Silverline DIY Series User manual

Register online: silverlinetools.com
3
GUARANTEE
YEAR
ANS DE GARANTIE
JAHRE GARANTIE
AÑOS DE GARANTÍA
ANNI DI GARANZIA
JAAR GARANTIE
LATA GWARANCJI
Version date: 06.06.17 silverlinetools.com
XXXXXX
263570
FR Marteau piqueur électrique 1 500 W
DE Elektro-Abbruchhammer, 1500 W
ES Martillo de demolición 1500 W
IT Demolitore elettrico 1500W
NL 1500 W elektrische breekhamer
PL Elektrycznymłotudarowy1500W
DIY 1500W Electric Breaker
MIN
263570_Manual.indd 1 06/06/2017 14:22

2
1
5
623
7 8
A
1
(180°) (180°)
3 3
2
1
2
4
263570_Manual.indd 2 06/06/2017 14:22

silverlinetools.com 3
English ................04
Français ...............10
Deutsch................16
Español................22
Italiano................28
Nederlands ..........34
Polski ..................40
263570_Manual.indd 3 06/06/2017 14:22

GB
4
Voltage:.................................................220-240V~, 50Hz
Power: ...........................................................1500W
Impact rate:.....................................................1900min-1
Impact energy:...................................................45 Joule
Hex steel size:.................................................29mm/1-1⁄8"
Oil type:..........................................................15W-40
Protection class: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ingress protection:....................................................IP20
Cable length: .........................................................4m
Dimensions (LxWxH): .....................................650x152x230mm
Netweight:....................................................... 14.4kg
Aspartofourongoingproductdevelopment,specicationsofSilverlineproducts
mayalterwithoutnotice.
Sound and vibration information:
According to Machinery Directive 2006/42/EC:
SoundpressureLPA:..............................................91.8dB(A)
SoundpowerLWA:...............................................102.8dB(A)
Uncertainty K:...................................................... 2.8dB
Weighted vibration
Main handle ah,CH:............................................. 18.104m/s2
Auxiliary handle ah,CH:.......................................... 17.534m/s2
Uncertainty K:.....................................................1.5m/s2
According to Outdoor Noise Directive 2000/14/EC:
GuaranteedsoundpowerLWA:..................................... 105dB(A)
The sound intensity level for the operator may exceed 85dB(A)
and sound protection measures are necessary
Specication
WARNING:Alwayswearearprotectionwherethesoundlevelexceeds85dB(A)andlimitthetime
ofexposureifnecessary.Ifsoundlevelsareuncomfortable,evenwithearprotection,stopusingthe
toolimmediatelyandchecktheearprotectioniscorrectlyttedandprovidesthecorrectlevelof
sound attenuation for the level of sound produced by your tool.
WARNING: User exposure to tool vibration can result in loss of sense of touch, numbness,tingling
and reduced ability to grip. Long-term exposure can lead to a chronic condition. If necessary, limit
thelengthoftimeexposedtovibrationanduseanti-vibrationgloves.Donotoperatethetoolwith
handsbelowanormalcomfortabletemperature,asvibrationwillhaveagreatereffect.Usethe
guresprovidedinthespecicationrelatingtovibrationtocalculatethedurationandfrequency
of operating the tool.
Soundandvibrationlevelsinthespecicationaredeterminedaccordingtointernationalstandards.
Theguresrepresentnormaluseforthetoolinnormalworkingconditions.Apoorlymaintained,
incorrectly assembled, or misused tool,may produce increased levels of noise and vibration.
www.osha.europa.euprovidesinformationonsoundandvibrationlevelsintheworkplacethat
maybeusefultodomesticuserswhousetoolsforlongperiodsoftime.
Description of Symbols
Theratingplateonyourtoolmayshowsymbols.Theserepresentimportantinformationaboutthe
product or instructions on its use.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Wear head protection.
Wear hand protection.
Read instruction manual.
Caution!
