepare food on the rack e
that drips excessively, then slide the baking
tray qonto the bottom rail. By doing this,
dripping fat for example will be caught and
the appliance is then easier to clean.
5) Close the glass door 6before starting the
grilling or baking process.
6) Use the timer 4to set the required grilling or
baking time. The maximum grilling or baking
time is 120 minutes.
NOTE
► If the cooking time for the food is less than
20 minutes, first set the timer 4to 40 minutes
and then turn it back to the required grilling
or baking time.
The control lamp 5indicates that the appliance is
now switched on. The switch of the timer 4now
rotates itself anti-clockwise to “OFF - 0”.
The appliance switches off automatically after the
set period, there is a beep and the control lamp 5
switches off.
NOTE
If you want to interrupt the heating process
prematurely, turn the temperature control 2
counter-clockwise to the stop and set the timer 4
to "OFF - 0".
7) After cooking, remove the rack eor the baking
tray qusing the tongs 0.
8) Set the function switch 3to “OFF”.
Grilling with the rotisserie
1) Put the crumb tray 7into the appliance.
2) If inserted, remove the rotisserie zfrom the
appliance.
3) Push the baking tray qonto the lower rail.
4) Fix the food to be grilled with the skewer
clamps t. Ensure that the food in the cooking
chamber can turn freely without touching the
sides. The rotisserie z may change its direction
of rotation if the food strikes against a resistance.
The two depressions on the rotisserie zmust
remain freely accessible, otherwise you will
not be able to grasp the rotisserie zwith the
tongs w.
5) Fit the rotisserie zin the cooking chamber
(see chapter “Using the rotisserie”)
6) Close the glass door 6.

11
SGBR 1500 A1
GB
IE
NOTE
If you want to interrupt the heating process pre-
maturely, turn the temperature control 2counter-
clockwise to the stop and set the timer 4to
"OFF - 0".
7) Adjust the temperature control 2to the desired
temperature.
8) Set the function switch 3to “Upper & lower
heat/hot air/rotisserie” . Set the timer 4
to the desired grill time.
The appliance starts the grilling process and
the rotisserie zstarts turning.
The control lamp 5indicates that the appliance is
now switched on. The switch of the timer 4now
rotates itself anti-clockwise to “OFF - 0”.
The appliance switches off automatically after the
set period, there is a beep and the control lamp 5
switches off.
NOTE
If you want to interrupt the heating process pre-
maturely, turn the temperature control 2counter-
clockwise to the stop and set the timer 4to
"OFF - 0".
9) After the grilling process is completed remove
the rotisserie zwith the help of the tongs w.
10) Set the function switch 3to “OFF”.
EXAMPLE: GRILLED CHICKEN
Ingredients
♦ Grilling chicken (approx. 1.3 kg,
guts removed)
♦ Spices (salt, paprika)
♦ Cooking oil
1) Season the chicken on the inside and outside
with salt and paprika powder. Brush it from
the outside with heat resistant cooking oil.
2) Push the chicken onto the spit and fix it in
place with the skewer clamps t. Ensure that
the notches on the rotisserie zremain free
so that you can remove the rotisserie z with
the help of the tongs w. Depending on the
shape of the chicken, it may be necessary
to fasten the wings and legs with a fireproof
string to stop them impacting the sides when
turning.
3) Push the baking tray qonto the lower rail.
4) Preheat the appliance for about 10 minutes
using the function "Upper & lower heat/hot
air" to 210°C.
5) Put the chicken on the rotisserie into the
appliance using the tongs w.
6) Set the function switch to "Upper & lower
heat/hot air/rotisserie" and close the
door.
7) Set the timer 4 approx. 90 minutes. The
cooking time can vary depending on the
size and nature of the chicken.
8) Brush the chicken every now and again with
some cooking oil. This will make it crispy.
9) Once the set time is up, carefully remove the
rotisserie with the chicken using the tongs w.
Loosen the skewer clamps tand pull the
chicken off the rotisserie z.

