Sauder County Line 416977 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-15
Français pg 16-18
Español pg 19-21
Lot # 361588 05/01/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Night Stand
County Line Collection | Model 416977
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Sweet stand.
Sweet dreams.

Table of Contents Assembly Tools Required
3
4
5-15
16-18
19-21
22
23
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
416977 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A END (2)
B TOP (1)
C BOTTOM (1)
D BACK (1)
D42 RIGHT DRAWER SIDE (1)
D43 LEFT DRAWER SIDE (1)
D154 DRAWER BACK (1)
D960 DRAWER BOTTOM (1)
E RIGHT FRONT LEG (1)
F LEFT FRONT LEG (1)
G RIGHT REAR LEG (1)
H LEFT REAR LEG (1)
I LONG FRONT/BACK SKIRT (2)
J SHORT SIDE SKIRT (2)
K DRAWER FRONT (1)
416977www.sauder.com/services Page 3
A
B
C
D
E
F
G
H
I
JK
I
J
A
D42
D960
D43
D154

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
416977 www.sauder.com/servicesPage 4
BLACK 9/16" LARGE HEAD SCREW - 10
1S
SILVER 1/4" MACHINE SCREW - 2
61S
3S GOLD 5/16" FLAT HEAD SCREW - 8
CAM SCREW - 24
8F
HIDDEN CAM - 24
1F
WASHER - 2
10I CAM COVER - 8 19P
PULL - 1
98K
35AA 35AD35AC
UNIVERSAL CABINET RAIL - 2 DRAWER RIGHT - 1 DRAWER LEFT - 1
30S BLACK 1-9/16" FLAT HEAD SCREW - 4
DRAWER FRONT
BRACKET - 1
7G
METAL BRACKET - 4
4G

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push twenty-four HIDDEN CAMS (1F) into the ENDS (A),
BACK (D), LONG FRONT/BACK SKIRTS (I), and SHORT
SIDE SKIRTS (J).
416977www.sauder.com/services Page 5
Arrow
1F
Arrow
The arrow in the HIDDEN
CAM must point toward the
hole in the edge of the board.
Hole
A
D
I
J
I
J
A
Arrow
1F
(24 used)

Step 2
416977 www.sauder.com/servicesPage 6
B
E
F
G
H
I
J
I
J
8F
å Turn twenty-four CAM SCREWS (8F) into the TOP (B)
and LEGS (E, F, G, and H).
å Fasten four METAL BRACKETS (4G) to the SKIRTS (I and J).
Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
8F
BLACK 9/16" LARGE HEAD SCREW
(4 used in this step)
1S
The BRACKET should
be even with the edge.
4G

å Fasten the LEGS (E, F, G, and H) to the ENDS (A) and
SHORT SIDE SKIRTS (J). Tighten twelve HIDDEN CAMS.
Step 3
416977www.sauder.com/services Page 7
E
F
G
H
J
J
A
A
12
These surfaces must be even.
These surfaces must be even.
Finished edge
Finished edge
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Metal bracket
Metal bracket
Remember:
Righty tighty.
Lefty loosey.

Step 4
416977 www.sauder.com/servicesPage 8
1
2
3
1
2
3
Glide end
Glide end
E
F
A
A
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
å Fasten the UNIVERSAL CABINET RAILS* (35AA) to the
ENDS (A). Use four GOLD 5/16" FLAT HEAD
SCREWS (3S) through holes #1 and #3.
å NOTE: Use the holes shown in the ENDS (A).
å *patent pending glide system
VIEW THE DRAWER GLIDE VIDEO

å Fasten the BACK (D) and LONG BACK SKIRT (I) to the
LEFT REAR LEG (H). Tighten three HIDDEN CAMS.
å Fasten the LONG FRONT SKIRT (I) to the LEFT FRONT
LEG (F). Tighten one HIDDEN CAM.
Step 5
416977www.sauder.com/services Page 9
D
I
I
F
A
Finished edge
Metal bracket
Surface
with
HIDDEN
CAMS
Metal bracket
H
Don't worry. It isn't
Rome. This can be built
in a day.

Step 6
å Fasten the BACK (D) and LONG BACK SKIRT (I) to the
RIGHT REAR LEG (G). Tighten three HIDDEN CAMS.
å Fasten the LONG FRONT SKIRT (I) to the RIGHT FRONT
LEG (E). Tighten one HIDDEN CAM.
å Fasten the BOTTOM (C) to the SKIRTS (I and J). Use four
BLACK 9/16" LARGE HEAD SCREWS (1S) through the
METAL BRACKETS and into the BOTTOM.
å Push a CAM COVER (19P)
onto each HIDDEN CAM
on the SKIRTS (I and J).
416977 www.sauder.com/servicesPage 10
E
G
A
C
I
J
I
J
D
BLACK 9/16" LARGE HEAD SCREW
(4 used in this step)
1S
Surface
with holes
Long edge
(8 used)
To cover the HIDDEN
CAMS on the SKIRTS.
19P
