SIMONINI FLYING Victor 2 User manual

Operators Manual
For all Versions of
Victor 2 / Victor 2 Plus / Victor 2 Super
SIMONINI FLYING SRL
Via Per Marano 4303 -41010 San Dalmazio di Serramazzoni (Mo)
P.I and C.F. 01557360367
Tel: [phone] Fax: [phone].
www.Simonini-flying.com
[e-mail]

THIS MANUAL IS THE INTELLECTUAL
PROPERTY OF SIMONINI FLYING SLR AND
MUST NOT BE REPRODUCED OR COPIED
BY ANY MEANS WITHOUT PRIOR
WRITTEN PERMISSION OF THE AUTHOR.
Important Notice
DANGER
THIS ENGINE, BY ITS DESIGN, MAY BE SUBJECT TO SUDDEN
STOPPAGE. ENGINE STOPPAGE CAN RESULT IN CRASH LANDINGS.
SUCH CRASH LANDINGS CAN LEAD TO SERIOUS INJURY OR DEATH
AND OR DAMAGE TO PROPERTY.
DO NOT FLY THE AIRCRAFT EQUIPPED WITH THIS ENGINE AT
LOCATIONS, AIRSPEEDS, ALTITUDES OR OTHER CIRCUMSTANCES
FROM WHICH A SUCCESSFUL ENGINE OFF LANDING CANNOT BE
MADE, AFTER SUDDEN ENGINE STOPPAGE, EITHER DELIBERATE OR
ACCIDENTAL OR INCIDENTAL.
WARNING
THIS ENGINE IS NOT A CERTIFICATED AIRCRAFT ENGINE. IT HAS NOT
RECEIVED ANY SAFETY OR DURABILITY TESTING NOR DOES IT
CONFIRM TO ANY AIRCRAFT STANDARDS.
IT IS FOR USE IN EXPERIMENTAL, UNCERTIFICATED AIRCRAFT AND
VEHICLES ONLY, WHERE ENGINE FAILURE WILL NOT COMPROMISE
SAFETY.
THE USER ASSUMES ALL RISK OF USE AND ACKNOWLEDGES BY HIS
USE THAT HE KNOWS THIS ENGINE IS LIABLE TO STOP SUDDENLY.

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
I
CONTENTS
SAFETY................................................................................................................................................1
1. DESCRIPTION OF ENGINE.....................................................................................................................3
1.1 EACH ENGINE IS SUPPLLED WITH:..................................................................................................3
1.2 VICTOR 2 PLUS DIMENSIONS..........................................................................................................3
1.3 EXPLODED VIEW OF VICTOR 2 / VICTOR 2 PLUS / Victor 2 Super ENGINE.......................................4
1.4 PARTS LIST FORSIMONIHI VICTOR 2 ENGINE .................................................................................5
2. FUEL AND OIL......................................................................................................................................6
2.1 Mixing procedure: .........................................................................................................................7
2.2 Oil Mixing Ratios............................................................................................................................7
3. GEARBOX OIL.......................................................................................................................................8
4. FUEL PUMP .........................................................................................................................................9
5. BREAKING IN PROCEDURE.................................................................................................................10
6. STARTING PROCEDURE......................................................................................................................11
7. NORMAL WORKING CONDITIONS......................................................................................................12
8. CARBURETOR....................................................................................................................................13
8.1 BING CARBURETOR EXPLODED VIEW...........................................................................................15
9. EXHAUST SYSTEM..............................................................................................................................16
10. REDUCTION GEARBOX.....................................................................................................................17
10.1 REDUCTION RATIOS AVAILABLE.................................................................................................17
10.2 Propeller Mass Moment of Inertia:............................................................................................17
10.3 Propeller Mass Balance and Pitch setting for Ground Adjust Propeller:......................................17
10.4 Procedure to fill gear box oil:.....................................................................................................19
10.5 Procedure to drain gear box oil:.................................................................................................19
10.6 Exploded View of Simonini Type “C” Gearbox............................................................................21
10.7 Part list for Simonini Type "C" Gear Box.....................................................................................22
11. IGNITION SYSTEM............................................................................................................................23
11.1 IGNITION CIRCUIT DIAGRAM......................................................................................................25
12. SPARK PLUGS...................................................................................................................................26

