Sima XL-SP-8 User manual

SIMA
XL-SP-8 Amplified Speakers
User Manual for XL-SP8-PR
www.simaproducts.com

Speaker Specifications and Drawing - XL-SP-8ing - XL-SP-8
1
2
3
4
5
6
7
9
10
Model XL-SP-8
Woofer Size 8”
Wattage 80w
Frequency Response 55Hz-18kHz
Dimensions (in.) 18.1x12.2x10.6
Weight (lbs) 19.8 lbs.
Microphone Input YES (1/4”)
Stereo Input YES
Ground Stands Included NO
1. MIC LEVEL – Used to adjust the volume of
the microphone input.
2. MIC INPUT CONNECTOR – ¼” balanced
Input for connecting low impedance
microphones to the Low-Noise preamp.
3. LINE LEVEL – Used to control the level of
the line input.
4. LINE INPUT CONNECTOR - RCA Input for
connecting line level signals.
5. TREBLE CONTROL - Controls the high
band of the Channel Equalizer, +/- 10 dB at
3.5kHz.
6. LINE OUTPUT – ¼” balanced output
connector used to link multiple XL-SP8s
together.
7. BASS CONTROL - Controls the low band of
the Channel Equalizer, +/- 12 dB at 100Hz.
8. AMP CLIP LED - LED lights when the amp is
at maximum and about to clip.
9. VOLTAGE SELECTOR – Set this switch to
either 115VAC or 220VAC to match your
power source.
10.AC POWER INLET – Connect the supplied
standard IEC AC power cable here.
•On / Off Switch with indicator light
•Extra Replacement Fuse included,
use only T2A fuse
8

(optional)
Hooking up the Speakers to the Volume Control Box
It is suggested that you place the two speakers on the ground cloth next to the base of the frame.
The Volume Control Box should sit next to the DVD player. It lets you adjust the audio volume level without having to
walk up to each speaker.
To connect the speakers for use with your projector and DVD player use the RCA cables provided. Follow the steps and
diagram below.
1. Connect the L + R audio output of your DVD player to the L + R input on the Volume Control Box.
2. Connect the Video output of your DVD player to the Video input of your projector.
3. Connect the L Audio output of the Volume Control Box to the L Line input of the XL-SP speaker you have
located to the left of the screen and frame.
4. Connect the R output of the Volume Control Box to the R Line input of the other XL-SP speaker you have
located to the left of the screen and frame.
5. Plug the AC line cords into the AC Power Inlet on the back of each speaker and insert the other ends into a
properly grounded GFI outlet.
6. Set the volume level on the Volume control box to min.
7. Set the Line Input level, Bass and Treble controls on the back of each speaker to the middle (12:00 o’clock)
position. For the XL-SP10 only, set the Master Volume control also to the mid (12:00 o’clock) position.
8. Turn on the Power switch on the back of each speaker. The light in the switch will light indicating AC power is
on.
9. Place a DVD or CD into the DVD player and start the movie or audio.
10. Adjust the Volume Control Box for a good audio level. If you hear no sound, be sure the DVD is playing. Check
all cable connections. If the sound is not loud enough with the Volume Control Box set to maximum, turn the
Line Input Level control on the back of each speaker up. Also, be sure any volume setting in the DVD player or
projector is set properly.

Speaker Specifications
-Commercial grade amplified speakers Model XL-SP-8 XL-SP-10
Woofer Size 8” 10”
Wattage 80w 120w
Frequency Response 55Hz-18kHz 50Hz-20kHz
Dimensions (in.) 18.1x12.2x10.6 21x12.2x13.5
Weight (lbs) 19.8 lbs. 37.4 lbs.
Microphone Input YES (1/4”) YES (XLR style)
Stereo Input YES YES
Ground Stands Included NO YES
-Moisture resistant speaker cones
-Bass and treble control on speaker
-Universal speaker stand mount(stand not
included)
-Line-out allows for expansion of sound
system
-2-Channel passive volume control box
included
- 30 foot Stereo RCA audio cables included
Speaker System - 90 Day Limited Warranty Sima Products
Corporation
Limited Warranty
Sima Products Corp. (“Sima”) warrants that if the accompanying product proves to be defective to the
original purchaser in material or workmanship within 90 days from the original retail purchase, Sima will,
at Sima’s option, either repair or replace same without charge (but no cash refund will be made).
What you must do to enforce Warranty:
You must deliver, mail or ship the product, together with both the original bill of sale and this limited
Warranty statement as proof of warranty coverage to:
Sima Products Corp.
Attn: Customer Service
140 Pennsylvania Ave.
Bld. #5
Oakmont, PA 15139
Phone # [phone]
Fax # [phone]
It is recommended that you call Sima at the number listed above to obtain a return authorization number.
Limitation of Liability and Remedies
Sima shall have no liability for any damages due to lost profits, loss of use or anticipated benefits, or other
incidental, consequential, special or punitive damages arising from the use of, or the inability to use, this
product, whether arising out of contract, negligence, tort or under any warranty, even if Sima has been
advised of the possibility of such damages. Sima’s liability for damages in no event shall exceed the
amount paid for this product. Sima neither assumes nor authorizes anyone to assume for it any other
liabilities.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may
also have other rights which vary from
state to state.
