Silvercrest SMSZ 1 A1 User manual

SMART MOTION SENSOR
Operation and safety notes
IAN 341805_2001
SMART MOTION SENSOR SMSZ 1 A1

GB/IE/NI/MT/CY Operation and safety notes Page 3

3GB/IE/NI/MT/CY
SMART MOTION SENSOR
Warnings and symbols used ..........................................Page 4
Introduction .............................................................Page 4
Intended use ............................................................Page 4
Scope of delivery .......................................................Page 5
You will need............................................................Page 5
Safety notices ...........................................................Page 5
Description of parts.....................................................Page 7
Technical data ...........................................................Page 8
Positioning the product ................................................Page 9
Wall mounting ..........................................................Page 10
Pairing product and mobile device...................................Page 11
Unpairing product from mobile device ..............................Page 13
Settings ..................................................................Page 14
Additional functions ....................................................Page 15
Privacy policy ...........................................................Page 16
Tap-to-Run / Automation ..............................................Page 17
Disconnecting product manually from network ....................Page 17
LED signals...............................................................Page 18
Replacing the battery ..................................................Page 19
Cleaning and care ......................................................Page 19
Troubleshooting.........................................................Page 19
Disposal..................................................................Page 20
Warranty ................................................................Page 21
Simplified EU declaration of conformity .............................Page 22

4 GB/IE/NI/MT/CY
Warnings and symbols used
The following warnings are used in the instruction manual, quick start guide, safety instructions and on
the packaging:
DANGER! This symbol in combination
with the signal word “Danger” marks
a high-risk hazard that if not prevented
could result in death or serious injury.
NOTE: This symbol in combination
with “Note” provides additional useful
information.
WARNING! This symbol in
combination with the signal word
“Warning” marks a medium-risk hazard
that if not prevented could result in death
or serious injury.
IP21
Suitable for indoor use only.
CAUTION! This symbol in combination
with the signal word “Caution” marks
a low-risk hazard that if not prevented
could result in minor or moderate injury.
Direct current / voltage
ATTENTION! This symbol with the
signal word “Attention” indicates a
possible property damage.
Zigbee 3.0 wireless technology
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
The instructions for use are part of the product.
They contain important information concerning
safety, use and disposal. Before using the product,
please familiarise yourself with all of the safety
information and instructions for use. Only use
the product as described and for the specified
applications. If you pass the product on to anyone
else, please ensure that you also pass on all the
documentation with it.
Intended use
This smart motion sensor (hereinafter called
“product”) is an Information Technology device.
This product is used for indoor surveillance. The
product registers temperature changes in the
detection area caused by humans or animals.
The registered movements are displayed on your
mobile device.

5GB/IE/NI/MT/CY
Suitable Not suitable
Private use Industrial/commercial purposes
Use in tropical climates
Any other use is considered improper. Any claims
resulting from improper use or due to unauthorised
modification of the product will be considered
unwarranted. Any such use is at your own risk.
The Lidl Home app is required to
control and set up the product.
Scope of delivery
Fig. A:
1 Motion sensor
1 Wall bracket
1 Battery (CR123A)
2Screws
2Dowels
1 Metal pin
1 Quick start guide
1 Safety advice booklet
You will need
Gateway:
IAN 341809_1910 /
IAN 341809_2001 /
IAN 343820_1910 /
IAN 343820_2001 /
IAN 343821_1910 /
IAN 343821_2001
Router:
2.4 GHz, IEEE 802.11b/g/n
Mobile device:
iOS 9.0 or higher
Android 5.0 or higher
Ø 5,5 mm / E
* for optional wall mounting
Safety notices
BEFORE USING THE PRODUCT, PLEASE
FAMILIARISE YOURSELF WITH ALL OF THE
SAFETY INSTRUCTIONS AND INSTRUCTIONS
FOR USE! WHEN PASSING THIS PRODUCT ON
TO OTHERS, PLEASE ALSO INCLUDE ALL THE
DOCUMENTS!
mWARNING! DANGER TO LIFE AND
RISK OF ACCIDENT FOR INFANTS AND
CHILDREN!
mDANGER! Risk of suffocation!
Never leave children unsupervised with the
packaging material. The packaging material
poses a suffocation hazard. Children frequently
underestimate the dangers.
The packaging material is not a toy.
This product can be used by children aged
from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given supervision
or instruction concerning use of the product
in a safe way and understand the hazards
involved.
Children shall not play with the product.
Cleaning and user maintenance shall not be
made by children without supervision.
mATTENTION!
Risk of property damage
This product does not contain any parts which
can be serviced by the user.
Keep the product away from moisture, dripping
and splashing water!
Do not place burning candles or other open
fire on or next to the product.
Sudden temperature changes may cause
condensation inside the product.

