ACADIAN / NORMANDY / BRUNSWICK
SINGLE DOOR WALL CABINET
MODEL # AXCBSACA03-WH
/171
TM
TM
SI
M P
HOME®
LIFE BY DESIG N

/172
TM
TM
SI
M P
HOME®
LIFE BY DESIG N
Questions, problems, assembly help, missing parts?
No need to return the product, we will gladly help and ship your
replacement parts free of charge
Please call Customer Service at 1-866-518-0120 ext. 262
Monday to Friday between 9 am –4 pm EST
or go to
www.simpli-home.com/parts request
In order to assist you in a timely manner, please have the following
information ready:
Model # _________________Part Number or Letter_____________________
Purchased at ____________Date of Purchase _________________________
If you wish to return the product, please contact the retailer where the
product was purchased.

/173
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
SAFETY INFORMATION

/174
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger, but lose moisture more
slowly than other finishes.
To help protect your wood furniture, take these steps:
·Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly. Don't over-humidify; that can damage wood
by causing it to expand and contract.
·Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp.
·If you can avoid it, don't put furniture near heating vents. If you must, keep the piece 3
to 4 inches away from the wall, giving the heat and air space to circulate.
·Dust with soft dry cloth.
·Do not use liquid or aerosol products.
·To avoid marking, do not place rubber on surface (foot pads, etc.)
·For soil build-up, wipe with damp cloth & dry.
·Do not use abrasive cleaners.
CARE and MAINTENANCE
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.

PRE-ASSEMBLY INFORMATION MODEL # AXCBSACA03-WH
/175
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PART DESCRIPTION
TOP
QTY 1 LEFT SIDE
QTY 1 RIGHT SIDE QTY 1
BOTTOM SHELF
QTY 1 MIDDLE SHELF
QTY 1
SHELF
QTY 1
BOTTOM BACK PANEL
QTY 1 TOP BACK PANEL
QTY 1
BACK BAR
QTY 1
Front /
Avant
Front /
Avant
.A.BL .BR
.C.D.E
.F.G.H
.I.J
Front /
Avant
Front /
Avant
DOOR
QTY 1
WALL MOUNT BAR
QTY 1

PRE-ASSEMBLY INFORMATION MODEL # AXCBSACA03-WH
/176
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
HARDWARE DESCRIPTION
.1.2.3
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
.4.5.6
.7.8.9
CAM LOCK PIN
CAM LOCK
QTY 12 SETS
WOOD DOWEL
Ø8 X 30mm
QTY 14 HINGE
QTY 2
MAGNET AND PLATE
QTY 1 SET
HANDLE
M4 X 25 mm
QTY 1 SET
SHELF SUPPORT
QTY 4
WALL ANCHOR
QTY 2
.10
PHILLIPS SCREW
M4 X 50mm
QTY 3
PHILLIPS SCREW
M3 X 15mm
QTY 12
PHILLIPS SCREW ROUND HEAD
M4 X 15mm
QTY 2

COMPONENTS-KEY DIAGRAM MODEL # AXCBSACA03-WH
/177
E
C
D
G
BR
Front /
Avant
Front /
Avant
Front /
Avant
A
J
I
F
H
BL

/178
STEP-1
ASSEMBLY MODEL # AXCBSACA03-WH
P
X
1. Attach Cam Lock Pins 1 into pre-drilled holes on parts A , BL , BR .
2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten.
3. Insert one Dowel 2 into guide holes on each Side BL , BR .
4. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
5.AttachMagnet4usingPhillipsScrews9intopre-drilledholes onLeftSideBL.
6. Use Phillips screwdriver to secure screws.Do not over-tighten.
Front /
Avant
1
1
1
Front /
Avant
Front /
Avant
1
2
A
BL
BR
2
9
4
2

/179
STEP-2
ASSEMBLY MODEL # AXCBSACA03-WH
1. Insert Dowels 2 into guide holes on each part C , D , I .
2. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
2
2
2
2
2
2
2
Front /
Avant
I
C
D

/1710
STEP-3
ASSEMBLY MODEL # AXCBSACA03-WH
Front / Avant
Front / Avant
1
1. Align Wood Dowels and Cam Lock Pins with guide holes and attach parts C , D , I
to Left Side BL .
2. Insert two Cam Locks 1 into guide holes on parts C , D .
3. Use Phillips screwdriver to secure Cam Locks.
I
BL
D
C
Front / Avant
Front / Avant
D
C
BL
I
1
1

/1711
STEP-4
ASSEMBLY MODEL # AXCBSACA03-WH
Front / Avant
Front / Avant
Front / Avant Front / Avant
BL
BL
BR
BR
I
I
C
C
D
D
1
1. Repeat Step-3 for the Right Side BR .