12 SGBR 1500 A1
GB
IE
Cleaning and care
DANGER – ELECTRIC SHOCK!
► Before cleaning the appliance, disconnect the
plug from the mains power socket!
Risk of electric shock!
NEVER immerse the appliance in water or
any other liquid!
WARNING! RISK OF INJURY!
► Always allow the appliance to cool down
before cleaning it. Otherwise there is a risk
of burns!
■ It is best to clean the appliance and accessories
as soon as they have cooled down. This makes
food residues easier to remove.
ATTENTION! DAMAGE TO PROPERTY!
► Do not use abrasive or aggressive cleaning
materials. These could damage the surface of
the appliance!
► Do not clean the components of the appliance
in a dishwasher!
►Do not clean the cooking chamber with an
oven spray as this may make residues on the
heating elements impossible to remove.
■ Wipe the appliance with a damp cloth. If neces-
sary, put a little mild detergent on the cloth and
wipe this off afterwards with a cloth dampened
with clean water. Dry everything properly.
■ Clean the cooking chamber and the glass door 6
with a moist cloth. If necessary, put a little mild
detergent on the cloth and wipe this off after-
wards with a cloth dampened with clean water.
Dry everything properly.
■ Clean the tongs 0/w, the rotisserie z, the
skewer clamps t, the restrainer r, the baking
tray q, the rack eand the crumb tray 7in
warm soapy water. Dry all parts properly after
cleaning.
Storage
■ Store the cleaned appliance and its accessories
in a clean, dust-free and dry location.

13
SGBR 1500 A1
GB
IE
Troubleshooting
Fault Cause Solution
The appliance is not
working.
The mains plug is not connected to the
mains power.
Insert the plug into a mains power
socket.
The mains power socket is defective. Use a different mains power
socket.
The appliance is defective. Contact Customer Services.
The control lamp 5
comes on and but the
appliance does not
heat up.
The function switch 3is set to OFF. Turn the function switch 3to the
desired function.
The cooking time of
the food seems very
long
The glass door 6has been opened often
to check the cooking progress.
Do not open the glass door 6
any more often than is absolutely
necessary.
The wrong temperature level has been set. Check the temperature settings.
Smoke and smells
develop during use.
There is detergent or food residue on the
heating elements.
Remove the food from the ap-
pliance and continue cooking
process with the glass door 6
open until the smoke stops.
If the malfunction cannot be corrected with the above suggestions, or if you have found some other
kind of malfunction, please contact our Customer Service.

14 SGBR 1500 A1
GB
IE
Warranty and service
The warranty provided for this appliance is
3 years from the date of purchase. This appliance
has been manufactured with care and inspected
meticulously prior to delivery. Please retain your
receipt as proof of purchase. In the event of a
warranty claim, please contact your Customer
Service unit by telephone. This is the only way to
guarantee free return of your goods.
The warranty only covers claims for material and
manufacturing defects, not for transport damage,
wearing parts or for damage to fragile components
such as switches or batteries. This appliance is
intended solely for private use and not for com-
mercial purposes.
The warranty shall be deemed void in the case
of misuse or improper handling, use of force and
interventions which have not been carried out by
one of our authorised Service centres.
Your statutory rights are not restricted by this warranty.
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must
be reported immediately after unpacking, but no
later than two days after the date of purchase.
Repairs made after expiry of the warranty period
are chargeable.
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: [email protected]
IAN 102464
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: [email protected]
IAN 102464
Hotline availability:
Monday to Friday 08:00 - 20:00 (CET)
Disposal
Under no circumstance should
the appliance be disposed of
as standard domestic waste.
This product is subject to the
provisions of European Direc-
tive 2012/19/EU.
Dispose of the appliance via an approved waste
disposal company or your municipal waste dis-
posal facility. Please observe applicable regulations.
Please contact your waste disposal facility
if you are in any doubt.
The packaging is made of environmen-
tally friendly materials which you can
dispose of at your local recycling centre.
Importer
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

15
SGBR 1500 A1
FI
Sisällysluettelo
Johdanto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Määräystenmukainen käyttö . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Toimitussisältö. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Laitteen kuvaus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Tekniset tiedot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Turvallisuusohjeet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Sijoittaminen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Laitteen käyttö . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Lasiluukku. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Murualustan asettaminen paikoilleen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Paistovartaan käyttäminen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Paistopellin/uuniritilän käyttäminen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Ennen ensimmäistä käyttöä . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Laitteen käyttäminen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Toimintokytkin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Lämpötilansäädin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Ajastin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Grillaaminen ja leipominen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Grillaaminen paistovartaalla . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Puhdistus ja hoito . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Säilytys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Vian korjaus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Takuu ja huolto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Hävittäminen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Maahantuoja . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