6 GB/IE/NI/MT/CY
In this case, allow the product to acclimate for
some time before using it again to prevent short
circuits!
Do not operate the product near heat sources,
e.g. radiators or other devices emitting heat!
mDANGER!
It is necessary to repair the product if it has
been damaged in any way, for example, if the
housing is damaged, if liquid or objects have
penetrated the product or if the product has
been exposed to rain or moisture. Repair work
is also required if the product is not working
properly or has been dropped.
In such cases, the product should not be used
until it has been inspected by authorised
service personnel.
Only have the product repaired by qualified
personnel. Never open the housing of the
product.
Safety instructions for batteries /
rechargeable batteries
mDANGER TO LIFE! Keep batteries /
rechargeable batteries out of reach of children.
If accidentally swallowed seek immediate
medical attention.
Swallowing may lead to burns, perforation of
soft tissue, and death. Severe burns can occur
within 2 hours of ingestion.
DANGER OF EXPLOSION! Never
recharge non-rechargeable batteries. Do
not short-circuit batteries / rechargeable
batteries and / or open them. Overheating, fire or
bursting can be the result.
Never throw batteries / rechargeable batteries
into fire or water.
Do not exert mechanical loads to batteries /
rechargeable batteries.
Risk of leakage of batteries /
rechargeable batteries
Avoid extreme environmental conditions and
temperatures, which could affect batteries /
rechargeable batteries, e.g. radiators / direct
sunlight.
If batteries / rechargeable batteries have
leaked, avoid contact with skin, eyes and
mucous membranes with the chemicals!
Flush immediately the affected areas with fresh
water and seek medical attention!
WEAR PROTECTIVE GLOVES! Leaked
or damaged batteries / rechargeable
batteries can cause burns on contact with
the skin. Wear suitable protective gloves at all times
if such an event occurs.
In the event of a leakage of batteries /
rechargeable batteries, immediately remove
them from the product to prevent damage.
Remove batteries / rechargeable batteries
if the product will not be used for a longer
period.
Risk of damage of the product
Only use the specified type of battery /
rechargeable battery!
Insert batteries / rechargeable batteries
according to polarity marks (+) and (–) on
the battery / rechargeable battery and the
product.
Use a dry lint-free cloth or cotton swab
to clean the contacts on the battery /
rechargeable battery and in the battery
compartment before inserting!
Remove exhausted batteries / rechargeable
batteries from the product immediately.

7GB/IE/NI/MT/CY
Description of parts
A
CR123A
LED
[1] [2] [6] [7] [8] []
[]
[][][9][3] [4] [5]
[1] Screw (x2)
[2] Dowel (x2)
[3] Metal pin
[4] Motion sensor
[5] LED
[6] Pin hole (Reset button / Network key)
[7] Battery compartment
[8] Tamper alarm button
[9] Protective strip
[] Battery compartment cover
[] Screw holes
[] Wall bracket
[] Battery
Not illustrated:
[] Quick start guide
[] Safety instructions

8 GB/IE/NI/MT/CY
Technical data
Operating voltage 3 V
Battery type 3 V (CR123A)
Frequency band 2.4 to 2.485 GHz
Max. transmitted power 13 dBm
Operation time 12 months (60 alarms/day)
Mounting height 2.1 m
Communication protocol ZigBee 3.0
Reception range approx. 70 m (free area)
Detection range/angle ≤ 10 m (at +25 °C) / 90°
Operating temperature +5 to +35 °C
Operating humidity 10 to 80 %
Measurements 65 x 65 x 29 mm
IP protection class IP21
Trademark notices
iOS and Apple are registered trademarks of
Apple Inc. in the USA and other countries.
App Store is a registered trademark of
Apple Inc.
Android, Gmail, Google Play and Google
Assistant* are registered trademarks of
Google Inc.
Zigbee is a registered trademark of The Zigbee
Alliance.
The SilverCrest trademark and trade name is
the property of their respective owners.
Any other names and products may be
trademarks or registered trademarks of their
respective owners.
* Google Assistant is not available in certain
languages and countries.

