BOILER DETAILS
USER, INSTALLATION AND SERVICING INSTRUCTIONS
ALU HE
Aluminium condensation boilers
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
199839
Authorised User No. 02285

2
SAFE HANDLING
This boiler may require 2 or more operatives to move it into its installation site, remove it from its packaging and
during movement into its installation location. Manoeuvring the boiler may include the use of a sack truck and involve
lifting pushing and pulling.
Caution should be exercised during these operations.
Operatives should be knowledgeable in handling techniques when performing these tasks and the following precau-
tions should be considered:
– Grip the boiler at the base
– Be physically capable
– Use personal protective equipment as appropriate e.g. gloves, safety footwear.
During all manoeuvres and handling actions, every attempt should be made to ensure the following unless unavoi-
dable and/or the weight is light.
– Keep back straight
– Avoid twisting at the waist
– Always grip with the palm of the hand
– Keep load as close to the body as possible
– Always use assistance
WARNING
Caution should be exercised when performing any work on this appliance.
Protective gloves and safety glasses are recommended.
– Avoid direct contact with sharp edges.
– Avoid contact with any hot surfaces.
NOTICE
Please be aware that due to the wet testing of the appliance, there may some residual water in the hydraulic circuit.
– Protect any surfaces, carpets or floorings.
– Use a suitable container to catch any water that escape when removing the protective caps from the connections.
All descriptions and illustrations provided in this manual have been carefully prepared but we reserve the right to make
changes
and improvements in our products that may affect the accuracy of the information contained in this manual.
IMPORTANT NOTICE
For the first year all of our appliances are protected by our manufacturer’s guarantee which covers both parts and
labour.
As you would expect from Sime Ltd, it is our aim to provide our valued customers with the best in after sales and
service.
To take advantage of any extended warranty offered, all you have to do is to adhere to these 3 simple conditions:
The installation must be carried out to Manufacturers/Benchmark Standards by a Gas Safe Registered
Engineer, and recorded in the installation manual.
The appliance must be registered with both Sime Ltd and Gas Safe within 30 days of installation.
The appliance must be serviced every 12 months, within 30 days of the anniversary of the installation date, by either
Sime Ltd or a Gas Safe registered engineer- ensuring that the Benchmark service record in the installation
manual is completed.
Failure to comply with the above will result in only the 12 month warranty being offered.In the absence of any proof
of purchase, the 12 month warranty period will commence from the date of manufacture of the boiler as shown on the
appliance data plate.

3

4
Please refer to commissioning instructions for filling in the checklist at the back of this installation guide.
Note: All Gas Safe registered installers carry a ID Card.
You can check your installer is Gas Safe Registered by calling 0800 408 5577
SIME COMBINATION BOILERS
Installer checklist
Please remember to carry out the following checks after installation. This will achieve complete customer
satisfaction, and avoid unnecessary service calls. A charge will be made for a service visit where the fault is not
due to a manufacturing defect.
Has a correct by-pass been fitted and adjusted?
Has the system and boiler been flushed?
Is the system and boiler full of water, and the correct pressure showing on the pressure gauge?
Is the Auto Air Vent open?
Has the pump been rotated manually?
Is the gas supply working pressure correct?
Is the boiler wired correctly? (See installation manual).
Has the D.H.W. flow rate been set to the customer requirements?
Has the customer been fully advised on the correct use of the boiler, system and controls?
Has the Benchmark Checklist in the use and maintenance section of this manual, been completed?
––
The Benchmark Scheme
Sime is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and com
-
missioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise
safety, efficiency and performance.
Benchmark is managed and promoted by the Heating and Hotwater Industry Council.
For more information visit www.centralheating.co.uk.
Please ensure that the installer has fully completed the Benchmark Checklist in the use and maintenance section of
the installation instructions supplied with the product and that you have signed it to say that you have received a full
and clear explanation of its operation.
The installer is legally required to complete a commissioning checklist as a means of complyng with the appropriate
Building Regulations (England and Wales).
All installations must be notified to Local Area Building Control either directly or through a Competent Persons
Scheme.
A Building Regulations Compliance Certificate will then be issued to the customer who should, on receipt, write the
Notification Number on the Benchmark Checklist.
This product should be serviced regularly to optimise its safety, efficiency and performance.
The service engineer should complete the relevant Service Record on the Benchmark Checklist after each service.
The Benchmark Checklist may be required in the event of any warranty work and as supporting documentation
relating to home improvements in the optional documents section of the Home Information Pack.
I
mportant Information
IT
IS A STATUTORY REQUIREMENT THAT ALL GAS APPLIANCES ARE INSTALLED BY COMPETENT PERSONS,
IN
ACCORDANCE WITH THE GAS SAFETY (INSTALLATION AND USE) REGULATIONS (CURRENT EDITION). The
manu
facturer’s instructions must not be taken as overriding any statutory requirements, and failure to comply
wi
th these regulations may lead to prosecution.
N
o modifications to the appliance should be made unless they are fully approved by the manufacturer.
G
AS LEAKS: DO NOT OPERATE ANY ELECTRICAL SWITCH, OR USE A NAKED FLAME. TURN OFF THE GAS SUPPL
Y
AND
VENTILATE THE AREA BY OPENING DOORS AND WINDOWS CONTACT THE GAS EMERGENCY SERVICE
ON
080
0111999.

