Howdens HYH1335 User manual

IMPORTANT: Ensure the cabinet is level,
plumb and secured to the wall before installing this product.
Follow the installation manual for fixing the feet to your
cabinet.
Note: The 400 & 500 larder unit should have 5 feet fitted
(one in a front centre position for extra stability as shown).
300, 400 & 500mm Pull Out Larder
HD516020
44010850
HYH1335/HYH1336
Assembly
HYH1335/1336
1
300 Door
400 & 500 larder
additional foot
166mm (Standard)
188mm (Framed)
232mm
Note: Be aware of handle screw positions when
fixing the door straps. For integrated handle
ranges the door straps will need to be placed
off centre.
Door Bracket x2
Door
Strap x2
Important Notes:
Do not use a power driver for this product installation
18kg maximum load per basket
Ensure packaging is disposed of in a safe environmentally friendly way
We recommend the larder door handle is fitted horizontally
For five piece door constructions , care should be taken when fixing screws through into the back of the door
The Pull-Out runners will require adjusting once baskets are loaded, as weight distribution will affect the closing action
MAKE SURE UNIT IS SECURED TO THE WALL BEFORE USING THE PULLOUT LARDER
1536mm
1
8
k
g
1
8
k
g
1
8
k
g
1
8
k
g
1
8
k
g
Screw x12
(4.5x16mm)
500 Door
164mm/
188mm
164mm/
188mm
425mm
1536mm
2mm
400 Door
325mm
1536mm
2mm 2mm
Secure the unit to the wall using suitable
wall fixing screws through the bracket
supplied
Spike using a
bradawl

HD516020
44010850
HYH1335/HYH1336
2
3
Secure frame to the door
and fit baskets
Screw x2
(M6x28mm)
3
Screw x1
(4.5x16mm)
THIS SCREW MUST BE
FITTED BEFORE USE
Basket Bracket x10
Basket x5
Frame x1
Screw x1
(4x45mm)

Note: The runner mechanism
should be cleaned out using
a vaccum cleaner
Use the allen key to adjust the soft
close action
4mm
Turn this screw
for additional
up/down
adjustment
Door Adjustment
Soft Close Adjustment
Frame Removal
2
1
5
4
3
A
B
B
A
1
2
3
4
5
1
3
4
5
2
Push button
in and hold
HD516020
44010850
HYH1335/HYH1336