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
II
13. ELECTRICAL STARTER.......................................................................................................................27
13.1 Typical Electric Wiring Schematic for Starter Motor...................................................................28
14. BATTERY..........................................................................................................................................29
14.1 Power source:............................................................................................................................29
14.2 Relay for power Supply to starter:..............................................................................................29
14.3 Fuse:..........................................................................................................................................29
14.4 Typical wiring diagram...............................................................................................................30
15. INSTRUMENTS.................................................................................................................................31
15.1 Minimum instruments required with the engine:.......................................................................31
16. Special operation condition.............................................................................................................33
16.1 Engine mounted inside cowling:.................................................................................................33
17. LIQUID COOLING SYSTEM:...............................................................................................................34
18. AIR FILTERATION SYSTEM................................................................................................................35
19. MAINTENENCE SCHEDULES: ............................................................................................................36
19.1 Description of checks.................................................................................................................36
19.2 Initial Start-up Procedure:..........................................................................................................37
19.3 Storage procedure.....................................................................................................................38
20. CHECK FOR CARBON BUILD-UP AND RING CONDITION....................................................................38
21. GEARBOX MAINTENANCE................................................................................................................39
22. TORQUE DATA:................................................................................................................................40
23. WEAR LIMITS:..................................................................................................................................40
24. TECHNICAL DATA.............................................................................................................................41
24.1 Description................................................................................................................................41
24.2 Temperature..............................................................................................................................42
24.3 Ignition and Generator System ..................................................................................................43
24.4 FUEL SYSTEM:............................................................................................................................43
24.5 OTHER INFORMATION ...............................................................................................................44
24.6 STANDARD VERSION INCLUDE ..................................................................................................44
24.7 WEIGHT.....................................................................................................................................44
25. OPERATING LIMITATION..................................................................................................................45
26. WARRANTY CONDITION...................................................................................................................45

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
III
ANNEX ..................................................................................................................................................47
DECLARATION OF QUALITY................................................................................................................47
Record no 14: Aluminum Alloy LM 25................................................................................................48
DUCATI Regulator..............................................................................................................................49
DUCATI Alternator.............................................................................................................................50

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
1
SAFETY
Safety is paramount and all persons using this engine must be responsible for their own safety as
well as the safety of those in the vicinity and those who may be affected.
We include some important safety information and tips; however this list is neither complete nor
comprehensive.
GENERAL SAFETY POINTERS
1. Never mix fuel in an enclosed space or area where the fumes could be accidentally ignited or
may cause self-combustion.
2. Ensure that all controls work in the correct sense and that you know ON and OFF positions of
the throttle and ignition. Make sure that these are easily accessible when in the process of
starting the engine and that you can operate them in the correct sense instinetive1y and
immediately.
3. Ensure that no fuel can be spilled on to the hot exhaust or hot engine parts. Use only safety
approved fuel containers and never transport fuel in an unsafe manner.
4. Do not refuel the aircraft or vehicle with engine running.
5. Check all engine mounts and frames regularly as well as all the drive components, fuel lines,
wiring and fuel and air filters.
6. Check for fuel contamination, air vents and exhausts. Protect engine while it is not in use from
any Contamination entering fuel or carburetor system.
7. Ensure that you remove all storage protection before starting the engine.
8. Maintain your engine in top condition and assume it is going STOP running at any time.
Ensure that you have a way out to safety in event of unexpected failure.
9. Never run the engine on the ground with the propeller turning unless you are doing so in a
designated engine run up area and can observe anyone or anything entering the danger area.

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
2
10. If Starting by hand cranking the propeller, have an observer who is well briefed and can act
as a safety officer. Ensure Aircraft is suitably restrained.
11. Never leave your aircraft with the engine running. You may be held responsible if the aircraft
causes an accident even If you are not in the cockpit.
12. Always maintain the engine / aircraft log and enter any unusual engine behavior. Do not fly
until the problem has been corrected and the corrective action recorded in the logbook.

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
3
1. DESCRIPTION OF ENGINE
1.1 EACH ENGINE IS SUPPLLED WITH:
Bing carburetors (BING 54 36mm for Victor 2 and Victor 2Plus, BING 54 38mm for Victor2Super), air
filters, fuel pump, exhaust systems, electric starter, reduction gear type “C” with elastic joint on primary
gear, system to charge battery in flight.
1.2 VICTOR 2, VICTOR2PLUS AND VICTOR2SUPER ENGINES DIMENSIONS

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
4
1.3 EXPLODED VIEW OF VICTOR 2 / VICTOR 2 PLUS / VICTOR 2 SUPER ENGINE
Exploded view of Victor 2 engines. Part list as numbered items.

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
5
1.4 PARTS OF SIMONINI VICTOR 2 / VICTOR 2 PLUS / VICTOR 2 SUPER ENGINES
PART# DESCRIPTION QUANTITY
1BOLTS FOR EXHAUST MANIFOLD x4 4
2EXHAUST MANIFOLD x 2 2
3EXHAUST MANIFOLD GASKET x 2 2
4CYLINDER BOTTOM GASKET x2 2
5 CYLINDER x2 2
6VYTON 0 RING x 2 OUTER 2 2
7STUD FOR CYLINDER HEAD, 6 FOR EACH CYLINDER 12
8CYLINDER HEAD x 2 2
9CYLINDER HEAD WASHER, 6 FOR EACH CYLINDER 12
10 CAP NUTS FOR CYLINDER HEAD, 6 FOR EACH CYLINDER 12
11 VYTON 0 RING x 2 INNER 2
12 WATER OUTLETS TOP AND BOTTOM x 4 4
13 HOSE CLIPS FOR WATER OUTLET AND HOSE PIPE BENDS x10 10
14 HEAT DISSIPATER TOP I BOTTOM 1
15 HOSE PIPE HEAT DISSIPATOR TO WATER PUMP 1
16 8MM. BOLT TO HOLD WATER PUMP POSITION 1
17 WATER PUMP 1
18 ENGINE COVER PLATE, MAG END 1
19 12 MM. BOLT TO HOLD MAGNETO 1
20 6 MM. SCREWS TO HOLD ENGINE COVER PLATE 6
21 NUT TO POSITION WATER PUMP 1
22 HOSE PIPES WITH 90 DEG. BEND FROM CYLINDER HEADS TO HEAT
DISSIPATERS x4 4
23 WATER PUMP BELT 1
24 FLAT WASHER FOR WATER PUMP 1
25 WATER PUMP BELT PULLEY 1
26 8 MM. BOLT 1
27 WASHER 8MM. 1
28 ENGINE MAG END CASING 1
29 BOLT 8MM. 1
30 GASKET INLET AT REED VALVES x 2 2
31 REED VALVES x 2 2
32 RUBBER FLANGE TO HOLD CARBURETORS x 2 2
33 HOSE CLIPS TO HOLD CARBURETORS x 2 2
34 CARBUREITORS x 2 2
35 SPRING WASHERS FOR CARBURETOR BOLTS x 12 12
36 CARBURETOR BOLTS 6 MM x 12 12
37 BREATHER TUBE FOR CARBURETORS x 2 2
38 HOSE CLAMPS x 2 FOR AIR FILTERS 2
39 A IR FIL1ERS x 2 2
40 SPRING WASHERS FOR CRANKCASE 8mm 20
41 CRANKCASE 1
42 WASHER FOR DEPRESSION OUTLET FROM CRANKCASE 1

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
6
43 DEPRESSION OUTLET FOR FUEL PUMP 1
44 NUT FOR ELECTRIC STARTER x 2 2
45 WASHER FOR ELECTRIC STARTER x 2 2
46 SPRING WASHER FOR ELECTRIC STARTER x 2 2
47 BOLT FOR ELECTRIC STARTER x2 2
48 ELECTRIC STARTER 1
49 PISTON ASSEMBLY 2 2
50 CONNECTING ROD ASSEMBLY x 2 2
51 OIL SEAL 4
52 CIRCLIPS FOR Oil SEALS 7
53 BEARINGS 2
54 CONROD PIN 2
55 CRANKSHAFT WITH WOODRUFF KEY HOUSING SHAFT 2
56 CRANKSHAFT WITH MALE SPLINE 1
57 BEARING 2
58 CRANKSHAFT WITH FEMALE SPLINE 1
59 WOODRUFF KEY 1
2. FUEL AND OIL
The VICTOR 2 / VICTOR 2 PLUS / Victor 2 Super engine uses unleaded or leaded petrol at
least 87 octane rating. The engine requires the petrol to be premixed with two-stroke oil.
STOP: Do not run the engine without ensuring that it is correctly loaded (e.g. propeller is
mounted).
Fuel contamination can be a major cause of engine failure. Ensure that your fuel container is
clean inside before you use it to fill up with fuel or oil.
Filter all fuel that goes into the fuel container. Also use a filter when transferring fuel from fuel
container into the aircraft tanks. The Victor 2 / Victor 2 Plus / Victor 2 Super engine is designed
to run on unleaded petrol or leaded petrol or avgas mixed with 2 Semi-synthetic Oil.
The Oil to be premixed with fuel must meet or exceed the specifications API, TC, JASO, FC.
It is recommended only to use a semi-synthetic 2-stroke oil like Bardahl or MixoilSynt Api or
equivalent. Use of Semi-Synthetic Oil pre-mixed in the petrol / avgas will greatly reduce the
buildup of carbon deposits in the cylinder heads and pistons. This will increase your service
intervals.

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
7
2.1 MIXING PROCEDURE:
Use a clean container of known volume.
Pour Oil into container.
Pour Fuel into the can using a fine mesh filters.
Close container cap firmly and shake container for a few moments so that the oil and fuel are
mixed properly.
2.2 OIL MIXING RATIOS
Type of fuel Fuel Qty.%age of oil Oil Qty.Type of fuel Fuel Qty.%age of oil Oil Qty.
Unleaded 10 Lit. 3% 300ml. Leaded/Avgas 10 Lit. 2.5% 250ml.
15 Lit. 3% 450ml. 15 Lit. 2.5% 375ml.
20 Lit. 3% 600ml. 20 Lit. 2.5% 500ml.
25 Lit. 3% 750ml. 25 Lit. 2.5% 625ml.
30 Lit. 3% 900ml. 30 Lit. 2.5% 750ml.
33.3Lit. 3% 1lit. 40 Lit. 2.5% 1lit.

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
8
3. GEARBOX OIL
Reduction Gearbox Oil in the Simonini Type "C" reduction gearbox. Recommended Oil is
9OWX/140EP. The quantity required to fill the gearbox is 170cc with gear box upright and
225cc with gear box down.
Warning: Do not run the engine without sufficient oil in the Gear Box.
On the side of the Gear Box there are two Allen Screws which are used to inspect and indicate
the level of oil in the gear box.
It is always the lower of the 2 screws that indicates maximum oil level. The lower Allen screw
can be carefully opened to check that the oil leve1 is sufficient. Do not over fill above this level.
When the instillation requires the gear box to be fitted with the propeller shaft below the
crankshaft, the oil filler cap and the oil drain plug are interchanged.
Max Oil Level 177cc
Gear Box UP
Max Oil Level 225cc
Gear Box Down

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
9
Replace the Gearbox oil after the first 10 hours of use. The next change of Gearbox Oil is at 100
hours of use or once every 12 months, whichever comes first.
Stop: Ensure before every flight that you have sufficient oil in the gearbox.
4. FUEL PUMP
The Victor 2 / Victor 2 Plus /Victor 2 Super engine comes equipped with a Mikuni Membrane
Pump. This is a pneumatic pump operated by the pressure pulses from the crankcase of the
engine.
Install the pump 3 -4 cm higher than the crankcase pressure outlet. This will prevent a build-up
of fuel / oil mix in the lower compartment of the fuel pump, which in turn may lead to less
efficiency.
The length of the tube, which connects the engine crankcase depression to the fuel pump, should
be as short as possible, ideally less than 15 cm and not more than 30 cm long.
If your aircraft fuel tank is located more than 50/60 cm below the carburetor and fuel pump,
install an electric pump near the fuel tank. This pump will help push the fuel up to the membrane
pump and prevent vapor locks pump subsequent engine failures. Please follow the fitting
schedule of the electric pump.
Stop: The maximum fuel pressure exerted by the electric fuel pump should not exceed 0.3 bar
(4.35 psi).
When fitting an electric booster fuel pump ensure that there is fuel filter installed in line before
the pump. This will prevent the electric pump from clogging up with foreign material, which
may result in fuel starvation and resultant engine stoppage.
The electric booster fuel pump must be of the type where it allows fuel to pass through even
when it is not working.

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
10
5. BREAKING IN PROCEDURE
EACH SIMONINI VICTOR 2 / VICTOR 2 PLUS / VICTOR 2 SUPER ENGINE IS
ASSEMBLED AND RUN IN AT THE FACTORY.
EACH ENGINE IS SUBJECTED TO A DYNAMIC TEST. THE ENGINE IS
SECURELY MOUNTED ON A TEST BENCH AND A SUITABLE PROPELLER
INSTALLED ON IT.
THE ENGINE IS STARTED AND KEPT RUNNING FOR UP TO 4 HOURS AT
VARIABLE SPEEDS. TEMPERATURES AND POWER OUTPUTS ARE
REGULARLY CHECKED WHILE THE ENGINE IS BEING RUN.
THE CUSTOMER/USER IS NOT REQUIRED TO DO ANY RUNNING OR
BREAKING IN PROCEDURES ON THE ENGINE.
THE CARBURETORS ARE SET AT THE FACTORY FOR THE IDEAL
SETTINGS.
WHEN THE ENGINE IS MOUNTED ON YOUR AIRCRAFT, ENSURE THAT
BOTH CARBURETOR SETTINGS ARE EQUAL WHEN INSTALLING THE
THROTTLE AND CHOKE OPERATING CABLES.
Example of electric fuel pump that may be
used as a Booster pump

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
11
ADJUST THE CARBURETOR SLIDES UNTIL YOU GET AN 8 MM GAP UNDER
THE SLIDES WHEN VISIBLE FROM THE AIR FILTER SIDE.
TURN THE CARBURETOR AIRSCREWS FULLY CLOSE AND THEN UNSCREW
THEM BY 1 TO 1. 5TURNS.
THE ENGINE SHOULD BE RUNNING AT FULL OPEN THROTTLE WITH
6500RPM. IN THE CASE OF MAX. RPM. IS NOT DEVELOPED, CHECK
PROPELLER PITCH/SIZE AND MAIN JET SIZE.
6. STARTING PROCEDURE
NOTE: ALL SIMONINI ENGINES ARE RUN IN AT THE FACTORY AFTER ASSEMBLY.
Ensure that the engine is fitted securely to the aircraft. All electric concoctions must be checked
to be correct. All fuel lines must be securely fitted.
Stop: Ensure that there is sufficient fuel and oil in the fuel tank and enough oil in the gearbox.
Insufficient fuel and oil will cause the engine not to Start.
Ensure that there is sufficient coolant in the radiator. Insufficient coolant will cause the engine to
overheat in a matter of seconds and thereafter cause seizure of the pistons and resultant
catastrophic failure.
With the engine cold, Open fully chokes on the Bing Carburetors. Keep throttle at the idle
position.
Ensure that ignition switches are ON and that you can instantly switch them off if required.
Ensure that the aircraft brakes are on. If no brakes, ensure you have chocks under the wheels to
stop the aircraft from rolling away unintentionally.
Ensure that there is nobody near the Propeller and that the slipstream not causes damage to any
other aircraft or persons or property.

