Silvercrest KH 1139 User manual

KOMPERNASS GMBH · BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: KH1139-07/09-V1
Electric Oven & Grill
Operating instructions
Electric Oven & Grill
6
KH 1139
CV_KH1139_35699_LB6.qxd 22.07.2009 9:52 Uhr Seite 1

KH 1139
e
w
t
y
u
r
q
i
o
CV_KH1139_35699_LB6.qxd 22.07.2009 9:52 Uhr Seite 4

- 1 -
CONTENT PAGE
Safety information 2
Intended us 3
Items supplied 3
Setup 3
Description 4
Preparation for use 4
Switching off and transportation 5
Switching off .....................................................................................................................................5
Transporting ......................................................................................................................................5
Operation 5
Grilling and baking..........................................................................................................................5
Grilling and baking with circulating air .........................................................................................6
Tips for preparation and recipes 6
Muffins...............................................................................................................................................6
Hawaii toast......................................................................................................................................7
Baking deep-frozen pizza ...............................................................................................................7
Biscuits ...............................................................................................................................................7
Rolls....................................................................................................................................................7
Meringue...........................................................................................................................................8
Cleaning 8
Technical data 9
Troubleshooting 9
Disposal 10
Warranty & Service 11
Importer 11
Read these operating instructions carefully before using the appliance for the first time and preserve this
maual for later reference. Pass this manual on to whoever might acquire the appliance at a future date.
IB_KH1139_35699_LB6 22.07.2009 10:38 Uhr Seite 1

- 2 -
Electric Oven & Grill
KH 1139
Safety information
Important! Danger!
• Do not leave the appliance unattended when
it is in use.
• This appliance is not intended for use by indivi-
duals (including children) with restricted physical,
physiological or intellectual abilities or defi-
ciences in experience and/or knowledge un-
less they are supervised by a person responsi-
ble for their safety or receive from this person
instruction in how the appliance is to be used.
• Children should be supervised in order to make
sure that they do not play with the device.
• You may not open the housing of the appliance
or carry out any repairs. Should you do so, the
safety concept of the device may be compro-
mised and the warranty becomes void. Arrange
for defects on the appliance to be repaired
only by the dealer or authorised specialists.
• Arrange for defective power plugs and/or cables
to be replaced at once by qualified technicians
or our Customer Service Department.
• Ensure that fluids cannot permeate into the housing
of the appliance. Do not expose the appliance
to humidity and do not use it outdoors. Additio-
nally, DO NOT place fluid-filled receptacles
such as flower vases on the appliance. This
would increase the risk of fire and of receiving
an electric shock! Should liquids permeate into
the housing, unplug the appliance immediately
and arrange for it to be repaired by a qualified
technician.
• When the appliance is in use ensure that there
are no easily inflammable materials close to it
(e.g. dishcloths, oven cloths, etc.).
NEVER dry out textiles or other objects on or
above the appliance.
This would increase the risk of fire!
• NEVER touch the heating rods or the viewing
window when the appliance is in use, or before
it has cooled down completely. Do not reach in
to the cooking area when the appliance is in
use. Wait until the appliance has cooled down.
Otherwise, you could be burnt.
As the housing and the viewing window in the
glass door become very hot during use, you
must use an oven cloth or something similar to
open the oven flap. Otherwise, you could be
burnt.
• After use, allow the appliance to cool down
completely before transporting it.
• NEVER grasp the appliance, power cable or
power plug with wet hands. There is the risk
of receiving an electric shock.
• To disconnect, always pull out the plug itself
out of the power socket, do not pull the power
cable.
• Do not fold or crush the power cable.
• Lay the power cable in such a way that no one
can tread on or trip over it.
• Do not use extension cables.
• If you do not intend to use the appliance for an
extended period, you must disconnect it from
the power source. The appliance is completely
free of electrical power only when you unplug
it.
• Do not use an external timing switch or a separate
remote control system to operate the appliance.
IB_KH1139_35699_LB6 22.07.2009 10:38 Uhr Seite 2