5
SAFETY WARNINGS AND REGULATIONS
m
WARNINGS
– After having unpacked the boiler en-
sure that it is undamaged and com-
plete including the valve pack, hanging
bracket and template.
– The appliance must be used as in-
tended.
Sime declines all responsible
for any injury or damage to persons,
animals,or property as a result of im-
proper installation, adjustment, main-
tenance or use.
–In the event of water leaks, disconnect
the appliance from the mains power
supply, close the water mains and seek
help from a qualified engineer.
– Periodically check that the operating
pressure of the water heating system
when cold be included in the range
0.8-
6.0 bar
. If this is not the case, increase
the pressure or contact professionally
qualified personnel.
– If the appliance is not used for a long
period of time, the following operations
must be carried out:
-
set the main isolation switch to "OFF";
- close the gas and water valves for the
water heating system.
– In order to ensure optimal appliance
operations Sime recommends that
maintenance and checks are carried
out at least ONCE A YEAR or according
to the specific legal provisions .
m
WARNINGS
– It is recommended that all operators
read this manual carefully in order to
use the appliance in a safe and rational
manner.
–
This manual is an integral part of the
appliance. It must therefore be kept for
future reference and must always ac-
company the appliance in the event of
the appliance being transferred to an-
other Owner or System Manager or be-
ing installed on another system.
–
Installation and maintenance of this ap-
pliance must be carried out by a qual-
ified company or by a professionally
qualified technician in accordance with
the instructions contained in the man-
ual. Once the work is complete, the
company or technician will issue a dec-
laration of conformity with national and
local technical standards and legisla-
tion in force in the country where the
appliance will be used.

6
RESTRICTIONS
d
DO NOT
– To allow children under the age of 8 to
use the appliance. The appliance can
be used by children no younger than
8 years old, by people with physical
or cognitive disabilities, and by people
lacking experience or the necessary
knowledge, provided that they are su-
pervised or have been instructed on
how to use the appliance safely and
that they understand the risks associ-
ated with it.
– To allow children to play with the ap-
pliance.
–To allow unsupervised children to per-
form user maintenance and cleaning.
–Do not use electrical devices or appli-
ances such as switches, electrical ap-
pliances etc if you can smell gas. If this
should happen:
-
open the doors and windows to venti-
late the room;
- turn the gas off at the meter;
- call the emergency service 0800
111999.
– Do not touch the appliance with bare
feet or with any wet part of the body.
– Do not carry out any repair, mainte-
nance or cleaning operation before
having disconnected the appliance
from the mains power by setting the
main switch to "OFF", and closing the
gas supply.
– Do not modify the safety or adjustment
devices without authorization and in-
structions from the manufacturer.
d
DO NOT
– Do not block the condensate drain.
– Do not pull, detach or twist the electri-
cal cables coming out of the appliance
even if the appliance is disconnected
from the mains power supply.
– Do not expose the boiler to atmospher-
ic agents. These boilers can also be
installed in partially covered areas, as
per EN 15502, with a maximum ambi-
ent temperature of 60 °C and a mini-
mum ambient temperature of 0 °C. It
is generally advisable to install the
boilers below weathered roofs, on the
balcony or in a protected niche, to pro-
tect them from exposure to weathering
agents (rain, hail and snow). All boilers
provide a standard antifreeze function.
– Do not block or reduce the size of the
ventilation openings of the room where
the appliance is installed, if present.
– Remove the mains power and gas sup-
ply from the appliance if the external
temperature could fall below ZERO
(risk of freezing).
– Do not leave containers with flamma-
ble substances in the room where the
appliance is installed.
– Do not dispose of the packaging ma-
terial irresponsibly as it could be dan-
gerous. Packaging must be disposed of
as specified by the legislation in force
in the country where the appliance will
be used.

7
RANGE
MODEL CODE
ALU HE 80 8115701
ALU HE 116 8115710
ALU HE 160 8115720
ALU HE 200 8115730
ALU HE 240 8115740
ALU HE 280 8115751
COMPLIANCE
Our company declares that ALU HE boilers comply with the fol-
lowing directives:
–Gas Appliances EU Regulation 2016/426
– Low Voltage Directive 2014/35/UUE
– Electromagnetic Compatibility Directive 2014/30/EU
– Ecodesign Directive 2009/125/EC
– Regulation (EU) No. 813/2013 - 811/2013
– Boiler Efficiency Directive 92/42/EEC
SYMBOLS
a
WARNING
To indicate actions which, if not carried out correctly,
can result in injury of a general nature or may damage
or cause the appliance to malfunction; these actions
therefore require particular caution and adequate
preparation.
f
ELECTRICAL HAZARD
To indicate actions which, if not carried out correctly,
could lead to injury of an electrical nature; these ac-
tions therefore require particular caution and ade-
quate preparation.
d
DO NOT
To indicate actions which MUST NOT BE carried out.
m
CAUTION
To indicate particularly important and useful informa-
tion.
MANUAL STRUCTURE
This manual is organized as follows.
USER INSTRUCTIONS
TABLE OF CONTENTS 9
DESCRIPTION OF THE APPLIANCE
TABLE OF CONTENTS 15
INSTALLATION AND SERVICING
INSTRUCTIONS
TABLE OF CONTENTS 27
CASCADING SYSTEMS
TABLE OF CONTENTS 53