9GB/IE/NI/MT/CY
Positioning the product
B
2.1 m
1.5 m 6m
Side view
Top view
90 °
0m
6m
6m
10m 6m3m
10 m
Install the product at a height of 2.1 m above
the floor. The product detects movements within
a radius of 10 m (detection angle: 90° from
the centre of the sensor) (fig. B).
Avoid following situations and environments:
– Rooms in which pets often trigger the motion
alarm unnecessarily
– Air-conditioning
– Heat sources
– Direct sunlight
– Fans/rotating objects
– Vibrations

10 GB/IE/NI/MT/CY
Wall mounting
C
[] [2] [1][]
mWARNING! Risk of electric shock!
Do not drill into any pipes or mains cables
beneath the mounting surface. Use a voltage/
metal detector.
NOTES:
Mark the position of the 2 drill holes on the
wall through the screw holes [] of the wall
bracket [] (fig. C ).
Drill the 2 holes.
Insert the dowels [2] into the drill holes and
attach the wall bracket using the screws [1]
(fig. C ).
If you want to stick the product on a smooth
surface, remove the protective foil from the
adhesive tape on the back of the wall bracket
[] (fig. C ).
The arrow on the wall bracket must point
upwards (fig. C ).
The tampering alarm is deactivated as long as
the product is sitting in its wall bracket [].
If the product is removed from the wall bracket
[], the tamper alarm button [8] is triggered.

11GB/IE/NI/MT/CY
Pairing product and mobile
device
NOTES:
Screenshots are from the iOS 13.3 app version
(if not otherwise marked). Older iOS versions
may have functional limitations.
The Android version of the app follows the
same principles as the iOS version; you might
encounter discrepancies between the two
platforms, such as slightly different on-screen
commands or icons.
Updating the firmware might result in changes
to the app’s functionality.
An updated instruction manual can be found
here:
{ Me } tab:
Tap { User Manual } .
Preparation
Install Lidl Home app and setup Gateway
( Gateway instruction manual).
D
[9]
1. Pull protective strip [9] out of battery
compartment [7] (fig. D).
If already mounted: Remove product from wall
bracket [].
2. Wait until flashing red LED [5] goes off after a
warm-up phase of approx. 30 s.
3. After the warm-up phase has ended, the
product switches to test mode. If the movement
of a human body is detected in test mode,
a notification will be sent to the user as a
reminder. After 20 minutes, the product
automatically switches to power saving mode.
NOTES:
If the movement of a human body is detected
in power saving mode, a notification will be
sent to the user as a reminder. If a human body
is permanently moving within the detection
area, this will not be registered as multiple
motions. If no movement has been detected
in the detection area for at least 1 minute, the
product will start again to detect movements of
a human body.
If you want to switch to test mode, remove the
battery from the battery compartment and
reinsert it.

12 GB/IE/NI/MT/CY
4. Open Lidl Home app.
5. { Home } tab:
Tap (add further devices).
6. Select category:
{ Sensors } .
7. Select:
– iOS:
{ Motion Sensor }
– Android:
{ Motion Sensor }
8. Select Gateway.
Only necessary, if you have 2 or more
Gateways.
9. Tap { Done } .
10. Push metal pin [3] into pin hole [6] for 5 s until
green LED [5] flashes quickly (fig. E).
11. Ready for pairing.
12. Tap { Confirm indicator rapidly blink } .
13. Establishing connection.
14. Naming the product:
Tap and enter a name.

13GB/IE/NI/MT/CY
15. Tap one of the rooms to set location of product
(selected room is grayed out).
16. Tap { Done } .
17. Pairing completed.
18. Return to home screen:
Tap { < } .
Unpairing product from mobile
device
1. Open Lidl Home app.
2. { Home } tab:
Tap { Motion Sensor } .
3. Tap (top right).
4. Tap { Remove Device } .
Select:
– { Disconnect }
or
– { Disconnect and wipe data }
( “Additional functions”).
5. Tap { Confirm } .

14 GB/IE/NI/MT/CY
Settings
1. { Home } tab:
Tap { Motion Sensor } .
The battery level of the product ( ) is
shown in the top left.
turns orange when a motion is detected.
2. Tap { History } .
Movements and tamper-alarms are displayed
in a list.
Return to previous screen:
Tap { < } .
3. Tap :
If you deactivate the alarms, related
messages are no longer displayed in the
{ Message Center } under the { Me } tab.
Return to previous screen:
Tap { < } .

15GB/IE/NI/MT/CY
Additional functions
1. Tap (top right).
2. Tap .
Select:
– { Icon } :
* { Take Photo }
or
* { Select from Album }
– { Name } :
Rename product.
– { Location } :
Assign a room to the product.
* Access to the mobile devices’ camera
and photo library is required.
3. { Device Information } :
Virtual ID and product’s time zone are
displayed.
4. { Tap-to-Run and Automation } :
View smart scenes/automations involving the
product.
5. { Offline Notification } :
A notification is sent when the product is offline
for more than 5 hours.
– Offline notification on:
Tap .
– Offline notification off:
Tap .
6. { Share Device } :
Share access to the product with other family
members.
7. { Create Group } :
Add product to a group in order to synchronise
the use of all grouped devices.
= selected devices.
Tap { Confirm } .
Name group.
Tap { Save } .
Group is shown on the app’s home screen.