Risk of electrocution
Class II construction
Conforms to relevant legislation and safety standards
Environmental Protection
Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Please
recyclewherefacilitiesexist.Checkwithyourlocalauthorityorretailerforrecycling
advice.
IMPORTANT: Check oil level indicator is above half full before every use
Introduction
ThankyouforpurchasingthisSilverlinetool.Thismanualcontainsinformationnecessary
for safe and effective operation of this product.This product has unique features and, even if
youarefamiliarwithsimilarproducts,itisnecessarytoreadthismanualcarefullytoensure
you fully understand the instructions. Ensure all users of the tool read and fully understand
this manual.
Original Instructions
MIN
263570_Manual.indd 4 06/06/2017 14:22

DIY 1500W Electric Breaker263570
5
silverlinetools.com
General Safety
WARNING Read all safety warnings and all instructions.Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
WARNING: This appliance is not intended for use by persons (including children) with
reduced, physical or mental capabilities or lack of experience or knowledge unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.Children must be supervised to ensure that they do not play with
the appliance.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying,pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply.Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the inuence of drugs, alcohol
or medication. A moment of inattention while operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes,hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to power source and/or battery pack, picking up or carrying the tool.Carrying power tools
with your nger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. Awrench or a key
left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-related
hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.The correct
power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories,or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
Electric Breaker Safety
• Beawareoftheeffectsofvibrationwhenusingthiselectricbreaker.Bynatureoftheirdesign
electricbreakerswillproducealargeamountofvibration.Itisadvisedtowearspecialvibration-
reducinggloveswhenoperatingmachinerythatemitslargeamountsofvibration,andto
monitor and limit vibration exposure times
• Holdthemachinebytheinsulatedgrippingsurfaces;ifthetoolcomesintocontactwithalive
wire,theexposedmetalpartsofthepowertoolmaybecomelive
• Beforebeginningwork,usesuitabledetectorstodetermineifutilitylinesarehiddeninthework
areaorcallthelocalutilitycompanyforassistance.Contactwithelectriclinescanleadtore
andelectricshock.Damagingagaslinecanleadtoexplosion.Penetratingawaterlinecauses
property damage and may cause electric shocks
• Alwaysholditrmlywithbothhandsusingbothhandles,andensureyouhaveasecurestance
on level ground
• Whenusingthismachineincoldweatherorwhenthetoolhasnotbeenusedforalongtime,
operatethetoolundernoloadandwaitforittowarmupandlubricateitself
• Themachinehousingbecomeswarm,andthesteelbitmayevenbecomehotafterextended
periods of use. Do not touch these parts to prevent burns
• Somebuildingmaterialscontaintoxicsubstances.Alwaysuseadequatebreathingandskin
protectionwhenoperatingthismachineinadustyenvironment,especiallyifyouexpecttoxic
substancestobepresent,orifyouareunawareaboutthecompositionofthematerialstobe
workedon.Alwaysadheretolawsandregulationswhendisposingoftoxicsubstances
• Onlyuseextensionleadsofasuitabletypethatisapprovedfortheenvironmentyouareworking
in.Conductorsmustbeofadequatecrosssection,asthemachinemayotherwiseoperateat
reduced performance, and the extension lead may overheat. Check the extension cord for
damagebeforeeveryuse,atthesametimeascheckingthemachine’smainpowercable.
DamagedextensioncordsMUSTNOTbeusedandneedtobereplaced.Alwaysfullyunwindthe
extensionleadorcablereel,asitwilloverheatotherwise
• Insomesituationsyoumaywanttopoweryourmachineoffaconstructionsitegeneratoror
transformer.Thisisgenerallypossible;however,ensurethatthepowerratingofthepowersource
isatleastdoublethepowerratingofthismachine,andthatthepowersuppliedisofcompatible
voltage/frequency(see‘Specications’).Ensurethatthepowersourceisequippedwithautomatic
voltage regulation and surge protection, as voltage peaks may result in tool damage.