8

9
USER INSTRUCTIONS
TABLE OF CONTENTS
VERY IMPORTANT!
PLEASE MAKE SURE YOUR COMMISSIONING CHECKLIST AND THE SERVICE INTERVAL RECORDS ENCLOSED
ARE FILLED IN CORRECTLY.
ALL GAS SAFE REGISTERED INSTALLERS CARRY A GAS SAFE ID CARD.
BOTH SHOULD BE RECORDED IN YOUR COMMISSIONING CHECKLIST AND A SERVICE INTERVAL RECORDS.
YOU CAN CHECK YOUR INSTALLER IS GAS SAFE REGISTERED
BY CALLING ON 0800 408 5500 OR ALTERNATIVELY WWW.GASSAFEREGISTER.CO.UK
1 USING THE BOILER ALU HE 10
1.1 Control panel ..................................10
1.2 Start-up ......................................11
1.2.1 Preliminary checks.................... 11
1.2.2 Ignition.............................. 11
1.3 Adjusting the delivery temperature ................11
1.4 Malfunctions ..................................11
1.5 Fault / malfunction codes........................12
1.6 SIME remote control connection (optional accessory) 12
2 MAINTENANCE 13
2.1 Servicing......................................13
2.2 External cleaning...............................13
2.2.1 Cleaning the case ..................... 13
3 DISPOSAL 13
3.1 Disposal of the equipment (European Directive
2012/19/EU) ...................................13

10
1 USING THE BOILER ALU HE
1.1 Control panel
The control panel allows all operators to make all adjustments
necessary to manage
Sime ALU HE boilers and connected sys-
tems.
3
1
2
4
5
Fig. 1
1 DISPLAY ICONS DESCRIPTION
l
SUMMER MODE ICON .
n
WINTER MODE ICON .
r
DHW MODE ICON .
u
HEATING MODE ICON .
v
GRADUATED OUTPUT SCALE . The segments of the
bar light up in proportion to the output delivered by
the boiler.
f
BURNER OPERATION AND BLOCKING ICON .
h
RESET REQUIRED ICON .
z
CHIMNEY SWEEP FUNCTION ICON .
i
SECONDARY DIGITS . The boiler displays the system's
pressure value.
j
MAIN DIGITS . The boiler displays the values set, fault
status and outdoor temperature.
E
SUPPLEMENTARY SOURCES PRESENT ICON .
2 DESCRIPTION OF COMMANDS
T
ON/OFF BUTTON .
ON = Boiler has electric power.
OFF = Boiler has electric power but is not available
for operation. The protection functions are on, how-
ever.
U
SUMMER MODE BUTTON . By pressing this button the
boiler operates only on demand for domestic hot wa-
ter
(function not available) .
V
WINTER MODE BUTTON . By pressing this button the
boiler operates for heating and domestic hot water.
W
SET DHW BUTTON . By pressing this button the tem-
perature of the domestic hot water is displayed
(function not available) .
X
SET HEATING BUTTON . With the first press of this but-
ton the temperature of heating circuit 1 is displayed.
With the second press of this button the temperature
of heating circuit 2 is displayed. With the third press
of this button the temperature of heating circuit 3 is
displayed.
Y
RESET BUTTON . Lets you reset operation after an op-
erating error.
J
INCREASE BUTTON . By pressing this button the value
set is increased.
Q
REDUCE BUTTON . By pressing this button the value
set is reduced.
3 BUTTONS RESERVED FOR INSTALLER (access to INST pa-
rameters and CASCADE parameters)
c
CONNECTION THROUGH PC . To be used only with
the
Sime programming kit and only by authorised
personnel. Do not connect other electronic devices
(cameras, phones, MP3s etc.). Use a tool to remove
the cap and replace it after use.
w
WARNING: Communication port sensitive to static
electricity
. Before use, it is advisable to touch an
earthed metal surface to get rid of static electricity.
L
INFORMATION BUTTON . Press the button several
times to scroll through the parameters.
M
CHIMNEY SWEEP FUNCTION BUTTON . Press the but-
ton several times to scroll through the parameters.
N
REDUCE BUTTON . For changing the default values
set.
Z
INCREASE BUTTON . For changing the default values
set.
4 LIGHT BAR
Blue = Operation.
Red = Operating error.
5 TIMER (optional)
Mechanical timer (code 8092228) or digital timer (code 8092229)
for programming heating/dhw.

11
1.2 Start-up
1.2.1 Preliminary checks
a
WARNING
Should it be necessary to access the areas in the bot-
tom part of the appliance, make sure that the system
components and pipes are not hot (risk of burning).
Commissioning of the ALU HE boiler must be carried out by pro-
fessionally qualified personnel after which the boiler can op-
erate automatically. It may, however, be necessary for the sys-
tem manager to start the appliance autonomously after having
turned it off, without involving a technician: for example, after a
holiday.
In such cases it must first be checked that the fuel and water
system isolation valves are open.
1.2.2 Ignition
After having carried out the preliminary checks, proceed as fol-
lows:
–set the main system switch to "ON"
– the blue bar (4) comes on and the screen saved by the elec-
tronic circuit board before the appliance was turned off is
shown on the display.
Example: winter; delivery temperature (40°C); system pressure
(1.3 bar).
ON
Fig. 2
When heat is requested from the systems the boiler automati-
cally carries out:
–the operational checks
– ignition and starts automatic operation.
m
CAUTION
– When the display is not backlit (off), the first press
on each function button serves to backlight it (turn
it on).
– To manually stop the boiler press button T.
– The display will show the following screen.
1.3 Adjusting the delivery temperature
The control panel on ALU HE boilers lets you manually adjust the
delivery temperature on two temperature levels by choosing the
best ones for the systems managed (e.g. 80°C and 50°C).
To adjust the delivery temperature on the first of the two levels:
– press button X(twice if the display isn't backlit). The symbol
uwill be shown on the display
– press buttons Jor Quntil the desired value is displayed
(e.g. 80°C)
– press button Xagain. The symbol xwill be shown on the
display
– press buttons Jor Quntil the desired value is displayed
(e.g. 50°C)
Once the settings are completed, to go back to the starting
screen press button Xor wait for approx. 60 seconds without
touching any buttons.
1.4 Malfunctions
In the event of a fault/malfunction the message "ALL" will ap-
pear on the display with the alarm number and the light bar (4)
will turn red.
Example: “ALL 02” (Low System Pressure Error: less than 0.8
bar).
NOTE: in the case of "ALL 02" , the system can be reintegrated,
when cold, without disconnecting the power supply to be able to
see when the pressure reaches the correct value (be included
in the range 0.8-6.0 bar). The warning disappears when normal
conditions are reset and the boiler starts up again automatically.

12
In the case of all other errors, before repairing the fault, it is
recommended, as a precautionary measure, that you:
– disconnect the appliance from the mains power by setting the
main switch to "OFF"
– close the fuel isolation valve.
OFF
Fig. 3
NOTE: When, in addition to the message "ALL ..." the symbol
h
also appears on the display, after having repaired the
fault, button
Y
must be pressed for approx. 3 seconds, and
then released. The boiler starts up again normally.
1.5 Fault / malfunction codes
If a fault/malfunction is detected during boiler operation, the
message
"ALL" will appear on the display followed by the fault
code and the light bar (4) will go red.
Possible errors are reported below.
Type No. Description
ALL 01 Air pressure switch fault
ALL 02 Low water pressure in system
ALL 03 High water pressure in system
ALL 05 Boiler delivery probe fault
ALL 06 No flame detection
ALL 07 Safety thermostat or siphon pressure switch triggered
ALL 08 Fault in flame detection circuit
ALL 09 No water circulating in primary system
ALL 10 Hot water tank sensor/anti-freeze faulty
ALL 11 Modulator disconnected error
ALL 13 Smoke probe triggered
ALL 14 Smoke probe fault
ALL 15 Fan fault
ALL 18 Boiler delivery probe temperature above 117°C
ALL 19 External sensor fault (flashing warning)
ALL 20 Mix 1 zone safety thermostat triggered
ALL 21 Mix 1 Zone valve delivery probe fault
ALL 22 Mix 2 zone safety thermostat triggered
ALL 23 Mix 2 Zone valve delivery probe fault
ALL 24 S1 solar delivery probe fault
ALL 25 S2 solar exchanger probe fault (tank)
ALL 26 S3 2nd solar system delivery probe fault
ALL 27 Solar application coherence fault – hydraulic configu-
ration
ALL 29 Number of expansion boards connected fault
ALL 30 Return sensor fault
Type No. Description
ALL 31 Cascade delivery probe (SMC) fault
ALL 32 Three zone system configuration fault
ALL 35 Communication fault RS485 board
ALL 36 Number of boilers connected in cascade fault
ALL 45 Manual release performed more than 6 consecutive
times in the last hour
ALL 70 Cascade stop general fault
ALL 71 General fault with a boiler in the cascade
ALL 72 Delivery probe (SMC) disconnected error
ALL 80 Gas valve control circuit hardware fault
ALL 89 Gas valve control circuit hardware fault
ALL 98 Maximum number of software errors reached
ALL 99 Generic board software error
NOTE: If one of the faults listed above occurs, press button
T
to pause the boiler and contact Qualified Technical Personnel.
1.6 SIME remote control connection (optional
accessory)
The boiler is ready for connection to a SIME remote control. When
the remote control is connected or, alternatively, when a remote
supervision device is connected, the boiler display shows:
For set-up and use of the remote control, follow the instruc-
tions supplied with the device.
m
CAUTION
A Sime remote control and a remote supervision device
cannot be connected at the same time.

13
2 MAINTENANCE
2.1 Servicing
For the appliance to operate correctly and efficiently it is recom-
mended that the system manager calls upon the services of a
Professionally Qualified Technician to carry out
ANNUAL main-
tenance.
m
CAUTION
Maintenance must ONLY be carried out by qualified
professionals who follow the indications provided in
the INSTALLATION AND MAINTENANCE INSTRUC-
TIONS.
2.2 External cleaning
a
WARNING
– Should it be necessary to access the areas in the bot-
tom part of the appliance, make sure that the system
components and pipes are not hot (risk of burning).
– Before performing any maintenance, put on protec-
tive gloves.
2.2.1 Cleaning the case
When cleaning the cladding, use a cloth dampened with soap
and water or alcohol for stubborn marks.
d
DO NOT
Do not use abrasive products.
3 DISPOSAL
3.1 Disposal of the equipment (European Di-
rective 2012/19/EU)
Boilers and electrical and electronic appliances
used professionally or classified as profession-
al waste must not be disposed of as unsorted
municipal waste at the end of their life. In-
stead, they must be disposed of as per Direc-
tive 2012/19/EU and Italian Legislative Decree
49/2014. Please speak with your local retailer
regarding returning or replacing your appli-
ance, should your product be replaced by an-
other identical product. Your product has been
designed and manufactured in such a way as
to reduce its impact on the environment and
human health as much as possible. However,
it contains components which may be hazard-
ous if not disposed of correctly. Your role as
the product purchaser handling the appliance
at the end of its life is very important when it
comes to reducing the impact of waste on the
environment and human health, and promoting
recycling. The crossed-out wheeled bin sym-
bol found on your appliance, and shown here,
means that at the end of your product’s lifecy-
cle, it must not be disposed of with unsorted
municipal waste. Instead, it must be disposed
of, in accordance with the law, as electrical and
electronic waste. Individual countries may also
define specific rules on how to handle electrical
and electronic waste. Before disposing of your
appliance, please check the rules in force in
your country.
d
DO NOT
dispose of the product with urban waste.

14

15
DESCRIPTION OF THE APPLIANCE
TABLE OF CONTENTS
4 DESCRIPTION OF THE APPLIANCE 16
4.1 Characteristics ................................16
4.1.1 Operation............................ 16
4.1.2 Domestic Hot Water (DHW) ............. 17
4.2 Check and safety devices ........................17
4.3 Identification ..................................17
4.3.1 Technical Data Plate................... 18
4.4 Structure .....................................19
4.5 Technical features..............................20
4.6 Main water circuit ..............................21
4.7 Sensors ......................................22
4.8 Minimum water flow rate ........................22
4.9 Load losses ...................................22
4.10 Control panel ..................................23
4.11 Wiring diagram ................................24
4.11.1 RS 485 board......................... 25

16
4 DESCRIPTION OF THE APPLIANCE
4.1 Characteristics
ALU HE aluminium boilers generate heat through condensation
and are designed to heat rooms and produce domestic hot water,
if the system contains a storage tank. They are composed of:
– an aluminium body, with low water content and high exchange
surface, to maximise energy efficiency and heat yields
– a total pre-mix microflame burner in stainless steel that al-
lows high modulation ratios, combustion stability and low
emissions of pollutants (Class NOx = 6), to be achieved
– a variable speed fan required for modulation and air/gas mix-
ing
– a combustion circuit which can be "Type C" (sealed) or "Type
B" (open) with respect to the place where the boiler is in-
stalled, depending on the configuration of the combustion air
inlet adopted during installation
– a control panel which. if equipped with an external sensor,
allows the delivery temperature to be adjusted according to
the outdoor temperature (sliding temperature operation).
The boiler therefore provides only the heat the User actually
needs, avoiding energy being wasted and the associated costs.
If there are malfunctions or faults, the specific error codes are
displayed, which simplifies the work of Technical Service.
During planning solutions have been adopted to:
– constantly achieve the best air/gas mixture
– reduce heat dispersion
– reduce noise.
Sime ALU HE boilers can be installed as single units or in a cas-
cade composed of between two and eight appliances with the
same heating output.
When boilers are connected in a cascade, they communicate
ONLY with the master boiler, treating the cascade as a single
heat generator where:
Cascade output = Boiler output x no. of boilers installed
Sime ALU HE boilers can be connected to 0-10 V DC controls, to an
auxiliary sensor and to the
Sime Home or Sime Home Plus remote
controls. They can manage direct systems or direct systems and
two mixed systems (or two groups of mixed systems connect-
ed in parallel), if the optional kits "mix 1 kit-code 8092275" and
"mix 2 kit-code 8092276" are installed. A solar system can also
be installed using the “solar kit-code 8092277” and the “MOD-
BUS interface code 8092278” to communicate via MODBUS with
remote devices. All kits are optional accessories to be ordered
separately. After each stoppage, whether automatic or manual,
post-ventilation and post-circulation are performed. The system
should include an INAIL safety device 8101595, which is man-
datory for ITALY ONLY, and a plate heat exchanger or hydraulic
separator, depending on the system characteristics.
Sime ALU HE boilers also have the following functions:
– anti-freeze function, which is activated automatically if the
temperature of the water inside the boiler falls below the val-
ue set under “PAR 35” and if the outdoor temperature falls
below the value set under “PAR 36”
– antiblocking function for the pump and any diverter valve,
which is activated automatically every 24 hours if there have
been no requests for heat
– the chimney sweep function lasts 15 minutes and makes the
job of the qualified technician easier when measuring the pa-
rameters and combustion efficiency
–anti-legionella function when a storage tank is used
– automatic adjustment of the ignition output and minimum and
maximum heating output. The outputs are managed automat-
ically by the electronic circuit board to ensure maximum sys-
tem usage flexibility
–dispersal function, so that if the delivery probe detects a tem-
perature of 90°C, the fan runs until it falls to 89°C
–screed drying function, to keep the floor at a pre-set tempera-
ture profile with the help of the mixer valve
–"External sensor value correction" function.
4.1.1 Operation
When the general switch is activated the boiler is powered with
electricity. The blue bar (4) on the control panel lights up. The
symbols, "- -" message and the system pressure are shown cor-
rectly on the screen. To turn the boiler on or off press button T
then button Vto select "WINTER mode" or button Uto select
"SUMMER mode". The value of the delivery sensor detected at
that moment appears on the display.
m
CAUTION
When the display is not backlit (off), the first press on
each function button serves to backlight it (turn it on);
the second press to carry out the command.
When heat is requested from the systems or the storage tank,
if there is one, the control panel automatically carries out the
functional checks, and electrically powers the gas valve and igni-
tion transformer to turn on the flame. This is how automatic op-
eration of the boiler begins. When the request for heat is fulfilled
the flame goes out, but the fan and the circulation pump remain
in operation to carry out post-ventilation and post-circulation at
the end of which they stop and wait for the next request for heat.

17
4.1.2 Domestic Hot Water (DHW)
Domestic hot water can be produced if the system has a dhw
circuit with a storage tank. The dhw system can be created either
upstream or downstream of the water shut-off valve. The instal-
lation company is responsible for choosing and paying for all the
systems' components and devices.
m
CAUTION
The installation company is responsible for choosing
and paying for all the systems' components and de-
vices.
4.2 Check and safety devices
The ALU HE boilers are equipped with the following check and
safety devices:
– thermal safety thermostat 98°C with automatic reset
– system water pressure transducer
– delivery sensor (SM)
– return sensor (SR)
– exhaust sensor (SF)
– air pressure switch
– siphon pressure switch.
d
DO NOT
Do not commission or operate the appliance with safe-
ty devices which do not work or which have been tam-
pered with.
a
WARNING
Safety device may only be replaced by professional
qualified personnel using
Sime original spare parts.
4.3 Identification
The ALU HE boilers can be identified by means of:
1 Packaging label: this is located on the outside of the packag-
ing and provides a code, the serial number of the boiler and
the bar code
2 Technical Data Plate: this is located inside the front panel of
the boiler and provides the technical data, appliance perfor-
mance information and any other information required by
law in the country where the appliance will be used.
2
1
2
1
ALU HE


 















       
       

         
 

 











 
   
 
   
 
 
 
 
 
 
  


 


 

 