16 SGBR 1500 A1
FI
Johdanto
Onnittelut uuden laitteen hankinnasta.
Olet valinnut laadukkaan tuotteen. Käyttöohje on
osa tätä tuotetta. Se sisältää tärkeitä turvallisuutta,
käyttöä ja hävittämistä koskevia ohjeita. Tutustu
ennen tuotteen käyttöä kaikkiin käyttö- ja turvalli-
suusohjeisiin. Käytä tuotetta vain kuvatulla tavalla
ja vain mainittuihin käyttötarkoituksiin. Kun luovutat
tuotteen eteenpäin, liitä mukaan kaikki tuotetta
koskevat asiakirjat.
Määräystenmukainen käyttö
Miniuuni ja grilli on tarkoitettu yksinomaan ruokien
kuumentamiseen, kypsentämiseen ja grillaamiseen.
Tämä laite on tarkoitettu ainoastaan yksityiskäyttöön.
Älä käytä sitä ammattitarkoituksessa.
Muunlainen käyttö on määräystenvastaista ja voi
aiheuttaa esine- tai jopa henkilövahinkoja.
Toimitussisältö
♦ Miniuuni ja grilli
♦ 1 paistopelti
♦ 1 uuniritilä
♦ 2 pihdit
♦ Paistovarras 2 pidikkeellä
♦ 1 murualusta
♦ Käyttöohje
OHJE
Tarkista toimituksen täydellisyys ja mahdolliset
vauriot heti, kun olet poistanut laitteen pakkauk-
sesta. Käänny tarvittaessa huollon puoleen.
Laitteen kuvaus
Kuva A:
1Varrasmoottori
2Lämpötilansäädin
3Toimintokytkin
4Ajastin
5Merkkivalo
6Lasiluukku
7Paikalleen asetettu murualusta
8Alemmat lämpövastukset
9Paistovartaan kiinnitysteline
Kuva B:
0Pihdit (paistopeltiä ja uuniritilää varten)
qPaistopelti
wPihdit (paistovarrasta varten)
eUuniritilä
rLukitsin
tPaistovartaan pidikkeet
zPaistovarras
Tekniset tiedot
Nimellisjännite: 220 - 240 V ~,
50/60 Hz
Suurin tehontarve: 1500 W

17
SGBR 1500 A1
FI
Turvallisuusohjeet
VAARA – SÄHKÖISKU!
► Laitteen kotelon avaaminen tai korjaaminen on kielletty. Tämä
vaarantaa turvallisuuden ja aiheuttaa takuun raukeamisen.
Toimita vioittunut laite laitteen myyjän tai valtuutetun korjaamon
huollettavaksi.
► Anna vaarojen välttämiseksi vialliset verkkopistokkeet ja virtajohdot
heti valtuutetun ammattihenkilöstön tai huoltopalvelun
vaihdettavaksi.
► Varmista, ettei laitteen sisään pääse nesteitä. Älä altista laitetta
kosteudelle, äläkä käytä sitä ulkona. Laitteen päälle ei myöskään
saa asettaa mitään nestettä sisältäviä esineitä, kuten esim. maljakoi-
ta. On olemassa palovaara ja sähköiskun vaara! Mikäli laitteen
sisään pääsee kuitenkin jostain syystä nestettä, laitteen verkkopis-
toke on irrotettava pistorasiasta ja laite on vietävä korjattavaksi.
► Älä milloinkaan koske laitteeseen, virtajohtoon tai verkkopistok-
keeseen märin käsin. Muuten on olemassa sähköiskun vaara.
Älä koskaan upota laitetta veteen tai muihin nesteisiin! Nesteen
joutuminen laitteen jännitettä johtaviin osiin käytön aikana voi
aiheuttaa sähköiskun ja siten hengenvaaran.
