Steelcase Elective Elements On-Module End Panel User manual

Page 1 of 8
939500242 Rev D
Elective Elements - On-Module and Off-Module End Panel
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
© 2006 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
#2 Square
Drive Bit
#2 Phillips
Drive Bit
Components
Off-Module On-Module
End Panel Assembly End Panel Assembly
Filler Filler
Bracket-Filler
Bracket-Mounting
Off-Module End Panel On-Module End Panel

On-Module End Panel
1. Insert end panel bracket into
slots in wall panel.
2. Position end panel to bracket.
3. Align security bracket with end
panel bracket and end panel (using
holes provided), then secure with
(3) screws.
Page 2 of 8
939500242 Rev D
SECURITY
BRACKET
3
1
2

Page 3 of 8
939500242 Rev D
CONNECTING
BOLT
5a
5b
4
4. Insert (3) connecting
bolts into the holes on
underside of top.
5. Flip top over (5a) and
place onto the on-module
cantilever and end panel
(5b). Make sure the
connecting bolts are
inserted into the
corresponding holes.

Page 4 of 8
939500242 Rev D
6a
Underside
of Worksurface
ARROW POINTING IN DIRECTION OF
THE CONNECTING BOLT HEAD
CAM LOCK
6a
8
6. Insert (3) cam locks into the holes on the end
panel (6a), making sure the arrow on the cam
lock is pointed toward the connecting bolt (6b).
Turn cam lock with screwdriver 1/4 turn to secure
connecting bolt (6c).
7. Attach worksurface to on-module cantilever
using four (4) bolts.
8. Adjust glides as needed.
6c
6b
7

Page 5 of 8
939500242 Rev D
Off-Module End Panel
1. Assemble end panel, filler
and bracket together.
2. Remove base cover from
frame.
3. Mark bottom of frame the
distance from side of frame to
inside of end panel (3a). Attach
bracket using two (2) self-drilling
screws centered in slots. Back off
screw a 1/2 turn so the bracket
can move freely from side to side
for alignment of end panel (3b).
X
(2) SELF
DRILLING SCREWS
1
2
3b
3a

Page 6 of 8
939500242 Rev D
PANEL
END PANEL
4. Reinstall base cover onto frame.
5. Remove screw from end panel
bracket (5a). Insert bracket into slots
of the frame (5b). Fasten bracket to
end panel using previously removed
screw (5c).
4
5b
5a
5c

Page 7 of 8
939500242 Rev D
6. Insert (3) connecting bolts
into the holes on underside of
top.
7. Flip top over (7a) and place
onto the end panel (7b). Make
sure the connecting bolts are
inserted into the corresponding
holes.
CONNECTING
BOLT
7a
7b
6

9
Page 8 of 8
939500242 Rev D
8. Insert (3) cam locks into the holes on the end
panel (8a), making sure the arrow on the cam
lock is pointed toward the connecting bolt (8b).
Turn cam lock with screwdriver 1/4 turn to secure
connecting bolt (8c).
9. Adjust glides as needed.
8a
8c
Underside
of Worksurface
ARROW POINTING IN DIRECTION OF
THE CONNECTING BOLT HEAD
CAM LOCK
8b