 
Fig. 4

18
4.3.1 Technical Data Plate
YEAR OF MANUFACTURE
SERIAL NUMBER
NAME
WATER CONTENT IN BOILER
CODE
APPLIANCE TYPE
MAX OPERATING TEMPERATURE
MIN USEFUL INPUT (50-30°C)
MIN USEFUL OUTPUT (80-60°C)
APPLIANCE CLASSIFICATION
TYPE OF GAS
SUPPLY PRESSURE
MIN HEAT INPUT
NOx CLASS
GAS COUNCIL NUMBER CODE (UK)
WRAS CERTIFICATION (UK)
ELECTRICAL PROTECTION DEGREE
N° PIN
TYPE OF GAS
CODE
APPLIANCE TYPE
MAX OPERATING TEMPERATURE
MIN USEFUL INPUT (50-30°C)
MIN USEFUL OUTPUT (80-60°C)
APPLIANCE CLASSIFICATION
TYPE OF GAS
SUPPLY PRESSURE
MIN HEAT INPUT
NOx CLASS
GAS COUNCIL NUMBER CODE (UK)
WRAS CERTIFICATION (UK)
ELECTRICAL PROTECTION DEGREE
N° PIN
MAX USEFUL OUTPUT (50-30°C)
MAX OPERATING PRESSURE
MAX USEFUL OUTPUT (80-60°C)
MAX HEAT INPUT
TYPE OF GAS
ELECTRICAL SUPPLY
MAXIMUM ABSORBED POWER
COUNTRY OF INTENDED INSTALLTION
GAS CHANGE
APPLIANCE CATEGORY
BOX TO BE MARKED
IF THE GAS IS CHANGED
YEAR OF MANUFACTURE
SERIAL NUMBER
NAME
WATER CONTENT IN BOILER
MAX USEFUL OUTPUT (50-30°C)
MAX OPERATING PRESSURE
MAX USEFUL OUTPUT (80-60°C)
MAX HEAT INPUT
ELECTRICAL SUPPLY
MAXIMUM ABSORBED POWER
COUNTRY OF INTENDED INSTALLTION
GAS CHANGE
APPLIANCE CATEGORY
BOX TO BE MARKED
IF THE GAS IS CHANGED
Fonderie SIME S.p.A.
Via Garbo, 27 - 37045 Legnago - VR (Italy) - Tel. [phone]
ALU PLUS HE 1100 8115781
9999999999
400 V 3N~ - 50 Hz - 2134W
2018
200,01000,0
91,00
85
NOx class 6
1312CS6203
IP X0D
1312
196,4980,0
MADE IN ITALY
CALDAIA
A CONDENSAZIONE -CONDENSINGBOILER - CALDERA DE CONDENSACION - CALDEIRA
A
CONDENSACAO - CHAUDIERE A CONDENSATION - CONDENSATIEKETEL -
GASBRENNWERTKESSEL
- ȂǽǻǿȊǺ ȉȋȃȇȋȁȄȎȉǿȉ - KONDENZACIJSKI KOTEL - PLYNOVÝ
KONDENZAþ1I KOTEL - CONDENSARE CAZAN - KOCIOL KONDENSACYJNY - KONDENZÁCIÓS
Q max = Q min =
T max =PMS =
P max 80-60°C = P min 80-60°C =
L
°C
kW
kW
kW
kW
PIN n.
n
n
n
n
P max 50-30°C = P min 50-30°C =
1053,0 kW 211,0 kWnn
bar6 0,6 MPa
G20 20 mbar
I2H
AT-ES-FR- G20 20 mbar (2 kPa) B23P
GB-GR-IT-PT
I2E
DE G20 20 mbar (2 kPa) B23P
I2E(S)
BE G20 20 mbar (2 kPa) B23P
Fonderie SIME S.p.A.
Legnago - VR (Italy) - Tel. [phone]
ALU HE 160 8115720
9999999999
230V~ - 50Hz - 230W
2018
32,0
160,0
18,00
85
NOx class 6
1312CS6214
IP X0D
1312
30,6
156,1
MADE IN ITALY
CALDAIA
A CONDENSAZIONE -CONDENSINGBOILER - CALDERA DE CONDENSACION - CALDEIRA
A
CONDENSACAO - CHAUDIERE A CONDENSATION - CONDENSATIEKETEL -
GASBRENNWERTKESSEL
- ȂǽǻǿȊǺ ȉȋȃȇȋȁȄȎȉǿȉ - KONDENZACIJSKI KOTEL - PLYNOVÝ
KONDENZAþ1I KOTEL - CONDENSARE CAZAN - KOCIOL KONDENSACYJNY - KONDENZÁCIÓS
Q max = Q min =
T max =PMS =
P max 80-60°C = P min 80-60°C =
L
°C
kW
kW
kW
kW
PIN n.
n
n
n
n
P max 50-30°C = P min 50-30°C =
168,2
kW 34,3 kWnn
G20 G31 G20 G31
160,0
kW
156,1
kW
168,2
kW
32,0 kW
30,6 kW
34,3 kW
6 bar 0,6 MPa
G31 37 mbar
G20 20 mbar
B23P-C43-C53-C63-C83II2H3P
AT-CH-CZ-ES-FR-GB-GR-IE- G20/G31 20/37 mbar
IT-LT-PT-RO-SI-SK
B23P-C43-C53-C63-C83I2H
HU G20 25 mbar (2,5 kPa)
B23P-C43-C53-C63-C83I2H
DK-EE-FI-LV-NL-NO-SE G20 20 mbar (2 kPa)
B23P-C43-C53-C63-C83I3P
BE-PL G31 37 mbar (3,7 kPa)
ALU 80-116-160-200 HE
GAS AND PRESSURE TEST
GAS AND PRESSURE TEST
ALU 240-280 HE
Fig. 5
m
CAUTION
Tampering with, removing or failing to display the identification plate or carrying out any other operation which does not allow
safe identification of the product or which may hinder installation and maintenance operations.

19
4.4 Structure
1
2
3
4
5
6
7
8
22
21
23
24
24
27
22
14
12
28
9
10
11
12
13
15
18 26251920 17
16
14
13
20
18
17
13
1 Front panel
2 Gas valve
3 Pressure transducer
4 Pressure gauge fitting
5 Return sensor (SR)
6 Return manifold
7 Boiler drain valve
8 Foot
9 Condensate siphon outlet
10 Condensate collection tank
11 Boiler return
12 Smoke outlet fitting
13 Combustion air inlet
14 Boiler body
15 Gas supply pipe
16 Boiler delivery
17 Delivery sensor
18 System delivery manifold
19 Top panel
20 Fan
21 Control panel
22 Min. gas pressure switch
23 Inspection and cleaning doors
24 Side panels
25 Ignition electrodes unit
26 Flame detection electrode
27 Burner
28 Electrical wiring terminal board
Fig. 6

