Sim-Lab VARIO TRIPLE MONITOR MOUNT User manual

VARIO™ TRIPLE MONITOR MOUNT
75/100 + 100/200
VERSION 1.0
Last updated: 12-09-2022
INSTRUCTION MANUAL

2|2 15
BEFORE YOU START:
Thank you for purchasing this Sim-Lab product! On the following pages, you will find detailed instructions
on assembly. This requires only a set of simple tools and some of your time. Please check the bill of
materials before starting (page 14) and make sure all the parts are delivered.
This product combines some products we normally offer separately. In some cases there are slight
changes in the assembly instructions in this manual versus what the products’ own manual states.
We encourage you to read the product manuals for included products if this one doesn’t answer all of
your questions. Please refer to the following if needed:
www.sim-lab.eu/xero-play-pivots-manual
www.sim-lab.eu/vario-vesa-manual
Inserting Slot-Nuts:
You got excited, finished the build, put the caps on, but forgot to install
one element. Do not worry. It happens to everyone. In this diagram, you
can see how to insert a Slot-Nut directly into the slot from the side.
You can also use one of your smaller Hex wrenches to help wiggle
the Slot-Nut in place.
Tools needed:
4/5/6MM

3|3 15
76MM
or
3”
25MM
or
1”
BUILD 2X
M8 X 20
2X
Slot-Nut M8
4X
P6
1X
Profile 40X40
End-Cap
2X
Rubber
Foot
2X
P6
A8
A21
A13
A17

4|4 15
Instructions for the right side (P3)
are similar. See page 8 for the
orientation of the profile.
BUILD 2X
Profile 80X40
End-Cap
1X
M8 X 16
2X
Slot-Nut M8
4X
P2
(LEFT)
1X
Corner
Bracket
2X
Washer M8
2X
P2
A12
A21
A10
A19
A16

5|5 15
BUILD 2X
M8 X 16
2X
Washer M8
2X
A19
A16

6|6 15
Profile 80X40
End-Cap
2X
M8 X 25
(B3)
8X
Slot-Nut M8
(A21/B5/C17)
8X/8X/2X
P1
1X
Pivot
Bracket
4X
M8 X 20
(A15)
8X
Corner
Bracket
2X
A9
P1
A12
B1
A21
A15
B3
C17
B5

7|7 15
Instructions for the right side (P5)
are similar. See page 9 for the
orientation of the profile.
* Mind the orientation of the Slot-Nuts.
BUILD 2X
Profile 80X40
End-Cap
2X
M8 X 25
4X
Slot-Nut M8
(B5/C17)
4X/2X
P4
(LEFT)
1X
Pivot
Bracket
2X
B1
P4
A12 C17
*
B3
B5

8|8 15
M8 X 25
4X
Cap-Washer
M8
4X
Washer M8
(DIN 988)
4X
P3
A18
A14
A20

9|9 15
Adjust arm angles to your preference.
We included markings in the pivots.
Markings are placed in 10° increments.
120°
M8 X 40
4X
Nut M8
4X4X
Corner Bracket
Cap
B2
P5
B4
A11

10 |10 15
When part C14 is installed like suggested
above, it allows for a neutral position of the
monitor. The pitch of the monitor can be
adjusted after the monitor has been fitted.
24MM
or
1”
BUILD 3X
Vario VESA
Holder
4X
Vario VESA
Guide Block
4X
M8 X 40
(Set Screw)
1X
M5 X 10
4X
C4
C1
C14
C8

11 |11 15
When parts C14 and C15 are installed like
above, monitors are easy to install in a neutral
position. Parts C14 can be adjusted to change
the tilt and/or height.
Parts C15 can be adjusted to adjust the monitor
laterally if needed, and fix it in place.
BUILD 3X
Vario VESA
Plate
1X
Vario VESA
Pin Holder
2X
M8 X 40
(Set Screw)
2X
M5 X 20
(Set Screw)
2X
M5 X 16
4X
Vario VESA
Pin
1X
C2
C3
C5
C14
C7
C15
C15
C14

12 |12 15
M8 X 16
6X
Cap-Washer
M8
6X
A18
C11

13 |13 15
VESA
200
3X
M6 X 12
12X
A7
C6

14 |14 15
MONITOR STAND
PROFILE KIT
#Part QTY Note
P1 80X40 Length=1200mm 1
P2 80X40 3N Length=1200mm 1 Left upright, engraved.
P3 80X40 3N Length=1200mm 1 Right upright, engraved.
P4 80X40 3N Length=600mm 1 Left arm, engraved.
P5 80X40 3N Length=600mm 1 Right arm, engraved.
P6 40X40 Length=680mm 2
HARDWARE KIT
A7 VESA 200 adapter (optional) 4 Depends on purchase.
A8 Rubber foot 4
A9 Triple sandwich plate 80 2
A10 Corner bracket 40x40 4
A11 Corner bracket 40x40 cap 4
A12 Profile 80x40 end-cap 8
A13 Profile 40x40 end-cap 4
A14 Bolt M8 X 25 DIN 912 4
A15 Bolt M8 X 20 DIN 912 8
A16 Bolt M8 X 16 DIN 912 8
A17 Bolt M8 X 20 DIN 7380 4 Buttonhead.
A18 Cap-Washer M8 10
A19 Washer M8 DIN 125-A 8
A20 Washer M8 DIN 988 4
A21 Slot-Nut M8 24
Disclaimer: for some entries on this page, we supply more than required as spare
materials. Don’t worry if you have some leftovers, this is intentional.
BOX B - Xero-Play triple pivot set
HARDWARE KIT
#Part QTY Note
B1 Xero-Play triple pivot adapter set 1 Set of 8.
B2 Bolt M8 X 40 DIN 912 4
B3 Bolt M8 X 25 DIN 912 16
B4 Nut M8 4
B5 Slot-Nut M8 16
BOX C - Vario VESA triple adapter set
HARDWARE KIT
#Part QTY Note
C1 Vario VESA guide block 3
C2 Vario VESA pin holder 6
C3 Vario VESA pin 3
C4 Vario VESA holder 3
C5 Vario VESA plate 3
C6 Bolt M6 X 12 DIN 7991 12 Used with VESA 200 adapter.
C7 Bolt M5 X 20 DIN 7991 12
C8 Bolt M5 X 10 DIN 7991 12
C9 Bolt M4 X 16 DIN 7985 12 Philips head.
C10 Bolt M4 X 10 DIN 7985 12 Philips head.
C11 Bolt M8 X 16 DIN 912 6
C12 Bolt M6 X 16 DIN 912 12
C13 Bolt M5 X 16 DIN 912 12
C14 Set screw M8 X 40 DIN 916 9
C15 Set screw M5 X 20 DIN 916 6
C16 Washer M8 DIN 125-A 6
C17 Slot-Nut M8 6

15 |15 15
If you still have some questions regarding assembly of this product or about the manual itself,
please refer to our support department. They can be reached at
suppor[email protected]
Alternatively, we now have a Discord server where there are quite some experienced Sim-Lab
customers hanging out. They might just help you along if you ask them nicely ;)
www.sim-lab.eu/discord
If you feel like printing this manual, please consider the environment before doing so. For the best
results, make sure you print at 100% scale without borders.
Product page on the Sim-Lab website:
