Sim-Lab GT1-PRO User manual

GT1-PRO INTEGRATED TRIPLE MONITOR MOUNT
VERSION 1.0
Last updated: 19-07-2023
INSTRUCTION MANUAL

2|2 15
BEFORE YOU START:
Thank you for purchasing this Sim-Lab product! On the following pages, you will find detailed instructions on
assembly. This requires only a set of simple tools and some of your time. Please check the bill of materials before
starting (page 14) and make sure all the parts are delivered.
This manual presumes you are building your GT1-Pro cockpit and fitting it with the GT1-Pro integrated triple
monitor mount. For logistical reasons, the GT1-Pro integrated triple monitor mount hardware kit is an add-on to
the GT1-Pro integrated single monitor mount.
We encourage you to read the product manuals for included products if this one doesn’t answer all of your
questions. Please refer to the following if needed:
www.sim-lab.eu/xero-play-pivots-manual
www.sim-lab.eu/vario-vesa-manual
Inserting Slot-Nuts:
You got excited, finished the build, put the caps on, but forgot to install
one element. Do not worry. It happens to everyone. In this diagram, you
can see how to insert a Slot-Nut directly into the slot from the side.
You can also use one of your smaller Hex wrenches to help wiggle
the Slot-Nut in place.
6MM
Tools needed:
Breaking tabs:
Sometimes tabs from corner brackets need to be broken off in
order to fit as instructed. Place a flathead screwdriver behind
the tab and tilt upwards.
Always make sure to point away from you while doing so.
To know when to do this, we will show the following
symbol next to the brackets.

3|3 15
BUILD 2X
Slot-Nut M8
2X
500MM
1X
Profile 40X40
End-Cap
2X
A2
A6
B8

4|4 15
Corner
Bracket*
2X/2X
M8 X 16
4X
Slot-Nut M8
4X
850MM
1X
Washer M8
4X
Profile 40X40
End-Cap
2X
A1
A8
A10
A4 B3
A11

5|5 15
M8 X 16
4X
Washer M8
4X
B6 B7
600MM
or
23.6”

6|6 15
Cap-Washer
M8
Slot-Nut M8
4X
Integrated Bracket
2X
M8 X 25
4X 4X
A3
A9
A7
A11

7|7 15
Cap-Washer
M8
Slot-Nut M8
4X
M8 X 25
4X 4X
A7 A9 A11

8|8 15
M8 X 25
8X
Slot-Nut M8
8X
Pivot
Adapter
4X
C5
C1
C3

9|9 15
BUILD 2X
Profile 40X40
End-Cap
2X
M8 X 25
4X
Slot-Nut M8
4X
500MM
1X
Pivot
Adapter
2X
B2
C5
C1
C3
B5

10 |10 15
M8 X 40
4X
Nut M8
4X
C2
C4

11 |11 15
M8 X 16
6X
Washer M8
6X
Vario VESA
Holder
3X
Slot-Nut M8
6X D15
D14
D9
D1

12 |12 15
When parts D12 and D13 are installed like
above, monitors are easy to install in a neutral
position. Parts D12 can be adjusted to change
the tilt and/or height.
Parts D13 can be adjusted to adjust the monitor
sideways if needed, and fix it in place.
BUILD 3X
Vario VESA
Plate
1X
Vario VESA
Pin Holder
2X
M8 X 40
(Set Screw)
2X
M5 X 20
(Set Screw)
2X
M5 X 20
4X
Vario VESA
Pin
1X
D3
D2
D12
D6
D13
D13
D12
D4

13 |13 15
M8 X 40
(Set Screw)
3X
Corner Bracket
Cap
2X/2X
D12
A5 B4

14 |14 15
BOX B - GT1-Pro Integrated Triple Monitor Mount
PROFILE KIT
#Part QTY Note
B1 40X40 Length=850mm 1 Replaces A1.
B2 40X40 Length=500mm 2
HARDWARE KIT
B3 Corner bracket 40x40 2
B4 Corner bracket 40x40 cap 2
B5 Profile 40x40 end-cap 6
B6 Bolt M8 X 16 DIN 912 4
B7 Washer M8 DIN 125-A 4
B8 Slot-Nut M8 4
BOX D - Vario VESA Single Adapter (X3)
HARDWARE KIT
#Part QTY Note
D1 Vario VESA holder 1
D2 Vario VESA plate 1
D3 Vario VESA pin holder 2
D4 Vario VESA pin 1
D5 Bolt M6 X 12 DIN 7991 4 Used with VESA 100/200 adapter.
D6 Bolt M5 X 20 DIN 7991 4
D7 Bolt M4 X 16 DIN 7985 4 Philips head.
D8 Bolt M4 X 10 DIN 7985 4 Philips head.
D9 Bolt M8 X 16 DIN 912 2
D10 Bolt M6 X 16 DIN 912 4
D11 Bolt M5 X 16 DIN 912 4
D12 Set screw M8 X 40 DIN 916 3
D13 Set screw M5 X 20 DIN 916 2
D14 Washer M8 DIN 125-A 2
D15 Slot-Nut M8 2
BOX A - GT1-Pro Integrated Monitor Mount
PROFILE KIT
#Part QTY Note
A1 40X40 Length=600mm 1 Only for integrated single.
A2 40X40 Length=500mm 2
HARDWARE KIT
A3 Integrated bracket 2
A4 Corner bracket 40x40 2
A5 Corner bracket 40x40 cap 2
A6 Profile 40x40 end-cap 4
A7 Bolt M8 X 25 DIN 912 8
A8 Bolt M8 X 16 DIN 912 4
A9 Cap-Washer M8 8
A10 Washer M8 DIN 125-A 4
A11 Slot-Nut M8 12
BOX C - Xero-Play Triple Pivot Set
HARDWARE KIT
#Part QTY Note
C1 Xero-Play triple pivot adapter 8
C2 Bolt M8 X 40 DIN 912 4
C3 Bolt M8 X 25 DIN 912 16
C4 Nut M8 4
C5 Slot-Nut M8 16

15 |15 15
If you still have some questions regarding assembly of this product or about the manual itself,
please refer to our support department. They can be reached at
suppor[email protected]
Alternatively, we now have a Discord server where there are quite some experienced Sim-Lab
customers hanging out. They might just help you along if you ask them nicely ;)
www.sim-lab.eu/discord
If you feel like printing this manual, please consider the environment before doing so. For the best
results, make sure you print at 100% scale without borders.
Product page on the Sim-Lab website:
