How To Service and Maintain Your Simon DU2 LED Flashlight
Read the Entire Service and Maintenance Instructions Before you Start Servicing
Your High Performance DU2 LED Flashlight
These are the Supplies that You Will Need to Service Your DU2 Flashlight
Isopropyl Alcohol 90% or Stronger to Clean the Simon LED Flashlights
www.amazon.com/gp/product/B001B5JT8C
Cotton Swabs
http://www.amazon.com/Swisspers-Premium-Cotton-Plastic-Sticks/dp/B00028LZ0Y
White Cotton Rags
http://www.amazon.com/Cotton-Washcloths-Hand-Face-Towels-Pack-Washcloths/dp/B007JCHA6E
Micro Fiber Towels
http://www.amazon.com/Quickie-Original-490-24RM-Microfiber-24-Pack/dp/B005BGCI8K
Tool- Awl to Tighten the Chip Set Inside the Head Unit
http://www.amazon.com/Stanley-69-122-16-Inch-Handle-Scratch/dp/B00002X2FX
You most likely already have ALL the Supplies needed to Service your DU2 LED Flashlight Above around your
house. If Not we provided you links so that you can purchase them direct from Amazon.
These are the Most Popular Questions Asked.
Q.Why Do I Need to Service My DU2 Flashlight?
A.To Keep the DU2 in Top Performance
Q.How Will I Know When it is Time to Service the DU2 LED Flashlight?
A. We recommend in the first 20 hours of use after that the DU2 Will Tell You When it Needs to be Serviced, it will
start to Flicker and You will Try to Shake it to keep it on. This means that you Need to Service the DU2 flashlight. Most
People Service the Flashlight Before this Happens.
Step-By-Steps Instructions on How to Service Your DU2 LED Flashlight
1. Remove Rear Trigger Switch Tail Cap by Unscrewing the Rear of the Simon DU2
www.SimonFlashlights.net
2. Lightly DAB Your Cotton Swab into the 90% or Stronger Isopropyl Alcohol
3. Grab The Rear Trigger Switch and Look inside and you will see a Copper Nipple. Use Your Cotton
Swab to Clean Around the Copper Nipple and the End of the Copper Nipple.
4. Then Clean Inside the Rear Trigger Switch Threads and Wipe Clean Dry.
www.SimonFlashlights.net
5. Then Clean The Rear Battery Tube Threads and Wipe Dry.
6. Unscrew the Battery Tube from the Rear of the Head Unit and Clean the Threads and Wipe Dry.
7. Use New Cotton Swab to Clean the The Spring on the Rear Chip Set
www.SimonFlashlights.net
8. Clean the Threads on the Inside of the Rear of the Head Unit and Wipe Dry.
9. Unscrew The Lens Cap
10. Remove the Aluminuim Chrome Reflector Cone
www.SimonFlashlights.net
11. Inside the Head Unit You will See the Other Sides Chip Set Mounted with a Aluminum Ring with
Two Holes. Place Your AWL into the Hole and Tighten it Tight into the Head Unit.
12. Place The Chrome Aluminum Reflector Cone Back Inside the Front of the Head Unit and Make Sure
that you CENTER IT over The Diode and have a White Paper Gasket to Protect the Chip Set, Also Do
Not Pinch The Diode. (The Gasket Sometimes will be stuck on the Chip Set Already)
13. Hold the Chrome Reflector Cone Edge with Your Thumb While Wipping Clean the Interior of the
Chrome Reflector Cone with A Clean Soft Micro Fiber Cloth.
www.SimonFlashlights.net
14. Clean the Inside of the Lens with a Clean Micro Fiber Cloth Before your Screw on the Lens Cover
back on to Re-assemble.
15. Screw Back On The Lens Cover with the O-Ring and Lens and Make Sure When you are Re-
Assembeling The DU2 Flashlight that Everything Has Been Wiped Clean and DRY.
16. Screw together the DU2 Head unit with the Battery Tube. The Battery Tube ONLY fits one way so
you cannot make a mistake assembeling it. Make Sure Everything is 100% Dry
www.SimonFlashlights.net
17. Wiped Clean and DRY Both Ends of the Protected Simon Panasonic 18650 Rechargeable Battery.
18. Insert The Protected Simon Panasonic 18650 Lithium Ion Rechargeable Battery + Positive Side First
19. Screw on The Rear Trigger Switch and Turn On.
If You Have Any un-Answered Questions Please Contact Simon Flashlights
http://SimonFlashlights.net/contact/
Please Only Use the Recommended Simon Panasonic 18650 Batteries for Optimal Performance.