- 3 -
Clarification of the safety warnings
In the operating instructions there are the following
categories of safety warning:
Danger!
A warning with the word DANGER refers to possible
personal physical damage.
Important!
A warning with the word CAUTION refers to possible
property or environmental damage.
These warnings contain specific indications for
the economic use of the appliance.
Intended us
The Oven with Grill automat is intended for the heating,
cooking and grilling of food. It is intended exclusively
for these purposes and may only be used for them.
The user is also required to pay heed to all of the in-
formation in these operating instructions, especially
the safety instructions. All other uses are deemed to
be improper and may result in property damage
or even in personal injury. Kompernaß GmbH ac-
cepts no liability for damage caused by improper
use of the appliance.
Items supplied
The package contains
• the Oven with Grill automat KH 1139
• a roasting grill
• a baking tray
• a handle for the roasting grills/baking tray
• operating instructions
Setup
➩Place the appliance on a firm, level and heat-resis-
tant surface. Ensure there is sufficient ventilation
around the appliance.
Risk of fire!
The distance between the appliance rear side and
the wall should be at least 10 cm, with at least a
clear 10 cm above the appliance and 5 cm to each
side. For this reason the appliance may not be used,
for example, in cupboards or similar. Should it be so
used, there is likely to be insufficient ventilation for
the appliance, increasing both the risk of fire or of it
being damaged.
Risk of fire!
Ensure the appliance is placed on a firm, level and
heat-resistant surface. Failure to do so increases the
risk of fire or of it being damaged. The area under
the base of the appliance could become discolou-
red and damaged. Additionally, if placed on a soft
upper surface, the appliance could cause perma-
nent damage to it due to pressure indentations.
Risk of electric shock!
Do not place the appliance immediately adjacent
to sources of water, e.g. sinks or basins, or in damp
cellar areas. Otherwise, there is a risk of receiving
an electric shock.
Do NOT support yourself on the glass door.
Do NOT place objects on the glass door. This
would cause damage to the hinges.
IB_KH1139_35699_LB6 22.07.2009 10:38 Uhr Seite 3

- 4 -
Description
The Oven with Grill automat is intended for the heating,
cooking and grilling of food. The air circulation system
provides for an equable and rapid distribution of
heat in the appliance.
Operating Elements
1Temperature regulator
Stepless adjustment of the temperature from
100° C to 250° C
2Function switch for
OFF,
Upper heat,
Lower heat,
Upper and lower heat
3Control lamp (Power)
Glows during operation
4Time switch
Adjustment of the required baking/grilling
time from 0 – 60 min.
5Rocker switch for air circulation
6Glass door with handle
7Roasting grill
8Baking tray
9Handle for roasting grill/baking tray
Preparation for use
➩Take the electrical Oven with Grill and all ac-
cessories from the packaging.
Risk of crush injuries!
When opening and closing the door, do not place
your fingers/hand between the door hinges. They
could be crushed.
➩Before using the appliance for the first time, it
and all of the accessories must be cleaned free
of possible packaging residues. Clean the ac-
cessories with a handwarm and mild detergent
solution and then dry them ab.
➩Wipe the appliance housing with a cloth lightly
moistened with water and then dry it carefully.
➩When the appliance is completely dry inside
and out, insert the plug into a suitable power
socket (230 V~/50 Hz).
➩Now switch the appliance on, without the ac-
cessories and without foodstuffs. Leave the ap-
pliance door completely open.
➩Select the setting 250° C with the temperature
regulator 1. Place the function switch 2to
upper and lower heat.
➩Place the time switch 4at 15 minutes.
The appliance allows itself to be switched on
with the time switch 4. As soon as the time
switch 4is set the control lamp 3glows.
As the heating elements are lightly greased, a
slight smell may occur when first putting them
into operation. This is harmless and stops after
a short time. Open a window and provide for
sufficient ventilation.
➩When the appliance has switched itself off auto-
matically, place the function switch 2to OFF .
➩Remove the plug from the power socket and wait
until the appliance has cooled itself down.
➩Then clean the grill and baking area with a
cloth lightly moistened with water and then
dry it carefully.
IB_KH1139_35699_LB6 22.07.2009 10:38 Uhr Seite 4