1Main Handle
2On/Off Trigger Switch
3Lock-On Switch
4Oil Level Indicator
5Side Handle
6Tool Retainer
7 Tool Holder
8Brush Access Caps
Product Familiarisation
Included accessories:
1 x Flat chisel 30 x 410mm
1 x Point chisel 30 x 410mm
2 x Hex key
1xSpanner
1 x Oil bottle (supplied empty)
1 pair carbon brushes
Intended Use
• Electric breaker for heavy duty breaking of stone, concrete, masonry, tarmac and similar materials
Unpacking Your Tool
• Carefullyunpackandinspectyourtool.Fullyfamiliariseyourselfwithallitsfeaturesand
functions
• Ensure that all parts of the tool are present and in good condition. If any parts are missing or
damaged, have such parts replaced before attempting to use this tool
263570_Manual.indd 5 06/06/2017 14:22

GB
6
Before Use
Adjusting the side handle
Note: The included side handle features a vibration-reducing,dampening, ridged rubber grip.
Alwaysmakeuseofthishandlewhenoperatingthismachine.
• Wheninuse,alwaysholdthetoolrmlybytheMainHandle(1)andSideHandle(5)
• Thesidehandlecanberotatedtobestsuittheworktobeperformed:
1. Loosen the plastic knob of the handle clamping mechanism
2. Rotate the side handle in the position most suitable for the task at hand
3. Tightentheplasticknobrmlytolockthesidehandleinplace
Note: Forstorageintheincludedmetalcase,thesidehandleneedstobefoldedinlinewiththe
main handle.
Installing hex tting steels
WARNING: Onlyusethistoolwithgoodquality30mmor1-1/8”diametersteelbitswithhex
tting.Donotforceothertypesofsteelstot.Misuseofthistoolcouldcausepermanentdamage,
andmayinvalidateyourwarranty.
1. EnsuretheatportionontheshankofthesteelbitisfacingtowardstheToolRetainer(6),and
that the tool retainer is in the unlocked position
2. InsertthesteelintotheToolHolder(7),ensuringthegrooveinthesteelalignswiththetool
retainer
3. Pull out the spring-loaded tool retainer and rotate 180° into the locked position to secure the
bit (Fig.A)
4. Test that the steel has been correctly installed by trying to pull it out of the tool holder
Operation
WARNING: Alwayswearadequatepersonalprotectionequipmentwhensettingupand
operating this machine.
IMPORTANT: Checktheoillevelandthepowercordbeforeeachuse(see‘Maintenance’).
WARNING: Heavy breaking equipment produces larger amounts of vibrations. It is advisable
towearthickvibration-reducinggloveswhenoperatingthistool.
Switching on and off
• GripthebreakerrmlybyboththeMainHandle(1)andtheSideHandle(5)
• Tostartthebreaker,squeezetheOn/OffTriggerSwitch(2)
• Oncetheon/offtriggerswitchisdepressed,theLock-onSwitch(3)canbeengaged
• Tostopthebreaker,releasetheon/offtriggerswitch
Note:Ifthelock-onswitchwasengaged,depresstheon/offtriggerswitchagainandrelease,to
disengagethelock-onmechanismandswitchoffthemachine.
Notes:
• Applyingexcesspressuredoesnotresultinfasterormoreefcientbreaking
• Best breaking results can be obtained by only applying slight pressure to the tool, enough to
keeptheautomaticclutchengagedandthehammeractionworking
• If the pressure applied to the breaker has a noticeable effect on the speed, reduce the pressure
 Overloadingthebreakerwillreduceitsservicelife
Accessories
• A range of accessories for your electric breaker, including replacements steel bits, is available
throughyourauthorisedSilverlinedealer.
Maintenance
WARNING: Alwaysdisconnectthemachinefromthepowersupplybeforecarryingoutany
maintenance or cleaning.