20
4.5 Technical features
DESCRIPTION
ALU HE
80 116 160 200 240 280
CERTIFICATIONS
Country of intended installation AT - BE - CH - CY - CZ - DK - EE - ES - FI - FR - GB - GR - HU
IE - IT - LT - LV - NL - NO - PT - RO - SE - SI - SK
Fuel G20 / G31 G20
PIN number 1312CS6214
Category II2H3P I2H
Appliance classification B23P - C43 - C53 - C63 - C83
Class NO
x (*) 6 (< 56 mg/kWh)
HEATING PERFORMANCE
HEAT INPUT (**)
Nominal flow (Q
n max) kW 80 115,5 160 200 240 280
Minimum flow (Q
nw min) G20 / G31 kW 20 / 20 21 / 28,8 32 / 32 40 / 50 48 62
HEAT OUTPUT
Nominal (80-60°C) (P
n max) kW 77,8 112,3 156,1 195,7 234,4 275,4
Nominal (50-30°C) (P
n max) kW 83,8 122 168,2 208,6 251,8 295,3
Minimum G20 (80-60°C) (P
n min) kW 19,2 20,1 30,6 37,8 46,5 60,4
Minimum G20 (50-30°C) (P
n min) kW 21,6 22,8 34,3 42,5 52 66,0
Minimum G31 (80-60°C) (P
n min) kW 19,2 27,5 30,6 47,2 - -
Minimum G31 (50-30°C) (P
n min) kW 21,6 31,2 34,3 53,1 - -
EFFICIENCY
Max useful efficiency (80-60°C) % 97,3 97,2 97,5 97,8 97,7 98,3
Min useful efficiency (80-60°C) % 95,9 95,6 95,6 94,4 96,8 97,4
Max useful efficiency (50-30°C) % 104,7 105,6 105,1 104,3 104,9 105,4
Min useful efficiency (50-30°C) % 108,2 108,5 107,1 106,2 108,4 106,4
Useful efficiency at 30% of load (40-30°C) % 108,2 108,1 108,1 108,0 108,1 108,3
Losses after shutdown at 50°C W 251 276 301 327 352 377
ELECTRICAL SPECIFICATIONS
Power supply voltage V 230
Frequency Hz 50
Absorbed electrical power (Q
n max) W 211 263 230 360 408 438
Absorbed electrical power at (Q
n min)30% W 41 25 24 50 52 165
Absorbed electrical power in stand-by W666666
Electrical protection degree IP XOD
COMBUSTION DATA
Smoke temperature at Max/Min flow (80-
60°C) °C 66 / 57 65,1 / 56 61,9 / 58,1 69,6 / 58,1 70,7 / 58,3 69,2 / 61,5
Smoke temperature at Max/Min flow (50-
30°C) °C 51 / 32 46,4 / 30,4 52,3 / 34,5 50,6 / 31,0 50,2 / 30,3 49,6 / 35,9
Smoke flow Max/Min g/s 37,6 / 9,6 54,3 / 10,1 75,2 / 15,3 94,0 / 19,2 112,8 / 23 129,2 / 30
CO
2 at Max/Min flow rate (G20) % 9,3 / 9,1 9,3 / 9,1 9,3 / 9,1 9,3 / 9,1 9,3 / 9,1 9,5 / 9,0
CO
2 at Max/Min flow rate (G31) % 10,6 / 10,3 10,6 / 10,3 10,5 / 10,3 10,0 / 9,7 - -
NOx measured mg/kWh 50 47 48 40 33 37
NOZZLES  GAS
Gas consumption at Max/Min flow rate
(G20) m
3
/h 8,28 / 2,08 12,08 / 2,21 17,01 / 3,38 21,16 / 4,23 25,39 / 5,08 29,6 / 6,55
Gas consumption at Max/Min flow rate
(G31) kg/h 6.25 / 1,55 8,98 / 2,19 12,41 / 3,14 15,55 / 3,8 - -
Gas supply pressure (G20/G31) mbar 20 / 37 20 / 37 20 / 37 20 / 37 20 20
kPa 2 / 3,7 2 / 3,7 2 / 3,7 2 / 3,7 2 2
TEMPERATURE  PRESSURE
Max operating temperature (T max) °C 85
Heating adjustment range °C 20÷80
Min/Max operating pressure bar 0,8 / 6
kPa 80 / 600
Water content in boiler l 12,5 15,3 18,0 22,9 25,6 28,4
Loss of load water side T nom (20°C) mbar 65 80 80 90 90 100
Max. T at min./max. power °C 35 / 25 35 / 25 35 / 25 35 / 25 35 / 25 35 / 25
Water flow rate T 20°C m
3
/h 3,34 4,83 6,67 8,41 10,08 11,84
Water flow rate T 10°C m
3
/h 6,69 9,66 13,34 16,82 20,16 23,7
Total residual head (outlet + inlet) Pa 250 250 200 200 200 100
(*) NOx class according to UNI EN 15502-1:2015
(**) Heat input calculated using the lower heat output (Hi)
G20 Hi. 9.45 kW/m
3
(15°C, 1013 mbar) - G31 Hi. 12.87 kW/kg (15°C, 1013 mbar)
