Simpli Home WyndenHall brooklin+max AXCDCHR-003-LML User manual

DINING CHAIR
MODEL # AXCDCHR-003-LML
EZRA / HAWTHORNE / KENTVILLE

PRE-ASSEMBLY INFORMATION
PARTS DESCRIPTION
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
A
CHAIR BACK
QTY 1
SEAT
QTY 1
LEFT STRETCHER
QTY 1
B C
DEF
RIGHT STRETCHER
QTY 1
LEFT FRONT LEG
QTY 1
RIGHT FRONT LEG
QTY 1

PRE-ASSEMBLY INFORMATION
HARDWARE DESCRIPTION
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
1
ALLEN KEY SCREW
M8 x 45 MM
QTY 1
ALLEN KEY SCREW
M8 x 60 MM
QTY 4
ALLEN KEY SCREW
M8 x 90 MM
QTY 4
ALLEN KEY
5 MM
QTY 1
FLAT WASHER
Ø22 MM
QTY 9
LOCK WASHER
Ø13 MM
QTY 9
23
456
7
SELF-TAPPING SCREW
Ø3.5 X 40 MM
QTY 4

ASSEMBLY
STEP 1
Align Seat (B) into pre-drilled holes on Chair Back (A).
Attach Seat (B) to Chair Back (A) using Allen Key Screw (1)
and one Washer each of (4) and (7).
Use Allen Key (6) tighten. Do not over-tighten.

ASSEMBLY
STEP 2
Attach Seat (B) to Chair Back (A) using Allen Key Screws (3)
and four Washers each of (4) and (7).
Use Allen Key (6) tighten. Do not over-tighten.

ASSEMBLY
STEP 3
Attach Front Legs (E & F) using Allen Key Screws (2) and four Washers
each of (4) and (7).
Use Allen Key (6) tighten. Do not over-tighten.
Align the Stretchers (C & D) into Chair Back (A) and Front Legs (E & F).
with Self-Tapping Screws (5).
Fully tighten Self-Tapping Screws (5).

ASSEMBLY
STEP 4
Place Chair on a flat level surface to ensure it is level.
If it is uneven, adjust either the Seat (B) or Front Legs (E) and (F).
Ensure the Chair is level and then fully tighten all bolts.

ASSEMBLY
STEP 5
Use the zipper to close the fabric on the bottom of the Chair.