Cleaning
• Keepyourmachinecleanatalltimes.Dirtanddustwillcauseinternalpartstowearquickly,
shortening the machine’s service life
• Cleanthebodyofyourmachinewithasoftbrushordrycloth.Ifavailable,useclean,dry,
compressedairtoblowthroughtheventilationholes
General inspection
• Regularlycheckthatallthexingscrewsaretight.Theymayvibratelooseovertime
IMPORTANT: Duetotheaggressivenatureofthistool,thepowercablemaybecomedamaged
orwornthroughcontactwithsharpmasonry.Checkthecablebeforeeachuseandreplaceifworn
ordamaged.Donotusethetoolifthecableisdamagedinanyway.Havethecablereplacedbyan
authorisedSilverlineservicecentre.
Lubrication
WARNING: Alwaysensurethatthereissufcientoilinthebreakerpriortouse.
1. Standthetoolupverticallyandwaitafewsecondsfortheoiltocollect
2. Check the oil level in the Oil Level Indicator (4)
Note: Iftheoillevelislow,i.e.thelevelisbelowhalfoftheindicator,themachineneedstobe
topped up:
1. PutthemachineonitssidewiththeOilLevelIndicator(4)pointingupwards
2. Usingthesuppliedhexkey,unscrewandremovethefourboltsofthemetalcoverwhichholds
thelevelindicatorwindow
WARNING: Be careful not to lose or damage the seals.
3. Fillthereservoirwiththerecommendedoil(see“Specications”)
WARNING: DONOToverll.Onlytopupuntilthelevelreachesabout¾oftheindicator
window.
4. Replacethemetalcoveryouremovedpreviouslyandtightenthefourscrewssecurely
5. Standthemachineupvertically,checkforoilleaksaroundthemetalplate,andchecktheoillevel
afterrelling.Correctthelllevelifnecessary.
• Yourelectricbreakerispre-lledwithhighqualitymachineoilatthefactory.Thislubricantcan
be used to operate the machine for the equivalent of 3 hours continuous running each day for
20 consecutive days
• AfterthisusagetheoilneedstobechangedbyaqualiedtechnicianoranauthorisedSilverline
servicecentre(see‘Specications’forcorrectoilspecicationsand‘Disposal’forcorrectrecycling
procedure)
Note: It is advisable to change the carbon brushes of the motor at the same time as carrying out
an oil service.
Brush replacement
• Overtimethecarbonbrushesinsidethemotormaybecomeworn
• Excessivelywornbrushesmaycauselossofpower,intermittentfailure,orvisiblesparking
• To replace the brushes, remove the BrushAccess Caps (8) from both sides of the machine.
Removethewornbrushesandreplacewithnew.Replacebrushaccessplugs.Alternatively,have
themachineservicedatanauthorisedSilverlineservicecentre
Storage
• Aftercleaning,alwaysreturnthemachinetoitsoriginalmetalcase
• Storethistoolcarefullyinasecure,dryplaceoutofthereachofchildren
Disposal
Alwaysadheretonationalregulationswhendisposingofpowertoolsthatarenolongerfunctional
and are not viable for repair.