/1712
STEP-5
ASSEMBLY MODEL # AXCBSACA03-WH
1.SlideBackPanelsF,GfirmlyintoslotsonSidesBL,BRandBottomShelfC.
STEP-6
1. Align Wood Dowels and Cam Lock Pins with guide holes and attach Top A to parts
BL , BR .
2. Insert two Cam Locks 1 into guide holes on each parts BL , BR .
3. Use Phillips screwdriver to secure Cam Locks.
Warning Label
F
G
BR
Front /
Avant
C
BL
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
BL
BR
A
A
BL
BR
1

/1713
STEP-7
ASSEMBLY MODEL # AXCBSACA03-WH
1.UsePhillipsScrewsRoundHead8toattachBackPanelsF,Gthroughguideholes.
2.UsePhillipsscrewdrivertosecureScrews.Donotover-tighten.
STEP-8
1.UsefourShelfSupports6forCabinetShelfGindesiredlocation.
Warning Label
F
G8
Front /
Avant
A
Front /
Avant
E
6

/1714
STEP-9
ASSEMBLY MODEL # AXCBSACA03-WH
1.AttachHinge3toDoorHusingPhillipsScrews9intopre-drilledholesonDoorH.
2.AttachMagnetPlate4totopcornerofDoorHusingPhillipsScrews9into
pre-drilledholesonDoorH.
3. UsePhillipsscrewdrivertoattachHandle5toDoorH.
STEP-10
1.AttachHingeonDoorHtoRightSideBRusingPhillipsScrews9intopre-drilled
holesonRightSideBR.
2. Use Phillips screwdriver to secure screws. Donotover-tighten.
39
4
9
H
H
BR
9
5

/1715
ASSEMBLY MODEL # AXCBSACA03-WH
c
b
a
1. Determine the location for the unit on the wall. The Top A should be
approximately 1 ¼” above the top of the Wall Mount Bar J when mounted.
2. Place the Wall Mount Bar J at the predetermined height. Use a level to ensure
that it is straight. The flat side of Wall Mount Bar J should face outward away
from the wall. Hole (b) should align with your studs. Carefully mark the position of
each hole using the tip of the Phillips Screw 7 .
3. Install four Wall Anchors 10 to positions (a),(c) using a Phillips screwdriver.
Anchors are self-tapping and do not need pre-drilled holes.
4. Use your drill to create 1 hole 0.15” diameter x 2” deep at position (b) .
STEP-11 - Positioning
STEP-12 - Attach Wall Mount Bar to Wall
1.ScrewonePhillipScrew7throughthe
raisedsideoftheWallMountBarJatposition(b).
2.ScrewfourPhillipScrews7throughthe
raisedsideoftheWallMountBarJatpositions
(a),(c)whereWallAnchors10wereplaced.
3.Tightenallscrews.Donotovertighten.
a
bc
10
J
7
7
7
J

/1716
STEP-13
ASSEMBLY MODEL # AXCBSACA03-WH
1. Align the top of the Wall Mount Bar J with the bottom of the angled bracket
on the back of the Cabinet.
2. Gently slide the Cabinet down on to the Wall Mount Bar J .
J
JJ

/1717
TM
TM
SI
M P
HOME®
LIFE BY DESIG N
WARRANTY
Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max
product. These products have been made to demanding, high-quality
standards and are guaranteed for domestic use against manufacturing
faults for a period of 12 months from the date of purchase. This warranty
does not affect your statutory rights.
In case of any malfunction of your product (failure, missing parts, etc.)
please contact us at our toll free service line at 1-866-518-0120 ext. 262
from 9 am to 4 pm, Monday to Friday, Eastern Standard Time or by email at
[email protected].
We reserve the right to repair or replace the defective product, at its
discretion.
This product is guaranteed for 12 months if used for normal purposes.
Any warranty is invalid if the product has been overloaded or subject to
neglect, improper use or an attempted repair by other than an authorized
agent. Heavy-duty or daily professional/commercial usage are not
guaranteed.
Due to continuous product improvement, we reserve the right to change
the product specifications without prior notice.