- 5 -
Switching off and transportation
Switching off
➩Place the function switch 2and the time switch
4at OFF. Unplug the power plug from the
socket.
Transporting
➩If you wish to transport the appliance, first allow
it to cool down.
➩Remove the plug from the power socket.
➩Wrap the power cable around the retaining
hooks on the rear of the appliance.
Operation
Grilling and baking
➩Remove the roasting grill 7and baking tray 8
from the appliance. If required, cover these
with baking paper resp. smear the baking tray
8with butter or oil.
➩Allow the appliance to heat up for ca. 10 minutes
(dependant on the setting) to the required tem-
perature:
- Select the required temperature with the tem-
perature regulator 1.
For grilling, you must always select the highest tem-
perature setting (250° C).
- Then, select with the function switch 2either
upper heat (e.g. for toppings), lower heat
(e.g. for cakes) or upper and lower heat (e.g.
for Pizza). If you want to grill, always select
the setting upper heat with the function switch 2.
- With the time switch 4set the pre-heat time
(ca. 10 minutes).
- Close the glass door 6.
➩When the warm-up period is finished, place
the foodstuffs on the roasting grill 7resp. the
baking tray 8and slide it in on one of the run-
ners. Ensure that there is sufficient space between
the foodstuffs and the inner walls/heating ele-
ments of the appliance.
The most uniform baking results are obtained
when the baking tray 8resp. the roasting grill 7
are placed on the central runner and the air
circulation is switched on.
➩Close the glass door 6before starting the
grill or baking process.
If you are cooking especially fatty foodstuffs,
an increased smoke development can occur.
In this case, do not close the glass door 6
completely, instead, allow it to be slightly open:
If you carefully push the door to, it comes into
this position shortly before closing.
➩Adjust the time switch 4to the required grilling
or baking time.
The maximum grilling or baking time is 60 minutes.
➩If the cooking time for the foodstuff amounts to
less than 25 minutes, first of all place the time
switch 4at 60 minutes and then turn it back
to the required grilling or baking time.
The control lamp 3indicates that your Oven with
Grill is switched on. The switch of the time switch 4
now rotates itself anti-clockwise towards OFF.
When your Oven with Grill has reached the set
temperature, the heating elements switch them-
selves off at intervals, to ensure that the tempe-
rature is maintained.
IB_KH1139_35699_LB6 22.07.2009 10:38 Uhr Seite 5

- 6 -
➩The appliance switches itself off automatically
on completion of the programmed time. If you
wish to switch the appliance off prematurely,
turn the time switch 4back to OFF. Place the
function switch 2at the position OFF and re-
move the plug from the power socket.
You will hear a signal sound and the control lamp 3
extinguishes.
After the appliance has switched itself off, the
time switch 4can continue to run for a short
period.
➩To remove the roasting grill 7resp. baking tray
8, ALWAYS use the provided handle 9. To lift
the roasting grill 7out, you must engage the
small hook of the handle 9in the grill from above.
To lift the baking tray 8out of the appliance,
the large hooks of the handle 9must engage
with the front edge of the baking tray 8.
➩After grilling or baking, place the function
switch 2in the position OFF. Remove the plug
from the power socket. Allow the appliance to
cool down before cleaning it or switching it
back on.
Grilling and baking with circulating air
As a general rule, if you are baking or grilling with
air circulation vou can dispense with a pre-heating
of the cooking space. The cooking and browning
results are more even with the use of circulating air.
Take note of the instructions given in the recipes
when using air circulation.
➩Press the rocker switch 5for air circulation
until it engages in position "1".
The aerator in the grill and baking space starts to
rotate.
The methods of operation are then the same as for
grilling and baking without air circulation.
Tips for preparation and recipes
In this chapter we provide you with various examples
for the preparation of foods. These examples are re-
commendations. The preparation periods can vary.
Take note of the preparation details given on
the packaging of the foodstuff .
Muffins
Ingredients for four people:
• 1 Cup of flour
• 1 Teaspoon of baking powder
• 1 Egg
• 1 Tablespoon of melted butter
• 1 Cup of milk
• 3 Tablespoons of sugar
• Salt
• for variations, additionally nuts, chopped
bananas or chocolate flakes
IB_KH1139_35699_LB6 22.07.2009 10:38 Uhr Seite 6