• Donotdisposeofpowertools,orotherwasteelectricalandelectronicequipment(WEEE),with
householdwaste
• Contactyourlocalwastedisposalauthorityforinformationonthecorrectwaytodisposeof
powertools
263570_Manual.indd 6 06/06/2017 14:22

DIY 1500W Electric Breaker263570
7
silverlinetools.com
263570_Manual.indd 7 06/06/2017 14:22

GB
8
Problem Possible Cause Solution
Machine does not start
Interruptioninthepowersupply Checkthepowersupply;ensuretheplugisswitchedon.Havethepowercircuittestedbyaqualied
electrician
Thepowercableormainsplugisdefective HavethepowercablereplacedbyanauthorisedSilverlineservicecentre
Theon/offtriggerswitchisdefective HavetheswitchreplacedbyanauthorisedSilverlineservicecentre
Construction site generator in sleep mode Activate generator
Voltagefromgeneratortooloworincompatiblewith
this machine Thismachinemaybeincompatiblewiththisspecicpowersource
No hammering action
The machine is too cold Havethemachinewarmup,thenrunitundernoloadtowarmuptheoilandloosenuptheinternal
mechanisms
Insufcientlubrication
Checkoillevel(see‘Maintenance’)andtopupifappropriate.Runningthetoolwithinsufcientlubrication
mayhavecausedtooldamage,inwhichcasethemachineneedstoberepairedbyanauthorisedSilverline
service centre
A fault has occurred in the machine HavethetoolrepairedbyanauthorisedSilverlineservicecentre
The machine does not operate
atfullpower
The extension lead is too long or of inadequate
cross section Use a suitable extension lead
Thevoltageprovidedbythepower
supplyistoolow Checkpowersupplyandchangetoadifferentcircuitifpossible
A fault has occurred in the machine HavethetoolrepairedbyanauthorisedSilverlineservicecentre
Oil is leaking from the
machine housing Sealsmissing/damaged If occurring after an oil service or top-up, check the seals underneath the covers that had been removed duringservice.Otherwise,havethetoolrepairedbyanauthorisedSilverlineservicecentre
Troubleshooting
263570_Manual.indd 8 06/06/2017 14:22

DIY 1500W Electric Breaker263570
9
silverlinetools.com
Terms & Conditions
Silverline Tools Guarantee
This Silverline product comes with a 3 year
guarantee
Registerthisproductatwww.silverlinetools.comwithin30daysofpurchaseinordertoqualify
for the 3 year guarantee. Guarantee period begins according to the date of purchase on your
sales receipt.
Registering your purchase
Registration is made at silverlinetools.com by selecting the Guarantee Registration button. You
willneedtoenter:-
• Your personal details
• Details of the product and purchase information
OncethisinformationisenteredyourguaranteecerticatewillbecreatedinPDFformatforyou
toprintoutandkeepwithyourpurchase.
Guarantee period becomes effective from the date of retail purchase as detailed on your sales
receipt.
PLEASE KEEP YOUR SALES RECEIPT
Ifthisproductdevelopsafaultwithin30daysofpurchase,returnittothestockistwhereit
waspurchased,withyourreceipt,statingdetailsofthefault.Youwillreceiveareplacement
or refund.
If this product develops a fault after the 30 day period, return it to:
Silverline Tools Service Centre
PO Box 2988
Yeovil
BA21 1WU, UK
The guarantee claim must be submitted during the guarantee period.
You must provide the original sales receipt indicating the purchase date, your name,address
andplaceofpurchasebeforeanyworkcanbe
carried out.
You must provide precise details of the fault requiring correction.
ClaimsmadewithintheguaranteeperiodwillbeveriedbySilverlineToolstoestablishifthe
decienciesarerelatedtomaterialormanufacturingoftheproduct.
Carriagewillnotberefunded.Itemsforreturnmustbeinasuitablycleanandsafestatefor
repair,and should be packaged carefully to prevent damage or injury during transportation. We
may reject unsuitable or
unsafe deliveries.
AllworkwillbecarriedoutbySilverlineToolsoritsauthorized
repair agents.
Therepairorreplacementoftheproductwillnotextendtheperiod
of guarantee
Defects recognised by us as being covered by the guarantee shall be corrected by means of
repairofthetool,freeofcharge(excludingcarriagecharges)orbyreplacementwithatoolin
perfectworkingorder.
Retainedtools,orparts,forwhichareplacementhasbeenissued,willbecomethepropertyof
SilverlineTools.
Therepairorreplacementofyourproductunderguaranteeprovidesbenetswhichare
additional to and do not affect your statutory rights as a consumer.
What is covered:
Therepairoftheproduct,ifitcanbeveriedtothesatisfactionofSilverlineToolsthatthe
deciencieswereduetofaultymaterialsorworkmanshipwithintheguaranteeperiod.
Ifanypartisnolongeravailableoroutofmanufacture,SilverlineToolswillreplaceitwitha
functional replacement part.
Use of this product in the EU.
What is not covered:
SilverlineToolsdoesnotguaranteerepairsrequiredasaresultof:
Normalwearandtearcausedbyuseinaccordancewiththeoperatinginstructionsegblades,
brushes, belts, bulbs, batteries etc.
The replacement of any provided accessories drill bits, blades,sanding sheets, cutting discs and
other related items.
Accidental damage, faults caused by negligent use or care,misuse, neglect, careless operation
or handling of the product.
Use of the product for anything other than normal domestic purposes.
Changeormodicationoftheproductinanyway.
UseofpartsandaccessorieswhicharenotgenuineSilverlineToolscomponents.
Faultyinstallation(exceptinstalledbySilverlineTools).
RepairsoralterationscarriedoutbypartiesotherthanSilverlineToolsoritsauthorizedrepair
agents.
Claims other than the right to correction of faults on the tool named in these guarantee
conditions are not covered by the guarantee.
Battery Guarantee
Silverlinebatteriesareguaranteedfor30days.Ifadefectoccursonaregisteredbatteryduring
thetermoftheBatteryGuarantee,duetomaterialormanufacturingfault,thenSilverlinewill
replace it free of charge. This guarantee does not apply to commercial use nor does it extend to
normalwearandtearordamageasaresultofaccident,abuseormisuse.
CE Declaration of Conformity
The undersigned: Mr Darrell Morris
as authorised by: SilverlineTools
Declares that
This declaration has been issued under the sole responsibility of the manufacturer.
TheobjectofthedeclarationisinconformitywiththerelevantUnionharmonisationLegislation.
Identication code: 263570
Description: 1500W Electric Breaker
Conforms to the following directives and standards:
• Machinery Directive 2006/42/EC
• LowVoltageDirective2006/94/EC
• EMC Directive 2004/108/EC
• RoHSDirective2011/65/EU
• Outdoor Noise Directive 2000/14/EC
• EN 60745-1:2010, EN 60745-2-6:2010
• EN 55014-1+A2:2011, EN 55014-2+A2:2008
• EN 61000-3-2+A2:2009, EN 61000-3-3:2008
• EN 3744
Applied Conformity Evaluation Method
2000/14/EC: Annex V
Sound Power Level dB(A)
Measured: 102
Guaranteed: 105
Notied body: JiangsuTÜVProductServiceLtd.Shanghai,China
The technical documentation is kept by: SilverlineTools
Date: 07/04/14
Signed:
Mr Darrell Morris
Managing Director
Name and address of the manufacturer:
PowerboxInternationalLimited,CompanyNo.06897059.Registeredaddress:
Powerbox,BoundaryWay,LuftonTradingEstate,Yeovil,SomersetBA228HZ,UnitedKingdom.
263570_Manual.indd 9 06/06/2017 14:22

FR
10
AVERTISSEMENT : Portez toujours des protections auditives lorsque le niveau d’intensité est
supérieurà85dB(A)etlimitezletempsd’expositionsinécessaire.Sil’intensitésonoredevient
inconfortable,mêmeaveclesprotections,arrêtezimmédiatementd’utiliserl’appareil,vériezque
les protections sont bien en places et adaptés avec le niveau sonore produit par l’appareil.
AVERTISSEMENT : L’exposition de l’utilisateur aux vibrations peut engendrer une perte du toucher,
des engourdissements, des picotements et ainsi réduire la capacité de préhension. De longues
expositionspeuventégalementprovoquercessymptômesdefaçonchronique.Sinécessaire,
limitez le temps d’exposition aux vibrations et portez des gants anti-vibrations. N’utilisez pas cet
appareil lorsque la température de vos mains est en dessous des températures normales,car l’effet
vibratoire en est accentué. Référez-vous aux chiffres indiqués dans les caractéristiques techniques
des caractéristiques relatifs aux vibrations pour calculer le temps et la fréquence d’utilisation de
l’appareil.
