Simpli Home AXCBAN-03W User manual

Banting / Devlin / Argyle
Mid Century Wide Console Table
Model # AXCBAN-03W
TM
TM
1

2
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
simpli-home.com/product-registration
Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
Activate your 1-year warranty
Automatic entry to win a $500 gift certificate
Earn instant rewards and save
ü
ü
ü

3
Review your product and collect rewards!
Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Share photos and get your cash back!
Send us images or share them on social and qualify for instant
rewards. You may even receive store credit on your entire purchase!
simpli-home.com/share-images

4
For Fastest Customer Service:
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order information and issue.
6. Submit form.
7. A customer service associate will contact you.
Other ways to contact us…
Visit Us
Visit our site directly at
www.simpli-home.com
Email Us
[email protected]
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.

Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during Assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of Assembly.
Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
5

This furniture is designed for indoor use.
Damage to furniture can come from temperature changes in relative humidity (RH)
in our homes. Humid air oxidizes metal which results in rusting, corrosion, tarnishing
and roughness. Wood absorbs water as relative humidity rises and falls, and in doing
so it swells and shrinks.
To protect against the humidity effect, the metal is powder coated. The powder coat
layer protects the metal from oxidizing, corrosion, tarnishing and scratching and
keeps it looking good for years to come. The wood is sealed and lacquered to
protect against humidity.
To help protect your furniture, follow these steps:
·Use a humidifier, preferably one with an automatic control system that can
sense the humidity level and adjust itself accordingly
·Dust with soft dry cloth
·Wipe up spills promptly
·Clean with a dry cloth
·Do not use abrasive cleaners, chemical solvents, strong detergents, cleaners
with bleach, and furniture polish
·Use soft felt base coasters, placemats to help prevent scratches
·Keep furniture out of direct sunlight, which can cause cracking or roughness
on the protective layer
·If it can be avoided, do not put furniture near heating vents
·Keep the furniture 3 to 4 inches away from the wall, giving heat and air space to
circulate.
Care & Maintenance
6

.A
TOP
QTY 1
.BL .BR .C
.D.E.F
RIGHT LEG
QTY 1
LEFT LEG
QTY 1
LEG BACK CONNECTOR
QTY 1
LEG FRONT CONNECTOR
QTY 1 LEG LOWER CONNECTOR
QTY 1 LEG SUPPORTER QTY 2
Front /
Avant
Front /
Avant
Front /
Avant
UpSide/Vertical
Up Side / Vertical
UpSide/Vertical
Up Side / Vertical
UpSide/Vertical
Up Side / Vertical
Front /
Avant
Part Description
7
Model # AXCBAN-03WPre-Assembly Information

.1.2
Required -
Flathead screwdriver
Phillips screwdriver
Not Included
ALLEN KEY BOLT
M6 x 15 mm
QTY 18
LOCK WASHER
Ø10 / Ø6.5 x 1.5 mm
QTY 18
WASHER
Ø16 / Ø6.5 x 1.5 mm
QTY 22
PHILLIPS SCREW ROUND HEAD
M4 X 15mm
QTY 4
ALLEN KEY
QTY 1
.3.4
.5
Hardware Description
8
Model # AXCBAN-03WPre-Assembly Information

A
BL
BR
F
F
C
D
E
Front /
Avant
Front /
Avant
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
Up Side / Vertical
9
Model # AXCBAN-03WComponents - Key Diagram

Step 1
E
D
C
BR
5
1
2
3
5123
UpSide/Vertical
Front / Avant
UpSide/Vertical
UpSide/Vertical
Front / Avant
Up Side / Vertical
Front /
Avant
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
1. Align Parts C , D and E to Right Leg BR .
2. Use one Bolt 1 , one Lock Washer 2
and one Washer 3 to secure each part
C , D , E with BR .
3. Use Allen Key 5 to tighten Bolts.
Do not over-tighten.
10
Model # AXCBAN-03WAssembly

Step 2
Front / Avant
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
E
C
D
BR
BL
Front / Avant
Up Side / Vertical
E
BR
C
D
BL
3215
3215
1. Repeat Step 1 for Left Leg BL .
11
Model # AXCBAN-03WAssembly

Step 3
Step 4
BL
BR
C
D
E
BL
BR
E
C
D
F
F
BL
BR
E
C
D
F
F3
2
1
5
1. Align Leg Supporters F to Legs BL , BR .
1. Use Allen Key 5 to tighten Bolts.
2. Use four Bolts 1 , four Lock Washers 2 and four Washers 3 to secure each part
F with BL , BR .
3. Use Allen Key 5 to tighten Bolts.
5
12
Model # AXCBAN-03WAssembly

Step 5
5
1
2
3
1. Attach the assembled metal frame to Top A .
2. Use four Bolts 1 , four Lock Washers 2
and four Washers 3 to secure metal frame
and Top A .
3. Use Allen Key 5 to tighten Bolts.
4. Use four Phillips Screws Round Head 4 and four
Washers 3 to secure Top A and metal frame.
5. Use Phillips screwdriver to snugly tighten Screws.
A
A
4
3
A
F
13
Model # AXCBAN-03WAssembly

Step 6
Note: Levelers on bottom of legs can be adjusted if floor is uneven.
14