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
12
Engage electric starter. As soon as the engine fires, open throttle so the engine runs at slightly
over 2000/2200 rpm.
Ensure that the starter motor is disengaged from the engine. Do not run the Starter motor for
more than 5 seconds at a time.
Once the engine fires, within 10 seconds close the Chokes and the engine should be running
smoothly.
Once the engine is running for about 2 minutes, increase the RPM to 3800 -4000. Check
exhausts Gas temperatures on both cylinders. The difference should not exceed 20 ° C.
Warm up the engine until the water temperature reaches 50 ° C.
Now the engine should be ready for flight.
7. NORMAL WORKING CONDITIONS
It is recommended to use as much as gas your aircraft needs, it depends on your requirements
and as occasion may require. Reach height as soon as possible, above all if you are flying with a
delta motor.
Do not exceed maximum 6500 RPM. Do not run the engine in the climb out at Full Open
Throttle for more than 3 minutes.
Idling rpm should be 2000 rpm. Less than this may cause unnecessary vibrations. Higher idling
rpm will cause a reduction in the fuel /air mixture enrichment in the starting circuit of the
carburetor and may make cold engine start-ups difficult.
Before shut down,the engine should be run until any heat build-up from previous high power
settings (e.g. taxi back to hangar) has dissipated. Run the engine at 3000 rpm for 2 minutes and
then at 2000 rpm or smooth idle speed for a short while.
Do not idle for prolonged periods (e.g. holding point checks) as the normal rich conditions at this
carburetor setting may cause high carbon deposits on the spark plugs and piston rings causing
fouling. At low revolutions, the vibrations are high and the loads on the propeller, gearbox, and
drive train and should be avoided for longevity of the engine.

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
13
8. CARBURETOR
The Victor 2/ Victor 2 Plus / Victor 2 Super engine is equipped with 2 Bing Double Float
Carburetors. The Bing Carburetor is a piston type carburetor with float Chamber.
The following methods and combinations can adjust the Carburetor.
1. By Main Jet /Idle Jet / Needle Jet of various sizes.
2 .The Jet Needle size and position can also be varied.
3 .The Air / Fuel Mixture screw, Carburetor piston stop height can be changed.
When anyone of the above components or settings is changed, it affects the others so that other
small adjustments may be required.
Each Carburetor must be fitted with the slide axis at right angles in relation to the crankshaft
axis,both from the top and the intake side,to ensure equal fuel distribution to both cylinders.

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
14
When you receive the engine from Simonini Flying, the engine has been run in and the
carburetor settings checked.
NOTE: The Simonini Factory is at 600 meters above Mean Sea Level; thus when the engine is
run in at the Factory, it is set to produce maximum power at that altitude. If you are to operate
the engine at a very different altitude, you may need to retune the Carburetor mixture settings to
produce optimum power.
Stop: When you attach the throttle cable and choke cables, please ensure that you have both the
carburetor slides moving exactly equally up and down in unison. If not, it will cause the engine
to run rough or worse malfunction. The throttle control mechanism must enable the carburetor
slides to attain their full open position.
Ensure that aircraft movement or controls movement does not affect the movement of throttle
and choke cables. This may cause the throttle settings to change inadvertently.
Ensure that Air filters and Exhausts and Radiators are installed in place before starting the
engine. They must be in place to produce proper carburetion for the engine.
Special operating conditions or extreme altitude and or climatic changes will require different
Jetting. Contact your dealer for the correct carburetor jets setting. The Victor 2 engine/ Victor 2
Plus / Victor 2 Super engine is fitted With "Reed Valves" between the Carburetors and the
crankcase. These valves add to the efficiency of the engine in controlling carburetion and fuel
economy. The Reed Valves require changing of the VALVES after 400 hours of use.

Simonini Flying SRL
Victor 2 / Victor 2 Plus / Victor 2 Super Operator s Manual
15
8.1 BING CARBURETOR EXPLODED VIEW