- 7 -
Preparation:
➩Mix together in a bowl, slowly and one after
the other, the flour, baking powder, egg, milk,
salt and sugar.
➩Melt the butter in a pan and mix it into the pastry.
➩Subject to taste, blend in the nuts, chocolate
flakes or chopped bananas.
➩Place the mixture into typical muffin moulds
and bake at 200° C with upper heat and air
circulation for about 15 minutes.
Hawaii toast
Ingredients for 4 toasts:
• 4 Slices of toast
• 1–2 Tablespoons of remoulade
• 120 g cooked ham
• 1/2 Tin of pineapples
• 4 Slices of cheese for melting
• Curry
Preparation:
➩Toast the toast slices.
➩Spread the remoulade thinly over the toasts
and lay the slices of cooked ham on them.
➩Lay one slice of pineapple on each of the
garnished toasts.
➩Spice with curry.
➩Then place a slice of cheese over each of the
pineapple slices.
➩Lay the Hawaii toasts on the roasting grill 7
and bake for ca. 8 minutes on the middle
runner with upper heat and air circulation.
Baking deep-frozen pizza
Preparation:
➩Place the roasting grill 7on the middle runner
in the cooking area.
➩Lay the deep-frozen pizza without packaging
onto the roasting grill 7.
➩Bake the pizza with upper and lower heating
and switched on air circulation for ca.20 minutes.
➩Take heed of the details given on the packaging.
Biscuits
Ingredients:
• 125 g butter
• 125 g sugar
• 1 Packet of vanilla sugar
• 1 Pinch of salt
• 1 Egg
• 1 Egg white
• 250 g Plain flour
• 1 Teaspoon of baking powder
• Scraped peel of half a lemon
Preparation:
➩Beat the butter until foamy.
➩Add the sugar, vanilla sugar, lemon peel and
the eggs.
➩Mix together the flour, baking powder and
salt, then blend them into the mixture with a
mixing spoon.
➩Allow the pastry to stand for ca. 10 minutes.
➩Bring the pastry into the desired shape, e.g.
with the assistance of a mincer, biscuit shaper
or a shaping bag with nozzle.
➩Place the biscuits onto the baking tray 8, this
being first covered with baking paper.
➩Bake the biscuits in a pre-heated oven at 180° C
for ca. 10–15 minutes until golden brown.
The pastry volume is sufficient for several
baking trays 8.
Rolls
Ingredients:
• 300 g Flour (or wholemeal flour)
• good 2 Teaspoons of baking powder
• 200 g Linseeds
• 1 Egg
• 500 g Curds
• 1 Teaspoon of salt
• Subject to taste, caraway seeds, onions,
cubed bacon ...
IB_KH1139_35699_LB6 22.07.2009 10:38 Uhr Seite 7

- 8 -
Preparation:
➩Knead everything together well and then
shape it into small rolls.
➩Place the biscuits onto the baking tray 8this
being first covered with baking paper.
➩Bake at approx. 180°C for approx. 30 minutes.
The pastry volume is sufficient for several
baking trays 8.
Meringue
Ingredients:
• 1 Egg white
• Salt
• 45 g Sugar
Preparation:
➩Place the cooled egg white into a fat-free mixing
bowl. It may not contain any egg yolk, other-
wise the meringue will not be firm.
➩Beat the egg white at a slow speed, so that the
bubbles formed in the meringue are not too large.
➩Add a pich of salt to taste.
➩Gradually add in a half of the sugar when the
meringue starts to firm up.
➩Then beat it at the highest speed until stiff.
➩Add the remaining sugar. With this the meringue
attains the required solidity.
➩Fill the meringue mixture into a squeezing bag
with large star nozzles and, with a little space
between them, shape rosettes, tongues and
other designs on the backing tray, this being
first covered with baking paper.
➩Pre-heat the Oven with Grill to ca. 100° C
with air circulation.
➩Bake the meringues with air circulation at ca.
100° C for about 2 hours.
These recipes are provided without guarantee. All
ingredients and preparation information are guiding
values. Expand these recipe suggestions based on
your personal experiences. We hope you enjoy
the recipes and wish you "bon appetit".
Cleaning
Risk of electric shock!
Before you clean the Oven with Grill, you must
always remove the plug from the power socket.
There is a risk of receiving an electric shock!
Risk of electric shock!
When cleaning it, under no circumstances
may the appliance be submersed in water.
There is a risk of receiving an electric shock!
Important!
Do not use household detergents or sharp/pointed
objects to remove soiling. . They could damge the
special coatings on the inner walls of the Oven with
Grill.
➩Should soiling occur, the Oven with Grill can
be cleaned with a soft cloth lightly moistened
with a mild soapy solution.
➩Clean the baking tray 8and the roasting grill 7
in a detergent solution. Allow stubborn soiling
to be softened. Rinse them off with clear water.
Risk of electric shock!
The Oven with Grill must be completely dry before
using it again after cleaning. Therefore, after cleaning
leave the appliance door open.
IB_KH1139_35699_LB6 22.07.2009 10:38 Uhr Seite 8

