Simpli Home Brooklyn+Max WyndenHall AXCBSACA07-WH User manual

Acadian / Normandy / Brunswick
Space Saver Cabinet
Model # AXCBSACA07-WH
TM
TM
1

2
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
simpli-home.com/product-registration
Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
Activate your 1-year warranty
Automatic entry to win a $500 gift certificate
Earn instant rewards and save
ü
ü
ü

3
Review your product and collect rewards!
Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Share photos and get your cash back!
Send us images or share them on social and qualify for instant
rewards. You may even receive store credit on your entire purchase!
simpli-home.com/share-images

4
For Fastest Customer Service:
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order information and issue.
6. Submit form.
7. A customer service associate will contact you.
Other ways to contact us…
Visit Us
Visit our site directly at
www.simpli-home.com
Email Us
[email protected]
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.

This furniture is designed for indoor use.
CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Safety Information
Care & Maintenance
To clean, use a soft or slightly damp cloth, then wipe with a clean, dry cloth.
Dust with a soft dry cloth.
Do not use ammonia-based cleaning products, as they will damage the finish.
Do not leave liquids or damp cloths on this furniture.
To avoid dulling of the finish, do not place this furniture in direct sunlight.
Please inspect and tighten all screws or bolts on a regular basis to ensure
proper performance and safety of your item.
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
5

.A.BL .BR
Part Description
TOP
QTY 1 TOP LEFT SIDE
QTY 1 TOP RIGHT SIDE QTY 1
.CL .CR .D
.E.F.G
BOTTOM LEFT SIDE
QTY 1 BOTTOM RIGHT SIDE QTY 1 MIDDLE SHELF QTY 1
BOTTOM SHELF
QTY 1 TOP BAR QTY 1 BOTTOM BAR QTY 1
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
6
Model # AXCBSACA07-WHPre-Assembly Information

.H.I.J
Part Description
.JL .JR .K
DIVIDER
QTY 1
Front /
Avant
DOOR (L&R Same)
QTY 2 BOTTOM BACK PANEL
QTY 1
LEFT BACK PANEL
QTY 1 RIGHT BACK PANEL QTY 1
SHELF
QTY 2
7
Model # AXCBSACA07-WHPre-Assembly Information

.1
Hardware Description
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
CAM LOCK PIN
CAM LOCK
QTY 16 SETS
WOOD DOWEL
Ø8 X 30mm
QTY 13 HINGE
QTY 4 MAGNET AND PLATE
QTY 2 SETS
PHILLIPS SCREW
M4 X 50mm
QTY 6
PHILLIPS SCREW
M4 X 15mm
QTY 8
HANDLE
M4 X 25 mm
QTY 2 SETS
PHILLIPS SCREW
ROUND HEAD
M4 X 15mm
QTY 27
.12
FURNITURE TIP
OVER RESTRAINT
QTY 2 SETS
a. M4 X 25mm - QTY 2
( 1 is extra )
b. M4 X 15mm - QTY 1
c. M4 X 25mm - QTY 1
.11 .10 .9
.8 .7 .6 .5
.4 .3 .2
BRACKET
QTY 2
SHELF SUPPORT
QTY 8
PHILLIPS SCREW
M3 X 15mm
QTY 24
8
Model # AXCBSACA07-WHPre-Assembly Information

Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
A
F
BL
BR
CL
CR
D
E
G
H
I
I
J
JR
JL
K
K
9
Model # AXCBSACA07-WHComponents - Key Diagram

Step1
P
X
1
1. Attach Cam Lock Pins 1 into pre-drilled holes on each part A , BL , BR .
2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten.
3. Insert Dowels 2 into guide holes on parts F , H .
4. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
2
22H
F
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
1
1
1
1
1
A
BR
BL
10
Model # AXCBSACA07-WHAssembly

Step2
1. Align Wood Dowels with guide holes and attach Divder H to Middle Shelf D .
2. Use two Phillips Screws 8 to attach Middle Shelf D through guide holes from
Middle Shelf D to pre-drilled holes of Divider H .
3. Use Phillips screwdriver to secure Screws. Do not over-tighten.
8
8
Front /
Avant
Front / Avant
H
D
D
H
4
10
10
4. Attach Magnets 4 using Phillips Screws 10 into pre-drilled holes Divider H .
5. Use Phillips screwdriver to secure screws.Do not over-tighten.
11
Model # AXCBSACA07-WHAssembly

Step3
3. Insert two Cam Locks 1 into guide holes on part D .
4. Use Phillips screwdriver to secure Cam Locks.
1. Align Wood Dowels with guide holes on part BL and attach part F to Left Side BL .
2. Align Cam Lock Pins with guide holes on part D and attach part D to Left Side BL .
Front / Avant
Front / Avant
BL
H
F
D
Front / Avant
H
F
D
BL
Front / Avant
1
1
12
Model # AXCBSACA07-WHAssembly

Step4
1. Repeat Step 3 for the Right Side BR .
Front / Avant
Front / Avant
F
H
D
BL
BR
Front / Avant
F
H
D
BL
Front / Avant
BR
1
1
13
Model # AXCBSACA07-WHAssembly

Step5
Front / Avant
Front / Avant
Front /
Avant
A
BL
H
BR
Front / Avant
Front / Avant
1. Align Cam Lock Pins with guide holes
and attach part A to Sides BL , BR , H .
Front / Avant
Front /
Avant
BL
H
BR
Front /
Avant
A
1
2. Insert two Cam Locks 1 into guide holes on each part BL , BR , H .
3. Use Phillips screwdriver to secure Cam Locks.
14
Model # AXCBSACA07-WHAssembly

Step6
P
X
1. Attach three Cam Lock Pins 1 into pre-drilled holes on each part CL , CR .
2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten.
3. Insert Dowels 2 into guide holes on parts G , CL , CR .
4. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
1
2
2
G
CL
CR
1
1
1
1
2
2
2
Front /
Avant
Front /
Avant
15
Model # AXCBSACA07-WHAssembly

Step7
Front / Avant
1. Align Wood Dowels and Cam Lock Pins with
guide holes and attach parts E , G to part CL .
2. Insert Cam Locks 1 into guide holes on parts E , G .
3. Use Phillips screwdriver to secure Cam Locks.
Front / Avant
ECL
G
CL
E
G
11
16
Model # AXCBSACA07-WHAssembly

Step8
1. Repeat Step 7 for the Bottom Right Side CR .
Front / Avant
Front / Avant
CL
CL
CR
CR
E
E
G
G
1
1
17
Model # AXCBSACA07-WHAssembly

Step9
1. Align Wood Dowels with guide holes on top fame and attach top frame to
bottom frame.
2. Use four Phillips Screws 8 into guide holes on bottom fame .
3. Attach Bracket 5 using Phillips Screws 9 into pre-drilled holes on top frame
and bottom frame.
4. Use Phillips screwdriver to secure Screws. Do not over-tighten.
Front /
Avant
Front /
Avant
Front /
Avant
9
5
8
18
Model # AXCBSACA07-WHAssembly

Step10
Front /
Avant
Note:
The back of the cabinet frame does not have
pre-drilled holes to attach the back panels.
11
1. Attach the Back Panels J , JL , JR to back frame using Phillips Screws Round
Head 11 through guide holes from Back Panels.
2. Use Phillips Screwdriver to tighten screws. Do not over-tighten.
Warning Label
JR
JL
J
19
Model # AXCBSACA07-WHAssembly

Step11
1. Use four Shelf Supports 7 for each Shelf K in desired location.
KK
7
7
20
Model # AXCBSACA07-WHAssembly
