MD2465 INSTALLATION INSTRUCTION
If you have any questions, please contact us via [e-mail]
or call us at telephone [phone] (USA) Mon - Fri 10am - 6pm (Pacific time).
For more information,please visit our website:www.mountingdreamonline.com
(B1)
13"~43" Max:200x200mm/8x8"
Min:50x50mm/2x2"
Für die Installationsanweisungen auf Deutsch, siehe Seite 11~12.
Pour l'instruction en Français, veuillez vous reporter à la page 13~14.
Para las instrucciones de la instalación en Español, favor vea la página 15~16.
Per le Istruzioni in Italiano, vedi pagina 17~18.
x3 x1
TV
1 2

Before getting started, let’s make sure this mount is perfect for you!
2 Does your TV
(including accessories)
weigh less than
50 LBS (22.7 KG)?
4 Installation Tools
(Not Included)
Yes --- Perfect!
No --- This mount is NOT compatible.
MAX:200mm/8"
MAX:
200mm/8"
Yes --- Perfect!
No --- This mount is NOT compatible.
CAUTION:
Drywall with
wood studs?
Band Tape
2M2M
5 Safety Caution
Please read this instruction carefully before installation.
If you do not understand these instructions or have doubts about the safety of the
installation, assembly or use of this product, contact Customer Service via
[e-mail] or call us at telephone [phone] (USA) Mon
- Fri 10am - 6pm (Pacific time).
● This product is designed for use in wood stud and solid concrete wall.
- DO NOT install into drywall alone.
● The wall must be capable of supporting five times the weight of the TV and mount
combined.
● Do not apply this product to any purpose not indicated by Mounting Dream.
● Incorrect installation may result in product damage or body injury. Mounting Dream shall
bear no responsibility for any damage or injury resulted from incorrect installation,
incorrect assembly or misuse.
Solid concrete
wall?
Pencil Screwdriver Electrodrill Socket Wrench
1/2"(13mm)
Stud Finder Awl 1/8"(3mm)
Wood Drill Bit
3/8"(10mm)
Masonry Drill Bit Hammer
1
3 What is your wall
made of?
1 Is your TV VESA
equal to/greater than
50x50mm/2x2"
and equal to/less than
200x200mm/8x8"?

4
M8
M6
M4
1-4 Select TV Screws
TV back
Bracket Washer
Bracket
Long Screw
Spacer
No, go to PAGE 5 for detailed combination.
Yes, go to PAGE 5 for detailed combination.
TV back
1-5 Need Spacer?
Short Screw
Washer
1-3 Extended arms assembly example (for reference)
