Turnstone TS400C User manual

Page 1 of 2
TS400C Rev D
TS400C
Mobile Easel
R
©2001 Steelcase Inc.
Grand Rapids, MI 49501 U.S.A.
Printed in U.S.A.
1. Unpack panels and parts
Unpack the easel panels, base, top plate and top cap on carpeting (to avoid scratches). Lay the
panels on their edge with the marker board and tackable surfaces facing out. Place top edges
(the ends with the flip chart hang posts) together and the bottom edges about 2 feet apart. You
will need a #2 Phillips screwdriver and a soft rubber mallet to complete this installation.
Please check all pieces before beginning this
project. (This kit may contain extra screws for
your convenience.) If there are any problems
or discrepancies, call our customer service
department at 1-800-turnstone.
2. Attach top plate to panels
Attach the top plate to the top of the easel panel
as shown using four (4) phillips head screws.
Turn screws almost all the way in, but do not
tighten yet - We will come back to tighten these
later.
3. Attach center support and marker tray
Place center support in location between
the panels with flat surface facing to the top
plate. Attach center support to the edges of
the panels with (4) screws in the round holes
as shown. Snap the marker tray into the holes
in the center support.

Page 2 of 2
TS400C Rev D
4. Attach base to panels and casters to base
Attach the easel base to the panels using
eight (8) phillips head screws as shown.
5. Tighten screws in top plate
After base is attached and
screws are tightened, go back
to step 2 and tighten the eight (8)
screws holding the top plate on.
6. Attach top cap
Stand the easel upright onto it's
base with the casters on the
floor. Snap the top cap over the
top plate and push down into
place, keeping both ends level
as you attach into place.
7. Scribble away!
Here's the fun part...be sure to
use only dry erase markers.
6