16 GB/IE/NI/MT/CY
8. { FAQ } :
Check FAQ related to the product.
9. { Check for Firmware Upgrade } :
Display the ZigBee module’s firmware version
and check for firmware upgrade.
10. { Remove Device } :
Select:
– { Disconnect }
Remove product from the app. Data
remaining the product’s memory.
This operation only resets the product to
offline mode and starts the pairing mode.
If you want to remove all data of the product
and the cloud, read the following point.
– { Disconnect and wipe data }
Reset to factory settings.
This function deletes all data from the
product and in the cloud.
Use this function if you pass on,
dispose of or return the product to the
manufacturer.
Make sure that all data on the product
and in the cloud has been deleted.
Follow the instructions in the app.
or
– { Cancel }
Cancel removing the product.
Privacy policy
 { Me } tab:
{ Privacy Policy } :
Our complete privacy policy is available here.

17GB/IE/NI/MT/CY
Tap-to-Run / Automation
The app offers the possibility to integrate the
product together with other smart Home devices
in user-defined scenarios and automatic actions.
 { Smart } tab:
Select:
– { Tap-to-Run }
or
– { Automation }
Tap to create new scenarios and automatic
actions.
NOTE: Detailed description of these functions
can be found in the Gateway manual.
{ Me } tab:
Tap { User Manual } .
Disconnecting product
manually from network
E
[6]
[3][5]
5 s
6x
Push metal pin [3] into pin hole [6] for 5 s until
green LED [5] flashes quickly (fig. E).
Complete renewed pairing process within
3 minutes after reset.
This function only resets the product to offline
mode and starts the pairing mode. If you
want to remove all data from the product and
the cloud, refer to the chapter “Additional
functions”, { Disconnect and wipe data } .

18 GB/IE/NI/MT/CY
LED signals
Signal Meaning
Red
30 s Warm-up phase
1x Motion alarm / tamper alarm (Product had been removed
from the wall bracket)
Green
(quickly) Product connecting to network
3 s Successful pairing with network
6x Successful unpairing from network
Explanation of symbols
LED on LED flashing

19GB/IE/NI/MT/CY
Replacing the battery
F
[]
CR123A
Remove the battery compartment cover [].
Remove the battery. Insert a new battery
into the battery compartment [7]. Follow the
polarity indications (+/–) on the battery and in
the battery compartment. Reattach the battery
compartment cover (fig. F).
Cleaning and care
Cleaning
mWARNING! During cleaning or operation,
do not immerse the electrical parts of the
product in water or other liquids. Never hold
the product under running water.
Before cleaning, remove the battery from the
battery compartment [7].
Clean the product and its accessories with a
slightly moistened cloth.
Do not allow any water or other liquids to enter
the product’s interior.
Do not use abrasives, harsh cleaning solutions
or hard brushes for cleaning.
Let all parts dry afterwards.
Storage
When not in use, store the product in its
original packaging.
Store the product in a dry, secure location
away from children.
Troubleshooting
Problem Cause Solution
Product
cannot be
controlled.
Distance between
Gateway and
product too large.
Re-position
Gateway
or product.
Trigger the
product.
Walls or obstacles
between Gateway
and product.
Battery of the
product flat.
Replace
battery.

20 GB/IE/NI/MT/CY
Disposal
Before passing on, disposing of or returning the
product to the manufacturer, make sure that all
data has been deleted from the product and
the cloud.
To do this, refer to the chapter:
“Additional functions”, menu point:
{ Disconnect and wipe data }
The packaging is made entirely of recyclable
materials, which you may dispose of at local
recycling facilities.
Observe the marking of the packaging
materials for waste separation, which
are marked with abbreviations (a) and
numbers (b) with following meaning:
1–7: plastics / 20–22: paper and
fibreboard / 80–98: composite
materials.
The product and packaging materials are
recyclable, dispose of it separately for
better waste treatment.
The Triman logo is valid in France only.
Contact your local refuse disposal
authority for more details of how to
dispose of your worn-out product.
To help protect the environment, please
dispose of the product properly when it
has reached the end of its useful life and
not in the household waste. Information
on collection points and their opening
hours can be obtained from your local
authority.
Faulty or used batteries / rechargeable batteries
must be recycled in accordance with Directive
2006/66/EC and its amendments. Please return
the batteries / rechargeable batteries and / or the
product to the available collection points.
Environmental damage
through incorrect disposal of
the batteries / rechargeable
batteries!
Batteries / rechargeable batteries may not be
disposed of with the usual domestic waste. They
may contain toxic heavy metals and are subject to
hazardous waste treatment rules and regulations.
The chemical symbols for heavy metals are as
follows: Cd = cadmium, Hg = mercury, Pb = lead.
That is why you should dispose of used batteries /
rechargeable batteries at a local collection point.