- 9 -
Technical data
Mains voltage: 230 V~/50 Hz
Nominal power: 1380 W
Capacity:15 Litres
Troubleshooting
Symptom Possible cause and
solution
The appliance
does not heat
up.
The time switch 4is
showing OFF. Adjust the
time switch 4to a time
greater than 0 minutes
(OFF) .
A domestic fuse is defect.
Check the domestic fuses
and, if necessary, renew
the defective one.
The power socket is
defective. Try another
wall socket.
The appliance is possibly
defective. Arrange for
the appliance to be
checked by specialists.
The function switch 2
is at the position OFF.
It is not possible
to switch the
appliance off.
An electronic component is
defective.
Remove the plug from the
wall socket and arrange for
the appliance to be checked
by specialists.
IB_KH1139_35699_LB6 22.07.2009 10:38 Uhr Seite 9

- 10 -
Should a defect not allow itself to be eliminated,
please contact your dealer or the manufacturer.
Symptom Possible cause and
solution
The aerator for
the air circula-
tion does not
function.
The switch for air circula-
tion 5is in the position
"0". Move the rocker
switch for air circulation
to the position "1".
The appliance is possibly
defective. Arrange for
the appliance to be
checked by specialists.
The door glass
is broken or
showing crak-
ks.
Arrange for the appliance
to be checked/repaired by
specialists.
Disposal
Do not dispose of the appliance in your
normal domestic waste. This product is
subject to the European guideline
2002/96/EC.
Dispose of the appliance through an approved dis-
posal centre or at your community waste facility.
Observe the currently applicable regulations.
In case of doubt, please contact your waste disposal
centre.
Dispose of all packaging materials in an
environmentally responsible manner.
IB_KH1139_35699_LB6 22.07.2009 10:38 Uhr Seite 10

- 11 -
Warranty & Service
The warranty for this appliance is for 3 years from
the date of purchase. This appliance has been
manufactured with care and meticulously examined
before delivery. Please retain your receipt as proof
of purchase date. Should a claim need to be made
under the warranty, please make contact by tele-
phone with our service department. Only in this
way can a post-free despatch for your goods be as-
sured.
The warranty covers ONLY claims for material and
maufacturing defects, not for wearing or consuma-
ble or for damage to fragile components. This pro-
duct is for private use only and is not intended for
commercial applications.
The warranty will become void in the event of abusi-
ve and improper handling, use of force and internal
tampering not carried or approved by our authori-
zed service branch. Your statutory rights are not
restricted in any way by this warranty.
DES Ltd
Units 14-15
Bilston Industrial Estate
Oxford Street
Bilston
WV14 7EG
Tel.: [phone]
Fax: [phone]
e-mail: [e-mail]
Kompernass Service Ireland
Tel: [phone] (0,082 EUR/Min.)
Standard call rates apply. Mobile operators may vary.
e-mail: [e-mail]
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
IB_KH1139_35699_LB6 22.07.2009 10:38 Uhr Seite 11