Les niveaux sonores et vibratoires indiqués dans la section« Caractéristiques techniques»
du présent manuel sont déterminés en fonction de normes internationales. Ces données
correspondent à un usage normal de l’appareil, et ce dans des conditions de travail normales.
Un appareil mal entretenu, mal assemblé ou mal utilisé peut augmenter les niveaux sonores et
vibratoires. Le site www.osha.europa.eu offre de plus amples informations sur les niveaux sonores
et vibratoires sur le lieu de travail, celles-ci pourront être utiles à tout particulier utilisant des outils
électriques pendant des périodes prolongées.
Description des symboles
Laplaquesignalétiquegurantsurvotreoutilpeutprésenterdessymboles.Cessymboles
constituent des informations importantes relatives au produit ou des instructions concernant son
utilisation.
Port de protection auditive
Port de lunettes de sécurité
Port de masque respiratoire
Port de casque
Port de gants
Lire le manuel d’instructions
ATTENTION
Risque d’électrocution
Double isolation pour une protection supplémentaire
Conforme à la règlementation et aux normes européennes de sécurité pertinentes
Protection de l’environnement
Les produits électriques usagés ne doivent pas être jetés avec les ordures
ménagères.Veuillez les recycler dans les centres prévus à cet effet.Pour de plus
amples informations, veuillez contacter votre municipalité ou point de vente.
IMPORTANT : Avant chaque utilisation,veuillez vous assurez que l’indicateur du
niveau d’huile indique que plus de la moitié du réservoir est plein.
Tension : ............................................. 220 - 240 V~ - 50 Hz
Puissance : ......................................................1 500 W
Frappe : ..................................................1 900 coups/min
Impact d’énergie : ................................................45 Joule
Dimension de burin hexagonal : .................................29 mm/1-1⁄8"
Type d’huile : ................................................... 15 W - 40
Classe de protection : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Indice de protection :..................................................IP20
Longueur du câble :................................................... 4 m
Poids : ...........................................................14,4 kg
Dimensions (L x l x H) : ................................. 650 x 152 x 230 mm
Du fait de l’évolution constante de nos produits, les caractéristiques des produits
Silverlinepeuventchangersansnoticationpréalable.
Informations sur les niveaux sonores et vibratoires :
Conformément à la directive sur les machines 2006/42/CE
Pression sonore LPA :............................................. 91,8 dB(A)
Puissance sonore LWA : ..........................................102,8 dB(A)
Incertitude K :......................................................2,8 dB
Vibration pondérée
Poignée principale ah,CH : .......................................18,104 m/s²
Poignée auxiliaire ah,CH : ....................................... 17 ,534 m/s2
Incertitude K :.................................................... 1,5 m/s2
Conformément à la directive sur les émissions sonores dans l’environnement des
matériels destinés à être utilisés à l’extérieur des bâtiments 2000/14/CE
Puissance acoustique garantie LWA :.................................105 dB(A)
L’intensité sonore peut dépasser 85 dB(A) et il est nécessaire que l’utilisateur
prenne des mesures de protection sonore.
Introduction
Nousvousremercionsd’avoirchoisicetéquipementSilverline.Cesinstructionscontiennentles
informationsnécessairespourvousengarantirunfonctionnementefcaceetentoutesécurité.
Veuillez lire attentivement ce manuel pour vous assurer de tirer pleinement avantage des
caractéristiques uniques de votre nouvel équipement.
Gardez ce manuel à portée de main et assurez-vous que tous les utilisateurs l’aient lu et bien
compris avant toute utilisation. Conservez-le pour toute référence ultérieure.
Traduction des instructions originales
Caractéristiques techniques
MIN
263570_Manual.indd 10 06/06/2017 14:22
